Technotherm ISP-W 350 User manual

ISP-W 350 till 1200
ISP-R 350 till 1200
ISP-B 350 till 1200
ISP-Motiv 450 till 950
with receiver RF
Edition: 05/16
Nr. 911 360 671
Installation and technical manual
ISP-W / R / B / motives frameless – with receiver RF
GB
2
3
2 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
1. Important Safety instructions
•People (including children) who are limited in their physical, sensory, or mental capacities
should not use this device at any time. Furthermore do not handle this instrument if you do not
possess the necessary experience and knowledge to do so. This device should only be handled
under the supervision of a qualified person and after a thorough introduction.
•Do not leave children alone with the device, and supervise them at all times to keep them from
getting harmed.
•WARNING: Do not cover! Otherwise this instrument will overheat.
•Do not place the heater underneath a socket, drainage or the like.
•To keep from getting burned, do not touch heater´s surface whenever it is turned on.
•Please use the handle whenever you have to move the heater.
•Do not put the cord underneath the carpet or a rug and make sure that it is not a tripping
hazard
•Plug the heater into properly grounded sockets only.
•Do not use the heater in any other way than described in the user manual. Any other way of use
may lead to fire, electrocution, and may cause serious harm to the person.
•Do not use this device near bathtubs, showers or swimming pools.
•In case the connection cable is damaged it has to be replaced by the manufacturer or someone
commissioned by the manufacturer.
WARNING: Do not use a switching-oriented device, like a timekeeper, when operating this heater.
This could cause a change in the thermal adjustment which is potentially hazardous!
•To keep the device from overheating do not put towels or clothing on top.
•When using the heater, make sure it is in an upright position and positioned on a even and dry
place.
•Do not put any foreign objects into the vent. This may cause electrocution, fire or damage to
the heater.
•Do not use an extension cord unless approved by an electrician.
•This device is for private use only, do not use in any other way than intended by the
manufacturer.
•Do not use the device near curtains, highly combustible, extremely explosive or malleable
materials.
•Keep a distance of a at least 1.0 m between combustible materials- like furniture, cushions,
bedding, paper, clothing, curtains-and the heating device.
•Do not use the device in rooms were petrol, paint or any other flammable liquids are stored.
•Do not use the device outside.
Warning! this device has to be grounded
This device may only be operated using alternating current and the operating voltage indicated
on the power rating plate
•Nominal Voltage 230V AC, 50 Hz
•Protection class I
GB
3 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
ISP-W (white front panel, powder-coated)
ISP-R (red front panel, powder-coated)
ISP-B (black front plate, powder coated)
ISP-Motiv (front plate with motivs)
Prior to commissioning, please inform yourself about proper installation, commissioning, operation and
maintenance.
Below we give the necessary information:
The installation and electrical connection must be carried out by a qualified electrician. The panels are
designed for wall and ceiling mounting.
Wall mounting model ISP W / R / B / Motiv
The plate can be mounted horizontally or vertically. Drill mounting holes as indicated in Fig.1
(horizontally) or as in Fig.2 (vertically). The pack contains 4 (6 for the Models ISP 1200 and ISP 851) fixing
screws 6 x 70 mm.
To mounting the unit using all 4 (6 anchors for the Models ISP 1200 and ISP 851. The recommended
dowel size is 10 mm (not included).
The dimensions A and B are pitches of the holes to be drilled.
All models with the
width of 600 mm
incl. RF
drill spacing holes
A1 [mm]
B1 [mm]
A2 [mm]
B2 [mm]
ISP 350
324
360
360
324
ISP 450
624
360
360
624
ISP 600
624
360
360
624
ISP 750
924
360
360
924
ISP 950
1224
360
360
1224
ISP 1200
1524
A1/2 = 762
360
360
1524
B2/2=762
A1
B1
A2
B2
Fig: 1
Fig: 2
Detail view
GB
A1/2
B2/2
4 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
Distances
The distance between the lower edge of the heater from the floor must be at least 50 mm, 150 mm are
recommended. Side distance, for example, to furniture must be at least 100 mm and the distance up at
least 100 mm (see Abb. 2). In bathrooms, the heating plate is in compliance with the standard VDE 100 /
T701 to install. It can be mounted as shown in Abb. 1 from field 2 (range 1 is not allowed!)
The ISP heater is a product of protection class II, protection IP 44. The plate shall be affixed directly to
the junction box.
Electrical Connection
The ISP heating panel is equipped with a three-wire cable for 1 / N 230 V / 50 Hz
Color coding of conductors:
Phase - brown
Neutral - blue
Connection is made to a wall socket.
It is always a residual current circuit breaker for use with an operating current of 30 mA maximum. If the
supply cord of this appliance consumption is damaged, it must be replaced by the manufacturer or a
service technician.
All models with
the width of 400
mm
incl. RF
drill spacing holes
A1 [mm]
B1 [mm]
A2 [mm]
B2 [mm]
ISP 351
624
240
240
624
ISP 501
924
240
240
924
ISP 651
1224
240
240
1224
ISP 851
1524
A1/2=762
240
240
1524
B2/2=762
5 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
Operation of the ISP heating panels
It is recommended that the control of the ISP heating panels by an external room thermostat from
TECHNOTHERM (eg. radio receiver TPF or with the digital radio transmitter TBF. In addition, the ISP
heating panels are equipped with a limiting thermostat to ensure their safe usage.
WARNING
Do not install this device in areas that present an explosion hazard like a garage. Remove
all protective coverage before turning on the device. When using the device for the first
time you might detect a strong odor. This is no reason for concern; it is caused by
residues of production and will disappear shortly.
The rising heat may cause stains on the ceiling, however this phenomena can be caused by any other
heating device as well. Only a qualified electrician may open or remove the device from the power
supply.
4. Maintenance
Before cleaning the device be sure to turn it off. To clean use a damp towel and a mild detergent.
5. Assembly instruction
This Manual is very important and has to be kept at a safe place at all times. Be sure to hand this manual
to any other succeeding owner of the device.
The device is an electrical heater that was designed and intended to be mounted to walls. The device
comes with a power plug that has to be plugged into an outlet.
The device is designed to be connected to 230V (nominal) alternating current (AC).
WARNING: DO NOT COVER THE HEATER
GBGB
6 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
Technical datas of the 600 mm models
Model
Power
[Watt]
W x H x D [mm] Weight Model
Power
[Watt]
W x H x D [mm] Weight
ISP-W 350 300 600x600x15 8,7 ISP-W 350 RF 300 600x600x15 8,7
ISP-W 450 450 900x600x15 9,5 ISP-W 450 RF 450 900x600x15 9,5
ISP-W 600 600 1200x600x15 12,7 ISP-W 600 RF 600 1200x600x15 12,7
ISP-W 750 750 1200x600x15 12,7 ISP-W 750 RF 750 1200x600x15 12,7
ISP-W 950 950 1500x600x15 15,8 ISP-W 950 RF 950 1500x600x15 15,8
ISP-W 1200 1200 1800x600x15 19,1 ISP-W 1200 RF 1200 1800x600x15 19,1
ISP-R 350 300 600x600x15 8,7 ISP-R 350 RF 300 600x600x15 8,7
ISP-R 450 450 900x600x15 9,5 ISP-R 450 RF 450 900x600x15 9,5
ISP-R 600 600 1200x600x15 12,7 ISP-R 600 RF 600 1200x600x15 12,7
ISP-R 750 750 1200x600x15 12,7 ISP-R 750 RF 750 1200x600x15 12,7
ISP-R 950 950 1500x600x15 15,8 ISP-R 950 RF 950 1500x600x15 15,8
ISP-R 1200 1200 1800x600x15 19,1 ISP-R 1200 RF 1200 1800x600x15 19,1
ISP-B 350 300 600x600x15 8,7 ISP-B 350 RF 300 600x600x15 8,7
ISP-B 450 450 900x600x15 9,5 ISP-B 450 RF 450 900x600x15 9,5
ISP-B 600 600 1200x 600x15 12,7 ISP-B 600 RF 600 1200x600x15 12,7
ISP-B 750 750 1200x600x15 12,7 ISP-B 750 RF 750 1200x600x15 12,7
ISP-B 950 950 1500x600x15 15,8 ISP-B 950 RF 950 1500x600x15 15,8
ISP-W 1200 1200 1800x600x15 19,1 ISP-W 1200 RF 1200 1800c600x15 19,1
ISP-Motiv 450 450 900x600x15 9,5 ISP-Motiv 450 RF 450 900x600x15 9,5
ISP-Motiv 750 750 1200x600x15 12,7 ISP-Motiv 750 RF 750 1200x600x15 12,7
ISP-Motiv 950 950 1500x600x15 15,8 ISP-Motiv 950 RF 950 1500x600x15 15,8
„RF“: Units are supplied with preassembled radio receiver
Model
Power
[Watt]
W x H x D [mm] Weight Model
Power
[Watt]
W x H x D [mm] Weight
ISP-W 351 350 900x400x15 8,7 ISP-W 351 RF 350 900x 400x15 8,7
ISP-W 501 500 1200x400x15 11,6 ISP-W 501 RF 500 1200x400x15 11,6
ISP-W 651 650 1500x400x15 14,5 ISP-W 650 RF 650 1500x400x15 14,5
ISP-W 851 850 1800x400x15 17,4 ISP-W 851 RF 850 1800x400x15 17,4
ISP-R 351 350 900x400x15 8,7 ISP-R 351 RF 350 900x 400x15 8,7
ISP-R 501 500 1200x400x15 11,6 ISP-R 501 RF 500 1200x400x15 11,6
ISP-R 651 650 1500x400x15 14,5 ISP-R 650 RF 650 1500x400x15 14,5
ISP-R 851 850 1800x400x15 17,4 ISP-R 851 RF 850 1800x400x15 17,4
ISP-B 351 350 900x400x15 8,7 ISP-B 351 RF 350 900x 400x15 8,7
ISP-B 501 500 1200x400x15 11,6 ISP-B 501 RF 500 1200x400x15 11,6
ISP-B 651 650 1500x400x15 14,5 ISP-B 650 RF 650 1500x400x15 14,5
ISP-B 851 850 1800x400x15 17,4 ISP-B 851 RF 850 1800x400x15 17,4
GB
7 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
Connecting the recipient (only with the "RH" models)
Press on the receiver for more than 3 seconds the button until the
indicator light begins to flash. Then attach the transmitter in
configuration mode (see manual transmitter). If the indicator light on the
receiver stops flashing, the two products are assigned.
Disconnect the receiver
To delete all associated products you press the receiver button for about
30 seconds until the indicator light flashes briefly. All channels are now
deleted!
Technical data’s oft the receiver „RF“
• power supply 230 V, 50 Hz +/-10%
• protection class II
• consumption: 0,5 V
• switching capacity max.: 16 A 230 Veff Cos φ= 1
• radio frequency 868 MHz (Norm EN 300 220),
• radio range up to 300 m (outdoor), indoor up to 30 m, depending of structural factors and
electromagnetic interference.
• maximum number of recipients: 8 units
• temperature range: -5°C to +50°C
• dimensions: 120 x 54 x 25 mm
• IP 44 - IK 04
GB
8 Edition: 05/16
Manual ISP W / R / B / Motive- frameless
Lucht LHZ Elektroheizung GmbH & Co. KG
Obere Hauptstr. 61
09232 Hartmannsdorf
Fon: 03722 63370
Fax: 03722 633720
E-mail: info@technotherm.de
web: www.technotherm.de
TECHNOTHERM support
Fon: +49 (0) 911 93 78 32 10
GB

This manual suits for next models

11

Other Technotherm Heater manuals

Technotherm ISP Design S 350 User manual

Technotherm

Technotherm ISP Design S 350 User manual

Technotherm SM 2004 User manual

Technotherm

Technotherm SM 2004 User manual

Technotherm TT-KS 500 S X4 User manual

Technotherm

Technotherm TT-KS 500 S X4 User manual

Technotherm CPH 1000 E User manual

Technotherm

Technotherm CPH 1000 E User manual

Technotherm VPS series User manual

Technotherm

Technotherm VPS series User manual

Technotherm VPS-Design B 1000 User manual

Technotherm

Technotherm VPS-Design B 1000 User manual

Technotherm TT-KS LT User manual

Technotherm

Technotherm TT-KS LT User manual

Technotherm CHM 500 E User manual

Technotherm

Technotherm CHM 500 E User manual

Technotherm VPS 1000 User manual

Technotherm

Technotherm VPS 1000 User manual

Technotherm CPH 1000 User manual

Technotherm

Technotherm CPH 1000 User manual

Technotherm TT-KS 1500 S X4 User manual

Technotherm

Technotherm TT-KS 1500 S X4 User manual

Technotherm PH Ultraslim User manual

Technotherm

Technotherm PH Ultraslim User manual

Technotherm VPS Design 1500 RF User manual

Technotherm

Technotherm VPS Design 1500 RF User manual

Technotherm ISP-W 450 User manual

Technotherm

Technotherm ISP-W 450 User manual

Technotherm Q 1201 User manual

Technotherm

Technotherm Q 1201 User manual

Technotherm Frost Guard FW 501 User manual

Technotherm

Technotherm Frost Guard FW 501 User manual

Technotherm ISP 350 User manual

Technotherm

Technotherm ISP 350 User manual

Technotherm TT-KS S User manual

Technotherm

Technotherm TT-KS S User manual

Technotherm KBS 6/25 User manual

Technotherm

Technotherm KBS 6/25 User manual

Technotherm PH SlimLine User manual

Technotherm

Technotherm PH SlimLine User manual

Technotherm TTS 200 User manual

Technotherm

Technotherm TTS 200 User manual

Technotherm KS DSM Use and maintenance manual

Technotherm

Technotherm KS DSM Use and maintenance manual

Popular Heater manuals by other brands

VEAB BX 2E-15E User instructions

VEAB

VEAB BX 2E-15E User instructions

Truma Trumatic E 2400 E Operating and installation instructions

Truma

Truma Trumatic E 2400 E Operating and installation instructions

EUROM ALUTHERM BASEBOARD Wi-Fi instruction manual

EUROM

EUROM ALUTHERM BASEBOARD Wi-Fi instruction manual

Dimplex EvoRad Series instruction manual

Dimplex

Dimplex EvoRad Series instruction manual

EUROLAMP HB-3000R instructions

EUROLAMP

EUROLAMP HB-3000R instructions

Haverland RCTT Instruction and installation manual

Haverland

Haverland RCTT Instruction and installation manual

Kunft KCH3606 instruction manual

Kunft

Kunft KCH3606 instruction manual

Prem-I-Air N10T24 instruction manual

Prem-I-Air

Prem-I-Air N10T24 instruction manual

Prem-I-Air EH1524 User and installation guide

Prem-I-Air

Prem-I-Air EH1524 User and installation guide

Trotec TCH 25 E operating manual

Trotec

Trotec TCH 25 E operating manual

Rinnai RHFE-309FT Operation and installation manual

Rinnai

Rinnai RHFE-309FT Operation and installation manual

Vitek VT-2194 Manual instruction

Vitek

Vitek VT-2194 Manual instruction

HDT Camfire CV125CG Operation manual

HDT

HDT Camfire CV125CG Operation manual

Sawo PHOENIX PNX3-45NS manual

Sawo

Sawo PHOENIX PNX3-45NS manual

Clatronic RA 3735 instruction manual

Clatronic

Clatronic RA 3735 instruction manual

Bestron ABH401 instruction manual

Bestron

Bestron ABH401 instruction manual

Frico Jaguar Series Mounting and assembly instruction

Frico

Frico Jaguar Series Mounting and assembly instruction

Harvia sentiotec Concept R mini Instructions for installation and use

Harvia

Harvia sentiotec Concept R mini Instructions for installation and use

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
