Technotherm ISP-W 450 User manual

Installation and technical manual
ISP-W / R / B / Motifs frameless – with receiver RF
GB
13
14
ISP-W 350 - 1200
ISP-R 350 - 1200
ISP-B 350 - 1200
ISP-Motif 350 – 1200
ISP-W 351 - 851
ISP-R 351 - 851
ISP-B 351 - 851
ISP-Motif 351 till 851
with receiver RF
Edition: 12/17
No. 911 360 671

2 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
1. Important Safety instructions
•People (including children) who are limited in their physical,
sensory, or mental capacities should not use this device at any
time. Furthermore do not handle this instrument if you do not
possess the necessary experience and knowledge to do so. This
device should only be handled under the supervision of a qualified
person and after a thorough introduction.
•Do not leave children alone with the device, and supervise them at
all times to keep them from getting harmed.
•WARNING: Do not cover! Otherwise this instrument will
overheat.
•Do not place the heater underneath a socket, drainage or the like.
•To keep from getting burned, do not touch heater´s surface
whenever it is turned on.
•Please use the handle whenever you have to move the heater.
•Do not put the cord underneath the carpet or a rug and make sure
that it is not a tripping hazard
•Plug the heater into properly grounded sockets only.
•Do not use the heater in any other way than described in the user
manual. Any other way of use may lead to fire, electrocution, and
may cause serious harm to the person.
•Do not use this device near bathtubs, showers or swimming pools.
•In case the connection cable is damaged it has to be replaced by
the manufacturer or someone commissioned by the manufacturer.
WARNING: Do not use a switching-oriented device, like a timekeeper,
when operating this heater. This could cause a change in the thermal
adjustment which is potentially hazardous!
•To keep the device from overheating do not put towels or clothing
on top.
•When using the heater, make sure it is in an upright position and
positioned on an even and dry place.
GB

3 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
•Do not put any foreign objects into the vent. This may cause
electrocution, fire or damage to the heater.
•Do not use an extension cord unless approved by an electrician.
•This device is for private use only, do not use in any other way than
intended by the manufacturer.
•Do not use the device near curtains, highly combustible, extremely
explosive or malleable materials.
•Keep a distance of a at least 1.0 m between combustible materials-
like furniture, cushions, bedding, paper, clothing, curtains-and the
heating device.
•Do not use the device in rooms were petrol, paint or any other
flammable liquids are stored.
•Do not use the device outside.
Warning! This device has to be grounded
This device may only be operated using alternating current and
the operating voltage indicated on the power rating plate
•Nominal Voltage 230V AC, 50 Hz
•Protection class I
ISP-W (white front panel, powder-coated)
ISP-R (red front panel, powder-coated)
ISP-B (black front plate, powder coated)
ISP-Motif (front plate with motifs)
Prior to commissioning, please inform yourself about proper installation, commissioning, operation and
maintenance.
Below we give the necessary information:
The installation and electrical connection must be carried out by a qualified electrician. The panels are
designed for wall and ceiling mounting.
Wall mounting model ISP W / R / B / Motif
The plate can be mounted horizontally or vertically. Drill mounting holes as indicated in Fig.1
(horizontally) or as in Fig.2 (vertically). The pack contains 4 (6 for the Models ISP 1200 and ISP 851) fixing
screws 6 x 70 mm.
To mounting the unit using all 4 (6 anchors for the Models ISP 1200 and ISP 851. The recommended
dowel size is 10 mm (not included).
The dimensions A and B are pitches of the holes to be drilled.
GB

4 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
Distances
The distance between the lower edge of the heater from the floor must be at least 50 mm, 150 mm are
recommended.
Side distance,
for example, to
furniture must
be at least 100
mm and the
distance up at
least 100 mm
(see Abb. 2). In
bathrooms, the heating plate is in compliance with the
standard VDE 100 / T701 to install. It can be mounted as shown in Abb. 1 from field 2 (range 1 is not
allowed!)
The ISP heater is a product of protection class II, protection IP 44. The plate shall be affixed directly to
the junction box.
All models with the
width of 600 mm
incl. RF
drill spacing holes
A1 [mm]
B1 [mm]
A2 [mm]
B2 [mm]
ISP 350
324
360
360
324
ISP 450
624
360
360
624
ISP 600
624
360
360
624
ISP 750
924
360
360
924
ISP 950
1224
360
360
1224
ISP 1200
1524
A1/2 = 762
360
360
1524
B2/2=762
All models with
the width of 400
mm
incl. RF
drill spacing holes
A1 [mm]
B1 [mm]
A2 [mm]
B2 [mm]
ISP 351
624
240
240
624
ISP 501
924
240
240
924
ISP 651
1224
240
240
1224
ISP 851
1524
A1/2=762
240
240
1524
B2/2=762
A1
B1
A2
B2
Fig: 1
Fig: 2
Detail view
A1/2
B2/2
GB

5 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
Electrical Connection
The ISP heating panel is equipped with a three-wire cable for 1 / N 230 V / 50 Hz
Color coding of conductors:
Phase - brown
Neutral - blue
Connection is made to a wall socket.
It is always a residual current circuit breaker for use with an operating current of 30 mA maximum. If the
supply cord of this appliance consumption is damaged, it must be replaced by the manufacturer or a
service technician.
Operation of the ISP heating panels
It is recommended that the control of the ISP heating panels by an external room thermostat from
TECHNOTHERM (eg. radio receiver TPF or with the digital radio transmitter TBF. In addition, the ISP
heating panels are equipped with a limiting thermostat to ensure their safe usage.
WARNING
Do not install this device in areas that present an explosion hazard like a garage. Remove
all protective coverage before turning on the device. When using the device for the first
time you might detect a strong odor. This is no reason for concern; it is caused by residues
of production and will disappear shortly.
The rising heat may cause stains on the ceiling, however this phenomena can be caused by any other
heating device as well. Only a qualified electrician may open or remove the device from the power supply.
4. Maintenance
Before cleaning the device be sure to turn it off. To clean use a damp towel and a mild detergent.
5. Assembly instruction
This Manual is very important and has to be kept at a safe place at all times. Be sure to hand this manual
to any other succeeding owner of the device.
The device is an electrical heater that was designed and intended to be mounted to walls. The device
comes with a power plug that has to be plugged into an outlet.
The device is designed to be connected to 230V (nominal) alternating current (AC).
WARNING: DO NOT COVER THE HEATER
GBGB

6 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
Technical datas of the 600 mm models
Model
Power
[Watt]
W x H x D [mm] Weight Model
Power
[Watt]
W x H x D [mm] Weight
ISP-W 350 300 600x600x15 8,7 ISP-W 350 RF 300 600x600x15 8,7
ISP-W 450 450 900x600x15 9,5 ISP-W 450 RF 450 900x600x15 9,5
ISP-W 600 600 1200x600x15 12,7 ISP-W 600 RF 600 1200x600x15 12,7
ISP-W 750 750 1200x600x15 12,7 ISP-W 750 RF 750 1200x600x15 12,7
ISP-W 950 950 1500x600x15 15,8 ISP-W 950 RF 950 1500x600x15 15,8
ISP-W 1200 1200 1800x600x15 19,1 ISP-W 1200 RF 1200 1800x600x15 19,1
ISP-R 350 300 600x600x15 8,7 ISP-R 350 RF 300 600x600x15 8,7
ISP-R 450 450 900x600x15 9,5 ISP-R 450 RF 450 900x600x15 9,5
ISP-R 600 600 1200x600x15 12,7 ISP-R 600 RF 600 1200x600x15 12,7
ISP-R 750 750 1200x600x15 12,7 ISP-R 750 RF 750 1200x600x15 12,7
ISP-R 950 950 1500x600x15 15,8 ISP-R 950 RF 950 1500x600x15 15,8
ISP-R 1200 1200 1800x600x15 19,1 ISP-R 1200 RF 1200 1800x600x15 19,1
ISP-B 350 300 600x600x15 8,7 ISP-B 350 RF 300 600x600x15 8,7
ISP-B 450 450 900x600x15 9,5 ISP-B 450 RF 450 900x600x15 9,5
ISP-B 600 600 1200x 600x15 12,7 ISP-B 600 RF 600 1200x600x15 12,7
ISP-B 750 750 1200x600x15 12,7 ISP-B 750 RF 750 1200x600x15 12,7
ISP-B 950 950 1500x600x15 15,8 ISP-B 950 RF 950 1500x600x15 15,8
ISP-W 1200 1200 1800x600x15 19,1 ISP-W 1200 RF 1200 1800c600x15 19,1
ISP-Motiv 450 450 900x600x15 9,5 ISP-Motiv 450 RF 450 900x600x15 9,5
ISP-Motiv 750 750 1200x600x15 12,7 ISP-Motiv 750 RF 750 1200x600x15 12,7
ISP-Motiv 950 950 1500x600x15 15,8 ISP-Motiv 950 RF 950 1500x600x15 15,8
„RF“: Units are supplied with preassembled radio receiver
Model
Power
[Watt]
W x H x D [mm] Weight Model
Power
[Watt]
W x H x D [mm] Weight
ISP-W 351 350 900x400x15 8,7 ISP-W 351 RF 350 900x 400x15 8,7
ISP-W 501 500 1200x400x15 11,6 ISP-W 501 RF 500 1200x400x15 11,6
ISP-W 651 650 1500x400x15 14,5 ISP-W 650 RF 650 1500x400x15 14,5
ISP-W 851 850 1800x400x15 17,4 ISP-W 851 RF 850 1800x400x15 17,4
ISP-R 351 350 900x400x15 8,7 ISP-R 351 RF 350 900x 400x15 8,7
ISP-R 501 500 1200x400x15 11,6 ISP-R 501 RF 500 1200x400x15 11,6
ISP-R 651 650 1500x400x15 14,5 ISP-R 650 RF 650 1500x400x15 14,5
ISP-R 851 850 1800x400x15 17,4 ISP-R 851 RF 850 1800x400x15 17,4
ISP-B 351 350 900x400x15 8,7 ISP-B 351 RF 350 900x 400x15 8,7
ISP-B 501 500 1200x400x15 11,6 ISP-B 501 RF 500 1200x400x15 11,6
ISP-B 651 650 1500x400x15 14,5 ISP-B 650 RF 650 1500x400x15 14,5
ISP-B 851 850 1800x400x15 17,4 ISP-B 851 RF 850 1800x400x15 17,4
GB

7 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
Connecting the recipient (only with the "RH" models)
Press on the receiver for more than 3 seconds the button until the
indicator light begins to flash. Then attach the transmitter in configuration
mode (see manual transmitter). If the indicator light on the receiver stops
flashing, the two products are assigned.
Disconnect the receiver
To delete all associated products you press the receiver button for about
30 seconds until the indicator light flashes briefly. All channels are now
deleted!
Technical data’s oft the receiver „RF“
• power supply 230 V, 50 Hz +/-10%
• protection class II
• consumption: 0,5 V
• switching capacity max.: 16 A 230 Veff Cos φ= 1
• radio frequency 868 MHz (Norm EN 300 220),
• radio range up to 300 m (outdoor), indoor up to 30 m, depending of structural factors and
electromagnetic interference.
• maximum number of recipients: 8 units
• temperature range: -5°C to +50°C
• dimensions: 120 x 54 x 25 mm
• IP 44 - IK 04
Switching from X3D to X2D and vice versa:
X2D for TPF/TBF
X3D for TPF-Eco
1) Before the changeover, the assignment to the thermostat must be cleared.
Press and hold for 30 seconds (1):
after 3 seconds, the LED flashes slowly.
after 7 seconds, the LED flashes quickly. Keep the receiver button pressed until both
LEDs flash.
Release the button (2).
GB

8 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
2) Changeover
When switching on the installation (1), you have 4 seconds to press 3 times the receiver
button (2). The LED flashes (3): 2 times for X2D, 3 times for X3D.
GB

9 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
6. Regulation
From 01.01.2018, the EU conformity of these devices is additionally linked to the fulfillment of
the Ecodesign requirements 2015/1188.
The installation and commissioning of the devices is only permitted in conjunction with external
room temperature controllers that fulfill the following functions:
•electronic room temperature control plus week timer
and has at least one of the following properties:
•room temperature control, with presence detection
•room temperature control, with open window detection
•with distance control option
•with adaptive start control
•with working time limitation
•with black bulb sensor
The following room temperature controller systems
•RF Receiver together with the TPF-Eco Thermostat (Art.Nr.: 750 000 641) and the Eco-
Interface (Art.Nr.750 000 640) or
from Technotherm meet the following requirements and therefore the ErP Directive:
•electronic room temperature control plus week timer (RF)
•with distance control option (RF)
Use of the ISP Standard range (without external thermostat control) is not permitted
Installation of the receiver and the interfaces see separate instructions. For customer service - see last
page.
Failure to comply with these requirements will result in the loss of the CE mark.

10 Edition: 12/17
Manual ISP W / R / B / Motive- frameless
Model: ISP RF (These devices may only be used with a corresponding approved thermostat - e.g. TPF-Eco and the ECO interface)
Item
Symbol
Value
Value
Item
Value
Heat output
Type of heat input, for electric storage local space heaters only (select
one)
Nominal heat
output
P
nom
350 450 500 600 650 750 950 1200 Watt manual heat charge control, with integrated thermostat No
Minimum
heat
output
(indicative)
Pmin 350 450 500 600 650 750 950 1200 Watt manual heat charge control with room and/or outdoor temperature
feedback No
Maximum
continuous
heat output
Pmax,c 350 450 500 600 650 750 950 1200 Watt electronic heat charge control with room and/or outdoor
temperature feedback No
Auxiliary
electricity
consumptio
n
fan assisted heat output No
At nominal
heat
output
elmax 350 450 500 600 650 750 950 1200 Watt Type of heat output/room temperature control (select
one)
At minimum
heat
output
elmin <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 Watt single stage heat output and no room temperature control No
In standby
mode
el
SB
<0,5 <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 Watt Two or more manual stages, no room temperature control No
with mechanic thermostat room temperature control
No
with electronic room temperature control
No
electronic room temperature control plus day timer
No
electronic room temperature control plus week timer
Yes
Other control options (multiple selections possible)
room temperature control, with presence detection
No
room temperature control, with open window detection
No
with distance control option
Yes
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Model: ISP (These devices may only be used with a corresponding approved thermostat - e.g. TPF-Eco, the RF receiver and the ECO interface)
Item
Symbol
Value
Value
Item
Value
Heat output
Type of heat input, for electric storage local space heaters only (select
one)
Nominal heat
output
Pnom 350 450 500 600 650 750 950 1200 Watt manual heat charge control, with integrated thermostat No
Minimum
heat
output
(indicative)
Pmin
350 450 500 600 650 750 950 1200 Watt manual heat charge control with room and/or outdoor temperature
feedback No
Maximum
continuous
heat output
Pmax,c 350 450 500 600 650 750 950 1200 Watt electronic heat charge control with room and/or outdoor
temperature feedback No
Auxiliary
electricity
consumptio
n
fan assisted heat output No
At nominal
heat
output
elmax
350 450 500 600 650 750 950 1200 Watt Type of heat output/room temperature control (select
one)
At minimum
heat
output
elmin
<0,5 <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 <0,5 Watt single stage heat output and no room temperature control No
In standby
mode
el
SB
<0,5
<0,5
<0,5
<0,5
<0,5
<0,5
<0,5
<0,5
Watt Two or more manual stages, no room temperature control No
with mechanic thermostat room temperature control
No
with electronic room temperature control
No
electronic room temperature control plus day timer
No
electronic room temperature control plus week timer
No
Other control options (multiple selections possible)
room temperature control, with presence detection
No
room temperature control, with open window detection
No
with distance control option
No
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Contact
details:
Lucht LHZ Elektroheizung GmbG & Co. KG | Reinhard-Schmidt.Str.1 D-09217 Burgstädt
Lucht LHZ Elektroheizung GmbH & Co. KG
Reinhard-Schmidt-Str. 1
09217 Burgstädt
Fon: 03724 66869 0
Fax: [phone]
E-mail: [e-mail]
web: www.technotherm.de
TECHNOTHERM support:
Fon: [phone]
