Technotherm ISP Design S 350 User manual

ISP-Design 350 – 1200
ISP-Design S 350 - 750
Nr. 911 360 661
Edition: 02/17
Installation and technical manual
ISP-Design & ISP –Design S (Mirror) with receiver „RF“
GB
2
3

2 Edition: 02/17
Manual ISP-Design
1. Important Safety instructions
•People (including children) who are limited in their physical, sensory, or mental capacities
should not use this device at any time. Furthermore do not handle this instrument if you do not
possess the necessary experience and knowledge to do so. This device should only be handled
under the supervision of a qualified person and after a thorough introduction.
•Do not leave children alone with the device, and supervise them at all times to keep them from
getting harmed.
•WARNING: Do not cover! Otherwise this instrument will overheat.
•Do not place the heater underneath a socket, drainage or the like.
•To keep from getting burned, do not touch heater´s surface whenever it is turned on.
•Please use the handle whenever you have to move the heater.
•Do not put the cord underneath the carpet or a rug and make sure that it is not a tripping
hazard
•Plug the heater into properly grounded sockets only.
•Do not use the heater in any other way than described in the user manual. Any other way of use
may lead to fire, electrocution, and may cause serious harm to the person.
•Do not use this device near bathtubs, showers or swimming pools.
•In case the connection cable is damaged it has to be replaced by the manufacturer or someone
commissioned by the manufacturer.
WARNING: Do not use a switching-oriented device, like a timekeeper, when operating this heater.
This could cause a change in the thermal adjustment which is potentially hazardous!
•To keep the device from overheating do not put towels or clothing on top.
•When using the heater, make sure it is in an upright position and positioned on an even and dry
place.
•Do not put any foreign objects into the vent. This may cause electrocution, fire or damage to the
heater.
•Do not use an extension cord unless approved by an electrician.
•This device is for private use only, do not use in any other way than intended by the
manufacturer.
•Do not use the device near curtains, highly combustible, extremely explosive or malleable
materials.
•Keep a distance of a at least 1.0 m between combustible materials- like furniture, cushions,
bedding, paper, clothing, curtains-and the heating device.
•Do not use the device in rooms were petrol, paint or any other flammable liquids are stored.
•Do not use the device outside.
Warning! This device has to be grounded
This device may only be operated using alternating current and the operating voltage indicated
on the power rating plate
•Nominal Voltage 230V AC, 50 Hz
•Protection class I
•Receiver (RF-model) 7°C till 30°C
•Power 350W up to 750W
GB

3 Edition: 02/17
Manual ISP-Design
WARNING - THIS APPLIANCE MUST BE GROUNDED
We hope you enjoy using infrared radiating panel.
ISP-Design W (white glas plate)
ISP-Design B (black glas plate)
ISP- Design M (mokka glas plate)
ISP-Design S (Mirror glas plate)
Prior to commissioning, please inform yourself about proper installation, commissioning, operation and
maintenance.
Below we give the necessary information:
The installation and electrical connection must be carried out by a qualified electrician.
The panels are designed for wall mounting only!
Wall mounting only! No ceiling mounting allowed!
The plate can be mounted horizontally or vertically. Drill mounting holes as indicated in pic. 1
(horizontally) or as in pic.2 (vertically). The pack contains 4 (6 screws for the models ISP Design 600 /S
600 till 1200/S750 & ISP Design 501 till 851)) fixing screws 6 x 70 mm.
To mounting the unit using all 4 (6) anchors. The recommended dowel size is 10 mm (not
included).
The dimensions A and B are pitches of the holes to be drilled.
A/2
B
B
D
pic: 1
pic: 2
A
detail view
GB
D/2

4 Edition: 02/17
Manual ISP-Design
Distances
The distance between the lower edge of the heater from the floor must be at least 50 mm, 150 mm are
recommended. Side distance, for example, to furniture must be at least 100 mm. In bathrooms, the
heating plate is in compliance with the standard VDE 100 / T701 to install. It can be mounted as shown
in Abb.1 from field 2 (range 1 is not allowed!)
all models
with 690 mm
width
incl. RF
drill spacing holes
A[mm]
B
[mm
]
C [mm]
D [mm]
ISP Design 350
ISP Design S 350
324 360 360 324
ISP Design 450
624
360
360
624
ISP Design 600
ISP Design S 600
624 A/2 = 312 360 360 624 D/2 = 312
ISP Design 750
ISP Design S 750
924 A/2 = 462 360 360 924 D/2 = 462
ISP Design 950
1224
A/2 = 612
360
360
1224
D/2 = 612
ISP Design 1200
1524
A/2 = 762
360
360
1524
D/2 = 762
all models with
454 mm width
incl. RF
drill spacing holes
A[mm]
B [mm]
C [mm]
D [mm]
ISP Design 351
624
240
240
624
ISP Design 501
924
A/2 = 462
240
240
924
D/2 = 462
ISP Design 651
1224
A/2 = 612
240
240
1224
D/2 = 612
ISP Design 851
1524
A/2 = 762
240
240
1524
D/2 = 762

5 Edition: 02/17
Manual ISP-Design
Electrical Connection
The ISP heating panel is equipped plug.
It is always a residual current circuit breaker for use with an operating current of 30 mA maximum. If the
supply cord of this appliance consumption is damaged, it must be replaced by the manufacturer or a
service technician.
Operation of the ISP heating panels
It is recommended that the control of the ISP heating panels by an external room thermostat from
TECHNOTHERM (eg. radio receiver TPF or with the digital radio transmitter TBF. In addition, the ISP
heating panels are equipped with a limiting thermostat to ensure their safe
WARNING: DO NOT COVER THE HEATER
Technical data:
model width
690 mm
power
[Watt] W x H x D [mm] weight Model width 690 mm
power
[Watt] W x H x D [mm] weight
Design-W/B/M 350 350 730 x 690 x 20 14,8 Design-W/B/M 350 RF 350 730 x 690 x 20 14,8
Design-S 350 350 650 x 650 x 20 15,0 Design-S 350 RF 350 650 x 650 x 20 15,0
Design-W/B/M 450 450 1030 x 690 x 20 17,5 Design-W/B/M 450 RF 450 1030 x 690 x 20 17,5
Design-W/B/M 600 600 1330 x 690 x 20 23,0 Design-W/B/M 600 RF 600 1330 x 690 x 20 23,0
Design S 600 600 1250 x 650 x 20 23,0 Design S 600 RF 600 1250 x 650 x 20 23,0
Design-W/B/M 750 750 1330 x 690 x 20 23,0 Design-W/B/M 750 RF 750 1330 x 690 x 20 23,0
Design S 750 750 1250 x 650 x 20 23,0 Design S 750 750 1250 x 650 x 20 23,0
Design-W/B/M 950 950 1630 x 690 x 20 26,0 Design-W/B/M 950 RF 950 1630 x 690 x 20 26,0
Design-W/B/M 1200 1200 1930 x 690 x 20 29,0 Design-W/B/M 1200 RF 1200 1930 x 690 x 20 29,0
model width
545 mm
power
[Watt]
W x H x D [mm] weight
Model width
545 mm
power
[Watt]
W x H x D [mm] weight
Design-W/B/M 351 350 1050 x 454 x 20 14,0 Design-W/B/M 351 RF 350 1050 x 454 x 20 14,0
Design-W/B/M 501 500 1350 x 454 x 20 18,0 Design-W/B/M 501 RF 500 1350 x 454 x 20 18,0
Design-W/B/M 651 650 1650 x 454 x 20 22,0 Design-W/B/M 651 RF 650 1650 x 454 x 20 22,0
Design-W/BM 851 850 1950 x 454 x 20 26,0 Design-W/BM 851 RF 850 1950 x 454 x 20 26,0
W = white | B = black | M= mokka |S = mirror
„RF“: Units are supplied with preassembled radio receiver
GB

6 Edition: 02/17
Manual ISP-Design
Connecting the recipient (only with the "RH" models)
Press on the receiver for more than 3 seconds the button until the indicator light
begins to flash. Then attach the transmitter in configuration mode (see manual
transmitter). If the indicator light on the receiver stops flashing, the two
products are assigned.
Disconnect the receiver
To delete all associated products you press the receiver button for about 30
seconds until the indicator light flashes briefly. All channels are now deleted!
Technical data’s oft the receiver „RF“
• power supply 230 V, 50 Hz +/-10%
• protection class II
• consumption: 0,5 V
• switching capacity max.: 16 A 230 Veff Cos φ= 1
• radio frequency 868 MHz (Norm EN 300 220),
• radio range up to 300 m (outdoor), indoor up to 30 m, depending of structural factors and electromagnetic
interference.
• maximum number of recipients: 8 units
• temperature range: -5°C to +50°C
• dimensions: 120 x 54 x 25 mm
• IP 44 - IK 04
Switching from X3D to X2D and vice versa:
X2D for TPF/TBF
X3D for TPF-Eco
1) Before the changeover, the assignment to the thermostat must be cleared.
Press and hold for 30 seconds (1):
after 3 seconds, the LED flashes slowly.
after 7 seconds, the LED flashes quickly. Keep the receiver button pressed until both
LEDs flash.
Release the button (2).
GB

7 Edition: 02/17
Manual ISP-Design
2) Changeover
When switching on the installation (1), you have 4 seconds to press 3 times the receiver
button (2). The LED flashes (3): 2 times for X2D, 3 times for X3D.
Errors and technical modifications reserved!
Lucht LHZ Elektroheizung GmbH & Co. KG
Reinhard-Schmidt-Str. 1
09217 Burgstädt
Fon: 03724 66869 0
Fax: [phone]
E-mail: [e-mail]
