Technotherm PH SlimLine User manual

Feel good through warmth from electricity - www.technotherm.de
|1
Model
• PH Slimline
Instruction Manual -
PH SlimLine
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY
AND RETAINED FOR FUTURE REFERENCE. BE SURE
TO OBSERVE ALL LABELS AND WARNINGS ON THE
APPLIANCE
Id.-Nr. 900 370 401
Edion :01/18

Feel good through warmth from electricity - www.technotherm.de
Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
2|
1. PRESENTATION
First of all, we would like to thank you for having bought this product; we hope that it will give you ye-
ars of reliable heang. Before installing the heater, please read the following instrucons carefully. The
company is not responsible for any damage or problems resulng from incorrect installaon. Once your
heater is up and running, please store this booklet in a safe place for future reference.
RECYCLING
When you no longer need this heater, please follow the European Direcve 2002/96/CE as regards its
disposal. This heater cannot be discarded as normal rubbish. It must either be taken to a
special p or to a distributor oering to dispose for you. Recycling electrical appliances sepa-
rately allows component parts to be re-used and limits the damage to the environment that
would otherwise occur. Recycling saves power and resources. To encourage this, the heater
bears a symbol showing it cannot be put into a normal bin. For further informaon, get in touch with
your local council, or the supplier who you purchased this product.
VERY IMPORTANT!!
It is possible that the radiator may make slight sounds during the rst days of operaon. This is quite
normal in dry radiators and can occur when the aluminium elements expand and contract. Please note
there is no danger to the user. Children under 3 years old should be kept out of the equipment unless
they are constantly supervised. Children under 8 must only turn on / o the device provided in normal
posion and only if they have received instrucon concerning use of the equipment in a safe way and
understand the risks. All children under 8 years should not plug regulang, cleaning or maintenance
operaons.
Cauon: some parts of this product may become very hot and cause burns. Special aenon when
children and vulnerable people are present. The device must not be covered and air circulaon must
be allowed at all mes.
2. HOW TO USE YOUR ELECTRIC RADIATOR
Understanding the full programming potenal of your radiator will help to reduce energy consumpon.
• DISPLAY
The radiator has an electronic programmable thermostat with LCD screen specially designed to control
dierent types of heang opons.
1. Operang mode menu (all acve modes are framed).
2. Program number or parameters number.
3. Installaon parameter menu.
4. Key lock funcon indicator.
5. Room temperature indicator.
6. Type of me display (12H am/pm or 24H)
7. Graphic view for the current day program.
8. Display zone for Time, Temperatures and parameters.
9. Heang demand.
10. Pictogram for program creaon, status in normal mode.
11. Pictogram for pilot wire indicaon.
12. Current day of the week
13. Override funcon in AUTO mode or ITCS funcon acvated if blinking.
14. Windows open indicator.

Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
|3
• KEYBOARD
1. On/O
2. Minus Key - -
3. Validaon Key OK
4. Plus Key +
5. Right Navigaon key
3 FIRST INSTALLATION
This secon will help guide you to starng your thermostat for the rst me.
• POWER SUPPLY
Connect the electric radiator with the switch installed for this funcon.
When the thermostat is switched on for the rst me, you will be asked to make some neces
sary selecons (Clock, etc.). The baeries inside the thermostat will need to be charged for a
minimum of 24 hours in order to have maximum me saving capacity.
Now your thermostat will require adjustment of the me and date.
• TIME AND DATE ADJUSTMENT
First move the square cursor on the clock mode, then press the key (-) or (+) to start the adjust
ment. Each me a value blinks, you can adjust it with the (-) and (+) keys.
Once the value is chosen, conrm it with the (OK) key. The thermostat will move automacally
to the next value. List order of the me and date adjustments:
1. Time and day:
- Adjustment of the hours,
- Adjustment of the minutes
- Adjustment of the day (1 = Monday)
2. Date:
- Adjustment of the day number
- Adjustment of the Month (01=January, 12=December)
- Adjustment of the Year
• STARTING
The thermostat is now ready to work. The default working mode will be comfort .At any me,
when the light is o, press the OK, “-“, “+” or . Press OK and then press the second me to
show the xed temperature.
• ON/OFF
Press key if it is available on your radiator to turn o or turn on the radiator, Navigate to this
key using the ( ) scroll key to select mode .
Select OFF to turn the radiator to the o posion.

Feel good through warmth from electricity - www.technotherm.de
Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
4|
MODES OF OPERATION
How to change the working mode?
• Use the navigaon key right ( ) (in some models also you can
use the key le ) or to display the working mode line.
• Move the frame cursor on the desired working mode and press (OK)
to enter in the operang mode you have chosen.
• MANUAL MODE COMFORT
Manual working mode, the comfort temperature seng will be followed 24 hours a day / 7 days
a week. By pressing (-) or (+) keys, the temperature can be adjusted accordingly.
• MANUAL MODE REDUCED
During manual working mode the reduced temperature seng will be followed 24 hours a day
/ 7 days a week. By pressing (-) or (+) keys, the temperature starts to blink and can be adjusted.
• OFF MODE
This mode only is selectable on radiators without an On/O buon. On radiators with an On/O
buon, press this key to turn O. Use this mode if you need to switch o your installaon.
Be careful: in this mode your radiator can freeze.
• AUTOMATIC MODE
With this mode the thermostat will follow the chosen program (Built-in or customised) accor
ding to the actual me and the Comfort and Reduced temperature sengs.
You can easily override the current program temperature by changing the value with (-) or (+).
The current sengntemperature will blink.
The small hand logo will be displayed when the override funcon is acve. The original
temperature sengs will eturn when the mer reaches the next change in the programme.
If hand logo blinks then ITCS is acve (See the user menu for more explanaon on this
funcon).
• ANTIFREEZE MODE
Use this mode if you want to protect your radiator against freezing when going on holiday...
The an-freeze seng temperature is xed and can be adjusted in the parameter menu number
05 ‘AF’, see chapter 6. (Default value 5°C)
If you want to stop the mer funcon before the end, set the duraon period to “no” with (-) key.
• TIMER MODE
The Timer mode allows you to adjust the temperature and the duraon for a specic me.
- This funcon can be used when you stay at home for several days, or if you want to override
the program or some me.
- You can rst adjust the duraon in hours “H” if below 24H, then in days “d” with (-) or (+),
press (OK) to conrm. (Adjustable from 1 hour up to 44 days)
- You can also adjust the desired seng temperature to start the funcon. (Default value 21°C).
The logo will blink and the number of hours /days remaining is displayed unl the end of the period.

Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
|5
5. PROGRAMMING WEEKLY
Select the mode with the keys of displacement
When you enter in the Program mode, the rst operaon is to choose the program number using the
(-) or (+) keys. You can choose between a built-in program P1 to P9 or an user program U1 to U4. Select a
program and press ok to validate.
If you select a built-in program P1 to P9, you can view and select only one of the following pre-set program
opons.
P1: Morning, Evening & Weekend
P2: Morning, Midday, Evening & Weekend
P3: Day & Weekend
P4: Evening & Weekend
P5: Morning, Evening (Bathroom)
P6: Morning, aernoon & Weekend
P7: 7H – 19H (Oce)
P8: 8H – 19H & Saturday (Shop)
P9: Weekend (Secondary house)
The bars indicate the hours with comfort temperature and the rest of the day the spaces represent the eco
(reduced) temperature mode. (See the appendix secon to view a complete descripon of the Built-in
program)
• Use the navigaon key right ( ) to view the program of alternave days of the week.
• Press the (OK) key to conrm your choice and return to the main screen (in AUTO mode)
•
If you select a user program U1 to U4 as menoned above you can choose the program, view it and also
amend it.
Default seng:
• U1, U2, U3, U4 = in comfort for the week
• Press the conrmaon key (OK) to customise a user program
Descripon of the creaon of a user program:
• The program step is 30 minutes
• Each me a value or icon blinks you are
invited to make a choice with the (-) or (+)
keys. Once the choice is made press the (OK) key
to jump to the following step.
Day
Program of the day
Program number

Feel good through warmth from electricity - www.technotherm.de
Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
6|
• The program creaon will always start with day 1 (Monday).
• The key (-) acvates the ECO temperature mode to begin.
• The key (+) acvates the COMFORT temperature mode to begin.
• Use the (-) or (+) buons to select the duraon of the ECO and Comfort temperature modes in in-
tervals of 30 minutes.
• When you have completed the rst day the programme will automacally move to the next day.
Aer validang the seventh day, the system automacally returns to AUTO mode and your programme
mode will appear in the top right corner. For extra assistance, please contact the seller for a step by
step guide.
6. SPECIAL FUNCTIONS
• KEYBOARDS LOCK FUNCTION:
Use this funcon to prevent any changes to your sengs (In a child room, public area, etc...)
To acvate the Key lock funcon, rst press and maintain the validaon key (OK) and then press
simultaneously on the right arrow key ( ).
- The “ ” logo will be displayed on the screen.
- Repeat the same procedure to unlock the keyboard.
Note: The keyboards lock funcon is available in all modes.
• FUNCTION WINDOWS OPEN
This funcon will stop the radiator automacally when it detects a window open if the
radiator is running. When this feature is enabled, the icon appears at
the top le of the screen. If the system detects a fall of approximately 3 °C,
it stops the heang for a period of 1 hour. The icon will blink and the
temperature will be measured by the radiator. Pressing any buon at this
stage will stop the detecon of open windows. The radiator will begin to
funcon normally again and will restarts the detecon of open windows.
• MENU PARAMETERS
Your thermostat has a parameter’s menu. To enter this menu, press and
maintain the validaon key (OK) for 5 seconds. Then the parameter menu
will appear and the rst menu screen will be displayed. Now you can
select the parameters which must be adjusted with the navigaon keys
(). Press the (OK) key to edit the parameter that you wish to modify
and change its value with (+) or (-), then conrm with (OK).
Nº Default value & other possibilies
1 dEG: Type of degrees displayed
°C Celsius
°F Fahrenheit
2 24h: Selecon of the clock
24H (24:00)
12H (12:00 AM /PM)
3 dSt: Daylight summer me.
Yes the automac change over me between Summer and Winter is acvated according to date
No no daylight summer me automac change.

Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
|7
4 _ ._: Calibraon of the internal probe
The calibraon must be done aer 1 day working with the same seng temperature in
accordance with the following descripon:
Put a thermometer in the room at 1.5M distance from the oor (like the thermostat) and check
the real temperature in the room aer 1 hour.
When you enter on the calibraon parameter the actual value is displayed.
To enter the value shown on the thermometer, use the (-) or (+) keys to enter the real value. Then,
press (Ok) to conrm. The logo should be displayed, to inform that a calibraon is now made
and saved in the memory. If you need to erase a calibraon already made press on the
navigaon key le ( ). Then the logo must disappear.
* Pay aenon: Only the heang element managed by the thermostat must be used during the
complete step of the calibraon.
5 AF: An Freeze temperature:
This An-freeze temperature used in Holiday mode.
Adjustable 0.5 to 10.0°C with default value 5.0°C.
6 ITCS: Intelligent Temperature Control System
The Intelligent Temperature Control System will acvate your installaon in advance (2 hours
maximum) to assure the desired temperature at the hour programmed following your weekly pro
gram. This automac control system works in the following way:
When you start your thermostat for the rst me, it will measure the me taken by your
installaon to reach the set temperature. The thermostat will re-measure this me at each pro
gram change to compensate external temperature change & inuence. You can now program
your thermostat without the need to adjust the temperature in advance because your
thermosat does it automacally for you.
7 WIN: Automac detecon of open windows.
This feature allows detect automacally if you open a window.
No: deacvaon of the funcon.
Yes: Acvate the funcon
8 Clr: Factory seng
Press and maintain (Ok) key during 10s to reset Set points temperatures and user parameters in
this menu to factory default sengs. User programs will also be reseed.
* Pay aenon:
Ensure that you have all necessary elements to re-setup your installaon before to use this
funcon.
9 Soware version
_._
10 End: Exit the parameter’s menu
Press (OK) key to exit installaon parameter menu and return to normal operaon.

Feel good through warmth from electricity - www.technotherm.de
Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
8|
7. TECHNICAL CHARACTERISTIC
Measured temperature precision 0.1°C
Environmental:
• Operang temperature
• Shipping and storage temperature
0°C - 40°C
-10°C to +50°C
Seng temperature range
• Comfort, Reduced
• Timer
5°C to 37°C by 0,5°C step
5°C to 37°C by 0,5°C step
Regulaon characteriscs Proporonal band (PWM)
Power Supply 230Vac +/- 10% 50Hz
Output
• Maximum Load (Resisve only) TRIAC 230Vac
8 Amps (1850W)
Soware Version Displayed in the user menu.
Norms and direcves:
Your thermostat was designed in accordance with the follo-
wing Europeans norms and direcves:
EN 60730-1 : 2003
EN 61000-6-1 : 2002
EN 61000-6-3 : 2004
EN 61000-4-2 : 2001
Low voltage 2006/95/EC
EMC 2004/108/EC
8. TROUBLESHOOTING & SOLUTION
My Thermostat doesn’t work
Power supply - Check the power supply
My Thermostat show an Error message “Err” blink on the display
“Error” on sensor
Note:
For safety if there is a problem on the regulaon sensor the
regulaon will be replaced by a rate of 5 % funconing.
The logo and the text “Err” blinks. Error detected on
the internal sensor
- Contact your installer or seller.
My Thermostat seems work correctly but the heang doesn’t work correctly
Output - Check the connecons.
- Check the power supply of the heang element.
- Contact your installer.
My Thermostat seems work correctly but the temperature in the room was never in accordance with the program.
Program - Check the Clock.
-The dierence between Comfort & Reduced temperature
is too high?
- The step in the program is too short?
- Check the pilot wire funcon.

Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
|9
9. INSTALLATION
• BEFORE INSTALLING
Whilst the installaon of this heater is straighorward, please ensure you read the following carefully as
the manufacturer will not be liable for any damage or problems arising from incorrect installaon.
Unwrap your heater and clear the packaging away. The packaging has been specically chosen to allow
you to recycle it. If on unpacking, you discover any damage whatsoever, please get in touch with your sup-
plier within 24 hours and prior to installaon.
For assembly and installaon, please follow the instrucons as set out in this booklet. For safety reasons,
this heater should never be installed in close proximity to a bath or shower i.e. that you could touch the
controls whilst in the bath or shower. The radiator should not be placed below a socket. If the cable has
been damaged, it can only be replaced by the manufacturer, through its aersales team, or by a qualied
person. This ensures the user will not be in any danger. At the end of the manual, you will nd a Guarantee,
please check that this has been completed correctly, dated and stamped
Very important:
- Read installaon manual prior to installaon of this unit!
- Read user manual before pung this unit in operaon!
- Observe the warnings in the manuals!
- The installaon room must full the venlaon requirements!
- Installaon by an authorised person only!
• CONNECTING ELECTRICITY SUPPLY
- If the Thermal Emier that you have acquired does not have a plug on the supply cord, installa
on shouldbe carried out by a qualied electrician.
- Means for disconnecon must be incorporated in the xed wiring in accordance with the wiring
rules of thecountry where it is to be installed.
- Before connecng, check the supply is switched o.
- Before connecng the appliance to the xed wiring check that the voltage of supply is inside the
ratedvalues indicated in the marking plate 220 - 240V.
- The appliance must be connected to the fused system of xed wiring.
- Any problem arising from not following the instrucons above will invalidate your guarantee
- When wiring up, please follow the colours of wires.
• HANGING THE HEATER
The radiator comes complete with an installaon kit, comprising the following:
- Screws
- Brackets
Cardboard guide, (remove from the top of the box the radiator comes in). Please follow the illustrated
steps below to hang and install your radiator:
1. Take the radiator out of its packaging and choose where to hang it. Please notethe minimum
distances required around the heater.
2. Remove the cardboard guide from the lid of the box and place it at the rightheight, as shown
in diagram 4 below. We suggest you use a level to ensure theradiator is hung square. Using the
holes as your guide, mark where the bracketsneed to go.
3. Drill and plug the holes.
4. Screw the brackets to hold the radiator into place, using the screws and washersprovided.
5. Place the unit so that the brackets [15] t into the slot that has the upper prole ohe radiator.
6. Approximate the radiator to the holders of the wall brackets and screw xaon.
7. Use a hole drill for holes with appropriate stoppers for the type of wall.

Feel good through warmth from electricity - www.technotherm.de
Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
10|
Read installaon manual prior to installaon of this unit!
• Read user manual before pung this unit in operaon!
• Observe the warnings in the manuals!
• The installaon room must full the venlaon requirements!
• Installaon by an authorised person only!
10. CONNECTING ELECTRICITY SUPPLY
• If the Thermal Emier that you have acquired does not have a plug on the supply cord, installaon
should be carried out by a qualied electrician.
• Means for disconnecon must be incorporated in the xed wiring in accordance with the wiring
rules of the country where it is to be installed.
• Before connecng, check the supply is switched o.
• Before connecng the appliance to the xed wiring check that the voltage of supply is inside the
rated values indicated in the marking plate 220 - 240V.
• The appliance must be connected to the fused system of xed wiring.
• Any problem arising from not following the instrucons above will invalidate your guarantee
• When wiring up, please follow the colours of wires

Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
|11
11. WIRING DIAGRAM
12. GUARANTEE.
The manufacturer produces high quality products for internaonal markets. The company provides a
technical guarantee for the period of 2 years maximum. For this warranty to be valid you must present
the original invoice, delivery note or cket.
Prerequisites:
• The guarantee only covers manufacturing defects and/or any problem occurring from such defects.
Allproblems arising from installing and undersized heater (not enough heat, improper installaon,
etc) are notcovered by this guarantee.
• This heater is for domesc & light commercial use only, installaon in any other environment voids
thisguarantee
• Technotherm reserves the right to decide whether to repair or replace any defecve part or to
replace the enre heater.
• All costs arising from any damage caused by incorrect usage, transport, electrical supply are not
coveredby this guarantee, nor is any malicious damage.
This guarantee does provide compensaon for incidental or consequenal damage or injuries.

Feel good through warmth from electricity - www.technotherm.de
Instruction Manual - PH Slimline
Feel good through warmth from electricity - www.technotherm.de
GB
12|
TECHNOTHERM Support
[phone]
TECHNOTHERM a brand of Lucht LHZ GmbH & Co. KG
Reinhard-Schmidt-Str. 1 | 09217 Burgstädt | Germany
Telefon: [phone]
Telefax: [phone]
[e-mail] | www.technotherm.de Subject to errors and technical amendments. Dimensions without guarantee! Edion 01/18
Information requirements for electric local space heaters
Model: PH SlimLine
Item Symbol Value Value Item Value
Heat output Type of heat input, for electric storage local space heaters only (select one)
Nominal heat output Pnom 0,9 1,5 2,0 kW manual heat charge control, with integrated thermostat NO
Minimum heat
output (indicative) Pmin 0,5 1,0 1,2 kW
manual heat charge control with room and/or outdoor temperature
feedback
NO
Maximum continuo-
us heat output Pmax,c 0,5 1,0 1,2 kW electronic heat charge control with room and/or outdoor
temperature feedback
NO
Auxiliary electrici-
ty consumption
fan assisted heat output NO
At nominal heat
output elmax 0,9 1,5 2,0 kW Type of heat output/room temperature control (select
one)
At minimum heat
output elmin
1,2 1,2 1,2
kW
single stage heat output and no room temperature control No
1,2 1,2 1,2 Two or more manual stages, no room temperature control No
In standby mode
elSB
1,2 1,2 1,2
kW
with mechanic thermostat room temperature control N0
1,2 1,2 1,2 with electronic room temperature control No
electronic room temperature control plus day timer No
electronic room temperature control plus week timer Yes
Other control options (multiple selections possible)
room temperature control, with presence detection No
room temperature control, with open window detection Yes
with distance control option No
with adaptive start control Yes
with working time limitation No
with black bulb sensor No
Contact Information: Lucht LHZ Elektroheizung GmbG & Co. KG | Reinhard-Schmidt.Str.1 D-09217 Burgstädt
