Technotherm KS DSM Use and maintenance manual

Technotherm KS DSM – Control Guide
Contents:
1. Control via Radiator
a. Top Tips
b. Keypad
c. Choose Mode
d. Programming the Radiator
e. Set Time & Date
f. Advanced Settings
2. Control via App
a. Setting up the WiFi Hub
b. Setting up the App
c. Connecting to your Radiators
d. Using the App
e. Alexa
f. Google Home
1 – Control via Radiator
1A – Top Tips
•Be aware, all menus time out after ten seconds.
•To lock, or unlock, hold down and for 3 seconds.
1B – Keypad
•Increase
•Decrease
•Toggle Manual / Auto
•Bluetooth Connect (with app)
•Set Mode Temperature
•Program
•Advanced Settings
Manual
Comfort
Automatic
Economy
Off
Anti-Freeze
Connected to App
Open Window Detection

Set Auto mode
temperatures
Adaptive Start
Heating
1C – Choose Mode
•Press to cycle between Manual , Auto and Off .
•On Manual mode, the radiator will heat at a set temperature.
oUse and to set a temperature from 0 – 30 °C
•On Auto mode, the radiator will follow a set schedule.
oThe display will alternate between “PRO” and the set
temperature.
oSee “Programming the Radiator” for how to set the radiator
schedule.
oYou can use and to temporarily set a new
temperature while on auto mode. The radiator will heat at
your new temperature for 90 minutes before reverting to the
schedule.
•On Off mode, the radiator will receive commands but won’t heat until it is sent a
new command – either by the app or by the control panel.
1D – Programming the Radiator
•From Manual or Auto mode, hold down Prog. for 3 seconds until
you see this screen:
o
•Assign modes to each hour of each day of the week:

oPress Mode to toggle between the 3 modes: Comfort , Economy and
Anti-Freeze .
oUse and to move through the days, assigning the previous mode as
you go. E.g. if you select Comfort and then press to go through the
week, each hour you pass will be set to Comfort until you change mode again.
oUnfortunately, there is no way to skip through days of the week without overwriting
the modes.
oThe DSM has a 24/7 timer. When you reach the final hour of
the first day, the radiator will automatically move onto the next
day. The number at the top of the screen shows which day you
are on. 1 = Monday and so on.
oNote – it can be hard to see the top number if you are looking
down on the control panel!
oPress Config. at any time to leave the programming menu.
•Set temperature of Auto modes:
oPress Config . You should see the icon.
oPress to adjust temperatures.
oComfort , Economy and Anti-Freeze modes will be
shown in turn. Use and to adjust the
temperature and to switch to the next mode.
oPress Config. to exit.

1E – Set Time & Date
NOTE – if you have already connected the radiator to the app, you will not be able to change the date
or time via the radiator. The radiator will get the time from the app.
•Hold down Config. until you see the programming screen.
•Press Config. once more.
•The day of the week will flash in the top corner. 1 = Monday and so on.
•Use and to adjust the day and press to confirm.
•Use and to adjust the hours and press to
confirm.
•Use and to adjust the minutes and press to confirm.
1F – Advanced Settings
•Press Config. .
•Hold down Config. for 5 seconds until you see this screen:
•
•Use and to scroll through the options below.
•Press to select a setting.

•Use and to scroll through the options within the setting.
•Press to save setting changes. If you don’t press OK, the menu will time out and the
settings will return to normal.
Option
Setting
Options
Notes
C1
Temperature
Units
•° F (Fahrenheit)
•
° C (Celsius)
C2
Heating
Control Type
•H0.25
•H0.35
•H0.50
•H0.75
•Pi15
•Pi30
This setting controls how the heater, when
maintaining a set temperature, responds to
information from the thermostat.
H stands for Hysteresis. A hysteresis setting
means the radiator will respond when the
temperature goes above or below the set
temperature by a certain threshold. E.g. If you
select H0.25, it will respond when the
temperature is ±0.25 °C beyond the set
temperature.
Pi stands for PID Control, which in this context
means the radiator checks the temperature and
responds based on a time interval. E.g. Pi15
means the radiator will check the temperature
and respond every 15 minutes.
C3
Temperature
Measurement
Compensation
•- 3 to +3 ° C
(intervals of 0.1° C)
Adjust the baseline from which the radiator
reads the temperature. If it’s reading too low,
adjust to a minus number. If it’s reading too high,
adjust to a positive number.
C4
Firmware
Version
N/A
Check what firmware version the controller is
running.
C5
Open Window
Detection
•On
•Off
If active, the open window detector will stop
heating if there is a fall of 2.4 °C or more within 4
minutes.
C6
Adaptive Start
•On
•Off
If active adaptive start function will switch on in
advance of its schedule to ensure the room is at
temperature when the schedule begins.
C7
Toggle Mode
Options – full
options or just
manual
•Full
•Man
If you select “Man”, you will not see the “Auto”
option when you switch between modes. This is
useful if you only want the radiator to work as an
on-demand heater.

2 – Control via App
To control your radiators via WiFi you need to purchase a WiFi hub. Commands from your app are
received via the router and then the hub sends them to your radiators via a radio frequency.
2A – Setting up the WiFi Hub
•Connect the hub to your router with the supplied ethernet cable.
•Plug the hub into the mains with the supplied USB cable and power adaptor.
2B – Setting up the App
•Download the Lucht LHZ Smartcontrol App
•Create an account.
•You will be sent an email to verify your account.
Click on the link and return to the app. Press Back
to go to the login screen.
Note – you can also control your
DSM radiators by PC. Just go to this
link and follow the same steps:
https://smartcontrol.lucht-
lhz.de/#/signIn

•Login to your account
•Set up your house on the app. Add a name and select the time zone.
•Connect the WiFi hub to the App. The easiest way to do this is by pressing the connection
button on the WiFi hub while this screen is showing.
•If this doesn’t work, the App will prompt you to add the WiFi hub manually by entering the
long code on the back of the WiFi hub.
2C – Connecting to your Radiators
•Press install heater Hold down on radiator for
three seconds. You should see the symbol
appear at the top of the screen.
•NOTE – the symbol may be hard to see if you are looking
at the control panel from above!
•The radiator will appear on the app. You can change its
name and other settings via the “More” menu when you
click into the radiator.

2D – Using the App
Home Screen
This is where you can manage all your radiators and make universal changes to your account.
NOTE – the Lucht LHZ is also designed to work with power meters, so you will see some functions that
don’t affect your radiators.
•To delete a radiator – select the radiator by checking the circle in
the corner and pressing delete .
•To toggle between At Home and Away mode – tap the house icon
at the top . When the radiator is set to Away mode, your radiators
will heat as set but with all temperatures reduced by a set margin. You
can adjust this margin in the More -> Setup menu.
•To set up geolocation – press the menu button in the top right
corner and press Homes . Press your home and then press
Geolocation . From here you can set your location and radius. When
geolocation is enabled, your radiators will switch to Away mode when
your phone moves outside this radius.
•To invite new users – follow steps as above for Geolocation but
press Invite Users . Enter the email address of the new user. New
users will be able to access home and heating settings but will not be
able to invite other users.
Radiator Screen
From the home screen, tap your radiator to enter the radiator control screen. From here you can
adjust temperatures, change modes, program and edit the settings of the radiator.
•Use Man / Auto toggle to switch between manual and auto mode
•On Manual mode, you can use the tape measure, or the – and +
buttons, to adjust the temperature between 0 – 30 °C.
•You can also do this on Auto mode, where the new set temperature
will run for 90 minutes before it reverts to the schedule.
•You can adjust the programming by pressing More and then
Schedule .

Setting a Schedule
•Days are edited individually. Press the day you want to edit and assign modes to each hour.
•Do this by pressing the mode at the top and “painting” it onto the hours you want that
mode.
•You can set the temperature of the modes by pressing Set Temp. .
•You can use the Copy Day function to apply that day’s schedule to other days.
Setup
You can adjust your radiator’s settings via the More -> Setup menu.
•Change name
•Temperature Measurement
oCelsius (°C) / Fahrenheit (°F)
•Control
oHysteresis 0.2 °C, 0.3 °C, 0.5 °C, 0.7 °C
oPID15 / PID30
•Priority – this setting only comes into effect if you have
power meter on the app
oLow / Medium / High
•Away Offset (°C) – amount set temperatures will drop when you switch to Away mode
o0 – 5 °C
•True Radiant – toggle adaptive start feature
oYes / No
•Window Mode – toggle open window detection feature
oYes / No
Records
Press More -> Records to view statistics of set
temperature and power usage. You can switch between Daily,
Monthly and Annual view.
Hysteresis – radiator switches
on/off based on variance from
set temperature (i.e. 0.2 °C)
PID – radiator switches on/off by
checking set temperature after a
period of minutes (i.e. 15)

2E – Alexa
Use your voice to control your radiators via Amazon Alexa.
•First install the Heating Control skill on the Alexa app
ohttps://www.amazon.co.uk/VDI-S-L-Heating-
Control/dp/B079JWXZND/ref=sr_1_2?s=digital-
skills&ie=UTF8&qid=1548776112&sr=1-
2&keywords=heating+control
oMake sure the skill is enabled on Alexa
•Log in using your Lucht Smartcontrol app username and
password.
•Heating Control will display the long code of your WiFI hub. Press Link Device.
•You can then control your radiators using voice commands as follows:
Alexa Voice Commands
All voice controls must follow this formula:
“Start + Command + Device/s”
E.g. “Alexa ask Heating Control to switch on kitchen heater”
Start Command
Device Name
“Alexa, ask Heating Control…”
or
“Alexa, open Heating Control…”
•Name given to radiator on app – i.e. Kitchen.
or
•“House” or “The House”, to apply commands to
all heaters.
The user can finalise commands using the device type,
i.e. heater, but this is not mandatory.
Command List
… to turn off the <Device>.
… to switch off the <Device>.
… to turn on the <Device>.
… to switch on the <Device>.
… to set auto mode at <Device>.
… to set auto mode in <Device>.
… to set manual mode at <Device>.
… to set manual mode in <Device>.
… to set <Temperature> degrees at <Device>.
… to set <Temperature> at <Device>.
… to set <Temperature> degrees in <Device>.
… to set <Temperature> in <Device>.
… to get <Device> temperature.
… what’s the temperature of <Device>?
… what’s the temperature in <Device>?
… to get the House temperature?
… what’s the House temperature?
… what’s the temperature at Home?
… what’s the temperature in the House?
… what’s House temperature?
… to set <Temperature> in the House.
… to set <Temperature> degrees in the House.
… to set <Temperature> at Home.
… to set <Temperature> degrees at Home.
… to switch on the House.
… to switch on Home.
… to switch off the House.
… to switch off Home.

2F – Google Home
Use your voice to control your radiators via Google Home.
See Technotherm’s full guide:
https://www.electricradiatorsdirect.co.uk/media/pdf/Using%20DSM%20with%20Google%20Home.
pdf
