TECLOCK SSH-R1400 User manual

User’s Manual
Bluetooth Digital Hight Gauge
Type : SSH-R1400/SSH-R1600
Features
➢Measuring Range ：400mm/600mm
➢Resolution ：0.01mm
➢Ｗｉｒｅｌｅｓｓ Communication ：Ｂｌｕｅｔｏｏｔｈ
1
Q-162-1-E ver1.2

Description
１．Base
２，Post
３．Carriage
４．Fast Movement
５．Carriage Lock
６．Fine Adjustment
７．Probe Folder
８．Probe
９．Display
１０．ＭＯＤＥ Button
１１．ＳＥＴ Button
１２．SEND Button
１３．Slot for battery
１４．Slot for interface cable
2
月
２０．Automatic reference mode indicator
２１．Data sending
２２，Diameter / groove mode indicator
２３．Preset Mode
２６．Active reference indicator
２７．Unit(mm)
２８．+/-Indicator
２９．Low battery
13
10 11 12
14
20 21
22 23
26
27
28
29
Dimensions
Unit :mm

★Installing and replacing the battery
★Changing the probe
★Using the carriage
3
＊）Comply with the probe orientation !
➢Rapid carriage movement :
Turn the lever (4) and Updown
➢fine adjustment :
Tighten the carriage locking knob (5)
and rotate the knob (6).

1. Operating features of the instrument
①Button
The instrument has two operating modes: basic functions (direct access) and advanced functions.
In addition to the configuration functions, you can access to MIN, MAX and DELTA mode, plus
input of multiplication factor other than 1:1 (see chaps. 3 and 4).
②Button
The <favorite> button gives direct access to the function used most often (see chap. 7).
③Button
Sets a Preset value, resets the MIN/MAX mode, verifies a selection, and controls switching off the
instrument. By default, SIS mode enables automatic switch-off with no loss of origin (see chap. 8).
④Serial communication（Bluetooth/RS232/USB）
It is possible to activate or de-activate certain functions of the instrument via serial communication
(see chap. 11).
Data transmission parameters are 4800bps,7bits,even parity, and 2 stop bits.
2. Start
Press any button.
For a Bluetooth connection (see chap. 7).
4

3. Basic functions
Each short press on gives direct access to the basic functions :
4. Advanced functions
Prolonged pressure (>2s) on gives access to the advanced functions. Then, each short press
on accesses the required function
5
PrE
Auto
diA
OFF
On
bt(Bluetooth）
On
OFF
MAC
rEF
rEF1
rEF2
rESEt(Reset)
・Choice of reference：
REF1/REF2/AutoREF
・Inputting a preset value：
：Next ：Digit 0-9 ：Save
・Selection of Measurement mode：
OFF：Surface measurement ON：Diameter/Groove
Unit
dir
Auto
MAn
OFF
HId
bt.CFG
CSt(Constant)
SIMPLE
PAIr
Assign the constant value (Usually the value is “0.00”)
：next digit ：0-9 ：save
・Bluetooth ON/OFF
・Reset Pairing mode
・Display the MAC add.
Assign measurement unit(mm/inch)
Assign measurement direction (+/-)
Activates/deactivates the automatic switch-off
Auto : Activates / Man : De-activates
Assign Bluetooth profile(Config.)
SIMPLE/Pair/HID

5. Taking a constant with a calibration block
6. Diameter / groove measuring mode
To use this mode, you must first enter the touch value constant using the CSt menu or a calibration
block (see chap. 4)
Press the CST key and touch one of the
ground surfaces of the cylindrical gauge.
Release the probe and touch the opposite
surface. The probe constant value is displayed
and memorized until a new constant value is
taken. The value of the constant is stored and
then displayed for a few seconds.
Block Gauge
・Reference measurement
・Activation of the diameter
/ groove mode
・Deactivation of the diameter
/ groove mode
Note) The probe constant must
be re-entered after change of
probe or after modifying the
probe’s position.
“CSt” ：Constant value for reference measurement
・Surface measurement (low probe)
・Groove measurement (high probe)
・Height measurement (low probe)
6

7. Operation via Bluetooth
7.4. Bluetooth Connection :
1° Activate Bluetooth compatible software and hardware (Master: PC, Display Unit).
2° Start the instrument. By default the Bluetooth® module is active and the instrument is available for
connection (advertising mode).
3° If no connection is established during the advertisement period reactivate the Bluetooth® module
using the bt / On menu.
4° Instrument is ready to communicate (connected mode.)
7.5. Only with paired profile:
Pairing with master is automatically done at first connection.
To connect the instrument to a new master (new pairing), pairing information on the instrument must be
cleared using the bt/ rESEt menu.
7.6. Bluetooth Specifications:
7
7.1. HID mode（External Key board mode）
①Set HID mode by Advanced function.
②Set BT On mode by Advanced function.
③Reset Bluetooth mode by Basic function.
④Pairing connection the instrument to the PC.
（Instrument name：Hi Gage HID）
⑤Send the measured data by the DATA button.
7.2. Pair mode
①Set Pair mode by Advanced function.
②Set BT On mode by Advanced function.
③Reset Bluetooth mode by Basic function.
④Pairing connection the instrument to the PC.
（Instrument name：SY258）
⑤Send the measured data by the DATA button.
7.3. Bluetooth configuration
Items Specification
Frequency band 2.4GHz
Modulation GFSK
Max output power Class3(1mW)
Range
≦15m（open space），1-5m(industrial environment)
Version Bluetooth4.*
Display status Operating mode
off Bluetooth disconnected
blinkinng Bluetooth advertising
on Bluetooth connected
reset : clear pairing information
MAC : display the MAC address
Simple : profile without pairing
Pair : paired and secured profile
HID : virtual keyboard

８. Favorite key
The «favorite» key gives direct access to a predefined function, and can be configured according to the
needs of the user. In order to assign a function to the «favorite» key, give a prolonged press on ,
and then select the required function :
Validation of selection: By a prolonged press on or a short press on or .
Note :
- A function can also be assigned via RS232 or Bluetooth using the command.
９. Switching off
The dial gauge goes automatically into stand-by if not used for 10 minutes, unless automatic switch-off
mode has been turned off (see Chap. 4, advanced functions).
Stand-by mode can be forced by a prolonged press (> 2 sec) on
In stand-by mode, the value of the origin is retained by the sensor (SIS mode), and the instrument
automatically restarts with any movement of the measurement probe, RS command, Bluetooth® request
or press on button.
The instrument can be switched off completely for a long period of non-use, but this will necessitate a
zero reset on restart (the origin will be lost) :
- Prolonged press (>4 sec) on
10. Re-initializing the instrument
The initial instrument settings can be restored at any time by a prolonged press (>4 sec) simultaneously
on and until the message rESEt is displayed.
11. Connecting the instrument
The instrument can be connected to a peripheral via a Proximity (RS or USB), Power (RS or USB) cable
or Bluetooth®. See page 3 for connecting the Power cable.
Measured values can be transmitted and the instrument driven using predefined commands (see chap. 10
for a list of the main commands).
8

12. Serial communication commands
9
Selection and configuration Interrogation
CHA+ / CHA-
Assign measurement direction
CHA+:positive sense / CHA-:negative sense
CHA?
Measurement direction?
Response : CHA+ / CHA-
FCT0 / FCT1 / … / FCTA / … / FCTF
Assign «favourite» function FCT? «favourite» function ?
Response : FCT0～FCTF
MM / IN
Assign measurement unit
MM:mm/IN:inch UNI? Measurement unit active?
Response : MM/IN
KEY0 / KEY1
Assign Keypad Lock
KEY0:Lock/KEY1:Unlock KEY? Keypad locked?
Response : KEY0/KEY1
MUL +/-xx.xxxx Assign the multiplier value MUL?
Multiplier value?
Response : +/-xx.xxxx
PRE +/-xxx.xxx Assign preset value PRE?
Preset value?
Response : +/-xxx.xxx
STO1 / STO0
Assign Hold mode
STO1:ON / STO0:OFF STO?
Status of HOLD function?
Response : STO1/STO0
TOL1 / TOL0
Assign Tolerance mode
TOL1:ON /TOL0:OFF TOL?
Status of Tolerance mode?
Response : TOL1/TOL0
REF1 / REF2
Change active reference
Two tolerance values are REF1 or REF2
REF?
Active Reference ?
Response : REF1/REF2
ECO1 / ECO 0
Assign Economic mode
ECO1:ON / ECO0:OFF ECO?
Current economic mode?
Response : ECO1/ECO0
INTE1 / INTE0
Assign 2 points measurement mode
INTE1:ON / INTE0:OFF
INTE ?
2 points mode ?
Response : INTE1/INTE0
LCAL dd.mm.yy Modify last calibration date LCAL?
Date of last calibration?
Response : dd.mm.yyyy
NCAL dd.mm.yy Modify next calibration date NCAL?
Date of next calibration?
Response : dd.mm.yyyy
NUM x...x (up to 20 chars) Modify the instrument number NUM?
Instrument number?
Response : NUM x...x
MIN /MAX /DEL /NOR
Assign MIN, MAX, Delta, Normal mode
MIN:Minimum/MAX:Maximum/DEL:Delta=MAX-MIN/
NOR:Normal=Current value
MOD?
Active mode (MIN, MAX, Delta or Normal)?
Response : MIN/MAX/DEL/NOR
AOFF1 /AOFF0
Activates/deactivates the automatic switch-off
AOFF1:Activate/AOFF0:De-activate
AOFF?
Status of the automatic switch-off
Response:AOFF1/AOFF0
CFGBAR NOR / CFGBAR MAX
Assign Bargraph display
CFGBAR NOR:Normal bargraph/
CFGBAR MAX:Keep Bargraph on Max value
CFGBAR?
Bargraph configuration?
CFGBAR NOR/CFGBAR MAX
FACT1 / FACT2 / FACT5 / FACT10
Assingn analogue scale factor
FACT1:1scale=1digit/FACT2:1scale=2digits/
FACT5:1scale=5digits/FACT10:1scale=10digits
FACT?
Status of the analogue scale factor?
Response : FACT1/FACT2/FACT5/FACT10
RES1 / RES2 / RES3
Change of resolution
RES1:0.0001mm/RES2:0.001mm/RES3:0.01mm
RES?
Status of the current resolution?
Response : RES1/RES2/RES3
TOL +/-xxx.xxx +/-yyy.yyy
Inputting current tolerance limits
x:lower tolerance limit/y:upper tolerance limit
?
Current value (the displayed value)?
Response : +/-zzz.zzz ⇒current value
in the case of Tol mode
=+/-zzz.zzz ⇒current value
<+/-xxx.xxx ⇒lower tolerance limit
>+/-yyy.yyy ⇒upper tolerance limit
CLE Reset(Clear) of MIN, MAX or Delta SET?
Main instrument parameters?
Response : CHA+/CHA-,MM/IN,X1/X2/X5,
RES1/RES2/RES3,MIN/MAX/DEL/NOR,
STO0/STO1,KEY0/KEY1,BAT1/BAT0
UNI1 / UNI0
Activate / de-activate UNIT command(MM/IN)
UNI1:ON/UNI0:OFF
ID?
Instrument identification code?
Response : SYxxx
OUT1 /OUT0
Activate / de-activate continued data transmission
OUT1:ON/OUT0:OFF
BAT?
Status of Battery?
Response : BAT1: OK/ BAT0: low battery
PRE ON / PRE OFF Activate / de-activate Preset function(PRE command) VER?
Version No. and date of firmware
Response : Vx.x DD.MM.YYYY
ANA ON / ANA OFF Activate / de-activate the analogue scale MAC?
Bluetooth® MAC address?
Response :XXX…XXX(up to 12 chars)
PRE Recall Preset value
SET Zero reset
SBY xx xx number of minutes before stand-by
BT1 / BT0
Activate/de-activate Bluetooth® module
BT1:ON/BT0:OFF
BTRST Reset Bluetooth pairing information
OFF Switch-off (wake up using a button or RS)
RST Reset the instrument
SBY Put instrument in stand-by mode(SIS)
FAC RST Reset (Restores the factory parameters)
TOL +/-nnn.nnn +/-xxx.xxx +/-yyy.yyy
(In the case of SSI-650）
Inputting current tolerance limits
n :nominal value /
x :lower tolerance limit/y :upper tolerance limit

13.Maintenance
Carefully dry all mechanical parts of the instrument after contact with liquids to ensure proper
operation and avoid corrosion.
Don’t use aggressive products (alcohol, trichloroethylene or others) to clean plastic parts.
Don’t expose the instrument to direct sunlight, heat or humidity.
14. Specifications
15.Description of Bluetooth module:
This module is based on Nordic Semiconductor nRF8001 μBlue Bluetooth Low Energy Platform. The
nRF8001 is a single chip transceiver with an embedded baseband protocol engine, suitable for ultra-low
power wireless applications conforming to the Bluetooth Low Energy Specification contained within v4.0
of the overall Bluetooth specification. The nRF8001, used in the current revision of ISP091201, is a
product using a ROM for the baseband protocol engine.
16.Certification
10
contains bluetooth module ISP091201D
Region Certification
USA FCC ID : 2AAQS-ISP091201
Canada IC : 11306A-ISP091201
Brazil Anatel : 0516-14-4534
Korea South MSIP-CRM-iNs-ISP091201
Mexico IFT : RCPSYIS14-0655
Japan 001-A06167
Taiwan CCAH18LP2040T6
EU
India WPC : ETA-1003/2-17-/RLO(WR)
Type SSH-R1400 SSH-R1600
Resolution(mm)
Measuring range(mm) 0-400 0-600
Indication error(mm) ±40 ±50
Repeatability(μm)
Weight(g) 4970 5230
Working temperature(℃)
Strage temperature(℃)
IP protection
Battery life
Battery
0.01
10
CR2032
5～40
-10～60
IP51
About 6 months（under general using）

CERTIFICATE OF CALIBRATION
We hereby certify that this product has been calibrated and found to be in accordance with the
applicable NATIONAL STANDARDS and TECLOCK STANDARDS, Equipment used in this calibration has
traceable accuracy to the NATIONAL LENGTH and FORCE STANDARD.
Notice for use
Be sure to conduct a routine check for this product according to the purpose of use before use. This
product is precision instrument, periodically considering frequency of use, environmental conditions and
method of use.
It is not guaranteed for the performance of this product, which has been repaired or disassembled by
other than TECLOCK.
For appearance and other design improvement, this products
subject to change without advance notice.
TECLOCK Corporation
TECLOCK SmartSolutions Corporation
http://www.teclock.co.jp
HEAD OFFICE
2-10-3 MARUTA-CHO, OKAYA-SHI, NAGANO-KEN 394-0042
PHONE:[phone], FACSIMILE:81-266-22-4914
E-mail:[email protected]
