TECO TK3000 Use and care manual

TK GUIDES
FAN BLADE
REPLACEMENT
MODELS :
TK3000 – TK3000H
TK6000 – TK6000H
TK9000 – TK9000H
www.tecoonline.com | www.tecous.com

EQUIPMENT
www.tecoonline.com | www.tecous.com
Screw-drivers
Key for nut (10)Key for nut (10)
Fan Blade
(spare part)

WARNING
www.tecoonline.com | www.tecous.com
WARNING! Parts replacement and reparation may be carried out only by
qualified persons. If this are not performed properly, they can cause electric
shock, burns and fires
WARNING! TECO S.r.l. decline any responsibility in case of damages
caused by a wrong installation
Disconnect the chiller from power supply. Never touch internal part or
dismount chiller when it is connected to power supply to avoid potential
electric shock.

STEP n.
1
-Using the screw-driver, remove the screws indicated in the
picture here below (n°16 screws)
www.tecoonline.com | www.tecous.com

STEP n.
2
www.tecoonline.com | www.tecous.com
Disconnect ground
wire from the cover
Remove the cover

STEP n.
3
www.tecoonline.com | www.tecous.com
Remove the conveyor top
cover: take out the 6 screws
(shown in the picture) using
the small screw-driver

STEP n.
4
www.tecoonline.com | www.tecous.com
Remove the 2
screws mounted
alongside the
condenser, using
the screw-driver (as
shown in the
picture).

STEP n.
5
www.tecoonline.com | www.tecous.com
Move the condenser by
pulling on the free side.
Stop when you are sure
you can turn the nut of
the fan.

STEP n.
6
Replace the broken fan blade with a new
one: take out the nut using the key.
Please be careful when doing this
operation: the fan blade material is not too
strong and the new component can break.
Re-assemble the condenser (2 screws on
one side) and the conveyor (6 screws on
the top part) as before.
Then, put the cover on the chiller and
assemble each screw.
