SRE 803 injection

Dear Sir, Madam,
Congratulations with your purchase of a portable domestic heater. You have
purchased a quality product, which will serve you for many years to come. This,
of course, provided you use the heater correctly. Please read these Directions
for Use first, to ensure maximum lifetime for your heater.
Your heater comes with a 24-month manufacturer’s warranty on all defects in
materials or workmanship.
We wish you a warm and comfortable time with your heater.
Yours sincerely,
PVG International b.v.
Customer Service Department
1READ THE DIRECTIONS FOR USE FIRST.
2IN CASE OF ANY DOUBT,CONTACT YOUR DEALER.
3BEFORE YOU START READING, FOLD OUT THE LAST PAGE. EEEEEEEEEE
4
32

GENERAL DIRECTIONS FOR USE
Below you will find the main steps to be taken for
using your heater. For more details, please refer to
the MANUAL (pages 35 ff.).
•The first time you ignite your heater it will smell
like ’new’ for a short time.
•Store your fuel in a cool and dark place.
•Fuel has a limited shelf life. Start every heating
season with renewed fuel.
•The right quality of fuel will be assured, when
you use Zibro Plus for your heater.
•If you change to another brand and/or type of
parrafin oil, you must first finish up all the
remaining fuel in the heater.
MAIN COMPONENTS
Front plate
Grid
Base plate
Lid for removable
tank
Operation panel
Handle
Removable tank
Fuel gauge
removable tank
Air filter
Vent filter
Thermostat
Plug + cord
Information display
ON/OFF key
Childproof lock
Adjustment keys
(time and
temperature)
Timer
Indicator lights
A
B
C
4
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
EEEEEEEEEEEEEEEEEEEEEEE
Remove all packaging materials (refer to Section A, Fig. A).
Fill the removable tank 7(refer to Section B, Fig. D).
Insert the plug into the wall-socket.
Ignite the heater using the ON/OFF key N(refer to Section D).
If required, change the temperature using the adjustment keys
(refer to Section E).
Switch off the heater by pressing the ON/OFF key N.
1
2
3
4
5
6
4
33

This transportation cap
is packed separately in
the box. Only this cap
ensures trouble-free
transportation of the
heater after use.
Store it well!
WHAT YOU NEED TO KNOW IN ADVANCE
ALWAYS MAKE SURE THAT THERE IS SUFFICIENT VENTILATION
For each model the minimum size of space is specified in which you can use the
heater safely, without additional ventilation (refer to Section O).If a particular
room is smaller than the specified space, always put a window or door slightly ajar
(± 2.5 cm). We also recommend doing this in highly insulated or draught-free
rooms and/or at altitudes obove 1,500 metres. However, if there is insufficient
ventilation (i.e. oxygen), the heater will automatically switch off. Do not use your
heater in cellars or other underground areas.
THE RIGHT FUEL
Only use Class C1 paraffin fuel in accordance with BS2869; Part 2, or equivalent.
Your heater has been designed for use with high-quality water-free pure paraffin
oil, such as Zibro Plus. Only fuels of this kind will ensure clean and proper burning.
Lower quality fuel may result in:
Eincreased possibility of malfunctioning
Eincomplete burning
Ereduced heater lifetime
Esmoke and/or smells
Edeposits on the grid or mantle
Using the right fuel is therefore essential for safe, efficient, and comfortable use
of your heater.
Always refer to your local dealer for the right fuel for your heater.
Only the use of the
correct fuel will ensure
safe, efficient, and
comfortable use of your
heater.
4
34
A

MANUAL
AINSTALLING THE HEATER
Carefully remove your heater from the box and check the contents.
In addition to the heater you also need to have:
Eamanual fuel pump
Eatransportation cap
Ethese directions for use
Keep the box and the packaging materials (Fig. A) for storage and/or
transportation.
Open the lid of the removable tank Dand remove the piece of cardboard.
Attach the sticker to the inside of the lid.
Fill the removable tank as indicated in Section B.
The floor should be firm and completely level. Reposition the heater, when it
is not level. Do not try to correct the situation by placing books or other
goods under the heater.
Please refer to the separate instructions in the carton
box for fixing of the heater.
Insert the plug Linto the wall-socket (220/230 Volts - AC / 50 Hz) and set the
correct time using the adjustment keys P(refer to Section C).
Your heater is now ready for use.
BFILLING FUEL
Do not fill the removable tank in the living room, but in a more suitable place
(there can always be some spillage). Follow the procedure below:
Make sure that the heater is switched off.
Open the lid 4and lift the removable tank 7out of the heater (Fig. C).
Note: Some drops may leak from the tank. Put down the removable tank
(cap pointing upwards) and screw off the fuel cap.
Take the manual fuel pump and insert the smooth, most rigid tube into the
jerrycan. Make sure that it is in a higher position than the removable tank
(Fig. D). Insert the ribbed hose into the opening of the removable tank.
Lock the switch button on top of the pump (turn clockwise).
Squeeze the pump a few times, until fuel starts flowing into the removable
tank. As soon as this happens, there is no need to press any longer.
5
4
3
2
1
6
5
4
3
2
1
4
35
C
EEEEEE
D

☞
Check the removable tank fuel gauge Hwhile filling the tank (Fig. E). Stop
filling by loosening the switch button on top of the pump (turn anti-clock-
wise), once the gauge indicates that the tank is full. Never overfill the tank,
especially not when the fuel is very cold (fuel expands when it heats up).
Let the remaining fuel in the pump flow back into the jerrycan and carefully
remove the pump. Carefully screw the fuel cap back on the tank. Clean off
any spilled fuel.
Check whether the fuel cap is straight and tightened properly. Reinstall the
removable tank in the heater (cap down). Close the lid.
CSETTING THE CLOCK
It is only possible to set the correct time, when the heater is connected to the
mains and not burning. Use the adjustment keys Pto set the time. First press
either of the two keys to switch on the function (the CLOCK light and the
information display Mwill start blinking). Next, set the hours using the key on the
left (NHOUR) and the minutes using the key on the right (MMIN). Press once to
increase the value by one step. When you hold down the key, the value will
continue going up, until you release the key again. After approximately 10
seconds the light will stop blinking and the setting will be locked. 5 Minutes after
switching off the heater, the information on the display will disappear and the
heater will automatically switch into the stand-by position.
When the heater has been unplugged (or after a power failure), the time needs
to be set again.
DIGNITING THE HEATER
When used for the first time, a new heater may give out a smell for a short while.
You should therefore provide extra ventilation.
Just press the ON/OFF button Nto ignite the heater. The button will start blinking,
indicating that the ignition procedure has started. This will take a short while. Once
the heater is burning, the ON/OFF button will remain lit (red). The information
display Mwill show two numbers. The light next to them indicates that these
numbers refer to the temperatures (Fig. G). The actual room temperature is
indicated below ROOM, while the temperature setting is indicated below SET. The
latter can be changed with the adjustment keys (refer to Section E).
Prior to igniting the heater, always check for sufficient fuel in the removable tank.
ESETTING THE REQUIRED TEMPERATURE
The temperature setting can only be adjusted, when the heater is burning. Use the
adjustment keys Pto adjust the temperature. First press either of the two keys to
switch on the function (the TEMP light next to the information display Mwill start
blinking). Next, adjust the temperature using the key on the right (MMIN) to set
the temperature to a higher setting and the key on the left (NHOUR) to lower the
temperature. Press once to increase the value one step. After approximately 10
seconds the light will stop blinking and the setting will be locked (Fig. G).
8
7
6
4
36
E
empty full
K
T
I
M
E
R
H
O
U
R
M
I
N
19 1 4
SET ROOM
ON
OFF
POWER
FUEL
VENT
TEMP
CLOCK
G: The required
temperatureon the left,
the measured
temperature on the
right.
K
T
I
M
E
R
H
O
U
R
M
I
N
2 0 1 5
SET ROOM
ON
OFF
POWER
FUEL
VENT
TEMP
CLOCK
F: When the CLOCK
indicator light stops
blinking, the setting has
been locked to the
indicated value.

The available temperature settings range from 6°C minimum to 28°C maximum.
When the heater has been unplugged (or after a power failure), the temperature
will reset to the factory setting of 20°C.
FUSING THE TIMER
The timer allows you to switch on the heater automatically at a preset time.
Inorder to switch on the timer, the correct time must have been set (refer to
Section C) and the heater should be off.
Follow the procedure below:
Press the ON/OFF button Nand then the TIMER key Qimmediately after that.
The TIMER light and the information display Mwill start blinking.
Use the adjustment keys Pto set the time at which the heater must ignite.
Use the key on the left (NHOUR) to set the hours and the key on the right
(MMIN) to set the minutes (interval of 5 minutes).
After approximately 10 seconds the information display will show CLOCK
again and the TIMER indicator light will light up, indicating that the timer
function has been activated (Fig. H).
The timer will ensure that the room will have been heated to approximately
the required temperature at the set time.
When you want to switch off the heater and ignite it again with the timer, all
you have to do is press the TIMER key (refer to Section G).
Press the ON/OFF button Nonce to clear the timer setting.
GSWITCHING OFF THE HEATER
There are two ways to switch off the heater.
Press the ON/OFF button N.The information display will show the CLOCK
signal. Within approximately one minute the flame will have extinguished.
Press the TIMER key Q,when you want to switch off the heater and ignite it
again with the timer the next time. This not only switches off the heater, but
it also activates the timer function. You can change the required time with
the adjustment keys P(refer to Section F).
HTHE INFORMATION DISPLAY
The information display Mnot only serves as an indicator of the (set) time and
temperature (Sections C, E, and F), it also indicates any malfunctioning of the
heater. The code on the information display tells you what is the matter:
2
1
4
3
2
1
4
37
Y
-
L
O
C
K
T
I
M
E
R
H
O
U
R
M
I
N
2 0 1 5
SET ROOM
ON
OFF
POWER
FUEL
VENT
TEMP
CLOCK
H: The TIMER indicator
light indicates that the
timer function has been
switched on.
☞

CODE INFORMATION WHAT TO DO
e - 0 Temperature within the heater too high. Cool-down and re-ignite.
f - 0 Power interrupted. Re-ignite the heater.
e - 1 Faulty thermostat. Contact your dealer.
f - 1 Faulty burner thermistor. Contact your dealer.
e - 2 Starting problems. Contact your dealer.
e - 5 Tipping-over protection. Re-ignite the heater.
e - 6 Poor burning. Contact your dealer.
e - 7 Room temperature If necessary,
above 28°C. re-ignite the heater.
e - 8 Defective booster. Contact your dealer.
e - 9 Air filter dirty; or Clean filter
Fuel pump dirty. Contact your dealer.
-- : -- Out of fuel. Refill removable tank.
(&blinking
FUEL-light)
-- : -- Too little ventilation. Ventilate better.
(&blinking
VENT-light)
Always contact your dealer for any malfunctioning not listed above.
AUTOMATIC CLEANING MODE
When te heater has been burning continuously for two hours at its highest
setting, the burner will automatically start an autoclean procedure. The display
will show the autocleaningcode CL.05 running back to CL.00. The procedure takes
5minutes, during which the heater will burn at its lowest setting, while the burner
autocleans. When the burner is clean again, the heater will automatically switch
back to the highest setting again.
ICHILDPROOF LOCK
The childproof lock can be used to prevent children accidentally changing the
heater settings. When the heater is burning and the childproof lock is on, the
heater can only be switched off. Other functions are blocked then. If the heater
has already been switched off, the childproof lock also prevents accidental
ignition of the heater.
Activate the childproof lock by pressing the appropriate key Oand holding it down
for more than 3 seconds. The KEY-LOCK indicator light will light up (Fig. I),
indicating that the childproof lock has been activated. Switch off the childproof lock
by pressing the key Oand holding it down for more than 3 seconds once again.
JTHE 'FUEL' INDICATOR LIGHT
When the FUEL indicator light lights up, there is enough fuel left for another 10
minutes of heater use. The count-down of the remaining heating time can be seen
in the information display M(Fig. J). Every two minutes an alarm signal is
sounded, warning you to refill the removable tank. If you do not react, the heater
will extinguish by itself. The heater will also sound a warning signal, when it
switches off. The FUEL indicator light will blink, while four lines are blinking in the
information display. You can stop this by pressing the ON/OFF button Nonce.
4
38
E
R
H
O
U
R
M
I
N
e - o
SET ROOM
ON
OFF
POWER
FUEL
VENT
EMP
COCK
E
R
H
O
U
R
M
I
N
c l 0 5
SET ROOM
ON
OFF
POWER
FUEL
VENT
EMP
COCK
Incase of any
malfunctioning the
information display will
tell you what is the
matter.
K
E
Y
-
L
O
C
K
T
I
M
E
R
H
O
U
R
M
I
N
2 0 1 5
SET ROOM
ON
OFF
POWER
FUEL
VENT
TEMP
CLOCK
I: When the KEY-LOCK
light lights up, the
childproof lock has been
activated.
E
R
H
O
U
R
M
I
N
SET ROOM
ON
OFF
POWER
FUEL
VENT
1 0
EMP
CLOCK
J: When the FUEL
indicator light is lit, the
information display will
show the number of
minutes of fuel left in
the tank.

Once the heater has used up all its fuel and is extinguished it will take some time,
after the refill, before the heater is completely ready for use again.
KTHE 'VENT' INDICATOR LIGHT
When the VENT indicator light starts blinking, this is a sign that the room is not
vented sufficiently (Fig. K). If you do not provide additional ventilation, the heater
will switch off automatically after some time.
Ifthe indicator light continues blinking after extra ventilation, please contact your
dealer.
LMAINTENANCE
Switch off the heater and let it cool down, before you start any maintenance
work. Also disconnect the plug from the mains.
Your heater needs hardly any maintenance. It is, however, important that you
clean the air filter Iand the vent filter Jwith a vacuum cleaner and the grid 2
with a damp cloth, both on a weekly basis. Remove the air filter occasionally (Fig.
L) and clean it with soapy water. Prior to reinstallation, make sure that the air
filter cap has fully been dried.
Regularly inspect the fuel filter as well:
Remove the removable tank 7from the heater and remove the fuel filter
(Fig. M). Some drops may leak from the filter; keep a cloth at hand.
Remove the dirt by tapping the fuel filter upside-down against a hard surface.
(Never clean it with water!)
Reinstall the fuel filter into the heater.
We recommend that you remove dust and stains from time to time with a damp
cloth, because otherwise these may cause stains that are hard to remove.
Do not remove any heater components yourself. Always contact your dealer for
repairs. When the power cord is damaged, it may only be replaced by an
authorised fitter. Use a new cord of the type H05 VV-F.
MSTORAGE (END OF THE HEATING SEASON)
At the end of the heating season, you must store the heater in a dust-free place, if
possible in its original packaging.
Unused fuel cannot be used in the next heating season. We therefore recommend
that you burn up all fuel. If there is still some fuel left, do not throw it away, but
dispose of it in accordance with the local regulations for the disposal of domestic
chemical waste.
Always start the new heating season with fresh fuel. When you start re-using the
heater follow the instructions again (starting from section A and as specified).
3
2
1
4
39
M
L
Fuel filter
M
E
R
H
O
U
R
M
I
N
2 0 1 5
SET ROOM
ON
OFF
POWER
FUEL
VENT
TEMP
CLOCK
K:Ablinking VENT
indicator light is a sign
that you need extra
ventilation.
☞

NTRANSPORTATION
Take the following measures to avoid fuel leakage during the transportation of
the heater:
Let the heater cool down.
Remove the removable tank Gfrom the heater and remove the fuel filter
(refer to Section L, Fig. M). Some drops may leak from the filter; keep a cloth
athand. Store the fuel filter and the removable tank outside the heater.
Place the transportation cap into the position of the fuel filter (Fig. N).
Press it tight.
Always move the heater in an upright position.
OSPECIFICATIONS
Ignition electrical Dimensions (mm) width 516
Fuel paraffin (including base plate) depth 315
Capacity (kW) max. 3,6 height 450
Capacity (kW) min. 1,05 Accessories manual fuel pump
Suitable space (m3)**35-150 transportation cap
Fuel consumption (l/hr)*0,375 Mains 220V/230V
Fuel consumption (g/hr)*300 -- AC/50 Hz
Burning time per tank (hr)*14
Electrical consumption
igniter 368 W
Capacity removable tank (litres) 5,4 continuous 28 W
Weight (kg) 11 Fuse rating 250V, 5A
*At maximum setting
** Specified values are indicative
PWARRANTY PROVISIONS
Your heater comes with a 24-month warranty starting on the date of purchase.
Within this period all defects in material or workmanship will be repaired without
any charge. The following provisions shall apply regarding this warranty:
We expressly dismiss all other claims for damages, including consequential
damages.
Any repairs or replacements of components within the term of warranty will
not result in an extension of the term of warranty.
The warranty shall no longer apply, when the heater has been modified,
non-original parts have been used, or when it is repaired by third parties.
The warranty shall not apply to parts that are subject to normal wear, such as
the burner mat and the manual fuel pump.
4
3
2
1
4
3
2
1
4
40
O
transportation cap

The warranty shall only apply, when you present the original, dated proof of
purchase, provided no changes have been made to it.
The warranty shall not apply to damages caused by actions not in compliance
with the Directions for Use, neglect, and the use of an incorrect type of fuel,
or fuel past its use-by date. The use of incorrect fuel can even be dangerous*.
Transportation costs and the risks involved during the transportation of the
heater or heater components shall always be at the expense of the purchaser.
In order to avoid unnecessary costs, we recommend that you always read the
’Directions for Use’ carefully first. In case they offer no solution, please take the
heater to your dealer for repair.
*Highly inflammable substances may induce uncontrollable burning, causing flames to break out. Should this
happen, never try to move the heater, but always switch off the heater immediately. In case of emergency you
may use a fire extinguisher, but only a type B extinguisher: a carbon dioxide or powder extinguisher.
10 TIPS FOR SAFE USE
1Make surethat children are always aware of the presence of a burning
heater.
2Do not move the heater when it is burning or still hot. Do not refill nor
service the heater when it is burning or still hot.
3Position the front of the heater at a distance of minimum 1.5 metres
from walls, curtains, and furniture.
4Do not use the heater in dusty rooms or places with strong draughts. In
either situation you will not have optimum burning. Do not use the
heater in the immediate surrounding of a bath, a shower or a
swimmingpool.
5Switch offthe heater, before you leave or go to sleep. Unplug the
heater as well, when you go away for a longer period of time
(e.g. holidays).
6Store and move fuel only in suitable tanks and jerrycans.
7Make sure that the fuel is not exposed to heat or extreme temperature
changes. Always store the fuel in a cool, dry and dark place (sunlight
will affect the quality).
8Never use the heater in places where harmful gasses or fumes may be
present (e.g. exhaust gasses or paint fumes).
9Beware that the grid of the heater becomes hot. If the appliance is
covered there is a risk of fire.
10 Always make sure that there is sufficient ventilation.
7
6
5
4
41

EEEEEEEEE EEEEEEEEEEE EEE

EEEEEEE EEEEEEEEEEEEEEEEE
K
E
Y
-
L
O
C
K
T
I
M
E
R
H
O
U
R
M
I
N
2 0 1 5
SET ROOM
TEMP
CLOCK
POWER
FUEL
VENT
RM
QP N
E
O
I
J
F
D
K
L
H
G
A
E
B
C

3FRANCE
PVG France SARL
4, Rue Jean Sibélius
B.P. 185 - 76410
SOTTEVILLE SOUS LE VAL
tel: +33 2 32 96 07 47
fax: +33 2 32 96 07 77
email: [email protected]
iÖSTERREICH
PVG Austria VertriebsgmbH
Salaberg 49
3350 Haag
tel: +43 7434/44867
fax: +43 7434/44868
email: [email protected]
eBELGIË
PVG Belgium NV/SA
Industrielaan 55
2900 SCHOTEN
tel: +32 3 326 39 39
fax: +32 3 326 26 39
email: [email protected]
qSCHWEIZ
PVG Schweiz AG
Genuastrasse 15
4142 MÜNCHENSTEIN
tel: +41 61 337 26 51
fax: +41 61 337 26 78
email: [email protected]
2DEUTSCHLAND
PVG Deutschland GmbH
Beiersdorfstraße 4
46446 EMMERICH
tel: +49 2821 76713
fax: +31 412 648385
email: [email protected]
6DANMARK
PVG Scandinavia A/S
Niels Bohrsvej 10
6100 HADERSLEV
tel: +45 73 53 02 02
fax: +45 73 53 02 04
email: [email protected]
5ESPAÑA
PVG España S.A.
Pol. Ind. San José de Valderas II
Comunidad ”La Alameda”
C/Aurora Boreal, 19
28918 LEGANÉS (Madrid)
tel: +34 91 611 31 13
fax: +34 91 612 73 04
email: [email protected]
4UNITED KINGDOM
Lister Gases
Bridge Street
Holloway Bank, Wednesbury
West Midlands WS10 OAW
Tel.: +44 121 506 1818
Fax: +44 121 505 1744
email: gases@lister.co.uk
>ITALIA
PVG Italy SRL
Via Niccolò Copernico 5
50051 CASTELFIORENTINO (FI)
tel: +39 571 628500
fax: +39 571 628504
email: [email protected]
uNØRGE
Sunwind - Gylling A/S
Løxaveien 17 - P.O Box 64
1351 RUD
tel: +47 67 17 13 70
fax: +47 67 17 13 80
email: [email protected]
1NEDERLAND
PVG International b.v.
P.O.Box 96
5340 AB OSS
tel: +31 412 694694
fax: +31 412 622893
email: [email protected]
:POLSKA
PVG Polska Sp. z. o. o.
Kolonia Promna 58
26-803 PROMNA
tel: +48 48 613 22 33
fax: +48 48 613 22 33
email: [email protected]
9PORTUGAL
Markt (Portugal), Lda
Recta da Granja do Marquês
ALGUEIRÃO
2725 MEM MARTINS
tel: + 351 21 922 8530
fax: + 351 21 922 8536
email: [email protected]
REV 06/2001
DISTRIBUTED IN EUROPE BY PVG INTERNATIONAL BV
Table of contents
Other Tectro Heater manuals
Popular Heater manuals by other brands

L.B. White
L.B. White Tradesman K70 owner's manual

Mondial Designs Limited
Mondial Designs Limited MICA A-10 Instruction Manual and Technical Service

EOS
EOS IRS 35 Assembly and operating instruction

Calienta
Calienta 10622258 operating instructions

EWT
EWT EVORAD manual

Dimplex
Dimplex CAB10A Installation and operating instructions

Frico
Frico Infrapalm IHPA Assembly and operating instructions

Purmo
Purmo YALI DIGITAL PLUS Installation and operating manual

U-Line
U-Line H-6511 manual

Henny Penny
Henny Penny HC 900 Service manual

UNIPRODO
UNIPRODO UNI SAUNA V6.0KW user manual

Master
Master MH-80TBOA-OFR User's manual & operating instructions
