TEKA ILLUMINATION PINNACLE FLOODLIGHT User manual

THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF TEKA ILLUMINATION AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF TEKA ILLUMINATION IS STRICTLY FORBIDDEN.
Warning Hot Surface
NEEDED
FOR
INSTALLATION:
By Others
Wear Gloves
RELEASE DATE
8-14-17
REFERENCE NUMBER
INS-2621-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
Low Voltage
5/32” Allen Wrench
Waterproof Wire Connectors
Gloves
Lens
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
Aiming
Adjustment
Screw
Heavy Wall
Stem
Housing
Swivel Lock
Hinged
Clamp Rings
Locknut
PINNACLE FLOODLIGHT™ (PNF)
IMPORTANT - WEAR GLOVES TO AVOID GETTING FINGERPRINTS ON THIS PRODUCT. MANY TEKA ILLUMINATION PRODUCTS ARE DESIGNED TO NATURALLY PATINA.
OILS FROM YOUR SKIN WILL ACCELERATE THIS PROCESS WHERE TOUCHED AND ARE NEARLY IMPOSSIBLE TO REMOVE. THIS PROCESS OCCURS OVER TIME AND IS
DETERMINED BY THE INSTALLATION ENVIRONMENT.
· Suitable for wet locations
IMPORTANT LISTINGS AND CERTIFICATIONS
Please refer to the low voltage design guide at www.tekaillumination.com/lvguide before installation for proper wire selection.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local and
Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel with appropriate personal protective
equipment must perform all servicing of this product.
• Before wiring to power supply and during servicing, turn off and
lock out power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause an
unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part, as
this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body.
• Replace LED assembly only with correct wattage and type of
power supply appropriate for LED assembly.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted fixture is HOT!
WARNING - To reduce the risk of
FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing LED.
Fixture gets HOT quickly! Contact only switch/plug when
turning on. Do not touch hot lens, guard, or enclosure.
Keep fixture away from materials that may burn.
Do not operate the luminaire fitting with a missing or
damaged shield. Do not touch the source at any time. Use
a soft cloth or gloves. Oil from skin may cause damage.
SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
RELEASE DATE
8-14-17
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
REFERENCE NUMBER
INS-2621-00
1. Mount fixture onto suitable enclosure according
to designed lighting plan. Use locknut to secure. 2. Make watertight connections from remote
transformer to fixture leads using waterproof
wire connectors (By Others). See wiring
diagram.
Standard Fixture Installation
Aiming
1. To aim vertically, loosen the lamp head adjustment
screw using a 5/32” Allen wrench, adjust as needed,
then secure aiming position by tightening lamp
head adjustment screw.
Do not rotate more than 360 degrees to avoid
wire damage.
120V 12V
Fixture
COM
Remote
Transformer
COM
120V 12V
Fixture
COM
GROUND
WIRING DIAGRAM
Transformer
COM
GROUND
WIRING DIAGRAM
PINNACLE FLOODLIGHT™ (PNF)
Must install to a suitable enclosure. Recommended for use with Power Pipe™ or
Pillar Mount Canopy (PMC).
LED - For use with 12VAC
remote transformer or magnetic
transformers only. Teka Illumination
cannot guarantee performance with third
party manufacturers’ transformers.

IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
RELEASE DATE
8-14-17
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
REFERENCE NUMBER
INS-2621-00
PINNACLE FLOODLIGHT™ (PNF)
Aiming
5. Lift out driver, then disconnect from fixture.
Hold onto lead from fixture, then install new
driver via quick disconnect.
Do not pull on connector or wiring. Handle
with care.
3. Remove optic by pulling gently and lift up.
4. Use .050” Allen wrench to loosen two (2) set
screws holding LED module. Gently lift LED
module and disconnect from fixture.
6. Install new LED module. Replace optic by lining
tabs with optic holder, then pressing down gently
until secured into place.
1. Loosen two (2) captive screws on stainless steel
clamp rings using 5/32” Allen wrench until the
screws disengage from back plate.
2. Swing lens assembly open.
7. Replace optic by lining tabs with optic holder,
then pressing down gently until secured into
place.
8. Close swing assembly. Tighten two (2)
captive screws on stainless steel clamp rings
using 5/32” Allen wrench. Do not overtighten.
