Teknatool NOVA G3 User manual

FOR YOUR SAFETY
PLEASEREAD&UNDERSTANDTHISINFORMATIONBEFOREUSINGYOURNOVAG3CHUCK
DANGER: THIS CHUCK IS CAPABLE OF CONTRIBUTING TO SERIOUS INJURY,AS WITH
ANY OTHER POWERTOOL ACCESSORY, IF USED IMPROPERLY ON THE LATHE.
Before using the Nova G3, read and understand this instruction manual and the lathe
owner’s manual. If you do not have a manual, contact the supplier of your lathe to obtain
one before using the lathe and Chuck.
User must be professionally trained to use this chuck. Vocational school courses
recommended. As with other chucking methods, an extremely cautious and sensible
approach is necessary. With the Nova G3 Chuck it is not possible to give exact directions as
to the amount of tightening pressure required for workholding. Follow closely strict
guidelines in this manual for different jaw types on wood blank diameters and length, plus
turning speed.
BEFOREUSINGTHENOVAG3CHUCKMAKESURETHAT -
• EYE PROTECTION WHICH COMPLIES WITH CURRENTANSI STANDARD Z87.1 (USA) IS
WORN. WE RECOMMEND THATAFULLFACE SHIELD BE USEDATALLTIMES.
• Chuck is properly secured on lathe spindle. Follow mounting instructions for your lathe for
faceplates and other spindle fixtures.
• For safety, DO NOT ROTATE CHUCK UNDER POWER WITHOUT WOOD BEING GRIPPED.
•WARNING: EXCESSIVESPEED ISASERIOUSLATHEHAZARD.ALWAYSTURNATTHE
SLOWEST SPEED POSSIBLE.
• Speed will vary with wood blank size. The larger the blank the slower the speed. Consult
your lathe manual or lathe information plate for speed guidelines.
• DO NOTATTEMPT TO USE THE CHUCK UNLESSTHE LATHE SPEEDSARE KNOWN,
YOUMUST STRICTLYFOLLOW THE MAXIMUM SPEED LIMITS SETOUT IN THE
OPERATING SECTION OF THIS MANUAL.
DONOTEXCEEDTHEMUNDERANYCIRCUMSTANCES.
• EXAMINE WOOD CAREFULLY. ONLY MOUNT WOOD THATIS SOUND, If any cracks, splits,
or weakness is found in wood - DO NOT MOUNT ON CHUCK. DO NOT MOUNT ANY
WOODTHAT IS LIKELYTO BREAK UP DURINGTURNING (E.G. ROTTEN OR SPONGY
WOOD). DO NOT USE POORLYJOINTED or LAMINATED WOOD.
• Make sure wood is clamped firmly. Follow mounting instructions for different gripping
modes and jaw types. In the expansion mode do not use undue force or jaws may split
the wood.
• Do not exceed maximum guidelines in this manual for wood blank diameters or lengths
set out in this manual for different modes and jaw types.
DO NOTUSE WITHANYCOPYTURNEROPERATIONS.
• Check wood is securely held in chuck, before operation. Check grip by vigorously
wrenching wood blank back and forth. If any loosening occurs, re-examine holding area
for adequate grip (Following mounting guidelines) and any damage to holding area.
Rotate manually to make sure of clearance before switching power on.
•WARNING:FOR SAFEOPERATION
ITIS RECOMMENDEDTHAT TURNING BECARRIED OUTWITH JAW SLIDES
NOTEXTENDING BEYONG THE CHUCK BODY.HOWEVERTHEJAWSLIDES
CAN EXTENDABOUT 6.35MM (1/4”) BEYOND THE BODY OFTHE CHUCK TO
GIVEAWIDER RANGE OF EXPANSION, IF REQUIRED. EXTRACAUTION MUST
BE EXERCISED WHEN TURNING WITH JAW SLIDES EXTENDING BEYOND
THE BODY OF THE CHUCK.
• Irregular or out of balance stock needs to be turned at the slowest possible speed until it
is in balance. For use on outboard/left-hand rotation - MAKE SURE INSERT IS SECURELY
LOCKED WITH GRUBSCREW BEFORE USE. Use only hand held woodturning chisels to
shape wood being held in chuck.
• USE THE RIGHT CHISEL FOR THE JOBAND DO NOT FORCE TOOLS. Use safe and
commonly approved chisel techniques. Wherever possible stand to one side of the
revolving wood.
• WEAR PROPER CLOTHING. Do not wear any loose clothing, neck ties, gloves, bracelets,
rings or other jewellery that could get caught in moving parts. Wear protective hair covering
to contain long hair.
• Do NOT operate chuck or lathe while under the influence of DRUGS, ALCOHOL or any
MEDICATION.
•KEEP CHILDRENAND VISITORS AWAY.All children and visitors should be kept safe
distance from the work area.
Make workshop childproof with padlocks, master switches, or by removing starter keys.
Thankyou for purchasing your NovaG3 Chuck- the latest addition toour Woodturning Chuck
range. We are confident that it will be a great aid towards fast workholding and enhance your
woodturningcapablity.TheNova G3is designed fora rangeof woodholdingmodeswhile being
quick and easy to use.
NOVAG3 CHUCK
INSTRUCTIONMANUAL FITTING CHUCK TO LATHE
Check that the chuck thread specification matches the lathe spindle thread you
have. This is important for accuracy. The chuck body must contact an accurate
register on lathe, either a shoulder on spindle or bearing face etc to ensure chuck
willrun true.If further modifications are needed (e.g. spacer)these arethe
responsibility of the user.Agood check is to see whether it screws home the same
as a faceplate or similar spindle fitting.
DONOTUSE UNLESSCHUCK ISPROPERLYFITTEDTOSPINDLE.
NB: SOME FORM OF LOCKING MUST BE USED IFTHE LATHE IS
CAPABLE OF REVERSE MODE.
CHUCK OPERATION
Adjustment: The Nova G3 chuck features a chuck key, which locates easily and quickly
intothe gearing mechanism.The high poweredgearing delivers outstandinggrip at little
effort.Moving in a clockwise direction will expand
thejaws outwards (expansion),and moving the key
in an anti-clockwise direction will contract the jaws
inwards(contraction). Forexample, move thehandle
in an anti-clockwise direction to move the jaws to
clamp a work piece inside the jaws, and then move
the handle in a clockwise direction to release the
work.
MOUNTING & DISMOUNTING OF JAWS
The Nova G3 chuck comes with no jaws attached. With the many jaws available it is
very easy to use your single chuck for a very wide range of applications.All jaws in
theTeknatool range for the Nova G3 are secured and attached the same way.
Attaching Jaws - To mount the jaws to the Nova G3 chuck is another easy
process. Firstly wipe clean all jaw slides, especially the contact surfaces. Repeat
this with all four jaws you wish to attach. Jaw slides are numbered one to four and
have a corresponding jaw - of the same number. This may be represented by dots if
numbers are not present, i.e. 3 dots = #3. Place a jaw on its correct jaw slide and
positioninto the groove (locationring out from thejaw into the groove of the jaw
slide). The first few times, you may need to GENTLY tap the jaws into the locater
slot with a block of wood or plastic mallet. Place M6X10 counter sunk screws in
jaws and screw them to finger tightness. When both screws are in nip them up and
back off half a turn. Repeat this to the remaining three jaws. Now using the Chuck
key, scroll all jaws towards middle until they all come together. Now with all jaws
touching and equal pressure on each, tighten all screws up. This will eliminate any
run out. Ensure that there are no gaps between the jaws. If a gap does appear, it will
probably be due to a jaw being placed on its wrong number (e.g. a #2 jaw on a
#3 jaw slide).
To Remove Jaws - Simply using the 4mmAllen key supplied, unscrew all M6
counter sunk screws (there are eight of them). The jaws will come away once their
screws are released. Sometimes due to dust particle build up (after heavy turning)
the jaws may need a very light tap with a plastic hammer to dislodge them. It is
important to keep them in their set so not to mix them up with other jaws of the
same type.
IMPORTANT NOTE:
Accessory Jaws: Although the Nova G3 is compatible with all the Teknatool Accessory Jaws, it is not
recommended that the larger accessory jaws be used, as they will hold work to larger capacities than is
recommended with the Nova G3. For instance, we do not recommend that the following accessory jaws
are used with the Nova G3: 130mm Jaw (JS130N),PowerGrips (PJSN), Titan PowerGrips (13029)
Moreover, it is not recommended that work exceed a diameter of 14” and a depth of 5” with this chuck.
DOVETAIL OPERATION
Expansion of the jaws into a recess - This function is for bowl and platter turning where
the projection (depth) of the wood blank is not too great i.e. up to 100mm (4 inches).
Characteristicallythese itemshave aparallel wood grain. IT MUST NOT BEUSED FOR
ANYLONG WORK(OVER 100mmor 4inches)ASTHERE WOULDBE GREATDANGER
OFWOODTEARINGOUTANDDISLODGING FROM CHUCK.
Instructionsbelow applyto thestandard 50mm(2 inches)jaws butthe generaltechnique is
the same with other accessory jaws. However, the maximum size of wood blank that can
bemounted, the maximum turning speedand recess size varies withthe different
accessory jaws. Consult specific instructions included for each jaw set.
This strong holding method, using the standard 50mm (2 inches) jaws, you can turn bowls
upto350mm(14inches)indiameter.DONOTEXCEED600RPMWITHTHISOPERATION.
OUTOF BALANCE STOCKMUSTBETURNEDATTHE SLOWESTSPEED POSSIBLE.
50mm jaws - Any recess can be turned between 50mm (2 inches) and 70mm (2 3/4” inches)
diameter.For smallerlidsandthin platters(notexceeding 150mm or6inches diameter)only
a shallow recess of around 3mm (1/8 inch) is necessary. It will be matter of gaining
experience as to what combinations and sizes will best suit.
Copyright 2007
PublicationNumber:110-0706-001
AUTOSTOPFEATURE
TheNova G3has anin built safety feature which
preventsthe jawsslides frombecoming disloged
from the chuck. The auto stop feature is first in the
industrydoing away with shearing screws.
PARTS LIST & EXPLODED DRAWING
USING THE WOODWORM SCREW
Thewoodworm screwsupplied with the Nova G3chuck ispurpose designed for screw
chucking. It is a cylindrical screw which maintains its full holding power along the
wholelength, unlikenormal taperedscrews. Thethin threadform isspecially designed
tocause minimumdamage towood fibers.They gripbetter thanscrews becausethere
isa larger volumeof undamagedwood retainedwithin the screw.
The woodworm screw is made complete with the boss section in one piece. The
woodworm screw is to be used with the jaws remaining on the chuck. This facility is
very convinent for remounting work directly onto the jaws after the screw is removed.
(seemore, pageover)
NB: Direct threaded chucks #9 & #10 not used
(with the exception of the 4-threaded direct chuck)
CM5010181
10006
10029 Jawset50mm

TEKNATOOL
INTERNATIONALLtd.
www.teknatool.com
NOVA G3 CHUCK
You can register your warranty online by visiting www.teknatool.com
This Teknatool warranty is backed by a period of twenty-four months from the date of purchase. Teknatool International Ltd hereby agrees to make repairs or replace components without
charge for any defects due to faulty material or workmanship, provided that - a) The warranty period has not elapsed. Proof of purchase date (sales slip, registration of warranty etc) would
need to be forwarded to Teknatool International. b) If, in our opinion, the unit has not already been altered, repaired or modified in any way that would affect it’s operation; has not been
subjected to misuse, negligence, accident or not used strictly in accordance with instructions. c) Where necessary, transportation is prepaid by the customer to the Factory Service Centre
(or other uthorised Teknatool Service Centre)
Warranty does not cover costs or damages arising directly or indirectly from the operation of this Teknatool product. No other guarantee, written or verbal is authorised by Teknatool
International Ltd. Our Teknatool Distributors can issue their own warranty to cover this product. Their terms may vary from what is stated above - please check with your dealer if you have any
questions. Email our service contact: [email protected]. Our policy is one of continuous improvement. We therefore reserve the right to change specifications/designs without notice.
WARRANTY Serial Number:
Learn More
Visit our website
Free Project Ideas
Videos
Manuals
Frequently Asked
Questions
Register Warranty
www.teknatool.com
SPECIFICATIONS Thread Sizes: 1”8 tpi, 3/4”16 tpi and insert version. Warranty: 2 Year Comprehensive - see details Weight: 1.53kgs/ 3.373lbs on spindle. Body Diameter: 88,mm/3.48” Standard Equip- ment: Chuck body, 50mm jaws, chuck key, fastenings, instruction manual. See back of this sheet for the instruction manual.
Teknatool International Ltd, PO Box 305378 Triton Plaza, North Shore 0757, Auckland, New Zealand PH: [phone] FAX: [phone] Email: [email protected] Website: www.teknatool.com
Ideal for your Woodturning
Fits Nova & SuperNova Accessories
Fully compatible with allNova,SuperNova andSuperNova2 accessories. Widest accessoryrange of any chucking system on the market means
you can tackle a widerange of projects.
It’s not recommended to use the larger Teknatool Accessory Jaws with this chuck. See manual for more.
VERSATILE
Idealfor mini,midi and all lathes up to 7”centre height(14” diameteroverbed) Canalso beused for smallwork onlarger lathes.SuperNova andTitan chucks are recommendedfor largerwork. See websiteor reseller for moreinformation.
IDEALLATHESIZE
Screwchucking function,using the NovaWoodworm Screw(included with chuck) For the first stagemounting of woodenbowlblanks.
WOODWORM SCREW
Screws directly
into your lathe
spindle (same as
afaceplate)
Availablein
popular1”8TPI
RH and
3/4”16TPIthreads
as well as insert
versions.
USING THE WOODWORM SCREW (contd.)
To convert to this operation , place the boss section into the centre of the chuck and close
jaws into the slots. BEFORE FINALTIGHTENING MAKE SURE THATTHE FRONT OF THE
BOSS SECTION OF THE SCREW IS SEATED BEHIND AND AGAINST THE 50mm (2
INCHES) JAWS. This will prevent any tendency for the boss section to creep forward when
the screw is being used. NB: Recommended pre-drill size is 9/32” (7mm) for soft woods
and 5/16” (8mm) for hard woods.
The front face of the jaws have been machined to provide an accurate backing surface.
This is quite an advantage, providing a much tighter fit and wider tolerance for irregularly
faced stock. This feature is also quite an advantage when using the screw to mount a bowl
for first stage bowl turning - forming the outside of the bowl to be put straight onto the jaws
(the screw is first removed) after the recess has been formed.
The woodworm screws provides 15mm -1/2mm OR 39/64” (0.609”) of thread beyond the
jaws. Irregular, rough tree blanks (e.g. small sections of tree limbs) not exceeding the
above sizes can be held quite firmly BUT caution must be exercised. Check for adequate
contact. DO NOT USE THE SCREW FOR VERY LARGE WOOD BLANKS. Its intended for
small bowl and screw chucking work. The maximum capacity which should be mounted
on the screw is 250mm (10 inches) diamter X100mm (4 inches). DO NOT EXCEED 600
RPM FOR THIS OPERATION, and use tailstock with a live centre for support.
SPIGOT OPERATION
This is where the jaws contact around a wooden spigot for grip. This function is mainly for box,
goblet and vase turning, that is, end grain items with a fair degree of overhang. This situation is
one of the most difficult to provide secure holding no matter what fixing method is used.
EXTREMECAUTIONWITHTHIS OPERATIONMUSTBEEXERCISED. DONOTEXCEED850 RPM
FOR THIS OPERATION. If used properly, the Nova G3 Chuck provides a very powerful and secure
grip in this mode.
Instructions below apply to the standard 50mm (2 inches) jaws but the general spigot technique
is the same for other jaw types. However, maximum turning speed and recess size varies with
different jaw types. Consult accessory jaw manual or instruction sheets. With the standard set of
50mm (2 inches) jaws a maximum size woodblank of 100mm (4 inches) diameter (NOT spigot
size) by 150mm (6 inches) length can be turned. Square timber of same length and between
40mm (1.5 inches) to 50mm (2 inches) and grip of all four jaws into wood. MAKE SURE YOU HAVE
ANADEQUATE GRIP BEFORE OPERATION by vigorously wrenching the limb mounted on chuck.
If any loosening occurs DO NOT PROCEED with operation. Repeat tightening procedure and re-
test grip.
SPIGOT SIZE:
Standard Jaws will grip a round spigot between 45mm (1 49/64inches) to 65mm (2 5/16 inches)
approx. Square timber between 40mm (1 37/64inches) to 50mm (2 inches) square approx.
Jaw slides only - With the 50mm (2 inches) add-on jaws removed, the jaw slides will grip either
round or square timber down to 8mm (5/16inch). Length limits are the same for spigot work.
Small work not greater than this diameter can be turned at a speed NOT EXCEEDING 1800 RPM.
Larger work held in the jaw slides should NOT EXCEED 850 RPM.
FORMING SPIGOT:
When selecting wood make sure it is sound without splits or weakness - especially around the
area where the spigot is to be formed. REMEMBER WITH FREE END TURNING, THIS IS THE
ONLYAREAFOR GRIP. IFANYWEAKNESS ISFOUND,DO NOTPROCEED.Mount woodbetween
centres and turn the spigot area. Make the spigot as parallel as possible to maximise the
efficiency of the clamping action. Only approximate sizing of the spigot is necessary, as the jaws
will accommodate a wide range of spigot diameters within the spigot limits stated above. The
50mm (2 inches) standard jaw has a thin lip (or shoulder at the front face) which is designed to
bite into the timber as the jaws are tightened. DO NOT CUTARECESS FOR THE LIP TO FIT INTO,
AS THIS WILL REDUCE GRIPPING POWER.
FORMING RECESS
The jaw dovetail has been designed for use with a standard skew scraper. This chisel will make
arecess to theangle required. FORSAFETYREASONS WESTRONGLYADVISEAGAINSTUSING
ANY OTHER TOOL. A profile of this chisel is shown below. It is best to work with a tool, which is
already ground, to the correct angle. All that is necessary then is to keep the leading edge of the
chisel flat on the wood, moving forward and out to form the recess to the required diameter and
depth. Mount bowl blank on screw as described in previous section. It
may be convenient to first mark out with a pencil, a circle on the bowl
blank. To mark out the recess diameter with pencil, hold pencil point to
desired radius, supported on the toolrest. Then revolve blank by hand
thus creating a pencilled circle. However, as specified above, any recess
diameter can be made between 50mm (2 inches) - 75mm (3 inches) so
exact sizing of the recess is unnecessary.
Before scraping out the recess, slightly hollow out the centre of the bowl blank with a bowl gouge
or round nose scraper. The purpose is to relieve the centre so that when the recess is scraped out
only half the chisel edge needs to be used. We recommend this to reduce
tearing of the wood by scraping action; and to make the recess a little more
finished to give a better effect to the overall bowl. extra embellishments can also
be made to the recess to enhance the bowl. After the recess is finished and the
outside of the bowl is turned to shape, wind bowl back off screw. Bowl blank is
now ready to be reversed into the jaws. Expand the jaws into the recess. When
the jaws are expanded out into the recess, screw the wood blank gently back
and forth to make sure it is seated properly on the bottom face of the jaws.
WARNING: MAKE SURE THE JAWS ARE SEATED PROPERLY IN THE RECESS AND THAT THE
BOWLIS NOTINCORRECTLYRIDING ONTHE FLATSHOULDERSECTION OFTHE JAWS BEHIND
THE DOVETAIL. THIS COULD LEAD TO THE BOWLDISLODGING FROM CHUCK. LOOSEN JAWS
ANDREMOUNT CORRECTLY.
Now give a few gentle raps with the end of a chisel handle or wooden mallet around centre of bowl.
Use pinion handle to give an give an extra nip up. Refer to Chuck Operation. Refer again to safety
before operation.
FITS MOST LATHES
Ideal for Mini,
Midi and all
lathes up to 14”
swing over bed
Fast, strong geared grip
Teknatool InternationalLtd,PO Box305378TritonPlaza, North Shore 0757,
Auckland, NewZealand
PH:[phone] FAX:[phone]
Email:[email protected] Website:www.teknatool.com
easy to use
versatile
