Teknim TFB-1166 v2 User manual

TFB-1166 v2
INTELLIGENT ADDRESSABLE MANUAL CALL POINT WITH BUILT-IN ISOLATOR, RESETTABLE
Installation and User Manual
Release Date: 04/01/2021 Rev:03
IMPORTANT WARNINGS
GENERAL
✓Read this manual carefully before operating the equipment and save
it for future reference.
✓Observe all warnings and precautions specified in the operating
instructions. Follow all operating and usage instructions.
✓Keep devices away from water and moisture.
ENVIRONMENTAL CONDITIONS
Do not operate the device in extremely hot or cold environments
except under the following conditions.
Temperature: Between -10C ~ +70C
Humidity: ≤93% at +40°C
SERVICE
Do not attempt to repair the appliance yourself, you may be exposed
to electric shock if you open the appliance cover.
In the event of any malfunction, contact your dealer or authorized
service. Technical intervention to the device must be performed by
qualified service personnel.
FAULT CONDITIONS REQUIRING SERVICE
In the event of any malfunction or in the following cases, contact
your authorized service or dealer.
✓When the power cord is damaged,
✓When any liquid flows into the device or any object falls,
✓When exposed to water or rain,
✓If the device has been dropped or the housing has been
damaged
✓If the device has noticeable performance changes,
✓If the device does not operate normally according to the
operating instructions specified in the installation manual
WHAT YOU CAN DO ON YOURSELF
Do not attempt to repair the appliance yourself, as you may be
exposed to electric shock if you open the case. In the event of any
malfunction, contact your dealer or authorized service. Technical
intervention to the device must be carried out by qualified service
personnel. The appliance should be cleaned with a dry cloth. Do not
use any chemicals.
SHIPMENT AND TRANSPORTATION
The device must be handled carefully so that it is not exposed to any
external impact and does not allow any liquid to enter. Malfunctions
during improper handling are not covered by the warranty.
HUMAN AND ENVIRONMENTAL HEALTH
This device does not contain any chemical or biological substances that may
harm human health..
CE
1922
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu OSB 1. Cad. İsmet Tarman İş Merkezi
No:1 Kat:2 No:32 Ümraniye / İstanbul
17
1922-CPR-0898
EN 54-11:2001, EN 54-11:2001/A1:2005
Manual Alarm Devices
TFB-1166
Technical Data: See BİLGİ-TEC-170907-2 maintained at the
manufacturer
INSTALLATION AND CONNECTION
1. Mount the button on the wall so that the fire cable passes
through the base of the clip. Do not over-tighten the wall-
mounting screws.
2. On the board there are LIN+, LIN-, EARTH, LOUT- and
LOUT+ connectors. For the perfect operation please
connect + from control panel loop exit toLIN+ and –from
control panel loop exit to LIN-. And move to next device
from LOUT- and LOUT+
3. EARTH connection must be connected both on control
panel and inside of manual call point to ensure integrity
4. After the TFB-1166 is connected to the panel and give
address, the LED on it starts to blink with a blue light at
intervals of 20 seconds. LED lights steady RED in case
of alarm. If a short circuit occurs on the loop line, the
YELLOW LED on the call point lights up continuously
and the short circuit point is opened by two isolators to
protect the loop line.
Warning: TFM-128x Sub-base isolator modules must be
operated together with v2 version Addressable Panel,
TFC-1201 Loop Board, TFM-128X Sub-Base Modules and
TFM-1990 Isolator Module. Short circuit protection
function does not work if used with previous versions!
Make sure that the following label is on the products that will
work with short circuit protection function.

TEST
FEATURES
MANUFACTURER
*Complies with WEEE regulations. This product is made of high-quality parts and materials which are recyclable and
reusable. Therefore, do not dispose of the product with household or other waste at the end of its service life. Take it to a
collection point for the recycling of electrical and electronic equipment.
Model
Operating
Voltage
Voltage
Average /
Alarm
Consumption
Cable
Selection
Temperature and
Humidity
Type of Frangible Element
Body Material,
Dimensions,
Weight
TFB- 1166
24 VDC
15-32 VDC
100uA. /
4,5mA.
0,8mm ~
2.0mm
-10 ~ +70
≤93% @ +40°C
A, Indoor Usage
(Surface + Under Surface
Mounted)
RED ABS
86x55x88mm
145 gr
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu Organize Sanayi Bölgesi 1. Cadde İsmet Tarman İş Merkezi
No:1 Kat:2 No:32 Ümraniye / İstanbul
Phone: [phone] Fax: [phone]
www.bilgielektronik.com.tr [e-mail] www.teknim.com
3) Insert the key, push it upwards and
observe that the panel is reset after
resetting the button. In this case, the LED
on it starts flashing Blue light at 20 seconds
intervals.
2) Alarm status is observed in
Fire Panel. In this case, the LED
on the button will turn solid RED.
1) Press the center point.
IMPORTANT WARNING!
This Product only works with Teknim TFP-12XX
Intelligent Addressable Fıre Alarm Control Panels.
