Teknim TFS-3191R Troubleshooting guide

Release Date: 17/12/2017
Revision Date: 12/08/2022
Rev:05
Important Warnings
General
✓Before using the device read this manual carefully. Keep it just in case of necessity.
✓Abide all the rules and precautions stated in the manual. Follow all the instructions one by one.
✓Keep the devices away from water and moisture
Service
Do not try to fix the device on your own. Removal of cover may end up with electricity shock.
In case of any defect or malfunction, contact with your dealer or with authorized service. All the technical
interventions have to be done by technicians of company.
Malfunctions that require technical service
In case of any malfunction or below conditions contact with your authorized service,
✓When Mains cable or the plug is harmed,
✓Contact of device with a fluid,
✓Exposure of rain and water,
✓Fell down of device or harmed outer cover,
✓Serious performance fall on the device,
✓Depending on the instructions stated in manual, if your device not working properly
Contact with your authorized service in such terms.
Maintenance on your own
Do not try to fix the device on your own. Removal of cover may end up with electricity shock. In case of any
defect or malfunction, contact with your dealer or with authorized service. All the technical interventions have
to be done by technicians of company. Device must be cleaned up with a dry fabric. No-chemicals are
allowed for cleaning
Transportation
Device must be carefully transported avoiding all physical bump, stroke and possible fluid entry. Malfunctions
that caused by improper transportation is not under warranty.
Human and Environmental Health
This device contains no chemical or biological elements that could harm human condition.
Sub Models
TFS-3191R
Conventional Fire Alarm Siren, Red
TFS-3191W
Conventional Fire Alarm Siren, White
Technical Features
Power Input
24VDC –28VDC
Alarm Current Consumption
~15 mA ( @24VDC )
Sound Level
100 dB ±2 dB (24VDC,@ 1 m)
Sounder Type
Type A device
Piezo
Piezzo with leakproof seal
IP Class
IP21C
Operating Temperature Range
-10C ~ 55C
Usage Area
Internal indoor use
Humidity
@ +40°C between %0 to %95 Max
Dimensions (mm)
Ø:110mm, h:55mm
Housing Material
Red , White UL94 fireproof polycarbonate
Used Cable Cut
0.28mm ² ~ 1.5mm ²
Terminals
Number 1
To next siren Negative (-)power out
Number 2
Negative (-)power input
Number 3
To next siren Positive (+)power out
Number 4
Positive (+) power input
Weighted Sound Level Shape
Warning: Do not attempt to remove the electronic board from its plastic case. The electronic board is
closed for your safety. Users should avoid from interference.
TFS-3191R / TFS-3191W
Conventional Fire Alarm Siren
Installation & Operating Guide

Mounting and Connection
1. Remove the head of the siren from the base.
2. Mount the base part on the wall, using 2 of the 4 markings marked on the base.
3. Connect the cable according to the following diagram. The direction of the connection is important, the
siren of the panel must be connected to the Terminal 2 of the cable siren, and the cable siren to the
Terminal 4 of the siren.
4. For the next siren, enter a cable from the existing siren 1 terminal into the siren terminal 2 of the next
siren. In the same way, you will remove the existing siren 3 from the terminal block and insert the cable
into the terminal block 4 of the next siren.
Test
1. Check if the siren fault occurs when the panel is started.
2. Make sure that the connections are made correctly if the siren is faulty.
3. If the siren does not give a fault and the panel supports it, bring it to the panel test position.
4. Run the siren test. Listen to the siren sound during the test period.
5. During the test, if the device sounds uninterrupted, the test is complete.
1922
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu OSB 1. Cad. İsmet Tarman İş Merkezi
No:1 Kat:2 No:32 Ümraniye / İstanbul
19
1922-CPR-1227
EN 54-3
Alarm devices –Sounder
TFS-3191
Technical data: see BİLGİ-TEC-190718-1 held by the manufacturer.
Manufacture
* 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal
waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase
of equivalent new equipment, or dispose of it at designated collection points. For more information see:
www.recyclethis.info.
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu Organize Sanayi Bölgesi 1. Cadde İsmet Tarman İş Merkezi
No:1 Kat:2 No:32 Ümraniye / İstanbul / Türkiye
Telephone: [phone] Fax: [phone]
Sales: [email protected]
Technical Support: [email protected]
