Teknim TFS-1183R User manual

Release Date: 05/01/2021
Rev:01
Warnings
General
✓Read this manual carefully before operating the device and retain it for future reference
✓Pay attention to all warnings and precautions described in the manual.
✓Keep devices away from water and moisture utunuz.
Service
Do not attempt to repair the device by yourself, you may be exposed to electric shock if you open the device
cover.
In the event of any malfunction, contact your dealer or authorized service. Technical intervention to the device
must be performed by qualified service personnel.
Fault Conditions Requiring Service
In the event of any malfunction or in the following cases, contact your authorized service or dealer.
✓When the power cord or plug is damaged,
✓When any liquid flows into the device or the object falls,
✓When exposed to water and rain,
✓If the device has been dropped or the housing has been damaged
✓If the device has noticeable performance changes,
✓If the device does not operate normally according to the operating instructions specified
Call for service as incorrect operations can cause other malfunctions.
Maintenance on your own
Do not try to fix the device on your own. Removal of cover may end up with electricity shock. In case of any
defect or malfunction, contact with your dealer or with authorized service. All the technical interventions have
to be done by technicians of company. Device must be cleaned up with a dry fabric. No-chemicals are allowed
for cleaning.
Transportation
Device must be carefully transported avoiding all physical bump, stroke and possible fluid entry. Malfunctions
that caused by improper transportation is not under warranty.
Human and Environmental Health
This device contains no chemical or biological elements that could harm human condition.
Sub Models
TFS-1183R
Intelligent Addressable Flasher With Built-in Isolator, RED
TFS-1183W
Intelligent Addressable Flasher With Built-in Isolator, WHITE
Technical Features
Power
15VDC –32VDC (Nom.27VDC)
Current Consumption
~90 µA ( @27VDC )
Alarm Consumption
~Min.=4.31mA, Nom.=6.49 mA, Max.= 6.54mA. (27VDC )
Coverage
W-2,4-4
LEDs
Wide Range 7 Bright LED RED
Wide Range 7 Bright LED WHITE
Heart Led
White 20s period
Red 20s period
Protection Class
IP21C
Operating Temperature Range
-10C ~ 55C
Flasher Mode
3 (Slow, Normal, Fast)
Humudity
Between %0 - %95 at +40°C
Dimentions (mm)
Ø:110mm, h:55mm (Include Base Bracket)
Body Material
Red, UL94 Policarbonite
White, UL94 Policarbonite
Cable Selection
0.8mm ² ~ 1.5mm ²
Weight (W –WO Base)
207.7Gr.
Usage
Internal Usage / Siren Type : Type A
Terminals
1 -
Loop (-) IN
2 -
Loop (-) OUT
3 -
4 -
Loop (+) IN, OUT
EN 54-23 Visual Alarm Devices
Mounting and Connection
1. Remove the head of the flasher from the base.
2. Mount the base part on the wall, using 2 of the 4 markings marked on the base.
Attention: Do not attempt to remove the card from its plastic housing. Completely closed for
your safety. Users must avoid Intervention.
TFS-1183R / TFS-1183W
Intelligent Addressable Flasher With Built-in
Isolator
Installation Manual
Warning: The product only works with Teknim TFP-121x, Intelligent Addressable Fire
Alarm panels.

3. Connect the cable according to the following diagram.
Supported Flasher Modes and Descriptions
4. Replace the flasher. Make sure that the line on the head meets the long line on the base.
5. Turn the flasher clockwise to the base, making sure that the terminals are tight.
Test
1. TFS-1183 siren tests can be done in the menu of TFP-12XX Addressable Fire Alarm panels.
2. Check if flasher error occurs when panel is operated.
3. If flasher error, make sure the connections are made correctly.
4. If no flasher error, move the panel to the test position from the menus.
5. Run the flasher test. Observe the flasher side / flash status during the test period.
6. If the devices continuous warning lights are flashing during the test, the test is completed.
Manufacture
*2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste
in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
