Kit description
This document provides instructions for installing the Eye mezzanine board,
upgrading the firmware, and updating software licenses. The kit applies to the
following Tektronix instruments:
PRISM MPI2-10 Media Analysis Platform
PRISM MPX2-10 Media Analysis Platform
Supported upgrades
The following hardware upgrades are supported by this document:
MPI2-10-UP PHY. Add SDI Physical Layer Measurement Package to the
MPI2-10 product; includes automated measurement of 12G/3G/HD/SD-SDI
Eye pattern parameters, jitter parameters and jitter waveform display.
(Option MP2-FMT-4K required for 12G support)
MPX2-10-UP PHY. Add SDI Physical Layer Measurement Package to the
MPX2-10 product; includes automated measurement of 12G/3G/HD/SD-SDI
Eye pattern parameters and jitter parameters and jitter waveform display.
(Option MP2-FMT-4K required for 12G support)
Kit parts list
The following table lists the parts that are supplied with the upgrade kit.
Quantity Part Number Description
1 878-1285-XX ASSEMBLY, CIRCUIT BOARD,12G EYE MEZZ, 3895134XX
2 211-1117-XX SCREW, MACHINE; 4-40 X 0.187, PAN HEAD, STEEL, ZINC
FINISH, T-10, TORX DR
1 129-1889-XX 1SPACER POST .188 HEX X .325L BNC, MEZZ BOARD
MOUNTING
1 075-1095-XX PRISM FIELD UPGRADE INSTRUCTIONS
1The spacer post provided in the kit will not be needed for the MPI2-10 12G Eye board upgrade. The
MPI2-10 Mixed Media board comes with a second spacer post installed.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions 1

Kit description
2 PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions

MPI2-10 hardware upgrades
These instructions are for the qualified, trained personnel or personnel familiar
with servicing the product. Contact your nearest Tektronix, Inc., Service Center or
Tektronix Factory Service for installation assistance.
WARNING. Dangerous voltages may be present. To prevent electrical shock,
disconnect the power cord from the unit before starting the upgrade procedure.
Failure to do so could cause serious injury or death.
CAUTION. Many components within the instrument are susceptible to static
discharge damage. To prevent static discharge damage, service the product
only in a static-free environment. Observe standard handling precautions for
static-sensitive devices while installing this kit. Always wear a grounded wrist
strap, grounded foot strap, and static resistant apparel while installing this kit.
Recommended tool list
Table 1: Recommended tool list
Name Description
9/16 inch socket nut driver Used to removed BNC nuts.
Screwdriver handle Accepts Torx-driver bits
T-10 TORX tip Used for removing instrument screws.
TORX-driver bit for T-10 size screw heads.
T-15 TORX tip Used for removing instrument screws.
TORX-driver bit for T-15 size screw heads.
Torque driver Used to apply precisely a specific torque to
af
astener.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions 3

MPI2-10 hardware upgrades
Upgrade the PRISM MPI2-10 Eye mezzanine board
Complete the following steps to remove the currently installed mezzanine board
from the instrument and install the Eye mezzanine board:
1. Set the instrument so the bottom is down on a static-free work surface.
2. Remove the top cover as follows:
a. Use a TORX-driver with a T-10 TORX tip to remove the thirteen screws
securing the cover to the instrument.
b. Slide the cover back and then lift it from the back to remove it from the
instrument; set the cover aside.
Figure 1: Remove the cover
4 PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions

MPI2-10 hardware upgrades
3. Use the 9/16 inch socket nut driver to remove the two BNC nuts and lock
washers (SDI IN 1 and 2).
Figure 2: Remove the BNC hardware
4. Using a TORX-driver with a T-10 TORX tip to remove the screw securing
the BNC mezzanine board.
Figure 3: Remove the screw from the mezzanine board
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions 5

MPI2-10 hardware upgrades
5. Gently lift the back of the BNC mezzanine board from its connector and
remove it from the Mixed Media board.
Figure 4: Remove mezzanine board from Mixed Media board
6. Locate the new Eye mezzanine board from the kit (Tektronix part number
878-1285-XX).
Figure 5: Eye mezzanine board
6 PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions

MPI2-10 hardware upgrades
7. Guide the BNC connectors through the bracket and line up the two board
connectors with the connectors on the Mixed Media board.
CAUTION. Bending the Eye mezzanine board can damage the board or instrument.
Avoid fully inserting the back connector until the front connector is properly
aligned; this prevents the bending of the board.
8. Begin by engaging the connector near the BNCs. Do not fully insert.
9. Line up the connectors furthest away from the BNCs. Finish inserting the
first connector.
10. Gently press the last connector into the Mixed Media board.
NOTE. The MPI2-10 Mixed Media board comes with a second spacer post
installed. The spacer post in the kit will not be needed during the upgrade process.
Figure 6: Connect the Eye mezzanine board
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions 7

MPI2-10 hardware upgrades
11. Use a TORX-driver with a T-10 TORX tip to install the two screws in the Eye
mezzanine board. Tighten these screws to 0.6 N·m (5.31 in-lb).
Figure 7: Secure the Eye mezzanine board
12. Replace the two BNC nuts and lock washers. Tighten the BNC nuts to
1.0N·m(8.85in-lb).
13. Place the top cover over the instrument and use the TORX-driver with a T-10
TORX tip to reinstall the screws. Tighten these screws to 0.9 N·m (7.97 in-lb).
8 PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions

MPI2-10 hardware upgrades
14. Apply the MPI2-10-UP serial number label to the side panel (right side as
viewed from the front of the instrument). Place the new serial number label
below the labels that contain the regulatory marks.
NOTE. The MPI2-10-UP serial number label is included in the upgrade kit. The
label lets Tektronix Service know that the instrument contains the upgrade kit.
Figure 8: Installing the MPI2-10-UP serial number label
15. Upgrade the instrument firmware. (See page 21, Upgrade the instrument
firmware.)
16. Upgrade the software license. (See page 24, Upgrade the software license.)
17. Verify the upgrade. (See page 30, Verify the hardware upgrade.)
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions 9

MPI2-10 hardware upgrades
10 PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
