Tektronix WVR52003G User manual

xx
WVR5200
Waveform Rasterizer
ZZZ
User Manual
*P077053203*
077-0532-03

WVR5200
Waveform Rasterizer
ZZZ
User Manual
xx
www.tektronix.com
077-0532-03

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
TandemVu® is a registered trademark of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be new or reconditioned to like new performance. All replaced parts, modules and products become
the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, with shipping
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

Table of Contents
General safety summary .......................................................................................... vi
Preface.............................................................................................................. ix
Where to Find More Information ........................................................................... ix
Conventions Used in This Manual........................................................................... x
Getting Started ... .................. ........................................ .................. ...................... . 1
Key Features ................................................................................................... 1
Options.......................................................................................................... 3
Connecting Power ............................................................................................. 5
Network Installation........................................................................................... 5
Incoming Inspection........................................................................................... 8
Getting Acquainted with Your Instrument .......... .................. ...................... .................. .. 11
Front-Panel Controls ......................................................................................... 11
Instrument Online Help ...................................................................................... 13
Instrument Display ........................................................................................... 15
Signal Inputs and Outputs ........................................................................................ 19
SDI Signals.................................................................................................... 20
Dual Link Signals............................................................................................. 20
Reference Loop ............................................................................................... 21
Signal Generation............................................................................................. 22
Display Information............................................................................................... 23
Multi-Input Display Mode................................................................................... 25
Simultaneous Input Monitoring............................................................................. 28
3D Input Monitoring ......................................................................................... 29
SyncVu™...................................................................................................... 33
Waveform Display............................................................................................ 34
Vector Display................................................................................................. 36
TandemVu® (Overlay) Display............................................................................. 39
Gamut Display ................................................................................................ 40
Timing Display................................................................................................ 44
Datalist Display............................................................................................... 48
Bowtie Display................................................................................................ 50
LTC Display................................................................................................... 51
External Reference Waveform Display..................................................................... 52
Diagnostics Monitor Display................................................................................ 53
Ancilliary (ANC) Data Display ................... .................. ...................... .................. 54
Status Displays................................................................................................ 56
Audio Display................................................................................................. 74
Picture Display................................................................................................ 80
WVR5200 Waveform Rasterizer User Manual i

Table of Contents
Functions ........................................................................................................... 83
Gain, Sweep, and Magnification ............................................................................ 83
Cursors......................................................................................................... 84
Capture......................................................................................................... 85
Line Select..................................................................................................... 86
Headphone Volume and Source Adjustment............................................................... 87
Presets.......................................................................................................... 87
Software Upgrades ........................................................................................... 90
Checking Chroma/Luma Delay (Lightning Display).......................................................... 95
Checking Gamut................................................................................................... 97
To Set Up Gamut Checks .................................................................................... 97
Checking RGB Gamut ....................................................................................... 98
Checking Composite Gamut............................................................................... 101
Checking Luma Gamut..................................................................................... 102
Automating Gamut Checks................................................................................ 102
ARIB Displays................................................................................................... 103
ARIB Status ................................................................................................. 104
ARIB STD-B.39 Display .................................................................................. 105
ARIB STD-B.37 Display and Status Screens............................................................ 108
ARIB STD-B.35 Display and Status Screens............................................................ 111
ARIB TR-B.23 (1) Display and Status Screens ......................................................... 113
ARIB TR-B.23 (2) Display and Status Screens ......................................................... 115
ARIB TR-B.22 Display and Status Screens ............................................................. 117
Audio Monitoring ............................................................................................... 119
Configuring Audio Inputs.................................................................................. 119
Selecting Audio Inputs..................................................................................... 119
To Check Audio Level and Phase......................................................................... 120
To Check Surround Sound................................................................................. 123
Closed Captioning (CC), Teletext, AFD, and Safe Area Compliance ..................................... 127
Monitoring CC and Teletext............................................................................... 127
Monitoring for Safe Area Compliance ................................................................... 130
Monitoring for AFD Compliance......................................................................... 132
Application Example............................................................................................ 133
Timing a Studio ............................................................................................. 133
Index
ii WVR5200 Waveform Rasterizer User Manual

List of Figures
Figure 1: Connecting the instrument to a PC.................................................................... 6
Figure 2: Instrument online help................................................................................. 14
Figure 3: Display quadrants and related tile numbers ........... .............. ................................ 15
Figure 4: Changing from 4-tile to full-tile view ..... .................. ........................................ 16
Figure 5: Status bar................................................................................................ 16
Figure 6: Two SDI signal connection ........................................................................... 20
Figure 7: Dual Link information placement in waveform display........................................... 21
Figure 8: External reference signal connection ................................................................ 21
Figure 9: Signal generation connection......................................................................... 22
Figure 10: Navigate menus using the arrow keys and select button......................................... 24
Figure 11: Waveform display in Multi-Input mode showing multiple channels ... ........................ 28
Figure 12: Simultaneous 3D display of Left Eye and Right Eye signals.................................... 30
Figure 13: 3D Left and Right Eye images showing a Difference Map and Red/Cyan Anaglyph using
SIM............................................................................................................. 31
Figure 14: 3D Left and Right Eye images showing Green/Magenta Anaglyph and Checkerboard display
using SIM...................................................................................................... 32
Figure 15: 3D Left and Right Eye images showing Disparity Grid and Disparity Cursor measurement using
SIM............................................................................................................. 33
Figure 16: Vector display with Luma Qualified Vector (LQV) enabled..................................... 36
Figure 17: Lightning display..................................................................................... 37
Figure 18: TandemVu® (Overlay) display and menu option................................................. 39
Figure 19: Timing display........................................................................................ 44
Figure 20: Timing display of integer multiples of reference rates ..................... .......... ............ 46
Figure 21: Timing display of non-integer multiples of reference rates .............. .......... .......... .... 47
Figure 22: Datalist display ....................................................................................... 48
Figure 23: Bowtie display........................................................................................ 50
Figure 24: LTC display ........................................................................................... 51
Figure 25: External reference waveform (tri-level sync signal).............................................. 52
Figure 26: Diagnostics monitor display......................................................................... 53
Figure 27: ANC Data display .................................................................................... 54
Figure 28: Error log ............................................................................................... 56
Figure 29: Alarm Status display ................................................................................. 58
Figure 30: Video Session display of HD signal................................................................ 59
Figure 31: Audio Session display................................................................................ 62
Figure 32: Audio Loudness Session display.................................................................... 65
Figure 33: Audio Control Packet format........................................................................ 67
Figure 34: Audio Control Packet structure ..................................................................... 68
Figure 35: Audio Control display................................................................................ 68
Figure 36: Auxiliary Data Status display ........... .............. ................................ .............. 70
WVR5200 Waveform Rasterizer User Manual iii

Table of Contents
Figure 37: Dolby Status display ................................................................................. 72
Figure 38: Audio display ......................................................................................... 74
Figure 39: 16-Channel audio bars display...................................................................... 79
Figure 40: Picture display showing color bars ................................................................. 80
Figure 41: VChip, CC-Display, Teletext, and Safe Area Graticule in Picture display..................... 81
Figure 42: Using cursors in a waveform display............................................................... 85
Figure 43: Navigating line selection ............................................................................ 86
Figure 44: Sample of transfer.exe window after the upgrade is complete .................................. 93
Figure 45: Determining transition intersections in the Lightning display................................... 96
Figure 46: Diamond display plot ................................................................................ 99
Figure 47: Out-of-gamut examples............................................................................ 100
Figure 48: Arrorwhead gamut display plots.................................................................. 101
Figure 49: ARIB Status display, showing no data present.................................................. 104
Figure 50: ARIB STD-B.39 display (with the associated ARIB Status display)......................... 105
Figure 51: ARIB STD-B.37 display (with the associated ARIB Status display)......................... 108
Figure 52: ARIB STD-B.35 display (with the associated ARIB Status display)......................... 111
Figure 53: ARIB TR-B.23 (1) display (with the associated ARIB Status display) ...................... 113
Figure 54: ARIB TR-B.23 (2) display (with the associated ARIB Status display) ...................... 115
Figure 55: ARIB TR-B.22 display (with the associated ARIB Status display)........................... 117
Figure 56: Audio levels......................................................................................... 121
Figure 57: Checking for phase correlation ................................................................... 122
Figure 58: Surround sound indicators......................................................................... 124
Figure 59: Auxiliary Data Status display . ................................ .................. .................. 129
Figure 60: Closed caption display area ....................................................................... 129
Figure 61: Safe Action and Safe Title areas ...... .............. .............. .............. .............. .... 131
iv WVR5200 Waveform Rasterizer User Manual

Table of Contents
List of Tables
Table i: Product documentation.................................................................................. ix
Table 1: Service options ........................................................................................... 4
WVR5200 Waveform Rasterizer User Manual v

General safety summary
General safetysummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
To avoid fire or personal
injury
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Ground theproduct. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power disconnect. The power cord disconnects the product from the power source.
Donotblockthepowercord;itmustremain accessible to the user at all times.
Do not operate without covers. Do not operate this product with covers or panels
removed.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Avoid exposed circuitry. Do not touch exposed connections and components when
power is present.
Use proper AC adapter. Use only the AC adapter specified for this product.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Provide proper ventilation. Refer to the manual's installation instructions for details
on installing the product so it has proper ventilation.
vi WVR5200 Waveform Rasterizer User Manual

General safety summary
Terms in this manual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and terms on the
product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARN ING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
WVR5200 Waveform Rasterizer User Manual vii

General safety summary
viii WVR5200 Waveform Rasterizer User Manual

Preface
Preface
This manual contains information to help you use the Tektronix WVR5200
Waveform Rasterizer. This information includes the following:
How to set up various waveform displays for monitoring SD-SDI, HD-SDI,
and 3 Gb/s SDI video signals.
How to set up audio displays to monitor embedded AES/EBU audio signals.
How to set up parameters for monitoring auxiliary data, ancillary data, closed
captions, and timecode.
How to freeze video data.
How to set up error logging and alarms.
How to operate the instrument remotely.
How to navigate instrument menus.
How to operate the instrument front panel.
WheretoFindMoreInformation
This product is shipped with a Product Documentation CD that contains various
user documents for all users and reference information for system integrators. The
following table shows you where you can find this and more information about
your product. You can always find the most updated documentation and software
for your product on the Tektronix Web site at www.tektronix.com/downloads.
Table i: Product documentation
To read about Tektronix part number Use these documents
Installation, safety, and
environmental compliance
071-2888-XX Installation and Safety Instructions
Provides installation, safety, general specifications, and
environmental and compliance information.
This is a printed manual and is also available on
the Product Documentation CD and the Web at
www.tektronix.com/downloads.
Instrument operation 077-0532-XX User Manual (this manual)
In-depth descriptions of instrument operation.
Available on the Product Documentation CD and the Web at
www.tektronix.com/downloads.
Content-sensitive help topics NA Online Help
Detailed instrument operation and UI help is available in your
instrument by pressing the HELP button on the front panel of
the instrument.
WVR5200 Waveform Rasterizer User Manual ix

Preface
Table i: Product documentation (cont.)
To read about Tektronix part number Use these documents
Specifications and procedures for
checking instrument performance
077-0534-XX Specifications and Performance Verification Technical
Reference
Physical, electrical, and environmental specifications; functional
checks and performance verification procedures.
Available on the Product Documentation CD and the Web at
www.tektronix.com/downloads.
System integration information 077-0549-XX System Integration Technical Reference
Detailed information about installing the instrument into a
system.
Available on the Product Documentation CD and the Web at
www.tektronix.com/downloads.
SNMP commands 077-0261-XX WFM and WVR Series Management Information Base (MIB)
Programmer Manual
SNMP command reference for remotely controlling the
instrument.
Available on the Product Documentation CD and the Web at
www.tektronix.com/downloads.
Information about servicing the
instrument
077-0551-XX Service Manual
Detailed information about how to service the instrument at the
module level.
Available on the Web at www.tektronix.com/downloads.
Conventions Used in This Manual
The following icon is used throughout this manual:
Sequence step
or item
x WVR5200 Waveform Rasterizer User Manual

Getting Started
Your instrument shipped with a CD containing various user documents and a
printed manual with power-on, installation, and accessories information. That
manual is also available online at www.tektronix.com/downloads. This User
manual contains information about operating your instrument.
This chapter will help you set up and begin to use the instrument. It is divided
into the following four sections:
Key Features describes your instrument and provides a list of and key
features.
Options tells you where to go for a list of available options.
Network Installation shows you how to set up your instrument on an
Ethernetnetwork.
Incoming Inspection provides a procedure for verifying the basic operation
and functionality of your instrument.
Key Features
The WVR5200 Waveform Rasterizer is a portable, 1 RU half-rack, short-depth
rasterizer that provides comprehensive video and embedded audio features across
3 Gb/s, SD, and HD signal formats. This instrument provides an ideal solution for
basic video and audio (with Option AUD) monitoring needs with a form factor
suitable for space-constrained environments.
The following key features make this instrument an easy to use, flexible, and
effective tool.
Item Description
Flexible tile displays:
Full and Quad Tile
Quad Tile (4-Tile): View four measurement displays at once, one
in each tile.
In Quad Tile mode, the display provides four concurrent views of a
monitored signal (with a maximum of two trace displays at once).
The instrument also provides the flexibility to configure each of the
four display tiles independently, enabling you to quickly check the
integrity of a signal.
Full: View the active display full screen.
TandemVu® Patented display allows you to overlay the Waveform and Vector
or Waveform and Lightning displays, plus Picture Thumbnail, in
a single, full-tile display.
WVR5200 Waveform Rasterizer User Manual 1

Getting Started
Item Description
Multi-Input Display The Multi-Input Display mode allows you to simultaneously view up
to four SDI inputs of the same format. The feature is available in
Waveform, Vector, Lightning, Diamond, Split Diamond, Arrowhead,
and Spearhead displays. If you are monitoring a 2xHD Level B
3 Gb/s signal, you can select to view the streams of that signal
individually.
Presets Customizable presets allow you to quickly save and recall
commonly used configurations.
Digital support Support for digital applications.
Fully digital
processing
Fully Digital Processing allows for accurate, repeatable, drift-free
operation that surpasses traditional analog designs.
Waveform display Traditional waveform displays allow signals to be overlaid or
paraded. This display type allows you to use the Multi-Input Display
feature.
Vector display Vector display with Composite and Component Compass Rose
Graticules, and gain, sweep, and magnification controls. Traditional
and Lightning Vector displays are available. The latter visualizes
both luma and chroma amplitudes, and quantifies inter-channel
timing. This display type allows you to use the Multi-Input Display
feature.
Spearhead and
LQV™ (luma qualified
vector) display (Option
PROD)
Vector display that is gated by a specified luminance range. Each
vector tile may have a different luminance range specified. This
display type allows you to use the Multi-Input Display feature.
Stereoscopic 3D
video displays (Option
S3D)
These displays for camera alignment and
production/post-production applications help to quickly
resolve difficult content quality and reliability issues. (Option S3D)
Infinite Persistence All trace displays can also be set, tile by tile, to Infinite Persistence.
This mode traces waveforms over time on the same display,
providing a visual history of the trace.
Gamut monitoring Arrowhead, Spearhead, Diamond, Split Diamond, and 3D Quad
Diamond displays offer user-selectable gamut thresholds so that
you can set monitoring limits appropriate to a specific operation.
Gamut monitoring is fully integrated with the alarm logging and
reporting capabilities. This display type allows you to use the
Multi-Input Display feature.
LTC waveform display Longitudinal Time Code (LTC) is monitored in a frame rate display
to allow observation of amplitude and noise, and verify LTC is
locked to the video.
External Reference
Waveform display
The External Reference waveform display check the external
reference signal integrity, including its shape and amplitude. This
display is independent of the input video signal.
2 WVR5200 Waveform Rasterizer User Manual

Getting Started
Item Description
Surround Sound display of audio signals and phase relationships
of normal channel pairs.
Lissajous display lets you monitor a user-specified pairing of
channel inputs.
Support and options for viewing and monitoring both levels of
normal channel pairs for embedded audio signals.
Audio monitoring
(Option AUD)
Support for loudness measurement, audio control packet coding,
and many popular audio scales, including BBC scales.
Auxiliary data
monitoring (Option
DATA)
Support for monitoring auxiliary data including data conforming to
ARIB standards and CEA608, CEA708, AFD, and CGMS-A.
Timing display A Tektronix proprietary display that simplifies measuring the timing
difference between two signals. Using the Timing display enables
you to easily compare and correct the timing between two signals.
Closed Captioning
support (Option
DATA)
Support for simultaneous decode and display in multiple languages
of CC standards (CEA 608 (VBI), CEA 608 (ANC), CEA (608/708),
CEA 708, TeletextB (VBI), TeletextB OP47 SDP (ANC), and
TeletextB OP47 Multi (ANC)) with caption text and V-chip
information overlaid on the picture (monitor mode). There are also
settings for missing or incorrectly inserted closed captioning.
Picture area Support for standard and custom Safe Graticules for Picture
displays that look for incorrect placements of graphics, logos, Black
events, and Frozen events. Two Safe Area graticules and Safe
Title graticules are supported.
Status screens Status screens provide content status at a glance.
Error tracking Configurable alarms and error logging.
Remote control Full remote control for complete installation flexibility.
Data List display
(Option DATA)
Examines the contents of all digital formats, structures, and
transports and displays the data without any interpolation.
Ancillary data
inspector (Option
DATA)
Allows you to monitor all ancillary data present in a signal.
Options
Your instrument may have been ordered with one or more options.
Instrument Options Option 3G: Support for 3G-SDI (Level A and Level B) signal formats.
Option S3D: Adds monitoring support for SDI stereoscopic 3D video.
Option GEN: Multi-rate color bar and pathological signal generation provides
engineers with a simple signal source for quick signal path verification during
system and/or equipment setup and troubleshooting.
WVR5200 Waveform Rasterizer User Manual 3

Getting Started
Option AUD:16-
channel embedded AES/EBU audio simultaneous
monitoring support with Multichannel Surround Sound 1display and flexible
Lissajous display.
Option LOUD (requires Option AUD): Audio Loudness monitoring to ITU-R
BS.1770-3/1771, EBU R 128, and ATSC A/85 recommendations.
Option CAM: 4-SDI channel simultaneous monitoring (SIM) allows for
quick and easy setup of multiple cameras during content acquisition for OB
van and production studio applications. SIM function allows two channel
monitoring simultaneously with SyncVu™.
Option PROD: Advanced color gamut displays (Spearhead and Luma
Qualified Vector displays) work in conjunction with the Diamond gamut
display to provide the most comprehensive color gamut monitoring tool for
precise color gamut adjustments.
Option DATA: Comprehensive data monitoring helps to quickly resolve
difficult content quality and reliability issues through closed captioning,
subtitles, AFD decode/display and full ANC data support.
1Audio Surround Sound Display licensed from Radio Technische Werksütten GmbH and Co. KG (RTW).
You can check which options are on this instrument after it is powered on by
performing the following steps:
1. Press the CONFIG button on the front panel.
2. Use the General knob to navigate to Utilities.
3. Press the right arrow button to navigate to the Utilities submenu and select
View Instrument Options. The menu box on the right side of the display
shows the installed options.
Service Options You can add any or all of the following service options to any instrument. (See
Table 1.)
Table 1: Service options
Option Description
Option CA1 Adds a single calibration or coverage for the first designated calibration
interval, whichever comes first.
Option C3 Adds 3 years of Calibration Service.
Option C5 Adds 5 years of Calibration Service.
Option D1 Adds a Calibration Data Report.
Option D3 Adds 3 years of Calibration Data Report (when ordered with option C3).
Option D5 Adds 5 years of Calibration Data Report (when ordered with option C5).
Option R3 Adds 3 years of Repair Service (including the period under warranty).
Option R5 Adds 5 years of Repair Service (including period under warranty).
4 WVR5200 Waveform Rasterizer User Manual
