Tektronix DMM4040 Setup guide

DMM4040 and 4050
Digital Multimeters
Safety and Installation Instructions
~±1i<f.) J:.lj~[i~ = ~ ]7 )~
~±&~~i~8J3
111111111111111111111111111111111111111111111111111111111111
071·2693·00
Tektronix
/

071-2693-00
3525290
Tektronix~
/
DMM4040 and 4050
Digital Multimeters
Safety and Installation Instructions

Copyright © Tektronix. All rights reserved. Lic ensed software products are owned by Tektronix
or its subsidiaries or suppliers, and are protected by national copyright laws and international
treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information
in
this publication supersedes that in all previously published material. Specifications and price
change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix, Inc.
Tektronix, Inc.
14200
SW Karl Braun Drive
P.O. Box 500
Beaverton,
OR 97077
USA
For product information, sales, service, and technical support:
In
North America, call 1-800-833-9200.
Worldwide, visit
www.tektronix . com to find contacts in your area.
'-
•-
-
~
•

Warranty
Tektronix warrants that the product will be free from defects in materials and workmanship for a period of
three (3) years from the date of original purchase from an authorized Tektronix distributor. If the product
proves defective during this warranty period, Tektronix, at its option, either will repair the defective product
without charge for parts and labor, or will provide a replacement in exchange for the defective product.
Batteries are excluded from this warranty. Parts, modules and replacement products used by Tektronix for
warranty work may be new or reconditioned
to like new performance. All replaced parts, modules and
products become the property
of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the
expiration of the warranty period and make suitable arrangements for the performance of service. Customer
shall
be responsible for packaging and shipping the defective product to the service center designated by
Tektronix, shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for
the return of the product to Customer if the shipment
is to a location within the country in which the Tektronix
service center
is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and
any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or
inadequate maintenance and care. Tektronix shall not be obligated
to furnish service under this warranty
a) to repair damage resulting from attempts by personnel other than Tektronix representatives to install,
repair or service the product;
b) to repair damage resulting from irnproper use or connection to incompatible
equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or
d) to
service a product that has been modified or integrated with other products when the effect
of such
modification or integration increases the time or difficulty of serviCing the product.
THIS WARRANTY
IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS
IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W16-15AUG04]

Table of Contents
Title Page
About this Manual .. .. ............... .. .. ... .. ................... ... ...... .. .... .. .... ... ... ... ... .. .. ..... .. .. 1
Introduction.....
.. .. ....... ... .. .. ...... .. .. ......... .. ..................... .. ........................ ... .......... 1
User Documentation ........................................... .. .. ... ..... ... ................... .. . .. ... ..... 2
General Safety Surrunary
.. ........ .. .. ........ .. ........... ... ......... .. ..... .. ................. .. ...... .. 3
To Avoid Fire or Personal Injury .................................................................. 3
Symbols and Terms ........
.. ..... .. ... .. ........................................ .. ....................... 5
Safety and Electrical Symbols....................................................................... 5
Description
ofIEC 61010 Measurement Categories........... .. .. ................. .. ... 6
Compliance Information
.. ............... .. ...... .. ...... .................................... .. ..... ... ... .. 7
EMC Compliance ..... .. ..... ... .......... ... ..... .. ................................................ .. . .. .. 7
EC Declaration ofConformity - EMC .. ...... ... ................ .. ............ .. .......... 7
Australia /
New Zealand Declaration of Conformity - EMC .............. .. ... 8
Safety Compliance
.. ..... .. ..... .. ................ .. .. ........... .. .. .... .... .. .......... .. ................ 8
EC Declaration
of Conformity -Low Voltage ........................... ... .. ... .. .. .. 8
U.S Nationally Recognized Testing Laboratory Listing....
.. .................. ... 8
-. 8Canadian Certification
.. ............... .. ........ .. ..... ... ......................... .. ..............
Additional Compliances.
... .......... .. ... .. ......... .. ................ .. ..... ... .. ... .. ... ......,. 8
Equipment Type....................
.. .................................................................. 8
Safety Class .....
.. .............. .. ... ....... .. ........... ... . .. .. .. .................................... ... 8
Pollution Degree Description
.. .. ... ......................... ... ..... .. .......................... 8
Pollution Degree..........
... ... ... .............................................. .. .................. ... 9
Measurement Overvoltage Categories
.. ... ........................ .. ........... .... ...... .. 9
Environmental Considerations
... ............... .. .......... .. .... .. ................... .. .. .. ... .. .. .. ... 9
Product End-of-Life Handling
.. ... ... .. ............. ... .......... .. ................... ... ........... 9
Equipment Recycling....
... .... .. .. .. ..... .. ............ .. .. ..... .. ............. .. ............... .. . 9
Restriction
of Hazardous Substances .... .. .. ...................... ... .................... .. . 9
Perchlorate Materials ......................
.. ................... .. ........... .. ............ ... .... ... 9
Unpacking and Inspecting the
Meter .. .... .. ..... ... .. ................. .. .... .. ................... .. . 10
Storing and Shipping the Meter ................ .... .. .............................................. .. ... 10
Power Considerations .. .. ..... .. . .. . .. ... ... ... .. ...... .. .. .. ... ... ... .... ... ................................ 10
Selecting the Line Voltage ...................
.. ...... .. ...... .. .................. .. ................... 10
Replacing the Fuses.. .. .. ....... .. .................................................. .. .... .. .............. 11
Line-Power Fuse ...... ... .. ...................... .. ... ......................... .. ...................... 11
Current-Input Fuses............... ... ............................................. ... .. ............... 12
Connecting to Line Power .. ................................. .. .. .......... .. . .. .... .. .. .. .. .. . .. .. ... .. ... 14

•
DMM4040 and 4050
~
Safety and Installation Instructions
~
Turning Power On ............. ................ .. ..............................................................
14
~
Adjusting the Bail ................ ................ .. ...................................... .. ....................
15
Installing the Meter into an Equipment Rack .... .. ..................... .. .. .. ................. ..
16
~
Front Panel Features ..........................................................................................
17
Rear Panel Features .................................................... .. .....................................
19
~
Options and Accessories............................................. .. ................................... ,.
20
Cleaning the Meter............ .. .. . .. ..................................................... .. .. .................
20
~
General Specifications ................................................................................. .. ... .
21
Power . .. ...... .. ........................................ .. . ... .. .. ..................... .. .........................
21
~
Dimensions............ .. ...... .. . .. ................................................. .. ............. ... ........
21
Display................................................. ... ..... .. .............................................. ..
21
~
Environment ...... .. ...... .. ................ ... .................... .. .................. .. .....................
21
Triggering............. .. .. ............................ .. ...................................... .. ...............
21
~
Memory ......... .. .. ........ .. ............... .. ............ .. .................................... .. .............
21
Math Functions.,.......... ... . .. ............................. .. ................ .. ....... ... .............. .. .
21
~
Electrical............................................................................ .. .. ................. .......
22
Remote Interfaces..... ... .................................................... .. ........................ .. ..
22
~
Warranty .. .................... .. ........ .. ........... .. ...... .. .......... .. ....................... .. . ... ...... ..
22
Electrical Specifications ................... .. .. ............................... .. .... .. ......................
22
@!I
Input Characteristics............... .. .......... ........ .. .. ............................... ... .. .. .....
22
DC Voltage Specifications .. ... .. .......................................................... ... ...... ..
22
~
4050 Accuracy ....................... ... ............................ .. ..................................
23
4040 Accuracy .......................................... ............... .. ....... .. ......................
23
@I
Additional Errors................ .. .. ...... ............. .. .... .. ... .....................................
23
AC Voltage Specifications ........................................................... .. ............. ..
23
~
4040/4050 Accuracy ............ .. ..... ... ..................... .. ..... .. .. ................... ... ..... 24
Input Characteristics.................................................................................. 24
Additional Low Frequency Errors................................................... .. ...... ..
25
-
Resistance ........................ ... ......................................................... .. .. .. .. .......... 25
~
Input Characteristics...................................................... .. .......................... 25
4040 / 4050 Accuracy ............................ .. .................................................. . 25
~
Additional Ohms Errors ............................. ... ............................................ 26
DC Current .................................. .. ............... .. . ... .............. .. ........................... 26
Input Characteristics........... ........ .. ... .......... ... ........... ... .. ............................ .
26
-
4040/4050 Accuracy ................................................................................. 26
~ .
Additional Current Errors ........................................... .. .. ..........................
27
AC Current ............. ... ............ .. ...... .. ......... .. .......... ............. .. ..........................
27
1.: .
Input Characteristics..................................................................................
27
4040/4050 Accuracy ... .. ................ ... .. ................................................ .. .. .. . 28 ~ '
Additional Low Frequency Errors.................... .. ............................ .. .. ....... 29
Frequency ....................................... .. .............................................................
29
~
4040/4050 Accuracy ..................................... ... ..... .. ..... .. ....................... ... .
29
Gate Time vs. Resolution ............ .. .. ....... .. ........... .. ....................................
29
-
Additional
Low Frequency Errors .. ............................................ ... ....... ... ..
29
--
Capacitance (4050 Only)........................................................................... . .. . 30
r.
Temperature (4050 only) ............................................................... .. ..............
30
Additional Errors ...................... ... .................. ..... ... ........................................
30
~
Continuity...................................................................................... .. ... ... ........
30
....
Diode Test .................
... .. .... .. ................................ .. .......... .. ...........................
31
Measurement Rates (lEEE488[4])............. ... .................................................
31
~
c
~
<11 ,
ii
~

List of Tables
Table Title Page
I. Line
Voltage to Fuse Rating... .. ............ .. ...................... .. .. .. ........ .. .. ........................ 11
2.
Line-Power Cord Types Available from Tektronix ................... .. ... .. ....... .. ............ 14
~
3.
Front
Panel Features.................. .. .. ........................... .. ...... .. ................. .. ................. 18
4.
Rear Panel Features ... ... ... ...................................................... .. ................. .. .. ...... .. .. 19
5. Accessories............. .. ............ .. .......................... .. .. .. ................................................ 20
~
~
List of Figures
Figure Title Page
I. IEC 61010 Measurement Category (CAT) Levels....................... .. ............ .. .......... 6
2. Replacing the Line-Power Fuse ......... .. .................. .. .............................................. II
3. Replacing the Current-Input Fuses.......... .. ............................................... .. ........ .. .. 13
4. Bail Adjustment and Removal. .. .. .. .. ... .. .......... .. ....................... .. ............ .. .............. 15
5. Boot Removal............................................................. .. .......................................... 16
6.
Front Panel.. .. ..... .. ............ .. .................................................................................... 17
7.
Rear Panel ... .. .... ............. .......................... .. .... .. ......... .. ................... .. ...................... 19
iii

Safety and Installation
About this Manual
This manual contains the safety and installation information that a new user will need to
set up the Tektronix DMM4040
or DMM4050 Digital Multimeter (hereafter referred to
as the Meter) prior to operation. You will also find compliance information,
environmental considerations, general and electrical specifications, a list
of available user
documentation, and a list
of standard and optional accessories for the Meter.
Introduction
Both Meters are 6-1/2 digit, dual-display multimeters designed for bench-top, field
service, and system applications. Their full complement
of measurement functions plus
their RS-232, IEEE 488, and Ethernet Remote Interfaces make these multimeters ideal
candidates for precision manual measurements and use in automated systems.
For
portability, these multimeters include a carrying handle that also serves as a bail for
bench top operation.
There are a few feature differences between these two multimeters, and some
specifications are tighter for thc DMM4050. Features that exist in only one multimeter
will be identified with the addition
of "4050 Only" by each feature that is found only in
that model. Separate specification tables are also used to clarify the differences between
these nvo models.
The following is a list
of some of the features and functions:
• Bright, large-digit, wide-viewing-angle display
• Dual display for displaying two properties
of an input signal (e.g., ac voltage in one
display and frequency
in the other).
• Remote operation via IEEE 488, RS-232, and Ethernet interface.
• Trigger in and measurement-complete
out
• Front panel USB port for optional memory
• 6-1/2 digit resolution
• Half-rack width
• True rms ac
• 2 and 4-wire resistance measurements
• Extended 10 Q and I
GQ ranges
• Frequency measurements to 1
MHz
• Capacitance measurements (4050 Only)

•
DMM4040 and 4050
Safety and Installation Instructions
• Temperature measurement (4050 Only)
•
lOA current capability
•
Decibels (dB and dBm) with variable reference impedance and audio power
meas urement capability
• Input terminals on both front and rear
panels of the meter
• Closed-case calibration (no internal calibration
adjustments)
User Documentation
The user documentation for this Meter includes the following:
Accessory Where
to find Part number
Safety and in stallation instnlctions
(This manual)
liiiJI • -
': ~ . '
" ~
~Y
.. . ,.;:
--
+ +
www .TeI<lronix . co m
071-2693-xx
Te chnical Reference
(Specifications and Performance
Verification)
Ima .. _
~)
;w ! - -
- .,r +
www T ektronix.com
077-0362-xx
Programmer Manual IHI •
. - ~ .
~
..- ;;
--
" + www Tektronix com
077-0363-xx
Users Manual 1m.
__ _.
Available in the foll ow ing languages:
~
.. ..
.-
English J +
www T ektromx com
077-0361-xx
Fre
nch
077-0366-xx
Italian 077-0367-xx
German 077-0368-xx
Spanish 077-0370-xx
Japanese 077-0371-xx
S. Chinese 077-0372-xx
T. Chinese 077-0373-xx
Korean 077-0374-xx
Russian 077-0375-xx
•
•
•
•
•
2
II

General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to this
product or any other products connected to
it.
To avoid potential hazards, use this product only as specified.
Only qualifiedpersonnelshouldperform service procedures.
While using this product, you may need to access other parts of a larger system. Read the
safety sections
of the other component manuals for warnings and cautions related to
operating the system.
This instrument has been designed and tested
in accordance with the European standard
publication EN 61010-1:2001 and U.S./Canadian standard publications
UL 61010-1 and
CAN / CSA-C22 .2 No.61010-1-04. The instrument has been supplied in a safe condition.
This manual contains information and warnings that must be observed to keep the
instrument in a safe condition and ensure safe operation.
To use the instrument correctly and safely, read and follow the precautions
in this section
and follow all the safety instructions
or warnings given throughout this manual that relate
to specific measurement functions. In addition, fonow all generally accepted safety
practices and procedures required when working with and around electricity.
CAT I equipment is designed to protect against transients from high-voltage, low-energy
sources, such
as electronic circuits or a copy machine.
CAT II equipment is designed to protect against transients from energy-consuming
equipment supplied from the fixed instalition, such as TVs, PCs, portable tools, and other
houseshold appliances.
To
Avoid Fire or Personal Injury
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country
of use.
Use
Proper Voltage Setting. Before applying power, ensure that the line selector is in
the proper position for the source being used.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the Product. This product is grounded through the grounding conductor of the
power cord. To avoid electric shock, the grounding conductor must be connected to earth
ground. Before making connections to the input or output terminals
of the product, ensure
that the product
is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings information
before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that exceeds the
maximum rating
of that terminal.
Power Disconnect. The power cord disconnects the product from the power source. Do
not block the power cord; it must remain accessible to the user at all times.
Do Not
Operate Without Covers. Do not operate this product with covers or panels
removed.
Do Not Operate With Suspected Failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
3

DMM4040 and 4050
Safety and installation instructions
•
Avoid Exposed Circuitry. Do not touch exposed connections and components when
power
is present.
Use
Proper Fuse. Use only the fuse type and rating specified for this product.
Keep Product Surfaces Clean and Dry.
&& Warning
To avoid electric shock, personal injury, or death, read the
following before using the Meter.
• Use the Meter only as specified in this manual, or the protection provided
by the Meter might be impaired.
• Do
not use the Meter in wet environments.
• Inspect the Meter before using it. Do not use the Meter if it appears
damaged.
•
Inspect the test leads before use. Do not use them if insulation is
damaged or metal is exposed . Check the test leads for continuity.
Replace damaged test leads before using the Meter.
•
Verify the Meter's operation by measuring a known voltage before and
after using it. Do not use the Meter if it operates abnormally. Protection
may be impaired. If in doubt, have the Meter serviced.
• Whenever it is likely that safety protection has been impaired, make the
Meter inoperative and secure
it against any unintended operation.
• Servicing of the Meter should be performed by qualified service
personnel.
• Do not apply more than the rated voltage, as marked on the Meter,
between the
terminals or between any terminal and earth ground.
• While in IEC Measurement Category II environments, do not apply
voltages above 600 V ac to the input of the Meter. See "Description of IEC
61010 Measurement
Categories" later in this manual.
•
Always use the power cord and connector appropriate for the voltage and
outlet of the country or location in which you are working .
•
Always use a power cord with a ground connection and ensure the
ground is properly connected to the power distribution system.
• Remove test leads from the Meter before opening the case.
• Never remove the
cover or open the case of the Meter without first
removing it from the main power source.
• Use
caution when working with voltages above 30 V ac rms, 42 V ac peak,
or 42 V dc. These voltages pose a shock hazard.
• Use
only the replacement fuse(s) specified by the manual.
• Use the
proper terminals, function, and range for your measurements.
• Do not operate the Meter around explosive gas, vapor, or dust.
• When using probes, keep your fingers behind the finger guards .
•
When making electrical connections, connect the common test lead
before
connecting the live test lead; when disconnecting, disconnect the
live test lead before disconnecting the common test lead.
•
Disconnect circuit power and discharge all high-voltage capacitors before
testing resistance, continuity, diodes, or capacitance.
• Before
measuring current, check the Meter's fuses and turn OFF power to
the
circuit before connecting the Meter to the circuit.
• When servicing the Meter, use only specified replacement parts.
•
To prevent damage to the Meter, do not change the position of the
Front/Rear
switch while signals are applied to either the front or rear input
terminals.
4

Symbols and Terms
The following tenns and safety and electrical symbols may appear in the manual or on
the product:
A
&& Warning statement identifies conditions or practices that could result in injury
or death.
A
&. Caution statement identifies conditions or practices that could result in damage to
the
Meter or equipment to which it is connected.
&& Warning
To avoid electric shock, personal injury, or death, carefully read
the information under "General Safety Summary" before
attempting to install, use, or service the Meter.
Safety and Electrical Symbols
•
n Symbol Description Symbol Description
& Risk of danger. Important
information. See manual. @ Display
ON I OFF and Meter reset.
&.
Hazardous voltage. Voltage> 30 V
dc or ac peak might be present.
~
Earth ground
......
AC (Alternating Current)
-u-
Capacitance
-
---
DC (Direct Current)
+I-
Diode
......
or
:::::::
---
AC or DC (Alternating or Direct
Current)
-E3-
Fuse
11111
Continuity test or continuity beeper
tone n Digital signal
t Potentially hazardous voltage
\r
Maintenance or Service
[QI
Double insulated k Static awareness. Static discharge
can damage parts.
CAT II
Measurement Category
II is for
measurements performed
on
circuits directly connected to the
low voltage installation.
CAT I Measurement Category I
is for
measurements not directly
connected to mains.
5

I
•
DMM4040 and 4050
Safety and Installation Instructions
Description of IEC 61010 Measurement Categories
The lEC 61010 safety standard defines four Overvoltage (Installation) Categories (CAT I
to
CAT IV) based on the magnitude of danger from transient impulses as shown in Figure
1.
CAT I
Electronic
CAT II CAT III
Appliances, I MC Panels, et c.
PCs, TVs
Service
Enlrance
Serv
ic e
Enl
ra nce
CAT IV
------1
Meier
Underground Service
I
OUl bu il d in g
Transformer Oulbui
ldi ng
Meier
Underground Service
I •
•
caUtJ wh s.c ps
Figure 1. IEC 61010 Measurement Category (CAT) Levels
The lEC 61010 Measurement CAT level indicates the level of protection the instrument
provides against impulse withstand voltage.
CAT I equipment is designed to protect against transients from high-voltage, low-energy
sources, such as electronic circuits or a copy machine.
CAT II equipment is designed to protect against transients from energy-consuming
equipment supplied from the fixed installation, such as TVs, PCs , portable tools, and
other household appliances.
CAT III equipment is designed to protect against transients in equipment in fixed
equipment installations, such as distribution panels, feeders and short branch circuits, and
lighting systems in large buildings.
CAT IV equipment is designed to protect against transients from the primary supply
level, such as an electricity meter
or an overhead or underground utility service.
~
•
•
a
6

Compliance Information
This section lists the EMC (electromagnetic compliance), safety, and environmental
standards with which the instrument complies.
EMC Compliance
EC Declaration of Conformity-EMC
Meets intent of Directive 2004 / 108IEC for Electromagnetic Compatibility. Compliance was
demonstrated to the following specifications as listed
in the Official Journal of the European
Communities:
EN 61326-1 2006, EN 61326-2 2006. EMC requirements for electrical equipment for
measurement, control, and laboratory use.
1, 2. 3
• CISPR 11 :2003. Radiated and conducted emissions, Group 1, Class A
• IEC 61000-4-2:200
l. Electrostatic discharge immunity
• IEC 61000-4-3:2002. RF electromagnetic field immunity 4
•
-• IEC 61000-4-4:2004. Electrical fast transientlburst immunity
• IEC 61000-4-5:200l. Power line surge immunity
• IEC 61000-4-6:2003. Conducted RF immunity 5
• IEC 61000-4-11:2004. Voltage dips and interruptions immunity 6, 7
EN 61000-3-2:2006. AC power line harmonic emissions.
EN 61000-3-3:1995. Voltage changes, fluctuations, and flicker.
European Contact.
Tektronix UK, Ltd.
Western Peninsula
Western Road
Bracknell, RG
12 lRF
j United Kingdom
This product is intended for use in nonresidential areas only, Use in residential areas may cause electromagnetic
interference,
Emissions which exceed the
lev els required by this standard may occur when this equipment is cormected to a test
object.
To ensure compliance with the EMC standards listed here, high quality shielded interface cables should be used.
The tolerance
of the 100uADC, I OmADC ranges while subjected to the test field (3 Vim over the frequency range
of80 MHz to I GH z, 1.4 GHz to 2.0 GH z, and IVim from 2.0 GHz to 2.7 GHz, with 80 % amplitude modulation
at I kHz) can increase by +1- (0. 06 % of range) over the frequency range of 1.7 -1.9GHz. (IEC 61000-4-3),
The tolerance
of the 100uADC, 10mADC ranges wh i Ie subjected to the injected test signal (3 V rms over the
frequency range
of 150 kHz to 80 MHz, with 80 % amplitude modulation at I kHz) can increase by +1 -(0.08% of
range) at the frequency range of20 -50MHz. (lEC 61000-4-6).
6 Performance Criterion C applied
at the 70 %/ 25 cycle Voltage-Dip and the 0 0/01 250 cycle Voltage-Interruption test
levels (IEC 61000-4-11).
Instrument rebooting may
be experienced where the EUT takes approximately 18 seconds to recover from IEC
61000-4-11 transient immunity test.
7

DMM4040 and 4050
Safety and Installation Instructions
Australia / New Zealand Declaration of Conformity -EMC
Complies with the EMC provision of the Radioconununications Act per the following
standard,
in accordance with ACMA:
CISPR 11 :2003. Radiated and Conducted Emissions, Group I, Class A, in accordance
with
EN 61326-1 :2006 and EN 61326-2-1 :2006.
Safety Compliance
EC Declaration of Conformity -Low Voltage
Compliance was demonstrated to the following specification as listed in the Official
Journal
of the European Communities:
Low Voltage Directive
2006 / 95 / EC.
EN 61010-1: 2001. Safety requirements for electrical equipment for
measurement control and laboratory use.
u.s Nationally Recognized Testing Laboratory Listing
ISA-82.02.01. Safety Standard for Electrical and Electronic Test, Measuring ,
Controlling and Related Equipment -- General Requirements.
Canadian Certification
CAN/CSA-C22.2 No. 61010-1:2004. Safety requirements for electrical
equipment for measurement, control, and laboratory use.
Part I.
•
Additional Compliances
IEC 61010-1: 2001. Safety requirements for electrical equipment for •
measurement, control, and laboratory use. •
ANSllUL 61010-1:2004, 2nd Edition. Standard for electrical measuring and
test equipment.
Equipment Type
Test and measuring. •
Safety Class
Class I - grounded product.
Pollution Degree Description
A measure of the contaminants that could occur in the environment around and within a
product. Typically the i.nternal
environment inside a product is considered to be the same
as the external. Products should be used only in the environment for which they are rated.
• Pollution Degree
I. No pollution or only dry, nonconductive pollution occurs.
Products in this category are generally encapsulated, hermetically sealed, or
located in clean rooms.
• Pollution Degree 2. Normally only dry, nonconductive pollution occurs.
Occasionally a temporary conductivity that is caused by condensation must be
expected. This location
is a typical officelhome environment. Temporary
condensation occurs only when the product is out of service.
8

II
• • Pollution Degree
3. Conductive pollution, or dry, nonconductive pollution that
becomes conductive due to condensation. These are sheltered locations where
neither temperature nor humidity
is controlled. The area is protected from direct
sunshine, rain, or direct wind.
• Pollution Degree 4. Pollution that generates persistent conductivity through
conductive dust, rain,
or snow. Typical outdoor locations.
Pollution Degree
Pollution Degree 2 (as defined in IEC 610I0-1). Note: Rated for indoor use only.
Measurement Overvo/tage Categories
CAT I - 1000V I CAT II -600V
Environmental Considerations
This section provides information about the environmental impact of the product.
• Product End-of-Life Handling
Observe the following guidelines when recycling an instrument or component:
•
Equipment Recycling
Production of this equipment required the extraction and use of natural resources. The
equipment may contain substances that could be harmful to the environment or human
health
if improperly handled at the product's end oflife. In order to avoid release of such
substances into the environment and to reduce the use
of natural resources, we encourage
you to recycle this product
in an appropriate system that will ensure that most of the
materials are reused
or recycled appropriately.
This symbol indicates that this product complies with the applicable European Union
requirements according to Directives 2002/96IEC and 2006/66IEC on waste electrical
and electronic equipment (WEEE) and batteries.
For information about recycling options,
check the Support/Service section
of the Tektronix Web site (www.tektronix.com).
Restriction of Hazardous Substances
This product has been classified as Monitoring and Control equipment, and is outside the
scope
of the 2002/95IEC RoHS Directive.
Perchlorate Materials
This product contains one or more type CR lithium batteries. According to the state of
California, CR lithium batteries are classified as perchlorate materials and require special
handling. See www.dtsc.ca.govlhazardouswaste/perchlorate for additional information.
9

DMM4040 and4050
Safety and Installation Instructions
Unpacking and Inspecting the Meter
Every care is taken in the choice of packing material to ensure that your Meter will reach
you in perfect condition.
If the Meter has been subject to excessive handling in transit,
there may be visible external damage to the shipping carton. In the event of damage , keep
the shipping container and packing material for the
carrier's inspection.
Carefully unpack the Meter from its shipping container and inspect the contents for
damaged or missing items. If the Meter appears damaged or something is missing,
contact the carrier and Tektronix immediately.
Save the container and packing material in
case you have to return the Meter.
Storing and Shipping the Meter
To prepare the Meter for storage or shipping, use the original shipping container if
possible, as it provides shock isolation for normal handling operations. If the original
shipping container
is not available, use a box that is 17.5 x 15 .5 x 8.0 inches, with
cushioning material that fills the space between the Meter and the sides of the box.
To store the Meter, place the box under cover
in a location that complies with the storage
environment specifications described in the "General Specifications" section later
in this
manual.
Power Considerations
The Meter operates on varying power distribution standards found throughout the world
and
must be set up to operate on the line voltage that will power it. The Meter is packed
ready for use with a line voltage detennined at the time of ordering. If the selected line
voltage does
not match the power that the Meter will be plugged into, the Meter's line-
voltage setting must be changed and replacement
of the line fuse may be required.
Selecting the
Line Voltage
The
Meter operates on four different input line Voltages. The selected line-voltage setting
is visible through the window in the line-fuse holder on the Meter's rear panel.
I. Unplug the
power cord.
2. Insert a small screwdriver blade into the narrow recess to the left
of the fuse
holder and pry it to the right until the holder pops out. See Figure 2.
3. Remove the voltage-selector block from the fuse holder.
4. Rotate the selector block until the desired voltage rating faces outward.
5. Replace the selector block back into the fuse holder.
6. Install the fuse holder back into the Meter and reconnect the power cord.
Changing the line-voltage setting may require a different line-power fuse for proper
operation.
10

I
"
•
•
•
I
ri
Replacing the Fuses
•
I
I
I
•
!
It
i
I The
Meter uses one fuse to protect the line-power input and two fuses to protect current-
• 1\
measurement inputs.
•
I • Line-Power Fuse
The Meter has a line-power fuse in series with the power supply. Table 1 indicates the
proper fuse for each
of the four line-voltage selections. The line-power fuse is accessed
through the
rear panel.
I. Unplug the power cord.
2. Insert a small screwdriver blade into the narrow recess to the left of the fuse
holder and pry it to the right until the holder
pops out. See Figure 2.
3. Remove the fuse and replace
it with a fuse of an appropriate rating for the
selected line-power voltage. See Table I.
4. Replace the selector block back into the fuse holder.
&& Warning
To avoid electric shock or fire, do not use makeshift fuses or
short-circuit the fuse holder.
Table 1. Line Voltage to Fuse Rating
Line Voltage Selection Fuse Rating
100/120
0.25 A, 250 V (slow blow)
220/240
0.125 A, 250 V (slow blow)
eu e20.eps
Figure
2. Replacing the Line·Power Fuse
11

DMM4040 and 4050
Safety and Installation Instructions
Current-Input Fuses
The 400 rnA and 10 A inputs are protected by user-replaceable fuses.
•
The 400 rnA input is protected by a fuse (F2) rated at 440 rnA, 1000 V (fast
blow), 10,000 A minimum breaking capacity.
•
The 10 A input is protected by a fuse (Fl) rated at 11 A, 1000 V (fast blow),
10,000 A
minimum breaking capacity.
&& Warning
For protection against fire or arc flash, replace a blown fuse
with a fuse of an identical rating.
To test the current-input fuses:
I.
With the Meter powered up, plug a test lead into the VQ+t--jI-III1) connector.
2. Press i n] .
3. Insert the other end of the test lead into the 400 rnA input connector.
If the fuse is good, the Meter will read less than 200 Q. If the fuse is blown, the
Meter will read (I V e r· loa d.
4. Remove the probe from the 400 rnA connector and insert into the lOA
connector.
If the fuse is good, the Meter will read less than 1 Q. If the fuse is blown, the
Meter wi 11 read 0 \) e r· loa d .
&& Warning
To avoid electric shock, remove the power cord and any test
leads from the Meter before opening the current-input fuse
access door.
To replace the current-input fuses:
1. Unplug the power cord.
2. Turn the Meter upside down.
3.
Remove the retaining screw on the fuse access door. See Figure 3. -
•
4.
Remove the protective cover from the fuse holders by slightly depressing the
back edge of the cover to unlatch it from the printed circuit board. Pull up on the
back edge of the cover and remove it from the fuse compartment.
5. Remove the defective fuse and replace it with a fuse of an appropriate rating. See
Table 1.
6. Replace the protective cover by pushing it over the fuses while aligning the
catches with the holes in the printed circuit board. Press the cover down until the •
catches engage the printed circuit board.
7. Replace the fuse access door and install the retaining screw. •
•
•
12

-'
II
'I
8
p
•
I
•
•
j
Bottom front
left corner
Figure
3. Replacing the Current-Input Fuses
13
