Teledyne DALSA Piranha PC-30-02K80-00-R User manual

Piranha Color Camera 1
Piranha Color
Trilinear Camera
PC-30-02K80-00-R
PC-30-02K60-00-R
PC-30-04K80-00-R
PC-30-04K60-00-R
Camera User’s Manual 03-032-10211-08 3-Jun-11

Piranha Color Camera 2
© 2011 Teledyne DALSA. All information provided in this manual is believed to be
accurate and reliable. No responsibility is assumed by Teledyne DALSA for its use.
Teledyne DALSA reserves the right to make changes to this information without notice.
Reproduction of this manual in whole or in part, by any means, is prohibited without
prior permission having been obtained from Teledyne DALSA.
About Teledyne Technologies and Teledyne DALSA, Inc.
Teledyne Technologies is a leading provider of sophisticated electronic subsystems,
instrumentation and communication products, engineered systems, aerospace engines,
and energy and power generation systems. Teledyne Technologies’ operations are
primarily located in the United States, the United Kingdom and Mexico. For more
information, visit Teledyne Technologies’ website at www.teledyne.com.
Teledyne DALSA, a Teledyne Technologies company, is an international leader in high
performance digital imaging and semiconductors with approximately 1,000 employees
worldwide, headquartered in Waterloo, Ontario, Canada. Established in 1980, the
company designs, develops, manufactures and markets digital imaging products and
solutions, in addition to providing MEMS products and services. For more information,
visit Teledyne DALSA’s website at www.teledynedalsa.com.
Support
For further information not included in this manual, or for information on Teledyne
DALSA’s extensive line of image sensing products, please contact:
North America
605 McMurray Rd
Waterloo, ON N2V 2E9
Canada
Tel: [phone]
Fax: [phone]
www.teledynedalsa.com
[e-mail]
[e-mail]
Europe
Breslauer Str. 34
D-82194 Gröbenzell (Munich)
Germany
Tel: +49 - 8142 –46770
Fax: +49 - 8142 –467746
www.teledynedalsa.com
[e-mail]
[e-mail]
Asia Pacific
Ikebukuro East 13F
3-4-3 Higashi-Ikebukuro
Toshima-ku, Tokyo 170-0013
Japan
Tel: [phone]
Fax: [phone] (fax)
www.teledynedalsa.com
[e-mail]
[e-mail]

Piranha Color Camera 3
Contents
Features and Specifications 5
1.0 Introduction 5
1.1 Camera Performance Specifications 5
1.2 Image Sensor 11
1.3 Responsivity 12
Hardware Interface: Connectors and Timing 13
2.1 Installation Overview 13
2.2 Input/Output Connectors and LED 13
2.3 Camera LED 14
2.4 Power Connector 14
2.5 Camera Link Data Connector 15
2.6 Camera Timing 15
Software Interface: Configuring the Camera 21
3.1 First Power Up Camera Settings 21
3.2 Rebooting the Camera 22
3.3 Baud Rate 22
3.4 Select Cable 22
3.5 Help 22
3.6 Sensor Output 24
3.7 Data Output 26
3.8 Set Color Correction 27
3.9 Camera Selection Variables 28
3.10 Exposure Control 29
3.11 Spatial Correction 33
3.12 Averaging Horizontal Pixels 35
3.13 Processing Chain Overview and Description 36
3.14 Analog Gain and Analog Offset 38
3.15 Flat Field Correction 41
3.16 Digital Gain and Background Subtract 48
3.17 Look-Up Tables 49
3.18 Saving, Loading and Restoring Settings 51
3.19 Diagnostics 57
Optical and Mechanical Considerations 69
4.1 Mechanical Interface 69
4.2 Lens Mounts 70
4.3 Optical Interface 71
CCD Handling Instructions 73
5.1 Electrostatic Discharge and the CCD Sensor 73
5.2 Protecting Against Dust, Oil and Scratches 73
5.3 Cleaning the Sensor Window 74
Troubleshooting 75
6.1 Common Issues 75

Piranha Color Camera 4
Appendix A: ASCII Command Reference 79
Appendix B: Blue Correction Command 89
Appendix C: EMC Declaration of Conformity 91
Appendix D: Revision History 93
Index 95

Piranha Color Camera 5
Features and Specifications
1.0 Introduction
Camera Features
2048 or 4096 trilinear RGB line scan sensor.
Color spacing: 3 lines, center-to-center.
Forward and reverse scanning operation.
Maximum line rates of 22 kHz (2k60) and 32 kHz (2k80), or 12 kHz (4k60) and 17
kHz (4k80).
Programmable analog gain and offset.
FPN and PRNU correction.
White balancing algorithms.
Optional luminance output.
Spatial correction.
Anti-blooming.
Configurable base or medium Camera Link.
RoHS and CE compliant.
Applications
100% print inspection.
Electronics manufacturing inspection.
Postal and parcel sorting.
High performance document scanning and image lift.
Narrow and large web inspection.
High-end industrial inspection.
Models
Model Number
Description
PC-30-02k60-00-R
2k resolution, 3 taps at 60 MHz
PC-30-02k80-00-R
2k resolution, 3 taps at 80 MHz
PC-30-04k60-00-R
4k resolution, 3 taps at 60 MHz
PC-30-04k80-00-R
4k resolution, 3 taps at 80 MHz
1.1 Camera Performance Specifications
2k Model Performance Specifications
Test conditions and notes follow. All numbers measured at 12-bit unless specified
otherwise.
Sensor Features
Value
Imager Format
Trilinear CCD
Resolution
2048 pixels

Piranha Color Camera 6
Sensor Features
Value
Pixel Fill Factor
100%
Pixel Size
14 x 14 µm
Antiblooming
10x
Operating Ranges
Value
Minimum Line Rate
3.0 kHz (Operable to 1 Hz from external)
Maximum Line Rate
22.7 kHz (2k60) or 32.3 kHz (2k80)
Pixel RGB Throughput
Up to 80 Mps
Gain
-10 dB to +10 dB
Optical Interface
Value
Back Focal Distance
M72 Mount
19.56 mm (M72 x 0.75)
Sensor Alignment
x
y
z
z
± 50 µm
± 50 µm
± 250 µm
±0.2°
Lens Mount
M72 x 0.75, M42x1 and F-mount.
Mechanical Interface
Value
Camera Size
67 x 105 x 76 (l x h x w)
Mass
450 g
Power connector
Single voltage input (+12V to +15V) Hirose 6-pin circular male
Data connector
Camera Link MDR26F
Electrical Interface
Input Voltage
+12 to +15 volts
Power Dissipation
12 W
Operating Temperature (front
plate)
0 to 50 °C
Data Output Format
8 or 12 bits
Output Data Configuration
3 taps 8 bit
3 taps 12 bit
6 taps 8 bit

Piranha Color Camera 7
2k Model Operating Specifications
Test conditions and notes follow. All numbers measured at 12-bit unless specified
otherwise.
Operating Specifications
FFC
Unit
Color
-10dB
0dB
+10dB
Min
Typ
Max
Min
Typ
Max
Min
Typ
Max
Responsivity
Off
DN/(nJ/cm²)
R
76
228
240
252
758
G
127
380
400
420
1264
B
63
190
200
210
632
Responsivity
On
DN/(nJ/cm²)
R
95
285
300
315
948
G
158
475
500
525
1580
B
79
238
250
263
790
Dynamic Range
On
Ratio
RGB
758
240
76
Random Noise
On
DN rms
RGB
5.4
10
17
30
54
95
DC Offset
DN
RGB
180
180
180
FPN
Off
DN p-p
K60
RGB
25
55
137
K80
RG
K80
B*
60
140
450
FPN
On
DN p-p
RGB
10
PRNU global
Off
DN p-p
RGB
760
760
1000
PRNU pixel-to-pixel
Off
DN p-p
RGB
517
517
890
PRNU global
On
DN p-p
RGB
18
NEE
On
pJ/cm²
R
56.7
56.7
56.7
G
34
34
34
B
68
68
68
SEE
On
nJ/cm²
R
43.1
13.7
4.3
G
25.9
8.2
2.6
B
51.8
16.4
5.2
Saturation Output
Amplitude
DN
RGB
4095
4095
4095

Piranha Color Camera 8
4k Model Performance Specifications
Test conditions and notes follow. All numbers 12 bit unless specified otherwise.
Sensor Features
Value
Imager Format
Trilinear CCD
Resolution
4096 pixels
Pixel Fill Factor
100%
Pixel Size
10 x 10 µm
Antiblooming
100x
Operating Ranges
Value
Minimum Line Rate
3.0 kHz (Operable to 1 Hz)
Maximum Line Rate
12.1 kHz (4k60) or 17.6 kHz (4k80)
Pixel RGB Throughput
up to 80 Mps
Gain
-10 dB to +10 dB
Optical Interface
Value
Back Focal Distance
M72 Mount
91.56 mm (M72 x 0.75)
Sensor Alignment
x
y
z
z
±50 µm
±50 µm
±250 µm
±0.2°
Lens Mount
M72 x 0.75, M42x1 and F-mount.
Mechanical Interface
Value
Camera Size
67 x 105 x 76 mm (l x h x w)
Mass
450 g
Power connector
Single voltage input (+12V to +15V) Hirose 6-pin circular male
Data connector
Camera Link MDR26F
Electrical Interface
Input Voltage
+12 to +15 volts
Power Dissipation
12 W
Operating Temperature
(front plate)
0 to 50 °C
Data Output Format
8 or 12 bits
Output Data
Configuration
3 taps 8 bit
3 taps 12 bit
6 taps 8 bit

Piranha Color Camera 9
4k Model Operating Specifications
Test conditions and notes follow. All numbers measured at 12-bit unless specified
otherwise.
Operating Specifications
FFC
Unit
Color
-10dB
0dB
+10dB
Min
Typ
Max
Min
Typ
Max
Min
Typ
Max
Responsivity
Off
DN/(nJ/cm²)
R
38
114
120
126
379
G
63
190
200
210
632
B
32
95
100
105
316
Responsivity
On
DN/(nJ/cm²)
R
47
143
150
158
474
G
79
238
250
263
790
B
40
119
125
131
395
Dynamic Range
On
Ratio
RGB
758
240
76
Random Noise
On
DN rms
RGB
5.4
10
17
30
54
95
DC Offset
DN
RGB
180
180
180
FPN
Off
DN p-p
K60
RGB
40
87
275
K80
RG
K80
B*
60
140
450
FPN
On
DN p-p
RGB
10
PRNU global
Off
DN p-p
RGB
760
760
1000
PRNU pixel-to-pixel
Off
DN p-p
RGB
517
517
890
PRNU global
On
DN p-p
RGB
18
NEE
On
pJ/cm²
R
113.3
113.3
113.3
G
68
68
68
B
136
136
136
SEE
On
nJ/cm²
R
86
27.3
8.6
G
51.8
16.4
5.2
B
103.5
32.8
10.4
Saturation Output
Amplitude
DN
RGB
4095
4095
4095

Piranha Color Camera 10
Specification tables test conditions and notes 2k and 4k models:
Line Rate: 400 Hz.
Exposure Time (µs):
2K
4K
R
G
B
R
G
B
-10 dB
800
480
960
1600
960
1920
0 dB
253
152
304
506
304
607
+10 dB
80
48
96
160
96
192
Light Source: Broadband Quartz Halogen, BG-38, with 750nm cutoff filter
installed, Correction Color Temperature = 5300°K.
Ambient Test Temperature: 25°C.
Output swing (FFC off): 3220 DN includes 180 DN Dark Offset. (Range of 0 to
4095 DN).
Output swing (FFC on): 3800 DN.
All numbers are 12-bit unless specified otherwise.
The responsivity of each color is adjusted to achieve equal output.
Tested in Camera Link Mode clm 16.
PRNU specified at 75% of full swing.
General Notes:
Specifications apply to both 60 MHz and the 80 MHz camera models unless
indicated otherwise.
Specification with "FFC on" apply to the factory calibrated FFC. User calibrated
FFC may have a different affect on camera performance.
*FPN Notes:
2K80 cameras have increased FPN on the blue outputs between pixels 533 - 543
and 1506 - 1516.
4K80 cameras have increased FPN on the blue outputs between pixels 1045 - 1055
and 3042 - 3052.
Outside of this range, FPN meets the same specification as the other colors.

Piranha Color Camera 11
1.2 Image Sensor
The Piranha Color camera uses a trilinear CCD sensor with three lines of pixels: one
blue, one red and one green. Depending on your camera model, each line contains
either 2048 or 4096 pixels. As illustrated in the diagram below, the blue line has 2
outputs (taps), and the red and green lines have 4 outputs.
Figure 1: Sensor Block Diagram
Red Tap 2
Red Tap 1
Blue Tap 2
Blue Tap 1
2048 or 4096 pixels
Red Tap 4
Red Tap 3
Green Tap 2
Green Tap 1 Green Tap 4
Green Tap 3
Red Tap 2
Red Tap
1
Blue Tap
1
Green Tap 2
Green Tap
1
30 µm (4k)
42 µm (2k)
30 µm (4k)
42 µm (2k)
The three color lines are separated
30 µm (4k) or 42 µm (2k) apart
center to center.

Piranha Color Camera 12
1.3 Responsivity
2K Spectral Responsivity, FFC on
0
10
20
30
40
50
60
400 500 600 700 800 900 1000 1100
Wavelength (nm)
Responsivity [DN/(nJ/cm2)]
Blue
Green
Red
4K Spectral Responsivity, FFC on
0
5
10
15
20
25
30
400 500 600 700 800 900 1000 1100
Wavelength (nm)
Responsivity[DN/(nJ/cm2)]
Blue
Green
Red

Piranha Color Camera 13
Hardware Interface: Connectors
and Timing
2.1 Installation Overview
When installing your camera, you should take these steps:
1. Power down all equipment.
2. Following the manufacturer’s instructions, install the frame grabber (if applicable).
Be sure to observe all static precautions.
3. Install any necessary imaging software.
4. Before connecting power to the camera, test all power supplies. Ensure that all the
correct voltages are present at the camera end of the power cable. Power supplies
must meet the requirements defined in section 2.2.2 Power Connector.
5. Inspect all cables and connectors prior to installation. Do not use damaged cables
or connectors or the camera may be damaged.
6. Connect Camera Link and power cables.
7. After connecting cables, apply power to the camera.
8. Check the diagnostic LED. See the LED Status Indicator section below for an
LED description.
9. The camera powers on with a baud rate of 9600.
You must also set up the other components of your system, including light sources,
camera mounts, host computers, optics, encoders, and so on.
2.2 Input / Output Connectors and LED
The camera uses:
An LED to display the camera's status.
High-density 26-pin MDR26 connectors for Camera Link control signals, data
signals, and serial communications.
One 6-pin Hirose connector for power.
Camera Link Connector
Camera Link Connector
Power Connector

Piranha Color Camera 14
!
Note: Refer to the following sections for details on equipment recommendations and
camera connector information.
2.3 Camera LED
The camera is equipped with a red/green LED used to display the operational status of
the camera. The table below summarizes the operating states of the camera and the
corresponding LED states.
When more than one condition is active, the LED indicates the condition with the
highest priority. The fatal error state is accompanied by corresponding messages further
describing the problem.
Table 1: Diagnostic LED
Priority
Color of Status LED
Meaning
1
Flashing Red
Fatal Error. For example, camera temperature is too
high and camera thermal shutdown has occurred.
2
Flashing Green
Camera initialization or executing a long command
(e.g., flat field correction commands ccp or ccf).
During this state, any other sent command is ignored.
3
Solid Green
Camera is operational and functioning correctly and
ready to receive commands.
2.4 Power Connector
Figure 2: Hirose 6-pin Circular Male—Power Connector
Hirose 6-pin Circular Male
5
4
6
2
3
1
Mating Part: HIROSE
HR10A-7P-6S
The camera requires a single voltage input (+12 V to +15 V). The camera meets all
performance specifications using standard switching power supplies, although well-
regulated linear supplies provide optimum performance.
WARNING: When setting up the camera’s power supplies follow these guidelines:
Ensure +12 V to +15 V at the camera power input (after the voltage drop across
the power cable. This may mean that the power supply will have to provide a
voltage greater than the required camera voltage. For example, to achieve +12 V at
the camera, the power supply may need to be +12.5 V or greater.
Protect the camera with a fast-blow fuse between power supply and camera.
Do not use the shield on a multi-conductor cable for ground.
Keep leads as short as possible to reduce voltage drop.
Use high-quality linear supplies to minimize noise.
Use an isolated type power supply to prevent LVDS common mode range
violation.
Note: Camera performance specifications are not guaranteed if your power supply
does not meet these requirements.
Table 2: Hirose Pin Description
Pin
Description
Pin
Description
1
Min +12 to Max +15V
4
GND
2
Min +12 to Max +15V
5
GND
3
Min +12 to Max +15V
6
GND

Piranha Color Camera 15
2.5 Camera Link Data Connector
Figure 3: Camera Link MDR26 Connector
Input Signals, Camera Link
The camera accepts control inputs through the Camera Link MDR26F connector.
The camera ships in internal sync, internal programmed integration (exposure mode 2).
EXSYNC (Triggers Line Readout)
Line rate can be set internally using the serial interface. The external control signal
EXSYNC is optional and enabled through the serial interface. This camera uses the
falling edge of EXSYNC to trigger pixel readout.
Direction Control
You control the CCD shift direction through the serial interface. With the software
command, scd, you determine whether the direction control is set via software control
or via the Camera Link control signal on CC3.
Output Signals, Camera Link
These signals indicate when data is valid, allowing you to clock the data from the camera
to your acquisition system. These signals are part of the Camera Link configuration and
you should refer to the Camera Link Roadmap, available from the Knowledge Center
on our website here, for the standard location of these signals.
Clocking Signal
Indicates
LVAL (high)
Outputting valid line
DVAL (high)
Valid data (unused, tied high)
STROBE (rising edge)
Valid data
FVAL (high)
Outputting valid frame (unused, tied high)
The camera internally digitizes 12 bits and outputs the 8 MSB or all 12 bits
depending on the camera’s Camera Link operating mode.
2.6 Camera Timing
The Piranha Color camera uses a base or medium Camera Link interface.
Base Configuration
A base configuration uses 1 MDR26 connector and 1 Channel Link chip. The main
characteristics of the base configuration are:
Ports supported: A, B, C.
IMPORTANT:
This camera’s
data should be
sampled on the
rising edge of
STROBE.
i

Piranha Color Camera 16
Serializer bit width: 28.
Number of chips: 1.
Number of MDR26 connectors: 1.
Base Configuration
One Channel Link Chip + Camera Control + Serial
Communication
Camera
Connector
Right Angle
Frame Grabber
Channel Link
Signal
1
1
inner shield
14
14
inner shield
2
25
X0-
15
12
X0+
3
24
X1-
16
11
X1+
4
23
X2-
17
10
X2+
5
22
Xclk-
18
9
Xclk+
6
21
X3-
19
8
X3+
7
20
SerTC+
20
7
SerTC-
8
19
SerTFG-
21
6
SerTFG+
9
18
CC1-
22
5
CC1+
10
17
CC2+
23
4
CC2-
11
16
CC3-
24
3
CC3+
12
15
CC4+
25
2
CC4-
13
13
inner shield
26
26
inner shield
Base Configuration Timing
Each pixel output has 8 bits for each of the three colors (red, green, and blue).
Table 3: Base Configuration Video Data
Base Configuration
Connector 1
Maximum SSF8
CLM1
Bits2
Taps3
Lum4
Time5
Port6 A
Port B
Port C
SOT7
2k60
4k60
2k80
4k80
5
8
1
No
NA
R0-7
G0-7
B0-7
30
14.5
7.3
14.5
7.3
40
19.3
9.7
19.3
9.7
60
22.79
12.1
28.99
14.6
80
NA
NA
31.8
17.5
910
8
1
Yes
T0
R0-7
B0-7
NA
30
14.5
7.3
14.5
7.3
T1
G0-7
Y7-0
NA
40
19.3
9.7
19.3
9.7

Piranha Color Camera 17
1010
12
1
Yes
T0
R0-7
B8-11R8-11
B0-7
30
14.5
7.3
14.5
7.3
T1
G0-7
Y8-11G8-11
Y0-7
40
19.3
9.7
19.3
9.7
Figure 4: Base Configuration
EXSYNC
TBD
R1
R2
R3
R4 R5 R6
R7
Rn 1
Rn
Rn 2
Rn 3
Rn 4
G1
Gn 1
Gn
Gn 2
Gn 3
Gn 4
G2
G3 G4
G5 G6
G7
B1
Bn 1BnBn 2
Bn 3Bn 4B2
B3
B4
B5
B6
B7
RED Data
GREEN Data
BLUE Data
n = Number of pixels per line (2048 or 4096)
Data = 8 -bits/color/pixel
Line and Data Valid
Pixel Clock
40 or 80MHz
Medium Configuration
A medium configuration uses 2 MDR26 connectors and 2 Channel Link chips. The
main characteristics of the medium configuration are:
Ports supported: A, B, C, D, E, F.
Serializer bit width: 28.
Number of chips: 2.
Number of MDR26 connectors: 2.
Medium Configuration (Connector 2)
2 Channel Link Chips
Camera
Connector
Right Angle
Frame Grabber
Channel Link
Signal
Cable Name
1
1
inner shield
Inner Shield
14
14
inner shield
Inner Shield
2
25
Y0-
PAIR1-
15
12
Y0+
PAIR1+
3
24
Y1-
PAIR2-
16
11
Y1+
PAIR2+
4
23
Y2-
PAIR3-
17
10
Y2+
PAIR3+
5
22
Yclk-
PAIR4-
18
9
Yclk+
PAIR4+
6
21
Y3-
PAIR5-

Piranha Color Camera 18
Medium Configuration (Connector 2)
2 Channel Link Chips
Camera
Connector
Right Angle
Frame Grabber
Channel Link
Signal
Cable Name
19
8
Y3+
PAIR5+
7
20
terminated
PAIR6+
20
7
terminated
PAIR6-
8
19
Z0-
PAIR7-
21
6
Z0+
PAIR7+
9
18
Z1-
PAIR8-
22
5
Z1+
PAIR8+
10
17
Z2-
PAIR9+
23
4
Z2+
PAIR9-
11
16
Zclk-
PAIR10-
24
3
Zclk+
PAIR10+
12
15
Z3-
PAIR11+
25
2
Z3+
PAIR11-
13
13
inner shield
Inner Shield
26
26
inner shield
Inner Shield
Notes:
*Exterior Overshield is connected to the shells of the connectors on both ends.
**3M part 14X26-SZLB-XXX-0LC is a complete cable assembly, including connectors.
Unused pairs should be terminated in 100 ohms at both ends of the cable.
Inner shield is connected to signal ground inside camera.

Piranha Color Camera 19
Medium Configuration Timing
Medium Configuration
Connector 1
Connector 2
Maximum SSF8
CLM1
Bits2
Taps3
Lum4
Port6 A
Port B
Port C
Port D
Port E
Port F
SOT7
2k60
4k60
2k80
4k80
14
8
2
No
RA0-7
GA0-7
BA0-7
RB0-7
GB0-7
BB0-7
60
22.7
12.1
28.6
14.5
80
NA
NA
31.8
17.5
15
8
1
Yes
R0-7
G0-7
B0-7
Y0-7
NA
NA
30
14.5
7.3
14.5
7.3
40
19.3
9.7
19.3
9.7
60
22.7
12.1
28.9
14.6
80
NA
NA
31.8
17.5
16
12
1
Yes
R0-7
B8-11
R8-11
B0-7
Y0-7
G0-7
Y8-11
G8-11
30
14.5
7.2
14.5
7.3
40
19.3
9.7
19.3
9.7
60
22.7
12.1
28.9
14.6
80
NA
NA
31.8
17.5
CLM 14 Pixels are Interleaved
Port
Sequence
1
2
3
4
5
6
7
8
9
10
A
RedA
R1
R3
R5
R7
R9
R11
R13
R15
R17
R19
B
GreenA
G1
G3
G5
G7
G9
G11
G13
G15
G17
G19
C
BlueA
B1
B3
B5
B7
B9
B11
B13
B15
B17
B19
D
RedB
R2
R4
R6
R8
R10
R12
R14
R16
R18
R20
E
GreenB
G2
G4
G6
G8
G10
G12
G14
G16
G18
G20
F
BlueB
B2
B4
B6
B8
B10
B12
B14
B16
B18
B20
Figure 5: Medium Configuration (8 Bits/Color/Pixel)
EXSYNC
TBD
Line and Data Valid
Pixel Clock
40MHz
R1
R3
R5
R7 R9 R11
R13
Rn 1
Rn
Rn 3
Rn 5
Rn
-7
G1
Gn - 1
Gn Gn 3
Gn 5 Gn 7
G3
G5 G7
G9 G11
G13
B1
Bn 1Bn
Bn 3
Bn 5
Bn 7 B3 B5
B7
B11 B13
RED Data 1
BLUE Data 1
GREEN Data 2
GREEN Data 1
G2 Gn 2GnGn 4 Gn 6Gn 8
G4 G6 G8 G10 G12 G14
RED Data 2
B2 Bn 2Bn
Bn 4
Bn 6
Bn 8
B4 B6 B8 B10 B12 B14
R2 R4 R6 R8 R10 R12 R14 Rn 2Rn
Rn 4
Rn 6
Rn 8
B9

Piranha Color Camera 20
Figure 6: Medium Configuration (12 Bits/Color/Pixel)
EXSYNC
TBD
R1
R2
R3
R4 R5 R6
R7
Rn 1
Rn
Rn 2
Rn 3 Rn 4
G1
Gn 1
Gn Gn 2
Gn 3
Gn 4
G2
G3 G4
G5 G6
G7
B1
Bn 1BnBn 2
Bn 3Bn 4B2
B3
B4
B5 B6 B7
RED Data
GREEN Data
BLUE Data
n = Number of pixels per line (2048 or 4096)
Line and Data Valid
Pixel Clock
40 or 80MHz
Notes for Base and Medium Configuration Timing:
1. CLM: Camera Link Mode.
2. Bits: Number of bits per pixel.
3. Taps: Number of camera link taps per color.
4. Luminance: Indicates if a tap constructed from the RGB using the SCC command
is output.
5. Time: Time multiplex interval.
6. Port: Camera Link port.
7. SOT: Output throughput [mega-pixels / second / color].
8. Maximum SSF: Maximum line rate [kHz] possible in this mode (may be reduced by
SBH, ELS and SRM).
9. The maximum line rate for SOT 60 for the 80 model is greater than the 60 model as
a result of the different readout clocking scheme.
10. Time multiplexing (CLM 9 and 10) is not supported in all frame grabbers.
11. Measurements were made using command settings els 0 and srm 2.
