Teledyne QuantaPro CP-10-04M02-50-L User manual

CP-10-04M02-50-L
QuantaPro 4M CAMERA USER MANUAL
CameraLink Version
Document #:03-032-20139
Teledyne DALSA, Inc.
605 McMurray Road
Waterloo, Ontario
Canada N2V 2E9
www.envision.co.kr •Supporting your Vision
(주)앤비젼 서울시 금천구 가산동 550-1 IT캐슬 1동 603호 (153-768)
Tel. [phone] Fax. [phone] e-mail. [email protected]

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 2 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
TABLE OF CONTENTS
1INTRODUCTION...............................................................................................................................................................3
1.1 DOCUMENT REVISION HISTORY....................................................................................................................................3
2CP-10-04M02-50-L CAMERA FEATURES.....................................................................................................................3
3CAMERA HARDWARE REQUIREMENTS ..................................................................................................................4
3.1 DC POWER INPUT..........................................................................................................................................................4
3.2 EXPOSURE OUTPUT.......................................................................................................................................................5
3.3 EXTERNAL TRIGGER INPUT...........................................................................................................................................5
3.4 CAMERA LINK ..............................................................................................................................................................6
3.5 MICRO CODE UPDATE ...................................................................................................................................................7
4CAMERA CONTROL SOFTWARE OPERATION .......................................................................................................8
4.1 USER COMMANDS.........................................................................................................................................................9
4.1.1 Summary..................................................................................................................................................................9
4.1.2 Commands Detail Description................................................................................................................................9
5MECHANICAL INTERFACE ........................................................................................................................................15
5.1 CAMERA MOUNTING ..................................................................................................................................................15
5.2 LIGHT SHIELD .............................................................................................................................................................15
6CAMERA WORKING ENVIRONMENT......................................................................................................................16

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 3 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
1Introduction
This document will describe electrical and mechanical interface requirements for the QuantaPro Camera
Link version camera.
1.1
Document Revision History
Revision
Date
Section
Description
00
Feb 23, 2012
---
Original Release
2CP-10-04M02-50-L Camera Features.
Front illuminated Full-Frame TEC Cooled area mode CCD.
24 x 24 µm Pixel size.
2084 (H) x 2084(V) Active Pixels.
50.2 x 50.2 mm Active Sensor Area.
Low Dark Current < 1 electron/pixel/second.
Camera Link interface for image data output and RS232 control communication.
One tap 10MHz pixel rate sensor signal output.
16 bit ADC data resolution.
Binning mode available for: 1x1, 2x2, 4x4, 8x8 and 16 x16.
Camera trigger mode: Internal/External/Single Trigger by Command.
Exposure output signal: TTL.
Programmable Exposure time: 1ms to 3,600,000 ms (1 hour)
Accuracy from Exsync trigger to Exposure output < 1 µs.
Frame rate > 2 Hz

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 4 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
3Camera Hardware Requirements
Figure 1 Connectors on the rear plate
3.1 DC power input
The QuantaPro camera needs a 24V/3A DC power supply (Not supplied with the camera). The power
cable is shown in Figure 2 below, with the pins in Table 1. The length of the cable will depend on the
customer’s system; however, it should not exceed 10 meters.
Figure 2 QuantaPro Power Cable

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 5 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
Table 1 Power Cable Pins Definitions
3.2 Exposure Output
The camera outputs a TTL exposure control signal from the SMA socket on the camera rear plate to
customer optical system. The exposure cable could be a 26 AWG coax cable which one end with SMA for
camera side and another end will select a connector which mates to the shutter device. The exposure coax
cable center pin is signal and the shield case is GND. When exposure signal is TTL high, the camera is in
exposure. When exposure signal is TTL low, the camera should be in dark and send one frame image data
via camera link cable.
Figure 3 Exposure cable end with SMA for Camera
3.3 External Trigger Input
The QuantaPro camera has three statuses. See Figure 4. At the pink area, the camera sensor is no charge
transfer in pixels. The green area is exposure time there is no pixel charge transfer too. The yellow area is
image read out time the all pixels charge will transfer to output. During the charge transfer time, the
camera should be in dark with no illumination in any wavelength light.
The frame trigger signal is the starter for grabbing an image. In different trigger mode, the frame trigger
signal is come from different source. The frame trigger signal is rise edge active.
When cameras run at external trigger mode, the camera needs a TTL frame trigger signal from the system.
The system can control the camera exposure start at a time point. The Frame Trigger signal rising edge to
exposure signal rising edge delay tolerance accuracy is less then 1 µs. The delay ‘B’ in Figure 4 is
considered the fixed system response delay. The Exsync coax cable is end with SMA connector to the
camera side which similar with the exposure cable and another end should mate to the system external
trigger output device. The external trigger signal can also get from the Camera link CC1.

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 6 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
Figure 4 QuantaPro Camera Statuses
3.4 Camera Link
The MDR 26 connector is for camera to connect to the DALSA CORECO X64 base frame grabber board
in the PC via a standard camera link cable. This camera link interface includes the image date link, RS232
port and CC1 external trigger input. Sapera - CamExpert can control the camera and snap the image. The
camera active pixels are 2084 x 2084 in no binning mode. User can set the display window pixel numbers
in below Figure 5 for own application.
Figure 5 Sapera CamExpert Camfiles setting
The Camera Link version camera is using RS232 port in Coreco X64 card. The RS232 port is provided for
communications to the microcontroller in camera. Select the correct serial port from your PC. Using the
HyperTerminal or DALSA Terminal, user can set the camera working mode such as trigger mode, binning
mode, exposure time, TEC temperature, getting camera information, setting OS ADC gain and save
settings. The default port setting is shown in Figure 6. User can change the RS232 baud rate in camera if
need.
B
Frame Trigger … …
Exposure Output … …
Image Output … …
C
D
D
A

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 7 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
Figure 6 RS232 Port Setting
3.5 Micro code update
(This section commands are for micro code renew only. Don’t use them in normal case.)
Use HyperTerminal
Change baudrate to 9600: SBR 9600
Change to boot loader: PJB
Speed up (or you will be waiting a long time): S 115200
Change HyperTerminal rate
Request upload: U
Send first file using HyperTerminal: Transfer | Send File...
Select file and Protocol "XModem"
Click "Send" and wait until done - click "Close"
Press "Enter" to get "OK>" prompt.
Send second file:
Request upload: U
Send second file using HyperTerminal: Transfer | Send File...
Select file
Click "Send" and wait until done - click "Close"
Press "Enter" to get "OK>" prompt.
Slow down: S 9600
Change HyperTerminal rate
Disable bootloader: D

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 8 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
4Camera Control Software Operation
Power on camera and connect the Camera Link cable from camera to CORECO X64 Card. If necessary,
configure a serial port on your frame grabber, Run HyperTerminal you will see the OK> prompt. Type
‘h’ will list all the commands and give a summary of their parameters. Shown as in Figure 7.
Figure 7 QuantaPro Text Commands GUI

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 9 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
4.1 User Commands
4.1.1 Summary
4.1.1.1 General Commands
GCM - Get Camera Model
GCP - Get all Camera Parameters
GCS - Get Camera Serial number
GCV - Get Camera Version, firmware version
H - Help
RC - Reset Camera
SBR - Set Baud Rate
4.1.1.2 Memory Commands
RFS - Restore Factory Settings
RUS - Restore User Settings
WUS - Write User Settings
4.1.1.3 Imaging Commands
SBH - Set Binning Horizontal
SBV - Set Binning Vertical
SET - Set Exposure Time
SFG - Set Frame Gap
SOA - Set OS ADC
SRM - Set Trigger Mode
TRG - Trigger
4.1.1.4 TEC Control Commands
STC - Set TEC Control
STE - Set TEC Enable
STV - Set TEC Voltage
4.1.2 Commands Detail Description
4.1.2.1 GCM –Get Camera Model
This command returns camera model.
OK>gcm
Camera Model No.: CP-10-04M02-50
OK>
4.1.2.2 GCP - Get Camera Parameters
This command returns all current camera configuration parameters.

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 10 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
OK>gcp
C A M E R A S E T T I N G S:
Camera Model No.: CP-10-04M02-50
Camera Serial No.: 14006648
Firmware Design Rev.: 03-081-20098-00
CCI Version: 03-110-20122-00
UART Baud Rate: 115200
Hot side temperature: 34.0 C
Cool side temperature: -10.3 C
Trigger Mode: 0 (internal)
Exposure Time: 100 ms
Frame Gap: 100 ms
Horizontal Binning: 1
Vertical Binning: 1
TEC: enabled
TEC Voltage: 4.8 V
TEC Set Point: -10.0 C
TEC Period: 2 s
OS Gain: 2.0
OS Offset: 20.0 mV
OK>
4.1.2.3 GCS –Get Camera Serial
This command returns camera serial number.
OK>gcs
Camera Serial No.: 14006648
OK>
4.1.2.4 GCV –Get Camera Version
This command returns camera firmware version information.
OK>gcv
Firmware Design Rev.: 03-081-20098-00
CCI Version: 03-110-20122-00
OK>
4.1.2.5 H –Help
This command returns a list of valid commands, a short description, and their arguments. The
fields are: <mnemonic> <description> <parameter types> <valid range>
Parameter types are: M: member of a set, I: integer, F: floating point
OK>h

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 11 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
gcm get camera model
gcs get camera serial
gcv get camera version
h help
rc reset camera
rfs restore factory settings
rus restore user settings
sbr set baud rate m 9600/19200/57600/115200/
wus write user settings
gcp get camera parameters
sbh set binning horizontal m 1/2/4/8/16/
sbv set binning vertical m 1/2/4/8/16/
set set exposure time i 1-3600000
sfg set frame gap i 0-65535
soa set OS ADC ff 1-6:-300-300
stc set TEC control fi -50-50:0-600
ste set TEC enable i 0-1
stm set trigger mode i 0-4
stv set TEC voltage f 4.5-12
trg trigger
OK>
4.1.2.6 RC –Reset Camera
This command does a soft reset of the camera. The last saved user settings will be restored.
The current baud rate setting will be maintained.
OK>rc
Camera Initialization in progress, Please Wait ...
OK>
4.1.2.7 RFS –Restore Factory Settings
This command restores the settings to those set at DALSA.
OK>rfs
OK>
4.1.2.8 RUS –Restore User Settings
This command restores the settings to those last saved by the user with the WUS command.
OK>rus
OK>
4.1.2.9 SBH –Set Binning Horizontal
This command is used to set the horizontal binning factor.

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 12 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
Valid values are: 1, 2, 4, 8, and 16.
Example: set camera to x4 binning mode horizontal.
Syntax: SBH <factor>
OK>sbh 4
OK>
4.1.2.10 SBR –Set Baud Rate
This command is used to set the serial communications baud rate.
Valid values are: 9600, 19200, 57600, and 115200.
The camera always powers up at 9600.
Syntax: SBR <baud rate>
OK>sbr 9600
UART speed changed; Reinitialize terminal program with new speed
OK>
4.1.2.11 SBV –Set Binning Vertical
This command is used to set the vertical binning factor.
Valid values are: 1, 2, 4, 8, and 16.
Example: set camera to x8 binning mode in vertical
Syntax: SBV <factor>
OK>sbv 8
OK>
4.1.2.12 SOA –Set OS ADC
This command is used to configure the gain and offset of the sensor output. A different pair of
values is saved for each horizontal binning mode (although only the current values are
displayed in the GCP screen).
Valid gain range is: 1 to 6 times.
Valid offset range is: -300 to +300 mV.
Syntax: SOA <gain> <offset>
OK>soa 4.5 150
OK>

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 13 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
4.1.2.13 SET –Set Exposure Time
This command is used to set the exposure time in milliseconds.
Valid range is: 1 to 3,600,000 ms.
Example: set camera exposure time to 8 seconds.
Syntax: SET <time>
OK>set 8000
OK>
4.1.2.14 SFG –Set Frame Gap
This command is used to set the period (in milliseconds) between exposures when in internal
trigger mode (STM 0).
Valid range is: 1 to 65,535 ms.
Example: set camera for next exposure at 8 seconds after sending current image data.
Syntax: SFG <time>
OK>sfg 8000
OK>
4.1.2.15 STC –Set TEC Control
This command is used to configure the TEC temperature control. When configured, this
function will automatically adjust the TEC voltage to maintain the specified cool side
temperature. The control algorithm will also enable or disable the TEC as required. If the set
point temperature is higher than the stable temperature at the minimum voltage the
algorithm will enable and disable the TEC to maintain the set point. If the hot side of the TEC
is above 70 C, the algorithm will disable the TEC to prevent damage to the electronics.
Valid set point temperature range is: -50 to +50 C.
Valid period is: 0 to 600 seconds. If the period is 0 then the control algorithm will not run.
The recommended period is: 10 seconds.
Syntax: STC <set point> <period>
OK>stc -20 10
OK>
4.1.2.16 STE –Set TEC Enable
This command is used to enable the TEC (Thermo Electric Cooler). Use this command if you
are not using the temperature control algorithm (STC command) and are going to manually
set the TEC voltage with the STV command.
Note: the temperature control algorithm (STC command) will overwrite this setting if
necessary to maintain the temperature set point.

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 14 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
Argument: 1 to enable, 0 to disable
Syntax: STE <enable>
OK>ste 1
OK>
4.1.2.17 STM –Set Trigger Mode
This command is used to set the trigger mode.
Valid values are:
0. Internal trigger
- SET to set the exposure time, SFG to set the time between exposures
1. External, Camera Link CC1 trigger
- SET to set exposure time, CC1 to trigger a frame read
2. External, SMA trigger
- SET to set exposure time, SMA to trigger a frame read
3. Software trigger
- SET to set exposure time, TRG to trigger a frame read
4. Test Pattern
5. Protect safe mode
Syntax: STM <mode>
OK>stm 1
OK>
4.1.2.18 TRG –Trigger
Use this command in trigger mode 3 to start a single exposure and readout (grab a image).
OK>trg
OK>
4.1.2.19 WUS –Write User Settings
This command writes the current values of the settings to non-volatile memory. These
settings will be automatically loaded on power up. As well, they can be recalled at any time
with the RUS command.
OK>wus
OK>

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 15 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
5Mechanical Interface
This section of the document will present the mechanical interface to the QuantaPro camera.
5.1 Camera Mounting
The camera is mounted to the customer’s system using the mounting holes provided. The camera
dimensions and mount screw locates are shown in mechanical drawings. The camera has the mount holes
on three sides for customer mounting camera options. It is recommended that the camera be mounted on
one side (front plate or side plate) to a flat surface fixture. Please see the drawings below for details..
5.2 Light shield
The camera needs shield from lens to camera front plate. Any light leakage from outside of camera will
affect the image. (The Light shield is not include for camera delivery)

QuantaPro Camera User Manual
For Camera Link Module
Doc #: 03-032-20139
Revision: 00
Date: Feb 23, 2012
Page 16 of 16
***THIS IS AN UNCONTROLLED COPY OF A CONTROLLED DOCUMENT PRINTED 2/28/2012 4:50 PM***
The information contained herein is proprietary to TELEDYNE DALSA and is to be used solely for the purpose for which it is supplied.
It shall not be disclosed in whole or in part, to any other party, without the express permission in writing by TELEDYNE DALSA.
6Camera Working Environment
In general, to avoid water condensation it is necessary to have all parts of the camera ABOVE the
dew point at given relative humidity. Table 2 below shows dew point versus relative humidity and
temperature for normal atmospheric pressure.
Temperature,
deg Celsius
Relative humidity
at normal pressure, %
Dew point,
deg Celsius
40
90%
38.05
40
80%
35.89
40
70%
33.49
30
90%
26.17
30
80%
28.18
30
70%
23.94
20
90%
18.31
20
80%
16.45
20
70%
14.37
10
80%
6.71
10
70%
4.78
10
60%
2.59
10
50%
0.05
10
40%
-2.98
0
80%
-3.04
0
70%
-4.82
0
60%
-6.84
0
50%
-9.19
0
40%
-12.00
-10
80%
-12.79
-10
70%
-14.43
-10
60%
-16.30
-10
50%
-18.46
-10
40%
-21.06
-20
80%
-22.56
-20
70%
-24.07
-20
60%
-25.78
-20
50%
-27.77
-20
40%
-30.15
Table 2 DEW POINT VERSUS RELATIVE HUMIDITY
