TDS12021xx AURUS-4XL Touch panel
The AURUS features a hardened glass touch panel with 4 buttons. It comes in 4 different
colours: WHITE, BLACK, ALUMINUM GREY and GOLD.
The buttons have white LED lights and a click sound for clear and instant feedback.
Soft night light and a build-in IR make sure you command your AURUS in any circumstances.
The AURUS is mounted in a single wall-box TDS90000AT (brick walls) or TDS90000PB
(Plaster board walls) with screws or claws (claws included in package). To be placed in
vertical position but can also be placed in horizontal position.
TELETASK only uses exclusive safety-glass with ceramic printing, hardened at 800°C for all
AURUS family members.
APPLICATION
AUTOBUS compatible touch panel
CHARACTERISTICS
General
Solid safety-glass front plate, ceramic background printed and
thermal hardened.
4 capacitive sensitive buttons.
1 hidden “CLEAN” button.
Build-in infrared receiver for remote control (TDS12503).
Build-in temperature sensor for room temperature control (floor
heating, ventilation heating, traditional heating and air-
conditioning).
Buzzer.
Order numbers
TDS12021WH white
TDS12021BL black
TDS12021AU gold
TDS12021LG aluminium-grey
Cleaning
To temporary disable the touch buttons, press long in the
centre of the upper side.
Use only dry microfiber cloth. Never use liquids or solvents!
SETTINGS
Button functions
Via PROSOFT Suite
T° sensor functions supported starting with PROSOFT Suit
V3.2 or higher.
AUTOBUS address
Via two rotary switches “Tens” & “units”
Jumpers
Terminating resistor (supplied with the central unit). To be used
when the interface is at the physical end of the AUTOBUS
cable.
INSTALLATION
Standard mounting
To be mounted with included wall bracket in about any
standard single wall box.
Or order the TELETASK standard single wall box for brick walls
ref. TDS90000AT. For plaster board or other hollow walls order
ref. TDS90000PB.
To be placed in vertical position but can also be placed in
horizontal position.
To change the orientation after installation, place a
flat-head screw driver in the provided slot at the back of the
housing. A standard flat-head screw driver of 5x100mm
(3/16x4in.) is recommended.
Flush mounting
Use Flush mounting box TDS90030 for flat mounting. For
hollow walls this has to be combined with Alu frame TDS90031.
Rem.: Normal operation of the temperature sensor will be
disturbed with flush mounting.
On-wall mounting
Use the TDS90035 on-wall box in case of concrete, marble, …
walls, if the standard in-wall solution is not possible.
Sealed on-wall box
TDS90037 is to be used as a preventive action to discourage
unauthorized use of the touch panel and to protect against dust,
waterdrops, water sprays, ….
Supply voltage
12V (supplied by the AUTOBUS - minimum 9V).
CONNECTIONS
AUTOBUS
With dedicated connection set (included with the package).
POWER CONSUMPTION
Max. 32 mA
DIMENSIONS
Front plate
90W x 140H x 13D (mm) thickness on wall
NET | GROSS WEIGHT
0,200 kg | 0,295 kg
PACKAGING CONTENT
TDS12021xx
AUTOBUS connection set + terminating resistor
Wall bracket
ENVIRONMENTAL CONDITIONS
Storage (with no condensation or icing)
Temperature: -20°C to +65°C max.
Relative humidity: 5% to 85% max.
Operation (with no condensation or icing)
Temperature: 0°C to +50°C max.
Relative humidity: 5% to 80% max.
IP PROTECTION RATE
IP20
EN
TELETASK can’t be responsible for potential errors in the data sheets and technical documentation. Changes in the product features can be made at any time, without prior notice

Touch panels
©, TELETASK, GENT, 2023 42 Version July 2023
SCHEMATIC DRAWING
