GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 2 of 17
Disclaimer
The information contained in this document is the proprietary information of Telit
Communications S.p.A. and its affiliates (“TELIT”). The contents are confidential and
any disclosure to persons other than the officers, employees, agents or
subcontractors of the owner or licensee of this document, without the prior written
consent of Telit, is strictly prohibited.
Telit makes every effort to ensure the quality of the information it makes available.
Notwithstanding the foregoing, Telit does not make any warranty as to the
information contained herein, and does not accept any liability for any injury, loss or
damage of any kind incurred by use of or reliance upon the information.
Telit disclaims any and all responsibility for the application of the devices
characterized in this document, and notes that the application of the device must
comply with the safety standards of the applicable country, and where applicable,
with the relevant wiring rules.
Telit reserves the right to make modifications, additions and deletions to this
document due to typographical errors, inaccurate information, or improvements to
programs and/or equipment at any time and without notice. Such changes will,
nevertheless be incorporated into new editions of this application note.
Copyright: Transmittal, reproduction, dissemination and/or editing of this document
as well as utilization of its contents and communication thereof to others without
express authorization are prohibited. Offenders will be held liable for payment of
damages. All rights are reserved.
Copyright © Telit Communications SpA 2009.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 3 of 17
Contents
1. INTRODUCTION ....................................................................................................................................4
1.1. SCOPE .............................................................................................................................................4
1.2. AUDIENCE ........................................................................................................................................4
1.3. CONTACT INFORMATION,SUPPORT .....................................................................................................4
1.4. DOCUMENT ORGANIZATION ................................................................................................................5
1.5. TEXT CONVENTIONS ..........................................................................................................................5
1.6. RELATED DOCUMENTS .......................................................................................................................6
1.7. DOCUMENT HISTORY .........................................................................................................................6
2. OVERVIEW ............................................................................................................................................7
2.1. VIEW OF GC864-QUAD-C9...............................................................................................................7
3. SYSTEM CHARACTERISTICS ..............................................................................................................8
3.1. POWER SUPPLY REQUIREMENTS ........................................................................................................8
3.2. GC864-QUAD-C9 MECHANICAL DIMENSIONS .....................................................................................9
3.3. GC864-QUAD-C9 MODULE CONNECTIONS........................................................................................10
3.3.1. ZIF Connector Pin-Out...........................................................................................................10
3.3.2. STAT LED.............................................................................................................................11
3.3.3. VAUX Power Supply..............................................................................................................11
3.3.3.1. VAUX1 Power Output ..................................................................................................................... 11
3.4. CONNECTIVITY TO THE ZIF INTERFACE...............................................................................................12
3.5. SERIAL PORTS ................................................................................................................................13
3.5.1. UART connectivity – serial port ..............................................................................................13
3.6. AUDIO SECTION OVERVIEW...............................................................................................................13
3.7. EXTERNAL SIM HOLDER IMPLEMENTATION .........................................................................................13
4. MOUNTING THE GC864-QUAD-C9 .....................................................................................................14
5. CONFORMITY ASSESSMENT ISSUES...............................................................................................15
6. SAFETY RECOMMENDATIONS..........................................................................................................16
7. LIST OF ACRONYMS ..........................................................................................................................17

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 4 of 17
1. Introduction
The information presented in this document is believed to be accurate and reliable.
However, no responsibility is assumed by Telit Communications S.p.A. for its use,
nor any infringement of patents or other rights of third parties which may result from
its use. No license is granted by implication or otherwise under any patent rights of
Telit Communications S.p.A. other than for circuitry embodied in Telit products. This
document is subject to change without notice.
1.1. Scope
The scope of this document is to provide a hardware description of the Telit GC864-
QUAD-C9 module, which is based on the Telit GE864-QUAD module and, as such,
only the added functionalities of the design will be taken into consideration.
1.2. Audience
This document is intended for customers integrating the GC864-QUAD-C9 in their
project.
1.3. Contact Information, Support
For general contact, technical support, to report documentation errors and to order
manuals, contact Telit’s Technical Support Center (TTSC) at:
[e-mail]
[e-mail]
[e-mail]
[e-mail]
Alternatively, use:
http://www.telit.com/en/products/technical-support-center/contact.php
For detailed information about where you can buy the Telit modules or for
recommendations on accessories and components visit:
http://www.telit.com
To register for product news and announcements or for product questions contact
Telit's Technical Support Center (TTSC).
Our aim is to make this guide as helpful as possible. Keep us informed of your
comments and suggestions for improvements.
Telit appreciates feedback from the users of our information.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 5 of 17
1.4. Document Organization
This document contains the following chapters:
“Chapter 1: “Introduction” provides a scope for this document, target audience,
contact and support information, and text conventions.
“Chapter 2: “Overview”gives an overview of the features of the product.
“Chapter 3: “System Characteristics”describes in details the characteristics of the
product, providing information such as power supply requirements, mechanical
dimensions and interfaces specifics.
“Chapter 4: “Mounting the GC864-QUAD-C9”provides some recommendations to
follow while mounting the module onto the hosting application.
“Chapter 5: “Conformity Assessment Issues” provides some fundamental hints about
the conformity assessment that the final application might need.
“Chapter 6: “Safety Recommendation” provides some safety recommendations that
must be followed by the customer in the design of the application that makes use of
the GC864-QUAD-C9.
1.5. Text Conventions
Caution or Warning – Alerts the user to important points about integrating the
module, if these points are not followed, the module and end user equipment
may fail or malfunction.
Danger – This information MUST be followed or catastrophic equipment failure
or bodily injury may occur.
Tip or Information – Provides advice and suggestions that may be useful when
integrating the module.
All dates are in ISO 8601 format, i.e. YYYY-MM-DD.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 6 of 17
1.6. Related documents
a. GE864 and GC864 Product description, 80273ST10008a
b. GE864 Hardware User Guide, 1vv0300694
c. Telit’s GSM/GPRS Family Software User Guide, 1vv0300784
d. AT Commands Reference Guide, 80000ST10025a
e. SIM Holder Design Guides, 80000NT10001a
f. Audio Settings Application Note, 80000NT10007a
1.7. Document History
Revision
Date
Changes
Location
0
2009-04-22
First issue
Trieste

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 7 of 17
2. Overview
The GC864-QUAD-C9 module has been designed to expand the original
functionalities of the GE864-QUAD module, integrating it onto PCB equipment
providing an extra ZIF connector interface and extra features described in the
following paragraphs.
NOTICE:
The GC864-QUAD-C9 provides the same characteristics of the GE864-QUAD, as far
as Quad-Band EGSM 850/900/1800/1900Mhz GSM and GPRS Class 10
technologies support and over the air firmware update by means of Premium FOTA
Management.
For further integration details (e.g. SIM Card Connectivity details, Hardware
Commands, etc.) that may not be explained in this document, refer to the Telit
documentation as specified in the related documents list (paragraph 1.6).
2.1. View of GC864-QUAD-C9
Figure 1 shows the position of pin 1 and pin 40 on the ZIF connector.
Figure 1

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 8 of 17
3. System characteristics
3.1. Power Supply Requirements
The power supply circuitry and board layout are a very important part in the full
product design and they strongly reflect on the product overall performances.
Latest improvements of the software allow the adoption of the following values:
Power Supply
Nominal Supply
Voltage
3.8 V
Max Supply
Voltage
4.5 V
Supply Voltage
Range
3.22 V – 4.5 V
Table 1
The recommended value of supply voltage is 3.8 V.
NOTICE:
Refer to the GE864-QUAD Hardware user guide (1vv0300694) for further information
about power supply requirements and consumptions about this family of Telit
modules.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 9 of 17
3.2. GC864-QUAD-C9 Mechanical Dimensions
The Telit GC864-QUAD-C9 module overall dimensions are the following:
Length
54,5 mm
Width
36 mm
Thickness
3.7 mm
Figure 2

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 10 of 17
3.3. GC864-QUAD-C9 module connections
3.3.1. ZIF Connector Pin-Out
The following table (table 2) describes the pin-out configuration for the ZIF connector.
Pin Number
Function
In/Out
Pin Number
Function
In/Out
1
VBATT
Power
21
RTS
In
2
VBATT
Power
22
DTR
In
3
VBATT
Power
23
DCD
Out
4
VBATT
Power
24
SIM_IN
In
5
VBATT
Power
25
SIM-RST
Out
6
GND
Ground
26
SIM-IO
In/Out
7
GND
Ground
27
SIM-CLK
Out
8
GND
Ground
28
SIM-VCC
Out
9
GND
Ground
29
GND
Ground
10
GND
Ground
30
VRTC
In
11
Not Connected
Not
Connected
31
RESET
Input
12
Not Connected
Not
Connected
32
STAT-LED
Out
13
Vaux
Out
33
EAR_MT+
Analog
Output
14
Not Connected
Not
connected
34
EAR_MT-
Analog
Output
15
ON_OFF
In
35
EAR_HF+
Analog
Output
16
DSR
Out
36
EAR_HF-
Analog
Output
17
RI
Out
37
MIC_HF+
Analog input
18
RXD
Out
38
MIC_HF-
Analog input
19
TXD
In
39
MIC_MT+
Analog input
20
CTS
Out
40
MIC_MT-
Analog input
Table 2

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 11 of 17
3.3.2. STAT LED
The STAT LED pin is used to display information about the network availability and
call status. It usually needs and external transistor to drive an external LED, as
depicted in the following figure:
Figure 3
The LED’s possible states and associated meanings are described in the following
table (table 3):
LED status
Device Status
Permanently off
The device is
switched off
Fast blinking
(Period 1s, Ton 0,5s)
Net search / Not
registered / Turning
off
Slow blinking
(Period 3s, Ton 0,3s)
Registered full
service
Permanently on
A call is active
Table 3
3.3.3. VAUX Power Supply
The Vaux power supply is connected on pin 13 in the ZIF Connector.
3.3.3.1. VAUX1 Power Output
Please refer to the GE864 Hardware User Guide (1vv0300694) for details about the
VAUX1 power output.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 12 of 17
3.4. Connectivity to the ZIF interface
The connection to the ZIF interface can be done via an appropriate 40 contacts flat
flex cable.
WARNING:
Be sure that the flex cable fits into the design of the application and that pin 1 and 40
of the cable are connected to the VBATT and MIC_MT- signals respectively.
In this case, use a compatible connector on the application side such as the specified
AVX connector (p/n 04-6240-040-001-800+) (Figure 4)
Figure 4
To connect the cable, simply insert it into the open socket without pressing it. Then
carefully close the socket lid until the contacts grip.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 13 of 17
3.5. Serial Ports
3.5.1. UART connectivity – serial port
Please refer to the GE864 Hardware User Guide (1vv0300694) for details about
UART connectivity.
3.6. Audio section overview
Please refer to the related Audio Settings Application Note (80000NT10007a) for
details about the audio hardware setup of this module.
3.7. External SIM Holder implementation
Please refer to the related SIM Holder Design Guide Application Note
(80000NT10001a) for details about SIM holder implementation.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 14 of 17
4. Mounting the GC864-QUAD-C9
The module has to be firmly attached to the host application in order to work properly
and avoid any source of future issues.
This is granted by the three mounting holes provided by the C9 and the use of M1.6
or M1.8 screws plus suitable washers. The maximum diameter of the screw head
including the washer must not exceed 4 mm.
It is recommended to set spacers between the module and the host device if your
design approach allows so.
WARNING:
It is mandatory for the host device to provide an opening for the RF equipment.
Please refer to the GE864 Hardware User Guide (1vv0300694) for details.
Be careful not to damage the C9 module by forcing it or twisting it or hardly pressing
it, especially on the shielding cover. Be sure it is positioned flat against the host
device.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 15 of 17
5. Conformity assessment issues
Please refer to the GE864 Product Description (80273ST10008a) for the conformity
assessments of this Telit module.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 16 of 17
6. Safety recommendations
Please refer to the GE864 Product Description (80273ST10008a) for information
about safety recommendations regarding this Telit module.

GC864-QUAD-C9 Hardware User Guide
1VV0300811 Rev. 0 – 2009-04-22
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 17 of 17
7. List of acronyms
DSR
Data Set Ready
GPRS
General Radio Packet Service
GSM
Global System for Mobile communication
HF
Hands Free
MT
Mobile Terminated
PCB
Printed Circuit Board
RF
Radio Frequency
RI
Ring Indicator
RTS
Ready To Send
SIM
Subscriber Identity Module
STAT-LED
Status Led
ZIF
Zero Insertion Force
