Telit Wireless Solutions NE866B1 Guide

[01.2017]
Mod.0818 2017-01 Rev.0
NE866B1
HW Design Guide
1VV0301354 Rev. 6 –2018-02-28

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 2of 70 2018-02-28
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
NOTICE
While reasonable efforts have been made to assure the accuracy of this document, Telit
assumes no liability resulting from any inaccuracies or omissions in this document, or from
use of the information obtained herein. The information in this document has been carefully
checked and is believed to be reliable. However, no responsibility is assumed for
inaccuracies or omissions. Telit reserves the right to make changes to any products
described herein and reserves the right to revise this document and to make changes from
time to time in content hereof with no obligation tonotify any person of revisions or changes.
Telit does not assume any liability arising out of the application or use of any product,
software, or circuit described herein; neither does it convey license under its patent rights
or the rights of others.
It is possible that this publication may contain references to, or information about Telit
products (machines and programs), programming, or services that are not announced in
your country. Such references or information must not be construed to mean that Telit
intends to announce such Telit products, programming, or services in your country.
COPYRIGHTS
This instruction manual and the Telit products described in this instruction manual may be,
include or describe copyrighted Telit material, such as computer programs stored in
semiconductor memories or other media. Laws in the Italy and other countries preserve for
Telit and its licensors certain exclusive rights for copyrighted material, including the
exclusive right to copy, reproduce in any form, distribute and make derivative works of the
copyrighted material. Accordingly, any copyrighted material of Telit and its licensors
contained herein or in the Telit products described in this instruction manual may not be
copied, reproduced, distributed, merged or modified in any manner without the express
written permission of Telit. Furthermore, the purchase of Telit products shall not be deemed
to grant either directly or by implication, estoppel, or otherwise, any license under the
copyrights, patents or patent applications of Telit, as arises by operation of law in the sale
of a product.
COMPUTER SOFTWARE COPYRIGHTS
The Telit and 3rd Party supplied Software (SW) products described in this instruction
manual may include copyrighted Telit and other 3rd Party supplied computer programs
stored in semiconductor memories or other media. Laws in the Italy and other countries
preserve for Telit and other 3rd Party supplied SW certain exclusive rights for copyrighted
computer programs, including the exclusive right to copy or reproduce in any form the
copyrighted computer program. Accordingly, any copyrighted Telit or other 3rd Party
supplied SW computer programs contained in the Telit products described in this instruction
manual may not be copied (reverse engineered) or reproduced in any manner without the
express written permission of Telit or the 3rd Party SW supplier. Furthermore, the purchase
of Telit products shall not be deemed to grant either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents or patent applications of Telit or other
3rd Party supplied SW, except for the normal non-exclusive, royalty free license to use that
arises by operation of law in the sale of a product.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 3of 70 2018-02-28
USAGE AND DISCLOSURE RESTRICTIONS
I. License Agreements
The software described in this document is the property of Telit and its licensors. It is
furnished by express license agreement only and may be used only in accordance with the
terms of such an agreement.
II. Copyrighted Materials
Software and documentation are copyrighted materials. Making unauthorized copies is
prohibited by law. No part of the software or documentation may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, without prior written permission of Telit
III. High Risk Materials
Components, units, or third-party products used in the product described herein are NOT
fault-tolerant and are NOT designed, manufactured, or intended for use as on-line control
equipment in the following hazardous environments requiring fail-safe controls: the
operation of Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems, Air
Traffic Control, Life Support, or Weapons Systems (High Risk Activities"). Telit and its
supplier(s) specifically disclaim any expressed or implied warranty of fitness for such High
Risk Activities.
IV. Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or
service names are the property of their respective owners.
V. Third Party Rights
The software may include Third Party Right software. In this case you agree to comply with
all terms and conditions imposed on you in respect of such separate software. In addition
to Third Party Terms, the disclaimer of warranty and limitation of liability provisions in this
License shall apply to the Third Party Right software.
TELIT HEREBY DISCLAIMS ANY AND ALL WARRANTIES EXPRESS OR IMPLIED
FROM ANY THIRD PARTIES REGARDING ANY SEPARATE FILES, ANY THIRD PARTY
MATERIALS INCLUDED IN THE SOFTWARE, ANY THIRD PARTY MATERIALS FROM
WHICH THE SOFTWARE IS DERIVED (COLLECTIVELY “OTHER CODE”), AND THE
USE OF ANY OR ALL THE OTHER CODE IN CONNECTION WITH THE SOFTWARE,
INCLUDING (WITHOUT LIMITATION) ANY WARRANTIES OF SATISFACTORY
QUALITY OR FITNESS FOR A PARTICULAR PURPOSE.
NO THIRD PARTY LICENSORS OF OTHER CODE SHALL HAVE ANY LIABILITY FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
DAMAGES (INCLUDING WITHOUT LIMITATION LOST PROFITS), HOWEVER CAUSED
AND WHETHER MADE UNDER CONTRACT, TORT OR OTHER LEGAL THEORY,
ARISING IN ANY WAY OUT OF THE USE OR DISTRIBUTION OF THE OTHER CODE
OR THE EXERCISE OF ANY RIGHTS GRANTED UNDER EITHER OR BOTH THIS
LICENSE AND THE LEGAL TERMS APPLICABLE TO ANY SEPARATE FILES, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 4of 70 2018-02-28
APPLICABILITY TABLE
PRODUCTS
NE866B1-E1

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 5of 70 2018-02-28
Contents
NOTICE 2
COPYRIGHTS................................................................................................ 2
COMPUTER SOFTWARE COPYRIGHTS...................................................... 2
USAGE AND DISCLOSURE RESTRICTIONS............................................... 3
APPLICABILITY TABLE................................................................................ 4
CONTENTS.................................................................................................... 5
1. INTRODUCTION.......................................................................... 8
Scope........................................................................................... 8
Audience....................................................................................... 8
Contact Information, Support........................................................ 8
Text Conventions.......................................................................... 9
Related Documents.................................................................... 10
2. GENERAL PRODUCT DESCRIPTION ...................................... 11
Overview..................................................................................... 11
Product Variants and Frequency Bands...................................... 11
Target market............................................................................. 12
Main features.............................................................................. 12
TX Output Power........................................................................ 13
RX Sensitivity ............................................................................. 13
Mechanical specifications........................................................... 13
2.7.1. Dimensions................................................................................. 13
2.7.2. Weight........................................................................................ 13
Temperature range..................................................................... 14
3. PINS ALLOCATION................................................................... 15
Pin-out........................................................................................ 15
LGA Pads Layout........................................................................ 20
4. POWER SUPPLY....................................................................... 21
Power Supply Requirements....................................................... 21
Power Consumption ................................................................... 22
General Design Rules................................................................. 23
4.3.1. Electrical Design Guidelines ....................................................... 23

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 6of 70 2018-02-28
4.3.1.1. +5V Source Power Supply Design Guidelines ............................ 23
4.3.1.2. +12V Source Power Supply Design Guidelines .......................... 24
4.3.1.3. Battery Source Power Supply Design Guidelines........................ 25
4.3.2. Thermal Design Guidelines......................................................... 26
4.3.3. Power Supply PCB layout Guidelines......................................... 27
VAUX/PWRMON Power Output.................................................. 28
3GPP Power Saving Mode (PSM) .............................................. 29
4.5.1. LP_WAKE design guide.............................................................. 30
5. DIGITAL SECTION .................................................................... 31
Logic Levels................................................................................ 31
Power On.................................................................................... 32
Unconditional Restart.................................................................. 34
Power OFF procedure ................................................................ 37
Communication ports.................................................................. 38
5.5.1. Serial Ports................................................................................. 38
5.5.1.1. MODEM SERIAL PORT 1 .......................................................... 38
5.5.1.2. MODEM SERIAL PORT 2 .......................................................... 40
5.5.1.3. RS232 LEVEL TRANSLATION................................................... 40
General purpose I/O................................................................... 42
5.6.1. Using a GPIO as an INPUT ........................................................ 43
5.6.2. Using a GPIO as an OUTPUT .................................................... 43
I2C Port ...................................................................................... 44
SIM Interface.............................................................................. 44
5.8.1. SIMIN Detection.......................................................................... 44
ADC Converter ........................................................................... 44
6. RF SECTION.............................................................................. 45
Bands Variants........................................................................... 45
TX Output power......................................................................... 45
RX Sensitivity ............................................................................. 45
RED requirements...................................................................... 45
Antenna requirements................................................................. 46
6.5.1. Main Antenna ............................................................................. 46
6.5.2. PCB design guidelines................................................................ 47
6.5.3. Antenna installation Guidelines................................................... 48
7. MECHANICAL DESIGN............................................................. 49
Mechanical Dimensions.............................................................. 49

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 7of 70 2018-02-28
7.1.1. Mechanical Drawing ................................................................... 49
7.1.2. Top View..................................................................................... 49
7.1.3. Bottom View (as seen from bottom side)..................................... 50
7.1.4. Side View.................................................................................... 51
8. APPLICATION PCB DESIGN .................................................... 52
Recommended footprint for the application................................. 52
PCB pad design.......................................................................... 53
PCB pad dimensions.................................................................. 54
Stencil......................................................................................... 55
Solder paste ............................................................................... 55
NE866B1 Solder reflow............................................................... 56
9. PACKING SYSTEM ................................................................... 57
Tray............................................................................................ 57
Tray Drawing.............................................................................. 59
Tape & Reel................................................................................ 60
Carrier Tape Drawing.................................................................. 61
Moisture sensitivity ..................................................................... 61
10. CONFORMITY ASSESSMENT ISSUES .................................... 62
Declaration of Conformity ........................................................... 62
11. SAFETY RECOMMENDATIONS................................................ 63
READ CAREFULLY.................................................................... 63
12. REFERENCE TABLE OF RF BANDS CHARACTERISTICS..... 64
13. ACRONYMS............................................................................... 67
14. DOCUMENT HISTORY .............................................................. 69

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 8of 70 2018-02-28
1. INTRODUCTION
Scope
This document introduces the Telit NE866B1 module and presents possible and
recommended hardware solutions for developing a product based on this module. All the
features and solutions detailed in this document are applicable to all NE866B1 variants,
where NE866B1 refers to the variants listed in the applicability table.
Obviously, this document cannot embrace every hardware solution or every product that
can be designed. Where the suggested hardware configurations need not be considered
mandatory, the information given should be used as a guide and a starting point for properly
developing your product with the Telit module.
Audience
This document is intended for Telit customers, especially system integrators, about to
implement their applications using the Telit module.
Contact Information, Support
For general contact, technical support services, technical questions and report
documentation errors contact Telit Technical Support at:
•TS-EM[email protected]
•[e-mail]
•[e-mail]
•[e-mail]
Alternatively, use:
http://www.telit.com/support
For detailed information about where you can buy the Telit modules or for recommendations
on accessories and components visit:
http://www.telit.com
Our aim is to make this guide as helpful as possible. Keep us informed of your comments
and suggestions for improvements.
Telit appreciates feedback from the users of our information.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 9of 70 2018-02-28
Text Conventions
Danger –This information MUST be followed or catastrophic
equipment failure or bodily injury may occur.
Caution or Warning –Alerts the user to important points about
integrating the module, if these points are not followed, the module and
end user equipment may fail or malfunction.
Tip or Information –Provides advice and suggestions that may be
useful when integrating the module.
All dates are in ISO 8601 format, i.e. YYYY-MM-DD.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 10 of 70 2018-02-28
Related Documents
•SIM INTEGRATION DESIGN GUIDE 80000NT10001A
•NE866B1_NL865B1_AT_Commands_Reference_Guide 80534ST10817A
•Telit EVB User Guide 1VV0301249
•xE866_IFBD_HW_USER_GUIDE 1VV0301368

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 11 of 70 2018-02-28
2. GENERAL PRODUCT DESCRIPTION
Overview
The NE866B1 is thefirst Category NB1 - aka Narrowband IoT (NB-IoT) - product in the Telit
portfolio. Specified in the Release 13 of the 3GPP standard, Cat NB1 devices are
specifically tailored for IoT applications, offering optimized power consumption and
enhanced coverage. In addition, with its ultra compact 15 x 19 mm LGA footprint, the
NE866B1 is designed for size sensitive applications.
This next generation of products supports the new features specified by 3GPP to boost IoT
applications, such as the Power Saving Mode (PSM) and the extended Discontinuous
Reception (eDRX), which allow the devices to wake up periodicallyto deliver only verysmall
amounts of data to the network and then go back to sleep for most of the time, thus allowing
longer battery operation. Enhanced coverage, with up to +20dB in maximum coupling loss
(MCL) compared to the other cellular technologies, is also one of the key benefits of this
new LTE flavor. LTE Cat NB1 devices are therefore optimized in cost, size and power
consumption compared to higher UE categories.These advantagesmake the NE866B1 the
perfect platform to enable a quick implementation of LTE technology in IoT/M2M where low
cost and low power are more relevant than high speed.
The NE866B1 helpsincrease theaddressable market for LTE technology to include a broad
range of new applications and use cases best served with lower maximum data rate, ultra-
low power, reduced complexity and cost. Some examples are smart metering, smart
parking, smart agriculture, waste collection, industrial sensors, healthcare monitors, home
automation, and many more low data rate IoT devices. The NE866B1 is offered in a dual-
band configuration for deployment in the European and Chinese NB-IoT networks, either in
in-band, guard-band or standalone mode; additional regional variants will follow. It is highly
recommended for new designs, but also in particular as a migration path for existing GPRS
devices, both new and updated designs benefit from a significant extension in lifecycle with
LTE Cat NB1.
The NE866B1 supports embedded SIM chip as a mounting option, making it the ideal
solution for durable and rugged designs, and reducing BOM cost and size on the customer’s
application.
Product Variants and Frequency Bands
NE866B1 bands combinations are listed below:
Product
2G Band
(MHz)
3G Band
(MHz)
4G Band
(MHz)
Region
NE866B1-E1
B20 (800)
B8 (900)
Europe
Refer to Chapter 13 for details information about frequencies and bands.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 12 of 70 2018-02-28
Target market
NE866B1 can be used for IoT applications, where low power consumption and enhanced
coverage are required rather than high speed data, for example:
•Smart metering
•Smart parking
•Smart agriculture
•Waste collection
•Industrial sensors
•Healthcare monitors
•Home automation
Main features
Function
Features
Modem
•NB-IoT cellular modem for low BW data communication
•Real Time Clock
•Internal IP stack
Interfaces
•Main UART for AT commands
•Auxiliary UART
•I2C
•SPI
•GPIOs
•ADC
•Antenna ports

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 13 of 70 2018-02-28
TX Output Power
Band
Power class
LTE All Bands
Class 3 (23dBm)
RX Sensitivity
Product
Band
Sensitivity (dBm)
NE866-B1-E1
B8, B20
-113
Mechanical specifications
2.7.1. Dimensions
The overall dimensions of NE866 family are:
Length: 19 mm
Width: 15 mm
Thickness: 2.2 mm
2.7.2. Weight
The nominal weight of the module is 1.5 grams.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 14 of 70 2018-02-28
Temperature range
Case
Range
Note
Operating Temperature
Range
–20°C ÷ +55°C
The module is fully
functional(*) in all the
temperature range, and it
fully meets the 3GPP
specifications.
–40°C ÷ +85°C
The module is fully
functional (*) in all the
temperature range.
Storage and non-
operating Temperature
Range
–40°C ÷ +85°C
(*) Functional: the module is able to make and receive data calls and SMS.

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 15 of 70 2018-02-28
3. PINS ALLOCATION
Pin-out
Pin
Signal
I/O
Function
Type
Comment
Asynchronous Serial Port - Prog. / Data / SPI / I2C / GPIO
A4
TXD
I
Serial data input
from DTE
CMOS 1.8V
A5
RXD
O
Serial data output
to DTE
CMOS 1.8V
B1
GPIO1
I/O
GPIO
CMOS 1.8V
Default
function
SPI_CS
O
SPI External CS
CMOS 1.8V
Alternate
Function
I2C_SDA
I/O
I2C Data
CMOS 1.8V
Alternate
Function
A1
SPI_CLK
O
SPI Clock
CMOS 1.8V

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 16 of 70 2018-02-28
Asynchronous Auxiliary Serial Port 2 / SPI / I2C / GPIO
C1
TX_AUX
O
Auxiliary UART
(TX Data to DTE)
CMOS 1.8V
Primary Logging
Port
Default Function
SPI_MOSI
O
SPI Master Data
Out
CMOS 1.8V
Alternate
Function
GPIO2
I/O
GPIO
CMOS 1.8V
Alternate
Function
C2
GPIO3
I/O
GPIO
CMOS 1.8V
Default Function
SPI_MISO
I
SPI Master Data
In
CMOS 1.8V
Alternate
Function
I2C_SCL
I/O
I2C Clock
CMOS 1.8V
Alternate
Function

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 17 of 70 2018-02-28
SIM card interface
C7
SIMVCC
-
External SIM signal
–Power supply for
the SIM
1.8V Only
See next
chapters
B7
SIMRST
O
External SIM signal
–Reset
CMOS 1.8
A7
SIMCLK
O
External SIM signal
–Clock
CMOS 1.8
A6
SIMIO
I/O
External SIM–Data
I/O
CMOS 1.8
B5
SIMIN
I
SIM Presence
input
CMOS 1.8
See next
chapters
ADC
F4
ADC_IN1
AI
Analog/Digital
converter input
A/D
RF Section
G2
ANT
I/O
LTE Main Antenna
(50 ohm)
RF
Miscellaneous Functions
G4
RESET*
I
Reset Input
VBATT
Pull up to
VBATT
(10Kohm)
G5
SLP_IND
O
Modem Sleep or
PSM Indication
CMOS 1.8
Do not Drive
this pad
G6
VAUX/POWE
RMON
O
1.8V stabilized
output
Power
D3
LP_WAKE
I
LPM / PSM Wake
Up
Analog

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 18 of 70 2018-02-28
Power Supply
E1
VBATT
-
Main power supply
(Baseband)
Power
E2
VBATT
-
Main power supply
(Baseband)
Power
D1
GND
-
Ground
Power
F1
GND
-
Ground
Power
G1
GND
-
Ground
Power
D2
GND
-
Ground
Power
F2
GND
-
Ground
Power
C3
GND
-
Ground
Power
E3
GND
-
Ground
Power
F3
GND
-
Ground
Power
G3
GND
-
Ground
Power
F6
GND
-
Ground
Power
Reserved pins
A2
RESERVED
-
RESERVED
A3
RESERVED
-
RESERVED
B2
RESERVED
-
RESERVED
B3
RESERVED
-
RESERVED
B4
RESERVED
-
RESERVED
B6
RESERVED
-
RESERVED

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 19 of 70 2018-02-28
C4
RESERVED
-
RESERVED
C5
RESERVED
-
RESERVED
C6
RESERVED
-
RESERVED
D4
RESERVED
-
RESERVED
D5
RESERVED
-
RESERVED
D6
RESERVED
-
RESERVED
D7
RESERVED
-
RESERVED
E4
RESERVED
-
RESERVED
E5
RESERVED
-
RESERVED
E6
RESERVED
-
RESERVED
E7
RESERVED
-
RESERVED
F5
RESERVED
-
RESERVED
F7
RESERVED
-
RESERVED
G7
RESERVED
-
RESERVED
WARNING:
Reserved pins must not be connected

NE866B1_Hardware_Design_Guide
1VV0301354 Rev. 6 Page 20 of 70 2018-02-28
LGA Pads Layout
TOP VIEW
NOTE:
Alternate functions are marked with dark blue text while default
functions are black text
For more information, please refer to the related SW documentation
WARNING
Reserved pins must not be connected.
A B C D E F G
1 SPI_CLK
GPIO1
SPI_CS
I2C_SDA
TX AUX
SPI_MOSI
GPIO2
GND VBATT GND GND
2 RFU RFU
GPIO3
SPI_MISO
I2C_SCL
GND VBATT GND ANT
3 RFU RFU GND LP_WAKE GND GND GND
4 TXD RFU RFU RFU RFU ADC_IN1 RESET*
5 RXD SIM_IN RFU RFU RFU RFU SLP_IND
6 SIMIO RFU RFU RFU RFU GND VAUX/PWRMON
7 SIMCLK SIMRST SIMVCC RFU RFU RFU RFU
