Telit Wireless Solutions LE910C series User manual

M
o
d
.
LE910Cx Multi Technology
Interface Board TLB
HW User Guide
1VV0301508 Rev. 5 –2022-02-02
Telit Technical Documentation

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 2of 27 2022-02-02
Not Subject to NDA
APPLICABILITY TABLE
PRODUCTS
LE910C1-NA
LE910C1-AP
LE910C1-NS
LE910C4-NS
LE910C1-EU

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 3of 27 2022-02-02
Not Subject to NDA
CONTENTS
APPLICABILITY TABLE 2
CONTENTS 3
1. INTRODUCTION 5
1.1. Scope 5
1.2. Audience 5
1.3. Contact Information, Support 5
1.4. Symbol Conventions 6
1.5. Related Documents 6
2. GENERAL DESCRIPTION 7
2.1. MultiTech Interface Board TLB View 9
3. FPGA 11
3.1. Programming the FPGA 11
3.1.1. Prerequisites 11
3.2. FPGA Mode Selection 13
4. 120-PIN BOARD TO BOARD CONNECTORS 15
4.1. Board to Board Connector J1 15
4.2. Board to Board Connector J2 16
4.3. Board to Board Connector J3 17
5. COMPONENT ASSEMBLY DIAGRAM 18
6. SCHEMATICS 20
7. PRODUCT AND SAFETY INFORMATION 21
7.1. Copyrights and Other Notices 21
7.1.1. Copyrights 21
7.1.2. Computer Software Copyrights 21
7.2. Usage and Disclosure Restrictions 22
7.2.1. License Agreements 22
7.2.2. Copyrighted Materials 22
7.2.3. High Risk Materials 22
7.2.4. Trademarks 23

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 4of 27 2022-02-02
Not Subject to NDA
7.2.5. 3rd Party Rights 23
7.2.6. Waiver of Liability 23
7.3. Safety Recommendations 24
8. GLOSSARY 25
9. DOCUMENT HISTORY 26

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 5of 27 2022-02-02
Not Subject to NDA
1. INTRODUCTION
1.1. Scope
The scope of this document is to describe the MultiTech Interface Board TLB which is
part of the complete EVB Development Kit (Dev-Kit).
1.2. Audience
This document is intended for Telit customers, especially system integrators, about to
implement their applications using the Telit LE910Cx module.
1.3. Contact Information, Support
For general contact, technical support services, technical questions and report of
documentation errors contact Telit Technical Support at:
• TS[email protected]
• TS[email protected]
• TS[email protected]
• TS[email protected]
• TS[email protected]
Alternatively, use:
https://www.telit.com/contact-us
For detailed information about where you can buy the Telit modules or for
recommendations on accessories and components visit:
https://www.telit.com
Our aim is to make this guide as helpful as possible. Keep us informed of your comments
and suggestions for improvements.
Telit appreciates the user feedback on our information.

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 6of 27 2022-02-02
Not Subject to NDA
1.4. Symbol Conventions
Danger: This information MUST be followed, or catastrophic
equipment failure or personal injury may occur.
Warning: Alerts the user on important steps about the module
integration.
Note/Tip: Provides advice and suggestions that may be useful when
integrating the module.
Electro-static Discharge: Notifies the user to take proper grounding
precautions before handling the product.
Table 1: Symbol Conventions
All dates are in ISO 8601 format, that is YYYY-MM-DD.
1.5. Related Documents
•LE910C1 HW User Guide, 1VV0301298
•Generic Evaluation Board Hardware User Guide, 1VV0301249

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 7of 27 2022-02-02
Not Subject to NDA
2. GENERAL DESCRIPTION
The MultiTech Interface Board TLB (aka MTB) is custom designed to interface the Telit
module variant LE910Cx with the Telit Generic Evaluation Board (EVB) forming the
complete LE910Cx Development Kit, allowing for great flexibility for integrating WIFI, The
MultiTech Interface Board TLB (aka MTB) is custom designed to interface the Telit
module variant LE910Cx with the Telit Generic Evaluation Board (EVB), forming the
complete LE910Cx Development Kit, allowing for great flexibility in integrating WIFI,
Bluetooth, and GPS technologies with the LE910Cx.
The MTB converts Telit module signals and functions into generic EVB signals and
functions.
The following components are included in the MultiTech Interface Board TLB design:
•Module LE910Cx
•3x M.2 mini card slots
•FPGA Programmable
•SMA RF connectors
•Board-to-Board connectors for connecting to the EVB main board
•Module-specific circuitry that is not part of the EVB's generic circuitry. and GPS
technologies with the LE910Cx.
The MTB provides the mapping of Telit module signals and functions into the generic EVB
signals and functions.
The MultiTech Interface Board TLB design includes the following components:
•LE910Cx module
•3x M.2 type mini card slots
•Programmable FPGA
•RF SMA connectors
•Board to Board connectors for interfacing to EVB main board
•Module specific circuitry which is not part of the generic circuitry of the EVB.
Power supply and control interface for the cellular module is provided from the EVB via
the B2B connectors.
To monitor the temperature, a thermistor is placed on the top GND plane, close to the
module which should be representative for the module’s backside temperature.

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 8of 27 2022-02-02
Not Subject to NDA
A programmable FPGA included in the MTB allows you to connect every functional
modem pin to the relevant peripheral M.2 cards hence enabling the most flexible way to
demonstrate interoperability between the LE910Cx module and peripheral accessories.
A typical example of this capability is in the case where 3x M.2 cards (WIFI module, GNSS
module and BT module) are plugged into the M.2 slots while the FPGA is programmed to
perform the correct signals mapping between the LE910Cx and the interfaces of each of
the M.2 accessories.

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 9of 27 2022-02-02
Not Subject to NDA
2.1. MultiTech Interface Board TLB View
Figure 1 and Figure 2, show the MultiTech Interface Board TLB top and bottom views:
Figure 1: MultiTech Interface Board TLB - Top View

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 10 of 27 2022-02-02
Not Subject to NDA
Figure 2: MultiTech Interface Board TLB - Bottom View

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 11 of 27 2022-02-02
Not Subject to NDA
3. FPGA
The FPGA used in this board is a Lattice Semiconductor MACHXO3 family device.
More information about this part can be found at:
http://www.latticesemi.com/en/Products/FPGAandCPLD/MachXO3
The tools to write, compile, place, route, and program the FPGA can be downloaded from
Lattice website.
The purpose of the FPGA in this board is to provide the maximum flexibility connecting
different peripherals of the LE910Cx pins.
The board includes a rotary mode selector for selecting a pre-defined FPGA configuration
for mapping the LE910Cx pins to the various peripherals.
For each mode, the signals from the module can be muxed to either or all of the M.2 slots
or to the main board connectors on the bottom side (for interfacing to the EVB).
3.1. Programming the FPGA
This section details the steps needed to program/flash the FPGA.
3.1.1. Prerequisites
1. The JEDEC file to be programmed. This is the file uploaded/flashed into the FPGA.
2. Installed Programming tool. This “Programmer and Deployment Tool” is
available for free from the Lattice Semiconductor website:
http://www.latticesemi.com/Products/DesignSoftwareAndIP/ProgrammingAndC
onfigurationSw/Programmer
To program the FPGA, follow these steps:
1. Power on the module (pressing the ON button on the EVB main board).
2. Launch the Diamond Programmer tool.
3. In the window that appears, click Detect Cable.

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 12 of 27 2022-02-02
Not Subject to NDA
4. Select Cable and click OK.
5. The main program window will display scanning and searching for the FPGA
component.
6. Click the line below File name and navigate to the JEDEC file location.. It is now
recommended to save the programmer window setup.
7. To program the FPGA, either click the menu icon or go to Design tab and select
Program.
8. A successful program sequence should be acknowledged as shown below:

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 13 of 27 2022-02-02
Not Subject to NDA
3.2. FPGA Mode Selection
As described previously, the board includes a rotary mode selection switch. The switch
reference location is SW700. It is a rotary switch with 16 states decoded by the FPGA logic
for the different modes needed.
Figure 3: FPGA Mode Selection Switch
The predefined modes currently supported by the FPGA are detailed below:
Mode Switch Selection
Functional Mode Description
0
Default
1
Slot1: SDIO, Main UART, WCI UART, DVI
Slot2: SPI
2
Spare
3
Slot1: SDIO
Slot2: Main UART, WCI UART
Slot3: SPI
4
Spare

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 14 of 27 2022-02-02
Not Subject to NDA
Mode Switch Selection
Functional Mode Description
5
Spare
6
Spare
7
Spare
8
Spare
9
Spare
10 (A)
LE910C1: Slot 1 HCI Bluetooth connection to EVB MAIN_UART (for testing only)
11 (B)
Spare
12 (C)
Spare
13 (D)
LE910 V2: SPI, I2C_GPIOs (10-SCL, 8-SDA) AT#I2CWR=8,10,30,4,19
14 (E)
LE910 V2: SPI to UART_AUX
15 (F)
LE910C1: WIFI SDIO SLOT1 (Normal EVB mode)
Table 2: FPGA Mode Selection
Note: Additional modes for supporting new bundling options may be
released in the future.
For more information, please contact a Telit representative.

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 15 of 27 2022-02-02
Not Subject to NDA
4. 120-PIN BOARD TO BOARD CONNECTORS
4.1. Board to Board Connector J1
Pin
Description
Pin
Description
Pin
Description
Pin
Description
Pin
Description
Pin
Description
1
GND
2
GND
3
4
5
GND
6
7
USB_SS_RX_P
8
GND
9
I2C_SDA
10
TGPIO_06
11
12
13
USB_SS_RX_M
14
GND
15
TGPIO_05
16
I2C_SCL
17
18
GND
19
GND
20
GND
21
VREG_MSME
22
VREG_MSME
23
GND
24
25
USB_SS_TX_P
26
GND
27
28
29
30
31
USB_SS_TX_M
32
GND
33
34
SPI_MOSI
35
36
GND
37
GND
38
39
40
TGPIO_04
41
GND
42
43
SPI_CS
44
TGPIO_02
45
TGPIO_03
46
SPI_MISO
47
48
49
VAUX/PWRMON
50
VAUX/PWRMON
51
52
SPI_CLK
53
54
55
TGPIO_08
56
TGPIO_07
57
TGPIO_01
58
TGPIO_09
59
60
61
62
TGPIO_10
63
64
TGPIO_20
65
66
67
VMMC
68
VMMC
69
MMC_CD
70
MMC_DAT3
71
72
73
MMC_DAT0
74
MMC_DAT2
75
MMC_CLK
76
MMC_DAT1
77
78
79
GND
80
GND
81
C107/DSR
82
MMC_CMD
83
84
85
86
87
88
89
TX_AUX
90
91
92
93
94
95
RX_AUX
96
97
98
99
100
WCI_TX
101
WCI_RX
102
103
C125/RING
104
RFCLK2_QCA
105
WLAN_SLEEP_CLK
106
C105/RTS
107
108
109
C104/RXD
110
C109/DCD
111
C103/TXD
112
C106/CTS
113
C108/DTR
114
115
116
117
118
119
120
Table 3: Board to Board Connector J1

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 16 of 27 2022-02-02
Not Subject to NDA
4.2. Board to Board Connector J2
Pin
Description
Pin
Description
Pin
Description
Pin
Description
Pin
Description
Pin
Description
1
GPS_LNA_BIAS
2
GND
3
GPS_LNA_EN
4
5
GND
6
7
GND
8
GND
9
GND
10
GND
11
GND
12
13
14
15
GND
16
17
18
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
26
27
GND
28
29
30
GND
31
32
33
34
35
36
37
GND
38
GND
39
40
41
GND
42
GND
43
44
GND
45
GND
46
GND
47
GND
48
GND
49
50
GND
51
GND
52
ADC_IN3
53
ADC_IN2
54
ADC_IN1
55
56
57
58
59
60
61
DVI_RX
62
DVI_TX
63
DVI_CLK
64
DVI_WAO
65
REF_CLK
66
GND
67
GND
68
GND
69
GND
70
GND
71
GND
72
73
GND
74
GND
75
GND
76
GND
77
SIMVCC1
78
SIMVCC1
79
HSIC_STB
80
HSIC_DATA
81
SIMCLK1
82
SIMIN1
83
SIMIO1
84
SIMRST1
85
86
VRTC
87
88
89
SIMVCC2
90
SIMVCC2
91
USB_VBUS
92
USB_ID
93
SIMIN2
94
SIMIO2
95
SIMRST2
96
SIMCLK2
97
GND
98
GND
99
100
101
102
103
USB_D+
104
GND
105
106
107
108
109
USB_D-
110
GND
111
112
113
114
115
GND
116
GND
117
118
119
120
Table 4: Board to Board Connector J2

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 17 of 27 2022-02-02
Not Subject to NDA
4.3. Board to Board Connector J3
Pin
Description
Pin
Description
Pin
Description
Pin
Description
Pin
Description
Pin
Description
1
VBATT
2
VBATT
3
VBATT
4
VBATT_PA
5
VBATT_PA
6
VBATT_PA
7
VBATT
8
VBATT
9
VBATT
10
VBATT_PA
11
VBATT_PA
12
VBATT_PA
13
VBATT
14
VBATT
15
VBATT
16
VBATT_PA
17
VBATT_PA
18
VBATT_PA
19
20
21
22
VBATT_PA
23
VBATT_PA
24
VBATT_PA
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
D8_THERM_ASTAR
67
68
69
70
71
72
73
74
75
76
77
78
79
GND
80
GND
81
GND
82
GND
83
GND
84
GND
85
GND
86
GND
87
GND
88
GND
89
GND
90
GND
91
RESET
92
ON_OFF
93
STAT_LED
94
95
SW_RDY
96
SHDN
97
GND
98
GND
99
GND
100
GND
101
102
103
GPS_SYNC
104
GPS_RFPAON
105
GPS_CLK
106
GND
107
108
109
GND
110
GND
111
GND
112
GND
113
JTAG_TDI
114
JTAG_PS_HOLD
115
JTAG_TMS
116
JTAG_TDO
117
JTAG_TRST
118
JTAG_TCK
119
JTAG_RTCK
120
JTAG_RESOUT
Table 5: Board to Board Connector J3

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 18 of 27 2022-02-02
Not Subject to NDA
5. COMPONENT ASSEMBLY DIAGRAM
Searchable Layout:
CS1868A_Placement.
pdf
Figure 4: Component Diagram - Top View

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 19 of 27 2022-02-02
Not Subject to NDA
Figure 5: Component Diagram - Bottom View

LE910Cx Multi Technology Interface Board TLB Hardware User Guide
1VV0301508 Rev. 5 Page 20 of 27 2022-02-02
Not Subject to NDA
6. SCHEMATICS
cs1868A-Schematics.
pdf
