Telycam Vision+N330X User manual

Vision+ N3 30X
User Manual
V1.0

〓〓〓〓〓〓 CONTENT 〓〓〓〓〓〓
— 1 —
CONTENT .........................................................................................................1
SAFETY GUIDES .............................................................................................2
USE CHECK ..................................................................................................... 4
PRODUCT HIGHLIGHTS ............................................................................... 6
CAMERA SPEC ................................................................................................7
INTERFACE DESCRIPTION ...........................................................................9
CAMERA DIMENSION .................................................................................10
INSTALLATION ............................................................................................. 11
IR REMOTE CONTROLLER ........................................................................ 13
VISCA IN(RS232 PORT) ................................................................................15
VISCA PROTOCOL ....................................................................................... 17
PELCO-D PROTOCOL .................................................................................. 30
PELCO-P PROTOCOL ................................................................................... 31
OSD MENU .................................................................................................... 32
UVC CONTROL .............................................................................................36
WEB SETTING ...............................................................................................37
VIEW RTSP VIDEO VIA VLC .......................................................................45
NDI TOOLS .................................................................................................... 46
VISCA OVER IP ............................................................................................. 48

〓〓〓〓〓 SAFETY GUIDES 〓〓〓〓〓
— 2 —
●Before operation, please fully read and follow all instructions in the manual.
For your safety, always keep this manual with the camera.
●The camera power voltage is 12V DC, rated currency is 2A. We suggest you
use it with the original power supply adapter supplied by the factory.
●Please keep the power cable, video cable and control cable in a safe place.
Protect all cables especially the connectors.
●Operational environment: -10℃~50℃, humidity less than 80%.
●To avoid any danger, please keep the camera away from the corrosive liquid.
●Avoid stress, vibration and damp during transportation, storage and
installation.
●Do not remove the camera housing and cover. For any service, please
contact authorized technicians.
●Video cable and control cable should be individually shielded, and cannot
be substituted with other cables. Do not direct the camera lens towards strong
light, such as the sun or the intensive light.
●Use a dry and soft cloth to clean the camera housing. Applied with neutral
cleaning agent when there is need to clean. To avoid damage on the camera lens,
never use strong or abrasive cleaning agents on the camera housing.
●Do not move the camera by holding the camera head. To avoid mechanical
trouble, do not rotate the camera head by hand.
●Put the camera on fixed and smooth desk or platform, avoid leaned
installation.
●Power Supply Polarity:

〓〓〓〓〓 SAFETY GUIDES 〓〓〓〓〓
— 3 —
Attention！
▲The video quality may be affected by the specific frequencies of
electromagnetic field.
▲Never grasp the head of the camera, and never move the camera by hand
when it is working, otherwise, mechanism maybe destroyed.
Declaration：
█Instructional Manual is for reference only. Please refer to the actual
product.
█Please contact Customer Service staff for the latest programs and
supplementary documentations.
█In case of any doubt or dispute in the instruction manual, the final
interpretation of the company shall prevail.

〓〓〓〓〓〓 USE CHECK 〓〓〓〓〓〓
— 4 —
PACKING LIST
Check all below items when open the package
Camera ················································· 1PCS
Power Adapter········································· 1PCS
Power Cable··········································· 1PCS
Remote Controller···································· 1PCS
USB Type-C Cable····································1PCS
RS232 Cable··········································· 1PCS
User Manual··········································· 1PCS
QC PASS··············································· 1PCS
Shock-absorbing Pad································· 1PCS
QUICK START

〓〓〓〓〓〓 USE CHECK 〓〓〓〓〓〓
— 5 —
Dial Switch Setting (at the bottom of the camera)
Dial Switch (ARM)
SW-1
SW-2
Instruction
1
OFF
OFF
Upgrading mode
2
ON
OFF
Debugging mode
3
OFF
ON
Undefined
4
ON
ON
Working mode
Dial Switch
SW-3
SW-4
Instruction
1
OFF
OFF
Reserved
2
ON
OFF
Reserved
3
OFF
ON
Reserved
4
ON
ON
Reserved
Dial Switch
SW-5
SW-6
Instruction
1
OFF
OFF
Undefined
2
ON
OFF
Working mode
3
OFF
ON
Undefined
4
ON
ON
Undefined

〓〓〓 PRODUCT HIGHLIGHTS 〓〓〓
— 6 —
★Adopting the most advanced image processing DSP, 1/1.8 inch 12MP sensor.
★4K wide angle optical lens: 30x optical zoom, with 60 degree field of view.
★IP(NDI®|HX) FHD 1080P60 video output, while supporting H.264, H.265
encoding.
★Support POE+: one single ethernet cable to get video, control, and power
supply.
★Fast video format switch.
★Special Focusing Algorithm: fast and precise focusing performance when
zooming or moving.
★Unique camera design with patent.
★Smooth PTZ mechanical design, accurate pan tilt motor control.
★Support field upgrade, one-click software upgrade through WebUI.
★RJ45(NDI®|HX), HDMI, SDI, USB Type-C outputs, fit for different
scenarios.
★Support Line in Audio input.
★Support HDMI, SDI high-quality audio output.
★Standard VISCA, PELCO-D, PELCO-D control protocol, quickly set up
through OSD menu.
★Support Auto-Tracking and lock the first person captured by the camera.
★Supplied with multi-functional IR remote controller, can set IP address via
OSD menu.
★Standard Sony VISCA over IP protocol, support network video and control
transmission simultaneously.
★Support SRT protocol for secure transmission of high-quality, low-latency
video over WANs.
★Support RTMP protocol directly streaming to Youtube Live, Facebook Live
and other platform.
★Support Auto tracking.
★Multi language menu: support Chinese, English and Russian.

〓〓〓〓〓 CAMERA SPEC 〓〓〓〓〓
— 7 —
Vision+ N3 30X
Sensor
1/1.8inch high quality、1200 MP CMOS Sensor
Video Format
HDMI
1920*1080P60/59.94/50/30/29.97/25/24/23.98
1920*1080I60/59.94/50
1280*720P60/59.94/50/30/29.97/25
SDI
1920*1080P60/59.94/50/30/29.97/25/24/23.98
1920*1080I60/59.94/50
1280*720P60/59.94/50/30/29.97/25
USB
MJPG, H.264: 1920*1080P30; 1280*720P30;
1024*576P30; 800*448P30
NV12: 1920*1080P10; 1280*720P25;
1024*576P30; 800*448P30
IP(NDI®|HX)
1920*1080P15~60; 1280*720P15~60;
1024*576P15~60; 640*360P15~30
Video Interface
HDMI, SDI, RJ45(NDI®|HX), USB Type-C
Audio Interface
3.5mm Line in
Zoom
30X Optical + 4X Digital
Focal Length
6.91mm~214.64mm
Aperture
F1.35~4.6
View Angel
60°(Far)~2°(Near)
Rotation Angle
Pan: ±170°; Tilt: -30°~+90°;
Rotation Speed
Pan: 0.1°~80°/s; Tilt: 0.1°~60°/s
Preset
Remote controller: 10; RS232: 128; Accuracy: 0.1°
Control Port
RS232 IN, RJ45(NDI®|HX)
Network Speed
1000M
Video encode
H.264 / H.265
Bit Rate Control
Variable Bit Rate, Constant Bit Rate
Video Bit Rate
1024~61440kbps
Protocol
HTTP, RTSP, RTMP, Onvif, Visca TCP, Visca UDP, Visca over IP,
NDI®|HX, Visca Serial, Pelco-P, Pelco-D

〓〓〓〓〓 CAMERA SPEC 〓〓〓〓〓
— 8 —
POE+
Supported
Daisy Chain
Support RS232 serial daisy chain
Minimum Lux
0.5lux
White Balance
Auto / Manual / ATW / Push / Indoor / Outdoor / Color Temperature
Exposure
Auto / Manual /Shutter / Iris / Bright
Focus
Auto / Manual
Iris
Auto / Manual
Shutter
Auto / Manual
Auto Track
Supported
Gamma select
Supported
BLC
Supported
2D Noise
Reduction
Supported
3D Noise
Reduction
Supported
Anti-flicker
OFF, 50Hz, 60Hz
Pan Tilt Flip
Supported
Mirroring
Supported
Input Voltage
DC12V/POE+(IEEE802.3at)
Dimension
220mm×190mm×193.5mm
Net Weight
1.9kg(4.2LBS)
Working
Temperature
-10℃~50℃
Working
Humidity
≤80%

〓〓 INTERFACE DESCRIPTION 〓〓
— 9 —
1.Camera Lens
6.Tripod Screw Hole
11.USB Type-C port
2.Camera Base
7.Installation Hole
12.HDMI port
3.IR Receiver Panel
8.RS232 ((IN) port
13.3G-SDI port
4.Power Indicator Light
9.RS232 (OUT) port
14.RJ45(NDI®|HX) port
5.Dial Switch
10.Line in port
15.DC 12V plug

〓〓〓〓 CAMERA DIMENSION 〓〓〓〓
— 10 —

〓〓〓〓〓 INSTALLATION 〓〓〓〓〓
— 11 —
Wall-Mount Installation:
1.Drill the hole on the wall referring to the wall mounting bracket hole position,
hole diameter of φ6mm, position the four φ6mm plastic expansion screws in the
drilled hole.
2.Use four M4*30 self-tapping screws to mount the wall-mount bracket on the
wall.
3.Fix the lower cover of the bracket to the base of the camera with imperial
screws（SIZE 1/4-20UNC*3/8）
Note：A layer of silicone shock-absorbing pad should be positioned between
the camera base and the bracket. (It is included in the package)

〓〓〓〓〓 INSTALLATION 〓〓〓〓〓
— 12 —
Ceiling-Mount Installation ：
1.Referring to the position of the cover plate holes on the bracket in the
concrete ceiling, drill a hole of φ6, and position 3 plastic expansion screws of φ6
in the hole.
2.Use three M4*30 self-tapping screws to mount the bracket the upper cover
plate on the ceiling.
3.Fix the lower cover of bracket to the base of the camera with imperial screws
（Size 1/4-20UNC*3/8）
Note：A layer of silicone shock-absorbing pad should be positioned between
the camera base and the bracket. (It is included in the package).
4.Istall the camera with both upper and lower cover of the bracket, fix the side
with M3*6 screws to prevent the camera from falling off.

〓〓〓 VISCA IN (RS232 PORT) 〓〓〓
— 13 —
POWER
Short press POWER key to enter standby mode from
normal working mode. Press it again, the camera will do
self-checking, then go back to HOME position. It will go
to preset position if power on mode has been set before.
FREEZE
Short press FREEZE key to freeze/unfreeze the image.
IRT (IR Transfer/IR Pass)
Open/Close the IR pass function. Once press the IRT key,
the camera will receive and pass the IR remote control
signal to the codec/terminal.(via VISCA IN port)
Set 1 ~ Set 4 ADDRESS SETTING
Long press for 3 seconds until the key light ON, to set
camera address.
CAM1 ~ CAM4（CAMERA SELETING）
Short press to select the relative camera.
NUMBER KEY (1-9)
Set Preset：Long press the number key (3 seconds) to set
preset.
Run Preset：Short press the number key to run preset.
CLR PRE (CLEAR PRESET)
CLR PRE+number key：to clear the relative preset.
Long press to clear all presets.

〓〓〓 VISCA IN (RS232 PORT) 〓〓〓
— 14 —
FOCUS KEY: +/-
Manual focus, only valid under manual focus mode.
ZOOM KEY: +/-
Set the Zoom rate.
NAVIGATE KEY：UP/DOWN/LEFT/RIGHT
Under working mode, use navigate key to set the pan tilt,
and select menu when enter OSD.
OK/ HOME KEY：Under working mode, short press
OK to make the camera go back to HOME position; and confirm the selection
when enter OSD.
AF/MF：AUTO FOCUS/ MANUAL FOCUS
RESET: Press 3 seconds to reset camera.
MENU: Enter OSD menu under working mode. Use as Go-Back function after
entering the menu.
F1: F1+OK: Aging mode (Factory debug use only).
F2: LEARN+F2+1: Calibration mode (Factory debug use only).
F3: Short press: One-touch white balance. (You need to set the white balance
mode in the menu to PUSH mode.)
F4: Reserved.
LIMIT L/ LIMIT R/ LIMIT CLR：
LEARN+LIMIT L：Set the pan tilt left limit position.
LEARN+LIMIT R：Set the pan tilt right limit position.
LEARN+LIMIT CLR：Clear the limit position.
AT CTL：To turn off/on the auto tracking.
AT MODE：Select auto tracking mode. (left/ middle/ right)
BRIGHT-/ BRIGHT+：Set image brightness, only valid under bright priority
exposure mode.
VIDEO FORMAT KEYS：
Long press 3 seconds to select different video format
output.

〓〓〓 VISCA IN (RS232 PORT) 〓〓〓
— 15 —
NO.
V_IN
V_OUT
1
DTR
DTR
2
DSR
DSR
3
TXD
TXD
4
GND
GND
5
RXD
RXD
6
A
7
IR
OUT
8
B
V_IN
RS485
1
2
3
4
5
6
A(+)
7
IR
OUT
8
B(-)
VISCA IN 与Mini DIN
Connection
Camera VISCA IN
Mini DIN
1
DTR
1
DSR
2
DSR
2
DTR
3
TXD
5
RXD
4
GND
4
GND
5
RXD
3
TXD
6
A(+)
6
NC
7
IR OUT
7
NC
8
B(-)
8
NC
VISCA IN 与DB9 Connection
CameraVISCA IN
Windows DB-9
1
DTR
6
DSR
2
DSR
4
DTR
3
TXD
2
RXD
4
GND
5
GND
5
RXD
3
TXD
6
A(+)
7
IR OUT
8
B(-)

〓〓〓 VISCA IN (RS232 PORT) 〓〓〓
— 16 —
VISCA Network Construction：
SERIAL PORT CONFIGURATION：
Parameter
Value
Baud rate
2400/4800/9600/115200
Start bit
1bit
Date bit
8bits
Stop bit
1bit
Check bit
None

〓〓〓〓 VISCA PROTOCOL 〓〓〓〓
— 17 —
Part1 Camera Return Command
Ack/Completion Message
command
Note
ACK
z0 41 FF
Returned when the command is accepted.
Completion
z0 51 FF
Returned when the command has been executed.
Error Messages
command
Note
Syntax Error
z0 60 02 FF
Returned when the command format is different or when a
command with illegal command parameters is accepted.
Command
Not
Executable
z0 61 41 FF
Returned when a command cannot be executed due to current
conditions. For example, when commands controlling the focus
manually are received during auto focus.
Part2 Camera Control Command
Command type
function
command
Address Set
Broadcast
88 30 01 FF
Address setting
IF_Clear
Broadcast
88 01 00 01 FF
I/F Clear
Command Cancel
8x 21 FF
CAM_Power
On
8x 01 04 00 02 FF
Power ON/OFF
Off
8x 01 04 00 03 FF
Address setting
CAM_Zoom
Stop
8x 01 04 07 00 FF
Tele(Standard)
8x 01 04 07 02 FF
Wide(Standard)
8x 01 04 07 03 FF
Tele(Variable)
8x 01 04 07 2p FF
p = 0(low)~7(high)
Wide(Variable)
8x 01 04 07 3p FF
Direct
8x 01 04 47 0p 0q 0r 0s FF
pqrs: Zoom Position
(0(wide) ~0x4000(tele))
Direct with
speed
8x 0A 04 47 0t 0p 0q 0r 0s FF
t: spd 0~7
pqrs: Zoom Position
(0(wide) ~0x4000(tele))
CAM_DZoom
ON
8x 01 04 06 02 FF
OFF
8x 01 04 06 03 FF
Combine Mode
8x 01 04 36 00 FF
Combine with optical
zoom control
Separate Mode
8x 01 04 36 01 FF
Separate with optical
zoom control
Stop
8x 01 04 06 00 FF
Enable In separate mode
Tele (Variable)
8x 01 04 06 2p FF
Enable In separate mode
Wide (Variable)
8x 01 04 06 3p FF
Enable In separate mode

〓〓〓〓 VISCA PROTOCOL 〓〓〓〓
— 18 —
Command type
function
command
Direct
8x 01 04 46 0p 0q 0r 0s FF
Enable In separate mode
CAM_Focus
Stop
8x 01 04 08 00 FF
Far(Standard)
8x 01 04 08 02 FF
Near(Standard)
8x 01 04 08 03 FF
Far (Variable)
8x 01 04 08 2p FF
p=0 (Low) to 7 (High)
Near (Variable)
8x 01 04 08 3p FF
p=0 (Low) to 7 (High)
Direct
8x 01 04 48 0p 0q 0r 0s FF
pqrs: Focus Position
Auto Focus
8x 01 04 38 02 FF
Manual Focus
8x 01 04 38 03 FF
One Push AF
8x 01 04 18 01 FF
CAM_Zoom Focus
Direct
8x 01 04 47 0p 0q 0r 0s 0t 0u
0v 0w FF
pqrs: Zoom Position
(0(wide)~ 0x4000(tele))
tuvw: Focus Position
CAM_WB
Auto
8x 01 04 35 00 FF
Indoor
8x 01 04 35 01 FF
Outdoor
8x 01 04 35 02 FF
One Push
8x 01 04 35 03 FF
ATW
8x 01 04 35 04 FF
Manual
8x 01 04 35 05 FF
One Push
Trigger
8x 01 04 10 05 FF
CAM_R Gain
Reset
8x 01 04 03 00 FF
Manual Control of R Gain
Up
8x 01 04 03 02 FF
Down
8x 01 04 03 03 FF
Direct
8x 01 04 43 00 00 0p 0q FF
pq: R Gain (0~0xFF)
CAM_B Gain
Reset
8x 01 04 04 00 FF
Manual Control of B Gain
Up
8x 01 04 04 02 FF
Down
8x 01 04 04 03 FF
Direct
8x 01 04 44 00 00 0p 0q FF
pq: B Gain (0~0xFF)
CAM_AE
Full Auto
8x01 04 39 00 FF
Automatic Exposure mode
Manual
8x 01 04 39 03 FF
Manual Control mode
Shutter Priority
8x 01 04 39 0A FF
Shutter Priority
Automatic Exposure mode
Iris Priority
8x 01 04 39 0B FF
Iris Priority Automatic
Exposure mode
Bright
8x 01 04 39 0D FF
Bright Mode (Manual
control)
