Tempo Architectural C6R User manual

06018 REV.B 06-26-20 ECN-1328328 Page 1 of 4
1961 McGaw Ave. • Irvine, CA 92614 • [phone] • tempollc.com
ELECTRICAL RATINGS
C6R Products operate at 120VAC or Universal
120-277VAC depending on model. Reference
label on xtures for details.
REQUIRED HARDWARE
1) Power Feed Cable (PFC)
OPTIONAL HARDWARE
1) Joiner Feed Cable (JFC)
2) Mounting Clips, screws provided (C6A-MC)
3) 10°/20° Mounting Clips (C6A-MTGBRKT-1020)
4) +/-90° Adjustable Mounting Bracket (PA-8)
NOTE: For maximum C6R lengths, please refer to
Specication Sheet
WARNING:
Read and understand these instructions before installing. This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and operation of the product and the hazards involved. Turn o
main power supply before you start installing C6R.
Ratings, Hardware and Warning............................................................................................................Page 1
Installation Instructions ..................................................................................................................Page 2-4
PFC
JFC
C6A-MTGBRKT-1020
C6A-MC
PA-8
!
INSTALLATION INSTRUCTIONS
IMPORTANT:
Before installing the C6R be sure to install Tempo Surge Suppression Device (SSD-120/SSD-277) to every branch circuit to validate warranty.
The product is CSA certied under standard CSA C22.2 No. 250.0 and UL Standard 2108.
C6R
RIGID LED COVE LINEAR LIGHTING, HIGH LUMEN
INTEGRAL POWER SYSTEM

06018 REV.B 06-26-20 ECN-1328328 Page 2 of 4
1961 McGaw Ave. • Irvine, CA 92614 • [phone] • tempollc.com
STEP 1
Connecting power to the C6R:
Connect the female connector on the PFC to the
male connector on C6R by lining up the locking
tab and pressing together rmly until tab locks
into place, Figure 1 & 2.
C6R
RIGID LED COVE LINEAR LIGHTING, HIGH LUMEN
INTEGRAL POWER SYSTEM
INSTALLATION
IMPORTANT:
To achieve proper xture ground, supplied Tempo Power Feed Cable (PFC) assembly must be used and attached to grounded J-Box. When
connecting eld wires to PFC wires observe polarity; i.e., White to Neutral, Black to Line and Green to ground.
Field Wires PFC for C6
Figure 1 Figure 2

06018 REV.B 06-26-20 ECN-1328328 Page 3 of 4
1961 McGaw Ave. • Irvine, CA 92614 • [phone] • tempollc.com
C6R
RIGID LED COVE LINEAR LIGHTING, HIGH LUMEN
INTEGRAL POWER SYSTEM
INSTALLATION (continued)
STEP 2
Connecting xture to xture:
The C6R sections can be joined together for
longer runs. Make connections same as power
feed connections shown in Step 1, Figure 3.
For end to end connections push sections
together, Figure 4.
C6R leads allow for sections to go around
corners without the need for a jumper cable,
Figure 5.
For applications requiring longer space in-
between sections use Jumper Feed Cable (JFC),
Figure 6.
STEP 3A
Install C6R using at mounting clip: C6A-MC:
Place mounting clip on surface and secure
using wall-dog screws (provided), Figure 7.
Place C6R on the mounting clip placing on side
of the xture track hook under the mounting
clip lip, Figure 8. Once rst hook is engaged,
carefully push down the xture onto the clip to
engage the opposite side, Figure 9.
Note: When installing a xture with the
Asymmetric Optic conrm that the label stating
“Wall Side” is facing away from desired beam
angle that would be pointing towards lighting
target.
Figure 3
Figure 5
Figure 7
Figure 9
Figure 4
Figure 6
Figure 8

06018 REV.B 06-26-20 ECN-1328328 Page 4 of 4
1961 McGaw Ave. • Irvine, CA 92614 • [phone] • tempollc.com
C6R
RIGID LED COVE LINEAR LIGHTING, HIGH LUMEN
INTEGRAL POWER SYSTEM
STEP 3B
Installing C6R using optional 10º/20º
mounting clip:
C6A-MTGBRKT-1020
Orient mounting clip on 10º side or 20º side
based on the application. Secure using wall-
dog screws provided, Figure 10. Install C6R on
the mounting clip by placing xture over the
mounting clip and push it onto the track until the
hooks on the clip engage the lip on the xture,
Figure 11 & Figure 12.
STEP 3C
Installing C6R using optional adjustable
mounting clip:
PA-8
Secure pivot arm assembly to mounting surface
using wall-dog screws provided, Figure 13. Install
C6R on the mounting clip by placing xture
over the mounting clip and pushing it onto the
track until the hooks on the clip engage the lip
on the xture, Figure 14 & Figure 15. Adjust
xture to desired angle and tighten using Philips
Screwdriver, Figure 16.
INSTALLATION (continued)
Figure 10
Figure 13
Figure 15
Figure 12
Figure 11
Figure 14
Figure 16
