Tempsens CALSYS 650 User manual

CALSYS 650
USER MANUAL
Dry Block Temperature Calibrator
Thermal Engineering Solutions

1. Introduction 4
1.1 Basic working of CALsys 650
1.2 Dimension
1.3 Wiring Diagram
2. Technical Specification 6
3. Installation 7
3.1 Environmental Condition
4. Unpacking & Initial Inspection 8
4.1 Installation
5. Operating Instruction 9
5.1 Power
5.2 Heating up the source
5.3 Operating Instruction
6. Operation of Controller 11
6.1 The Temperature Controller
6.2 Altering the Set point
6.3 Monitoring the Controller Status
6.4 Units
7. Digital Communications 12
8. Software Installation
9. Maintenance & Trouble shooting 16
9.1 Routine service
9.2 Replace the Controlling Sensor
9.3 Replace Solid state relay
10. Troubleshooting 17
7.1 Digital Communication Wiring
7.2 Digital Communication Parameter
7.3 Broadcast Communication
14
8.1 Installation
8.2 Parameter in Main Screen

Preface
2
Safety Information
Electrical Safety
Symbol Description Symbol Description
Risk of Danger. Important Information Hazardous Voltage. Risk of Electric Shock
Caution. Hot Surface Protective Earth Ground
Table 1. Symbols
To avoid possible electric shock or personal injury, follow for the voltage and plug Configuration in your country and
these guidelines. rated for the Product.
ŸThis equipment must be correctly earthed . ŸReplace the mains power cord if the insulation is damaged
or if the insulation shows signs of wear.
ŸA protective earth is used to ensure the conductive parts
cannot become live in the event of a failure of the ŸConnect one end of the supplied ground wire to the
insulation. protective earth ground terminal on the rear panel and the
other end to an earth ground.
ŸThe protective conductor of the flexible mains cable which
is colored green/yellow MUST be connected to a suitable ŸMake sure the ground conductor in the mains power cord is
earth. connected to a protective earth ground. Disruption of the
protective earth could put voltage on the chassis that could
ŸWarning: Internal mains voltage hazard. Do not remove
cause death.
the panels .
ŸDo not put the Product where access to the mains power
ŸBefore connecting to the electricity supply, please
cord is blocked.
familiarize yourself with the parts of the calibrator with the
help of operating manual . ŸDo not use an extension cord or adapter plug.
ŸAlways replace the fuse with one of the same rating, ŸDo not use the Product if it operates incorrectly.
voltage and type. ŸMake sure the power cord does not touch with hot parts of
ŸUse only the mains power cord and connect or approved the Product.
panels
This chapter contains important information for the safety. The following definitions apply to the terms “Warning” and
The not observance of these instructions may result in “Caution”.
serious personal injury or can cause serious damage to the Ÿ“Warning” identifies conditions and actions that may pose
unit and to the components system included. Use the hazards to the user.
instrument only as specified in this manual. Otherwise, the Ÿ“Caution” identifies conditions and actions that may
protection provided by the instrument may be impaired. damage the Instrument being used.
Refer to the safety information below and throughout the
manual.
Thank you for purchasing High Quality and Efficient CALsys This user manual contains information about the product and
650. its proper use and should be kept in a place where it will be
easy to access.
Please familiarize yourself with the information contained in
the safety precautions sections before using this product.

3
Health And Safety Instructions
Ÿ Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Wear appropriate protective clothing. Make sure that the space around the Product meets
minimum requirements.
Operators of this equipment should be adequately trained
in the handling of hot and cold items and liquids. Do not keep the Product in operation and unattended at
high temperatures.
Do not use the apparatus for jobs other than those for
which it was designed, i.e. the calibration of Do not set anything on top of the Product. Very high
thermometers. temperatures can cause the ignition of flammable
materials.
Do not handle the apparatus when it is hot (or cold), unless
wearing the appropriate protective clothing and having the BURN HAZARD - DO NOT touch the well access surface of
necessary training. the unit.
Do not drill, modify or otherwise change the shape of the DO NOT turn off the unit at temperatures higher than
apparatus. 100°C. This could create a hazardous situation. Select a set-
point less than 100°C and allow the unit to cool before
Do not use the apparatus outside its recommended
turning it off.
temperature range.
Materials used in this furnace may be irritating to skin,
If cased, do not return the apparatus to its carrying case
eyes, and respiratory tract. Consult the material
until the unit has cooled.
manufacturer's MSDS (Material Safety Data Sheet).
There are no user serviceable parts inside. Contact
HIGH VOLTAGE is used in the operation of this equipment.
Tempsens agent for repair.
SEVERE INJURY OR DEATH may result if personnel fail to
Ensure materials, especially flammable materials are kept
observe safety precautions.
away from hot parts of the apparatus, to prevent fire risk.
The top sheet metal of the furnace may exhibit extreme
Do not use the Product around explosive gas, vapor, or in
temperatures for areas close to the well access.
damp or wet environments.
Cautions
ŸDO NOT connect this unit to a non-grounded, non- fuse holder read115 V. This action will cause the fuses to
polarized outlet. blow and may damage the instrument.
ŸBefore working inside the equipment, turn the power off ŸComponents and heater lifetime can be shortened by
and disconnect the power cord. continuous high temperature operation.
ŸAlways replace the fuse with one of the same rating, ŸDO NOT use fluids to clean out the well.
voltage, and type. ŸNever introduce foreign material into the probe hole of the
ŸOverhead clearance is required. DO NOT place this insert. Fluids, etc. can leak into the calibrator causing
instrument under a cabinet or other structure. damage.
ŸDO NOT turn the unit upside down with the inserts in place; ŸDO NOT change the values of the calibration constants
the inserts will fall out of the unit. from the factory set values. The correct setting of these
parameters is important to the safety and proper operation
ŸUse of this instrument at HIGH TEMPERATURES for
of the calibrator.
extended periods of time requires caution.
ŸDO NOT drop or force the probe stems into the well. This
ŸCompletely unattended high temperature operation is not
type of action can cause a shock to the sensor and affect
recommended for safety reasons.
the calibration.
ŸDO NOT plug the unit into 230 V if the heater switches and

4
The 'CALsys 650' has been designed to provide stable
and accurate temperature to enable professionals to
calibrate Temperature Sensing Devices by comparison
method. The 'CALsys 650' model has been designed to
be rugged and easily maintained. This model provides
an isothermal enclosure (Metal block) in which the
thermocouple/RTD can be calibrated against the
temperature of the calibrator. For traceable calibration
a master calibration sensor should be placed into the
metal block alongside the unit under calibration. The
method is widely accepted because the calibrator
provides very stable temperature nearing to its
controlled point, the Master Thermocouple / RTD,
which is calibrated by independent Laboratory
traceable to National standards, compares the sensor
under calibration.
The 'CALsys' models are part of wide range of portable
calibrators designed and made by us.
Please contact us in case you required more information
about our other products.
1.1 Basic Working of CALsys 650
The purpose of the CALsys 650 is to provide an
isothermal enclosure for calibration purpose. The
heater blockhouses a heater and a control sensor used
by the temperature controller to sense the block
temperature. To obtain and maintain a required
temperature the controller varies the power to the
heater via solid state relay. There is one electricity
driven fan in the unit. It runs continuously and situated
under the heater chamber for cooling the heater, it runs
when PV exceeds the set value.
The calibrator controller uses a precision N type
thermocouple as a controlling sensor and controls the
well temperature with MI heater. To obtain and
maintain a required temperature the controller varies
the power to the heater via solid-state relay. There is
one electricity driven fan which is situated under the
heating chamber for cooling the heater. The CALsys 650
dry block calibrator was designed for portability,
moderate cost and ease of operation. With proper use
the instrument should provide continued accurate
calibration of temperature sensors and devices. The
user should be familiar with the safety guidelines and
operating procedures of the calibrator as described in
the User's Manual.
Chapter - 1
Introduction

5
1.3 Wiring Diagram
204.40
192.40
161.20
115
114.49 139.98
184
TOP
313
192.40
115.50 A
A
FRONT
161
192.40
204.40
268.66
BOTTOM
192.40
190
313
BACK
153.76
10
138.20 24.95
SECTION A-A
CHAMBER
FAN
CONTROLLER
313
267.85
SIDE VIEW

6
Chapter - 2
Technical Specification
Temperature Range 50 C to 650°C°
Accuracy ±1.0°C
Stability
± 0.025°C at 50°C
± 0.035°C at 350°C
± 0.07°C at 650°C
Resolution 0.1°C
Uniformity
± 0.04°C at 50°C
± 0.07°C at 350°C
± 0.09°C at 650°C
Time to Reach Max. Temperature 25 minutes
Operating Temperature 20 to 45°C
Method of Controlling Digital self-tuned PID controller
Controlling Sensor T/C “N” Type
Heaters MI Heaters
Voltage 230 V AC±10
Supply Frequency 50/60 Hz
Power 1.0 KW
Computer Interface RS-232
Dimensions 325(H) x 185(W) x 265(D) mm
Insert Construction Diameter 32x150 mm Long with 4 Holes of 6.5 x 120 mm insert depth
Weight Approximate 9 Kg

7
Chapter - 3
Installation
Place the black body on a flat surface with at least 10 inches of free space around the instrument. Overhead clearance
is required. DO NOT Place this unit under a cabinet or structure. Plug the power cord into a grounded mains outlet
located on the controlling unit rear panel. Observe that the nominal voltage corresponds to that indicated in the
technical specifications in the user's guide.
3.1 Environmental Conditions
Although the instrument has been designed for optimum durability and trouble-free operation, it must be handled
with care. The instrument should not be operated in an excessively dusty or dirty environment. Maintenance and
cleaning recommendations can be found in the Maintenance Section of this manual.
The instrument operates safely under the following conditions:
ŸTemperature range: 5 - 50°C (41 - 122°F)
ŸAmbient relative humidity: 15 - 50%
ŸPressure: 75kPa - 106kPa
ŸMains voltage within ± 10% of nominal
ŸVibrations in the calibration environment should be minimized
ŸAltitude less than 2000 meters

8
Our packing department uses custom designed
packaging to send out your unit. You are advised, after
unpacking the unit, to inspect it for any sign of damage,
and confirm that your delivery is in accordance with the
packing note. Unpack the Furnace carefully and inspect.
If you find any damage or any item is missing notify us or
our agent.
After unpacking you will find the following accessories
CALsys 650
Power Cord
RS-232 Cable and Software CD
Manual
Certificates
Ceramic Wool
Brass Block (Insert)
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Chapter - 4
Unpacking
4.1 Initial Inspection
1. Please open the carrying case carefully and takeout the operating manual from the box and read carefully.
2. Take out the Bath carefully and keep it at suitable place.
3. Connect the power plug to the rear power entry and connect the power plug to the mains.
4. As soon as the power in ON you shall observe display on the controller. It shows that the bath is ready for use.
Note
1. Please ensure that your unit is correctly connected to the electricity supply.
2. The apparatus must be correctly earthed (Grounded).
3. The unit's ON/OFF switch is located on the power inlet. Take care NOT to switch the unit OFF when it is hot – allow
cooling first.
Plier
(Block Remover) Power CableInsulation WoolRS-232 Cable
Software CD
Brass Block
K type TCCALsys 650

9
Chapter - 5
Operating Instruction
5.1 Power
Plug the calibrator power cord into mains outlet of the proper voltage, frequency and current capability. Typically this
will be (230 VAC±10, 50/60 Hz). Turn the controller using the “Mains”(user main power panel) and set the
temperature value in the controller. After this, ON the ON/OFF switch which is provided in back side of furnace.
5.2 Heating up the source
Press “UP” or “DOWN” key of controller to change the set-point value. When the set-point temperature is changed
the controller will switch the calibrator heater on or off to raise or lower the temperature. The displayed temperature
will gradually change until it reaches the set-point temperature. The Calibrator may require 15 to 20 minutes to reach
the set-point depending on the span. An another 5 to 10 minutes is required to stabilize the bath temperature within
± 0.1°C of the set-point.
Note
All other controller parameters are company set and locked. It is recommended not to change them.
When the source is operated at any temperature above ambient, the front face and plate become hot.
Always put the fan in “ON” Condition and do not switch the “Mains” off Directly, First set the controller to 0 Deg C and then
wait until the unit is not cooled below 100 Deg C.
Ÿ
Ÿ
Ÿ
5.3 Operating Instruction
1. Connect the 'CALsys 650' to a suitable power supply.
2. Place the metal insert in the bath.
3. Place the sensors for calibration & master sensor into a suitable insert hole.
4. Put insulation on top of the furnace so that it covers only metal insert (brass block) section. please note at
very high temperature we will recommended to use ceramic wool, it will improve stability time.
5. Set the controller to the required Temperature.
6. If test & master sensor is Thermocouple then always use compensating cable (for each type like J, K, T, E, N, R,
S, B) for interconnection between sensor and DMM.
7. Keep reference junction at 0 Deg C, if not possible then ADD mili volt (mV) of room (ambient) temperature
with sensors output mV to compensate the ambient temperature.
8. When temp of the controller are stable record the reading from DMM with at least 41/2 digit precision which
should be calibrated for the measuring range (mV & ohms measurements).
9. Find out the error by comparison method.
10. Reset the controller and / or repeat the calibration for another calibration point or for another sensor.
Power Entry
Controller
RS-232
ON/OFF

10
Note
1. Metal Insert should be of required hole size so that the hole size is suitable for sensor under calibration.
2. Always use a master sensor (master RTD/TC) for comparison calibration method.
3. Place the metal insert first then all sensors and then set controller at desired set point.
4. Check that all sensors (test & master) are immersed at same depth in insert (metal block).
5. If sensors are not immersed at same depth than there will be an error in temperature reading.
6. Always use a metal block calibrator. Metal block calibrator (insert) heat transfer characteristics should match those of the
normal measuring situations.
7. The temperature sensors should be long enough so that immersed a calibration bath, errors due to stem conduction can be
ignored.
8. Do not change the set value suddenly until the temperature reaches to existing set value.
Ex. : The set value is 100°C and when it reaches at 80°C now you set 150°C, this is improper method / incorrect method.
9. Plan the calibration point in increasing way then set the controller accordingly. This method will save the time.
10. Take the reading of sensors (master & test) at stable temperature with the help of Digital Multimeter or by using Tempsens
make TEMPMET 08 or TEMPMET 09 for reading RTD or TC sensor.
5.4 Cooling down the Source
Risk of Burns
1. Before transport the metal block, ensure that the temperature of bath has cooled sufficiently.
2. If the metal block can be brought quickly from higher temperature to lower temperature set the temperature
to the room temperature (ambient temperature).
3. Always cool the heated instrument to ambient temperature before disconnecting it from the mains,
switching it OFF / removing the temperature sensor / test item.
4. Always leave a heated instrument supervise / under observation.

11
Chapter - 6
Operation of Controller
6.1 The Temperature Controller
The controller has a dual display, the upper display indicates the measured temperature, and the lower display
indicates the desired temperature or set point.
6.2 Altering the Set point
To change the set point of the controller use the UP and DOWN keys to raise and lower the set point to the required
value. The lower display changes to indicate the new set point.
6.3 Monitoring the Controller Status
A row of beacons indicate the controllers status as follows,
OP1 Heat Output
OP2 Cool Output (only for models which operate below 0°C)
REM This beacon indicates activity on the PC interface
6.4 Units
Momentary pressing of the Scroll key will show the controller units °C or °F.
IMPORTANT NOTICE
The controller's function settings are preset and will not require adjustment.

12
Chapter - 7
Digital Communications
RS-232 is a standard communication protocol for linking
computer and its peripheral devices to allow serial data
exchange. RS-232 communications uses the Modbus
protocol. Rs-232 communications is not available if
Remote Set point is fitted. Cable screen should be
grounded at one point only to prevent earth loops.
Digital Communications (or 'comms' for short) allows
the controller to communicate with a PC or a networked
computer system.
7.1 Digital Communications Wiring
To use EIA232 the PC will be equipped with an EIA232
port, usually referred to as COM 1. To construct a cable
for EIA232 operation use a three core screened cable.
The terminals used for EIA232 digital communications
are listed in the table below. Some PC's use a 25 way
connector although the 9 way is more common.
* These are the functions normally assigned to socket pins.
Please check your PC manual to confirm.
7.2 Digital Communications Parameters
The following table shows the parameters available.
Com
Rx
Tx
HD
HE
HF
Common
Rx A(+)
Tx A(-)
Screen
Local Ground
EIA232 Connections
Standard
Cable
PC Socket Pin
No.
PC
Function*
Instrumen
t
Terminal Instrument
Colour 9 Way 25 Way Function
White 2 3 Receive,
RX HF Transmit,
TX
Black 3 2 Transmit,
TF HE Receive, RX
Red 5 7 Common HD Common
Link
Together
1
4
6
6
8
11
Rec’d line
sig. det
ect
data
terminal
ready
data set
ready
Link
Together
7
8
4
5
request t
o
send clear
to send
Screen 1 Ground
Digital Communication List
Name Scrolling
Display
Parameter
Description
Value Default Access
Level
ID MODULE
IDENTITY
Comms Identity NonE No module fitted As
order
code
Conf
L3 R/O
r232 RS232 Modbus interface
r485 EIA485 Modbus interface
r422 EIA422 Modbus 3216
only
dc,PRemote setpoint input. if
fitted this ID replaces the
above and no further
parameters are shown
Addr COMMU
NICA
TION
ADDRESS
Communication
address of the
instrument
1 to 254 1L3
Baud COMMU
NICA
TION
BAUD
RATE
Communication
Baud Rate
1200 1200 9600 Conf
L3 R/O
2400 2400
4800 4800
9600 9600
19.20 19.200
PRTy COMMU
NICA
TION
PARITY
Communication
Parity
nonE No Parity nonE Conf
L3 R/O
EuEn Even Parity
Odd Odd Parity
DELAY RX/TX
DELAY
TIME
To insert a delay
between Rx and Tx
to ensure that
drivers have
sufficient time to
switch over.
OFF No Delay Conf
L3 R/O
on Fixed Delay Applied
RE
Tran
COMMS
RETRANS
MISSION
Master Comms
broadcast
parameter see
section 15.2.1
nonE None nonE
WSP Working setpoint
PU Process variable
OP Output Demand
ERR Error
REGAD COMMS
RETRANS
MISSION
ADDRESS
Parameter added
in slave address to
which the master
communication
value will be
written
0 to 9999 0

13
7.3 Broadcast Communications
The 3200 broadcast master can be connected to up to
31slaves if no segment repeaters are used. If repeaters
are used to provide additional segments, 32 slaves are
permitted in each new segment. The master is
configured by setting the 'RETRN' parameter to W.SP,
PV, OP or Err.
Once the function has been enabled, the instrument
will send this value out over the communications link
every Control cycle (250ms).
Tx
Rx
Com
Tx
Rx
Com
32000
Master
EIA232
Slave 1
EIA232
3200
Master
Slave 31
Slave 2Slave 1
Wiring Connections
The Digital Communications module for use as a master
or slave is fitted in Comms Module slot H and uses
terminals HA to HF.
Rx connections in the master are wired to Tx
connections of the slave
Tx connections in the master are wired to Rx
connections of the slave

14
Chapter - 8
Software Inastallation
The provided Tempsens software offers possibilities to connect furnace temperature bath and change set point,
maximum time span, view real time graph and evaluate measuring data.
8.1 Installation
Install the calibration software using the installation guide file on CD ROM. After installation of the software; Double
click the application. It will open the screen of software.
8.2 Parameter in mainscreen
8.2.1 Communication
Communication between the furnace and the software is implemented via a RS-232 cable connected between the
furnace and the PC serial port. This enables the acquisition and recording of data, as well as the transfer of commands
from the software application to the tempsens furnace. Communication can be done by clicking on connect and
select correct COM port address (fig. 1) where furnace is connected. Also user has to select type of controller
version3216 (fig. 2). Then click on CONNECT button. Shown com2 connected successfully.
Fig. 1. Fig. 2.

15
8.2.2 Scale Trend : in scale trend you have to change the Y-Axis Min value 0 and Y-Axis Max value 1500. Maximum
Time Span, Minutes have to save data the data logging up to 120 minutes, than click on start graph button. After
complete the task click on save to file button.
Set Point (°C) : in which you can set temperature of furnace as your requirement.
PVI Value : Read the current PV value (present value of furnace temperature).
File will be stored in .xls format to save previous record open the file by clicking on menu file open.

16
Chapter - 9
Maintenance & Trouble shooting
9.1 Routine service
Turn the electricity supply off before attempting any cleaning operation. The only moving part is the fan. That has
sealed-for-life bearings. Depending on the environment in which it is used, periodic cleaning is recommended.
Cleaning may be accomplished by the use of a small dry paint brush. The instrument should be periodically checked to
ensure it is in good order both mechanically and electrically.
9.2 Replace the Controlling Sensor
Replacement of the controlling thermocouple is carried out as follows:
1. Make sure that the Calibrator Unit is not connected to the mains supply.
2. Remove the cover of the Calibrator.
3. Disconnect the thermocouple from the connector block.
4. Remove the thermocouple from the heating chamber present inside by unscrewing the Screw fitted in the
fitting.
5. Fit the new thermocouple.
6. Reconnect the new thermocouple to the connector block.
7. Replace the cover.
9.3 Replace Solid state relay
1. Disconnect the Calibrator Unit from the electrical supply.
2. Remove the cover of the furnace.
3. Locate the solid state relay.
4. Disconnect the wires, noting their position.
5. Remove the faulty relay and replace it with a new one.
6. Tighten the fixing screws.
7. Refit the wires has been noted in step 4.
8. Replace the cover.
9. Reconnect the furnace to the electrical supply.

17
Chapter - 10
Troubleshooting:
1. Unit fails to operate
Check fuse, if fuse blows repeatedly consult us.
2. Unit unstable
Control parameters have been interfered with - consult us.
3. If the temperature of the calibrator is not rising, ensure the followings:
(a) The power cord should not be loose at power entry.
(b) The switch should be in ON position
( C) The power supply should be rated capacity. (230V AC ±10 & 50/60 Hz)
4. If the temperature of the calibrator is not rising even after checking the above
(a) The heating element may be open.
(b) The thermocouple may be open.
(c) The Controller may be not giving output.
(d) The SSR may be damaged.
Warranty
This instrument has been manufactured to exacting standards and is warranted for twelve months against electrical
breakdown or mechanical failure caused through defective material or workmanship, provided the failure is not the
result of misuse. In the event of failure covered by this warranty, the instrument must be returned, carriage paid, to
the supplier for examination and will be replaced or repaired at our option.
FRAGILE CERAMIC AND/OR GLASS PARTS ARE NOT COVERED BY THIS GUARANTEE
INTERFERENCE WITH OR FAILURE TO PROPERLY MAINTAIN THIS INSTRUMENT MAY INVALIDATE THIS GUARANTEE
Limit of Liability
TEMPSENS not liable for any damages that arise from the use of any examples or processes mentioned in these
Specifications are subject to change without notice.
CAUTIONARY NOTE
TEMPSENS PRODUCTS ARE INTENDED FOR USE BY TECHNICALLY TRAINED AND COMPETENT PERSONNEL FAMILIAR
WITH GOOD MEASUREMENT PRACTICES.
IT IS EXPECTED THAT PERSONNEL USING THIS EQUIPMENT WILL BE COMPETENT WITH THE MANAGEMENT OF
APPARATUS WHICH MAY BE POWERED OR UNDER EXTREMES OF TEMPERATURE, AND ARE ABLE TO APPRECIATE THE
HAZARDS WHICH MAY BE ASSOCIATED WITH, AND THE PRECAUTIONS TO BE TAKEN WITH, SUCH EQUIPMENT.
Recommendation
The life of your 'CALsys 650' instrument will be prolonged if regular maintenance and cleaning to remove general dust
and debris is carried out.
The company is always willing to give technical advice and assistance where appropriate. Equally, because of the
program of continual development and improvement, we reserve the right to amend or alter characteristics and
design without prior notice. This publication is for information only.

18
Packing Instruction
To transport or store the instrument, please use the original box or a box padded with sufficient shock absorbing
material. For storage in humid areas or shipment overseas, the device should be placed in welded foil (ideally along
with silicon gel) to protect it from humidity.
Warranty
TEMPSENS CALsys 650 instrument have a warranty of one year from the invoice date. This warranty covers
manufacturing defects. User induced faults are not covered under this warranty.
Limit of Liability
TEMPSENS not liable for any damages that arise from the use of any examples or processes mentioned in this
Specifications are subject to change without notice
Information
Copyright: 2009, Tempsens All rights reserved.
This document may contain proprietary information and shall be respected as a proprietary document to
Tempsens with permission for review and usage given only to the rightful owner of the equipment with which this
document is associated.
Tempsens reserves the right to make changes, without further notice, to any products herein to improve
reliability, function, or design. Tempsens does not assume any liability arising out of the application or use of any
product described herein, neither does it convey any license under its patent rights nor the rights of others.
Copyright: © 2009
©

ABOUT US
Tempsens Instruments (l) Pvt. Ltd.
Tempsens Instruments (I) Pvt. Ltd. is a part of Pyrotech Group which was established by four technocrats in 1976 at
Udaipur, with their first product as Thermocouples and RTDs. Today ‘Tempsens’ is one of the largest manufacturers of
Temperature Sensors in India.
Tempsens Instruments (I) Pvt. Ltd. U# II was started in 2009 to produce cables with high standard of manufacturing
process conforming to national & international specifications. We manufacturer wide range of cables for
Temperature sensors and Instrumentation in various insulations as PTFE, FEP/PFA, Kapton, Silicon, Fiber Glass,
Ceramic Fiber, Refrasil/Nextel, PVC etc. in variety of configurations. These cables are available in temperature range -
60°C to 1200°C.
All our products are manufactured under strict ISO-9001 quality management system. We also provide Calibration
Certificates with all cables. We stock most types of cables which enable us for fast delivery of goods. Our engineering
staff are capable to custom design solutions for all applications for customers.
We are dedicated to provide the highest quality products that meet our customer's specifications for various
applications.
We continuously focus on improving our manufacturing processes and competitiveness in the industry
