Tenda O1 User manual

1
Outdoor Point to Point CPE
User Guide

i
Copyright Statement
© 2020 Shenzhen Tenda Technology Co., Ltd. All rights reserved.
is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand
and product names mentioned herein are trademarks or registered trademarks of their respective
holders. Copyright of the whole product as integration, including its accessories and software,
belongs to Shenzhen Tenda Technology Co., Ltd. No part of this publication can be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or
by any means without the prior written permission of Shenzhen Tenda Technology Co., Ltd.
Disclaimer
Pictures, images and product specifications herein are for references only. To improve internal
design, operational function, and/or reliability, Tenda reserves the right to make changes to the
products without obligation to notify any person or organization of such revisions or changes. Tenda
does not assume any liability that may occur due to the use or application of the product described
herein. Every effort has been made in the preparation of this document to ensure accuracy of the
contents, but all statements, information and recommendations in this document do not constitute
a warranty of any kind, express or implied.

ii
Preface
Thank you for choosing Tenda! Please read this user guide before you start.
Conventions
This user guide applies to the following CPEs. O4 is used for illustrations here unless otherwise
specified. The contained images and UI screenshots are subject to the actual products.
Product Model
Description
O1
500m Outdoor Point to Point CPE
O2
2Km Outdoor Point to Point CPE
O3
2.4G Long Range Outdoor Access Point
O4
5Km Outdoor Point to Point CPE
O9
5GHz 11ac 23dBi Gigabit Outdoor CPE
OS3
5GHz 11ac 867Mbps 12dBi Outdoor CPE
The typographical elements that may be found in this document are defined as follows.
Item
Presentation
Example
Cascading menus
>
System > Live Users
Parameter and value
Bold
Set User Name to Tom.
Variable
Italic
Format: XX:XX:XX:XX:XX:XX
UI control
Bold
On the Policy page, click the OK button.
Message
“”
The “Success”message appears.
The symbols that may be found in this document are defined as follows.
Symbol
Meaning
This format is used to highlight information of importance or special interest.
Ignoring this type of note may result in ineffective configurations, loss of data or
damage to device.
This format is used to highlight a procedure that will save time or resources.

iii
Acronyms and Abbreviations
Acronym or Abbreviation
Full Spelling
AP
Access Point
ARP
Address Resolution Protocol
AES
Advanced Encryption Standard
CPE
Customer Premises Equipment
CCQ
Client Connection Quality
DHCP
Dynamic Host Configuration Protocol
DNS
Domain Name System
DDNS
Dynamic Domain Name Server
GMT
Greenwich Mean Time
IP
Internet Protocol
ICMP
Internet Control Message Protocol
LAN
Local Area Network
MAC
Media Access Control
PoE
Power over Ethernet
P2MP
Point-to-MultiPoint
PVID
Port-based VLAN ID
RADIUS
Remote Authentication Dial In User Service
SSID
Service Set Identifier
TCP
Transmission Control Protocol
TKIP
Temporal Key Integrity Protocol
UDP
User Datagram Protocol
VLAN
Virtual Local Area Network
WAN
Wide Area Network
WEP
Wired Equivalent Privacy
WLAN
Wireless Local Area Networks
WMM
Wi-Fi multi-media

iv
Acronym or Abbreviation
Full Spelling
WPA-PSK
WPA-Preshared Key
WPA
Wi-Fi Protected Access

v
Getting more documents
If you want to get more documents of the device, visit www.tendacn.com and search for the
corresponding product model. The related documents are listed as below:
Document
Description
Quick Installation Guide
It introduces how to set up the device quickly for internet access, the
descriptions of LED indicators, ports, and buttons, FAQ, statement information,
and so on.
User Guide
It introduces how to set up more functions of the device for more requirements,
including all functions on the web UI of the device.
Data Sheet
It introduces the basic information of the device, including product overview,
selling points, and specifications.
Technical Support
If you need more help, contact us by any of the following means. We will be glad to assist you as
soon as possible.
Hotline
Global: (86) 755-27657180
Toll Free: Mon - Fri 9 am - 6 pm
(China Time Zone)
Email
[email protected].cn
United States: 1-800-570-5892
Toll Free: Daily 24 hours
Hong Kong: 00852-81931998
Toll Free: Mon - Fri 9 am - 6 pm
(China Time Zone)

vi
Contents
1Application scenario ...............................................................................................................1
1.1 ISP hotspot connection-WISP mode........................................................................................1
1.2 CCTV surveillance.....................................................................................................................6
2Login.....................................................................................................................................16
2.1 Login.......................................................................................................................................16
2.2 Logout ....................................................................................................................................19
3Web UI .................................................................................................................................20
3.1 Web UI layout.........................................................................................................................20
3.2 Common buttons ...................................................................................................................21
4Quick setup ..........................................................................................................................22
4.1 AP mode.................................................................................................................................23
4.2 Client mode............................................................................................................................26
4.3 Example of AP mode and client mode...................................................................................29
4.4 Universal repeater mode .......................................................................................................34
4.5 Example of universal repeater mode.....................................................................................37
4.6 WISP mode.............................................................................................................................40
4.7 Example of WISP mode..........................................................................................................44
4.8 Repeater mode ......................................................................................................................48
4.9 P2MP mode............................................................................................................................57
4.10 Example of repeater mode and P2MP mode.......................................................................63
4.11 Router mode ........................................................................................................................69
4.12 Example of router mode ......................................................................................................72
5Status ...................................................................................................................................75
5.1 System status .........................................................................................................................75
5.2 Wireless status .......................................................................................................................78
5.3 Statistics .................................................................................................................................80
6Network ...............................................................................................................................86
6.1 LAN setup...............................................................................................................................86
6.2 MAC clone..............................................................................................................................91
6.3 DHCP server ...........................................................................................................................93
6.4 DHCP client.............................................................................................................................95
6.5 VLAN settings .........................................................................................................................96

vii
7Wireless..............................................................................................................................100
7.1 Basic .....................................................................................................................................100
7.2 Advanced..............................................................................................................................127
7.3 Access control ......................................................................................................................130
8Advanced............................................................................................................................133
8.1 LAN rate................................................................................................................................133
8.2 Diagnose...............................................................................................................................135
8.3 Bandwidth control ...............................................................................................................143
8.4 Port forwarding ....................................................................................................................146
8.5 MAC filter.............................................................................................................................151
8.6 Network service ...................................................................................................................155
9Tools ...................................................................................................................................173
9.1 Date & time..........................................................................................................................173
9.2 Maintenance........................................................................................................................175
9.3 Account ................................................................................................................................182
9.4 System log ............................................................................................................................184
Appendix....................................................................................................................................185
A.1 A1. Default parameters........................................................................................................185
A.2 How to assign a fixed IP address to your computer ............................................................187
A.3 How to check the gateway IP address of a computer .........................................................189

1
1 Application scenario
1.1 ISP hotspot connection-WISP mode
An apartment needs to bridge an ISP hotspot for internet access.
1.1.1 Solution
Tenda CPE can meet this demand.
O4 is used as an example to illustrate the installation procedures. Procedures for other CPEs are
similar.
To establish the network quickly, you are recommended to set up the CPEs before installing them.
1.1.2 Set up the CPE
Step 1 Connect the computer to the CPE.
1. Uncover the housing of the CPE.
2. Use an Ethernet cable to connect the PoE/LAN/WAN port of the device to the PoE port of
the PoE injector.
3. Use the included power adapter to connect the PoE injector to a power socket. The
LAN/WAN LED indicator of the CEP lights up.
4. Use an Ethernet cable to connect your computer to the LAN port of the PoE injector.

2
Step 2 Set the CPE to WISP mode.
1. Start a web browser on your computer, and visit 192.168.2.1. Enter your user name and
password (default: admin/admin), and click Login.
2. Select WISP, and click Next.

3
3. Select the SSID of your ISP (Internet Service Provider) hotspot, which is Tenda_123456 in
this example, and click Next.
4. Enter the WiFi password of your ISP hotspot in the Key text box, and click Next.
5. Select the Internet Connection Type of your ISP hotspot, which is PPPoE in this example.
Enter the PPPoE user name and password provided by your ISP, and click Next.

4
6. Customize the SSID and key, and click Next.
7. Set an IP address belonging to different network segment as that of your ISP hotspot. For
example, if the IP address of your ISP hotspot is 192.168.2.1, you can set this device’s IP
address to 192.168.X.1 (Xranges from 0 to 254 excluding 2). Then click Next.
8. Click Save, and wait until the device reboots to activate the settings.
----End
When LED1, LED2, and LED3 indicators of the device are blinking, the device is connected to your
ISP hotspot successfully.

5
1.1.3 Instal the CPE
Step 1 Place the device at an elevated position in the open air.
Step 2 Uncover the housings of the device, and connect the PoE/LAN/WAN port of the device to
the WAN port of your wireless router. The LAN/WAN LED indicator lights up.
Step 3 Adjust the device’s direction or location on the selected pole until the LED1, LED2 and
LED3 of the device light up.
Step 4 Use the plastic straps to attach the device to the pole.
----End
ISP hotspot
CPE: WISP mode
Router

6
1.2 CCTV surveillance
To ensure the safety of employees and property, a video surveillance system needs to be installed
in a building site.
1.2.1 Solution
Tenda CPE can meet this demand.
O4 is used as an example to illustrate the installation procedures. Procedures for other CPEs are
similar.
1.2.2 Set up the CPEs
At least two CPEs are required for bridging.
Option 1: Automatic bridging (recommended)
Automatic Bridging is only applicable when the CPEs are in factory settings.
When performing peer-to-peer bridging, ensure that only two CPEs are powered on nearby.
Otherwise, the peer-to-peer bridging may fail.
For peer-to-multiple peers bridging, perform peer-to-peer bridging first, and then power on the
rest CPEs within 30 minutes.
A CPE can bridge to 15 CPEs at most.
Scenario 1: Peer-to-peer bridging
Step 1 Place the two CPEs next to each other, see the following figure.

7
Step 2 Remove the housing of each CPE, and use the included PoE injectors to power them on.
Wait until the LAN/WAN LED indicators of the CPEs light up.
Step 3 Wait for the two CPEs to negotiate and connect to each other automatically. The
following LED indicator status indicates successful connection of the two CPEs.
If the bridging succeeds, the DHCP servers of the two CPEs are disabled, and the IP address of the
CPE working in Client mode changes to 192.168.2.2.
Refer to your actual product for the supported PoE power supply distance.
If the peer-to-peer automatic bridging fails, reset the two CPEs to factory settings, and try again.
Reset method: When the CPEs are working properly, hold down the reset button for about 8
seconds, and then release it. When all LED indicators light up, the CPE is restored to factory settings
successfully.
----End
AP mode
LED 1, 2 and 3 indicators
light solid on
Client mode
LED 1, 2 and 3 indicators
blink

8
Scenario 2: Peer-to-multiple peers bridging
Step 1 Refer to Peer-to-peer bridging to make any two CPEs bridge to each other.
Step 2 Within 30 minutes after the peer-to-peer bridging succeeds, place the rest CPEs which are
in factory settings near the CPE with the LED1, LED2, and LED3 indicators solid on and
power them on. Wait about 1 minute. When the LED1, LED2, and LED3 indicators of these
new-added CPEs keep blinking, the peer-to-multiple peers bridging succeeds.
CPE 1: AP mode
LED 1, 2 and 3 indicators light
solid on
Client mode
LED 1, 2 and 3 indicators blink
Client mode
LED 1, 2 and 3 indicators blink
CPE 2
CPE 16

9
If the LED1, LED2 and LED3 indicators of a new-added CPE turn off after it is powered on for 1
minute, the bridging fails. Reset the CPE to factory settings, and wait until its LED1, LED2 and LED3
indicators keep blinking.
When using O2 to perform peer-to-multiple peers bridging, after the peer-to-peer bridging
succeeds, place the rest CPEs which are in factory settings near the CPE with the LED1, LED2, and
LED3 indicators solid on and power them on in 3 minutes.
If the bridging still fails, try manual bridging. Refer to Client mode for details
Option 2 Manual bridging
Step 1 Place the two CPEs next to each other.

10
Step 2 Connect the computer to CPE1.
1. Uncover the housing of CPE1.
2. Use an Ethernet cable to connect the PoE LAN/WAN port of CPE1 to the PoE port of the
PoE injector.
3. Use the included power adapter to connect the PoE injector to a power socket. The
LAN/WAN LED indicator of the CPE1 lights up.
4. Use an Ethernet cable to connect your computer to the LAN port of the PoE injector.
Step 3 Set CPE1 to AP Mode.
1. Start a web browser on the computer, and visit 192.168.2.1. Enter your user name and
password (default: admin/admin), and click Login.

11
2. Select AP, and click Next.
3. Set an SSID, which is Tenda_123456 in this example, Security Mode, which is WPA2-PSK in
this example, and Key, and click Next.
4. Click Save, and wait until the CPE reboots automatically to activate the settings.
Step 4 Set CPE2 to Client Mode.
1. Perform the procedure in Step 2 Connect the computer to CPE1 to connect the computer to
CPE2.

12
2. Start a web browser on your computer, and visit 192.168.2.1. Enter the login user name
and password (default: admin/admin), and click Login.
3. Select Client, and click Next.
