HIGH PEAK FRAME TENT
40 Hex
ASSEMBLY INSTRUCTIONS

High Peak Frame Tent (SPECIFICATIONS: 40 Hex)
1
Width 40 ft. / 9.1m
Length 40 ft. / 7.6m
Area 900 ft² / 83.2m²
Eave Height 9' / 2.7m
Overall Height 20' 5" / 6.2m
Pitch 11' 5" / 3.5m
Complete Weight 326 Lbs. / 148 Kg.
Series High Peak/Prestige
Class Cross Cable
Center Pole No
Style / Shape High Peak Frame Tent
Expandable No
Custom Printing
Available Yes
Fabric Material PVC Coated Polyester
Fabric Material Weight 16 oz. / yd2 / 540 gsm
Fabric Translucency Block-out
Water Repellency Waterproof
Flame Resistant Yes
UV Resistant Yes
Mold and Mildew
Resistant Yes
Frame / Pole Material Aluminum
Longest Component 9'3" / 2.8m
Persons required for setup 3
Occupancy 80 Sit Down Dinner
Occupancy (cont.) 120 Cathedral Seating
High Peak Frame Tent (OVERVIEW)
716 832-TENT (8368)
(example, not size specific)
Canopy
Center Mast Pole Pin
Center Mast
Cross Cable
Spreader Bar
Corner Fitting
Spreader Insert
Base Plate
Ratchet Rope
Recommended Tools:
• hard hat
• sledge hammer
• tape measure
• work boots
• 6 ft ladder
Pole and Bar Diameter:
2.5˝O.D. 2.25˝I.D.
Base Plate Dims:
Sidewalls
(optional)
1 in. Ratchet
Strap
Anchoring Stakes
5.75˝
4˝
1˝x1˝
.875˝x 1˝

STEP 1. CHECK ITEM LIST (40 Hex High Peak Frame Tent)
Item Illustration (all parts available for replacement) Item Size Quantity
2
9´-3˝ 12
174˝ 1
9´-3˝ 6
unique 6
None
Std. 6
40´ 3
Std. 4
1˝ 6
1.5˝ 6
None
3/4˝x 20˝ 6
3/4˝x 24˝ 6
None
40´x 40´ 1
Eave Spreader Bars
Center Mast Pole
and
Center Mast Pin
Leg Poles
Corner Fittings
Side Tee Fittings
Spreader Insert
Cross Cables
Base Plates
1˝ Ratchet Strap
Assembly w/ D-ring
1.5˝Ratchet Strap
Assembly
(for base plate)
Ratchet Rope
(smaller tents only)
Base Stake
Ground Stake
Corner Bar (unique)
Canopy Top
SKU: BT-FHHCRN
SKU: BT-FHAST111
SKU: BT-FHCM174
SKU: BT-FHSI
SKU: BT-FHAST111 (9´-3˝)
(to base plate–
larger tents)
SKU: BT-FHBP
SKU: BT-TARS1
SKU: BT-FHBP
SKU: BT-FHCM480
SKU: BT-FHSTK1
SKU: BT-FHSTK2
SKU: BT-FHH44WTT
SKU: BT-FHCMPP (pin) SKU: BT-FHCMPPP (plug) SKU: BT-FHCMB (bottom)
716 832-TENT (8368)
(to ground stake)

• When building or assembling anything
above shoulder height, wear a hard hat
• Steel toe boots are recommended
• Inspect the site, look for overhead and
underground obstructions— such as
utilities
• Call your local utility to have utility
lines marked (call 3–5 days ahead)—
call811.com is a good resource—
‘click’ 811 in Your State
• Inspect all ropes and tie lines
• Inspect poles, making sure there are
no bends or breaks
• Replace or repair any items in poor
condition
• Spread tarp (sold separately) in the
tent location, to protect canopy—
tarp/tarps should be as large as canopy
• Place eave bars, corner fittings, side
fittings and connectors on tarp
• Connect all fittings
• See (appendix A) for your tent plan,
eave bars layout and more information
• The last cable is attached differently
see (figure A)
• Because of the tension build-up,
the last cable is connected easier in
this manner
• Lift the last corner, 3 feet or higher
to connect the last cable end to the
corner hook—
Lifting corner actually reduces the
distance between the two corners
STEP 3. CONNECT EAVE BARS (40 Hex)
(FIGURE A.)
Position tarp in the exact tent location desired
(use small objects as weights on a windy day)
STEP 2. SAFETY CHECK LIST
3
716 832-TENT (8368)
Lift last corner
Cross cables
Lay tarp down first
(protects canopy step 4)
Spreader bar
Cross cables
Connector
Corner fitting

• Unfold canopy top, place over cross
cables and tarp
• DO NOT walk on canopy
• Center the top and stretch to edges
(flap as you go, to create ‘lift’)
Note: Locate the O-ring pull strap
attached to one of the corner loops,
that should be the last loop to be
put in place—the strap can be used
to pull the loop in place
• Connect three corners first, to the
corner fittings
• See (figure B.)
• The last corner requires the use of
an anchoring stake
• Pull the first three corner loops over
the corresponding outcrop-ring
• For the last loop, place an anchoring
stake through loop and against outcrop
• Pull corner loop and pry at the same
time— (pull stake back, away from tent)
— the overall canopy position should be
straighten, this will help with final loop
• Finally, push loop in place and slide
out anchoring stake
• Use O-ring pull strap to pull the
loop into place
(FIGURE B.)
Last corner loop
(pull back on stake/tool)
Outcrop-ring
Corner loop
Stake Line
STEP 4. CANOPY TOP
Legs
Ground
Stakes
(example, not size specific)
(example, not size specific)
Approx. 5ft.
from frame
5 ft.
5 ft.
• With the canopy on and the frame
in place, measure for ground stake
location
• Lay leg poles around frame to help
guide your measurement
• Measure 5 feet straight out from frame,
at each leg connector
• Slide stakes through D-ring of 1˝ ratchet
strap, before you continue
• Remember, one ground stake per leg
pole at the stake line, see (figure C,
next page) for proper staking
STEP 5. POSITIONING STAKES
4
716 832-TENT (8368)
Canopy top
Tarp

• At this time, finish sliding the stakes
through all of the D-rings, that are
connected to the 1˝ straps
• Hammer all stakes in position (half-way)
• Attach the hook end of the 1˝ ratchet
strap assembly to all outcrop rings
• Connect straps together, using ratchet
See (page 7) for Ratchet Strap use
• This makes complete 1˝ ratchet strap
assemblies, both ends connected—
leave a good amount slack, for now
• Ground stakes should be hammered
in vertical, not angled
(sledge hammer required)
• Determine the longest side of your
tent—this is were the first two leg poles
will be installed—
Check connection of 1˝ ratchet strap,
from frame to ground stake, before
these two legs are installed
• Complete the hammering process,
before you install each leg—
leave 6 inches showing, above
the ground
• Lift ‘first’ side of frame
• Insert legs on one side (remember pick
the longest side, for rectangular tents)
• Slide base plate onto these legs—anchor
hole should be facing interior of tent
• 1˝ Ratchet straps should have some
slack in them, at this point still
• Continue with ‘second’ corner & side legs
• The center pole goes in, before the
leg poles on the other side
Note: For the HEXAGON tent, install
three consecutive legs as side one—
the rest of the assembly is the same
Note: Large tents require frame tent jacks—general
rules are, one jack every 20´ and never place jack in
the middle of bar (usage can be found on Internet)
STEP 7. INSERTING LEG POLES
Insert all legs on one side—
appendix Awill help determine
the longest side of your tent
Other side sits
on ground
Base plate
First corner
Second corner
(Connect a 1.5˝ratchet strap,
from tent to base plate, each time
you insert a leg pole, see step 8)
STEP 6. ATTACHING 1˝ STRAPS
Correct Incorrect
Proper hammering of stakes
(FIGURE C.)
5
Use 1˝ strap here
6˝
Connect before
hammering
stakes
716 832-TENT (8368)
(example, not size specific)
Use the larger 24˝stake,
for ground anchor

(example, not size specific)
Base
plate
facing interior
Canopy
corner opening
quick link
Canopy
ropes
Attach 1.5˝strap, hook end
to quick link
Important: make sure canopy
ropes aren’t tangled!
Attach a
1.5˝strap with ring end
(each base plate)
• Under canopy you will see several
short ‘side release buckle straps’—
connect these to frame (eave bars)
• Raise other side of tent (2 people
required)—start at a corner
• Insert leg poles—the leg poles should
be vertical at this step
• Slide base plate onto these legs—
secure canopy to remaining base plates,
with corresponding 1.5˝strap, at
each leg
• TIGHTEN ALL 1˝and 1.5˝RATCHET STRAPS
• Fully tighten short straps, under canopy
• Lastly, secure base plates to ground by
hammering in the ‘base stakes’
STEP 10. INSTALL REMAINING LEGS
Insert leg poles (and base plates) on other side
Center Mast
Pole and
Bottom
(unlock hitch
pin)
Height of center
pole can be adjusted
to obtain proper
tension with canopy
Center Mast Pole
• For every leg pole, there is a base
plate and a 1.5˝ ratchet strap assembly
—connect the straps as each leg is
Installed
• Connect hook end to quick link and
ring end to base plate hook
(check that canopy ropes are not tangled)
• Tighten strap, before moving to the next
leg (not at 100%—secure fully at the end
of assembly)
See (page 7) for Ratchet Strap use
• One side of canopy still remains on tarp
• Lift center mast (two people will get
this step done quicker)—walk under
canopy, keeping the pole angled
• Insert mast pin into grommet at center
of canopy (make sure entire pin is
through and visible from outside)
• With the pole at an angle (not vertical),
lay notched bottom near the outer
end of the top cable—then slide the
bottom of pole towards the center
• Make sure mast pin stays in place
• At center, where cables cross, position
notched bottom over all the cables
• Lock hitch pin around cables to the
other side of center pole bottom
STEP 9. POSITIONING CENTER POLE
STEP 8. BASE PLATE STRAPS
6
716 832-TENT (8368)
(Connect a 1.5˝ratchet strap,
from tent to base plate,
each time you insert
a leg pole)
(example, not size specific)
Connect short
straps under canopy
to frame Strap replacement
(sku: BT-FHTSR)

23´-9˝
9´-3˝
40´
40´
20´
20´
• Release handle, crank until slot is
pointing up
• Close handle
• Pass strap underneath and through
the slot (as shown)
• While holding the whole strap
assembly attach both ends
(eg. tent to stake)
• Remove slack, before tightening
• Push ‘release’— lift handle
and tighten ratchet
• Roll-up any excess strap,
put under handle
• Close handle
FINISHED TENT
1˝Ratchet strap assembly
(one per leg location)
1.5˝Ratchet strap assembly
and base plate
(one per leg location)
7
1.) Remove base stakes
2.) Detach short straps under canopy
3.) Remove straps on one side
4.) Remove leg poles, on one side
5.) Remove side leg poles,
(adjacent to corner of 30 x 30 tent, only)
6.) Remove center mast
7.) Lay tarp under canopy
8.) Remove remaining straps
9.) Remove remaining legs
10.) Fold canopy
11.) Disconnect/remove eave poles
and connectors
12.) Remove ground stakes
STRIKE PROCEDURE (basically, reverse order from assembly)
USING RATCHET STRAPS
Release
(push, to lift handle
and to remove strap,
during disassembly)
Handle Axle/Slot
716 832-TENT (8368)
canopy
overhang
14˝
7˝
Optional Rain Gutter Available
– HPF Rain Gutter (attached view)
(Note: the vinyl is connected to both tents,
forming a ‘V’ shaped gutter)
SKUs: BT-FH10RG (10´), BT-FH15RG (15´), BT-FH20RG (20´),
BT-FH30RG (30´), BT-FH40RG (40´)

20X20
TENT
20X30
TENT
30X30
TENT
40 Ft.
HEXAGON
TENT
20X40
TENT
10X10
TENT
40 Ft.
HEXAGON
TENT
9´-3˝
9´-3˝
Mast:
174˝
Cable: 40´
15X15
TENT
10X20
TENT
Cable set-up
Eave spreader bars
30 Ft.
HEXAGON
TENT
20 Ft.
HEXAGON
TENT
Leg pole positions
(at corners)
Spreader inserts/connectors
15X30
TENT
Appendix A.
Other available sizes (High Peak Frame Tent)
• Tent Plan— showing details
(other available sizes below)
