Anchor AnchorSpan Liner User manual

GABLE END OF
LINER - ATTACHED
TO FIRST MID.
STEP 1
BE CERTAIN GABLE END VELCRO IS OPEN BEFORE BEGINNING INSTALLATION. CONNECT PULL ROPES TO
D-RINGS AT LOWER ENDS OF LINER MID.
STARTINGAT CHANNEL OPENINGS IN BEAMS, SLIDE KEDAR INTO INSIDE CHANNELS OF BEAMS. START BOTH
SIDES OF MID AT THE SAME TIME.
MIDS WILL BE PULLED IN WITH PULL ROPES. PULLEY MAY BE ATTACHED AT TOPARCH OF FRAME FOR THIS
PURPOSE, OR PUSH POLES CAN BE USED.
KEDARS
GABLE END VELCRO
MUST BE OPEN
BEFORE PULLING
LINER IN CHANNEL.
FIRST MID WITH GABLE
END ATTACHED.
FIRST MID WITH GABLE
END ATTACHED.
MID
CROSS SECTION LOOKING
AT SIDE OF ANCHORSPAN
GABLE END
ATTACH GABLE END TO
FRAME AT EAVE BAR.
ANCHORSPAN
BEAM (TYP.) SLIDE KEDAR INTO
BOTH CHANNELS
SIMULTANEOUSLY.
EC ASL
Installation Instructions
Anchor Span Liner

GABLE END HAS STRAPS
FOR ATTACHING TO END
UPRIGHTS.
ATTACH STRAPS TO END
EAVE BARS (IF WALLS WILL BE
INSTALLED, FASTEN STRAPS
AFTER INSTALLATION OF
WALLS.)
STEP 2
PULL LINER MIDS IN EVENLY SO THAT THEY STOPAT THE SAME LEVEL ON EACH SIDE OF THE BUILDING.
AT EACH CORNER OF LINER, HOOK SNAP ON STRAP INTO CHANNEL ON EAVE BAR AND THEN TIGHTEN STRAP.
