Tentsile Safari Trillium User manual

It is important that all users read and understand the materials in
this manual before any installation and use of the product.
NO MORE THAN 3 MONTHS CONTINUOUS USE AT ANY ONE TIME
DO NOT LEAVE OUTSIDE UNATTENDED FOR MORE THAN A WEEK.
Safari Trillium
OWNERS MANUAL

CONGRATULATIONS
YOU ARE NOW THE PROUD OWNER OF A
03: Introduction03: Introduction
04: Terms of Use04: Terms of Use
05: Specications05: Specications
06: Warnings & Disclaimers06: Warnings & Disclaimers
07- 08: Layout & Alignment07- 08: Layout & Alignment
09 - 22: Set up instructions09 - 22: Set up instructions
23: Floor calibration23: Floor calibration
24: Ratchet usage24: Ratchet usage
25: Policies25: Policies
26: The small print26: The small print
IT IS IMPORTANT THAT ALL USERS READ AND UNDERSTAND THE MATERIALS
IN THIS MANUAL BEFORE ANY INSTALLATION AND USE OF THE PRODUCT.
Safari Trillium
01 02
W A R N I N GW A R N I N G
TENTSILE IS NOT A TOYTENTSILE IS NOT A TOY
RISK OF SERIOUS INJURYRISK OF SERIOUS INJURY
A VISUAL AND TACTILE INSPECTION OF YOUR TENTSILE’S FLOOR,
STRAPS AND RATCHETS SHOULD BE MADE BEFORE EACH USE.
FOR SAFETY REASONS, STRAPS AND RATCHETS SHOULD BE
REPLACED EVERY 2 YEARS.
NO MORE THAN 3 MONTHS CONTINUOUS USE AT ANY ONE TIME
DO NOT LEAVE OUTSIDE UNATTENDED FOR MORE THAN A WEEK.
THE BASE OF THE TENT IS RATED FOR 3,500 HOURS OF UV EXPOSURE.
CHECK THE HEALTH AND STRENGTH OF THE TREES
CHOSEN TO BE ANCHOR POINTS BEFORE USE.
Recommended set up height 1.2m / 4 feet
MAX LOAD 400kg / 880lbs.
DO NOT EXCEED MAXIMUM WEIGHT LOAD CAPACITY.

Introduction
The Safari Trillium provides a unique opportunity for you and your friends to
experience the great outdoors with a whole new level of freedom and comfort.
Tentsile invented Tree Tents as treehouses you can take anywhere; combining
the versatility of a hammock with the comfort and security of a tent.
The Safari Trillium comprises of a triple hammock, suspended in tension
abovethe ground.
The unique design creates a comfortable base camp, irrespective of ground
conditions, as well as providing increased protection from insects, snakes and
other predators – if you venture somewhere more exotic.
This product was created because Tentsile loves trees and believes that if we’re
all hanging out in trees, they can’t cut them down!
20 trees are planted for every Tentsile Tree Tent sold.
PLAY, CAMP, EXPLORE...
Terms of Use
03 04
Tentsile Tree Tent should be set up only as
outlined in this manual.
NEVER jump into, onto or use it as a trampoline
or swing. It is not intended to be used for rock
climbing, cliff faces, overhangs or above or next
to large drops.
DO NOT attempt to use this product for anything
another than its intended purpose, and always
observe height and weight limits.
DO NOT use walls, fences, street furniture, roof
racks, movable platforms, posts or trees less than
25cm/10inches in diameter as anchor points, as
they may not be strong enough.
DO NOT use tensioning components other than
those supplied with this product.
DO NOT set up higher than 1.2metres / 4 feet from
the ground or above hard, sharp or pointy objects.
Tactile and visual checks should be made to
ALL tent components and ALL anchor points
before each use.
Replace any damaged elements if any are found.
Keep away from re and sharp objects.
DO NOT use after the consumption of any
intoxicating substances.
Children must be supervised by an adult at all times.
DO NOT attach to trees or branches that show
signs of structural weakness.
DO NOT adjust/open ratchets whilst tent
is occupied.
DO NOT use during lightning storms or high winds.
DO NOT use in areas of unstable ground.
Tentsile Tree Tents do not offer protection from
all animals.

Specications Warnings & Disclaimers
Size:
4.1x4.1x4.1m / 13.5x13.5x13.5ft
Floor area:
7.25sqm/78sqf
Bag Size:
52 x 28 x 28cm /
20.4 x 11 x 11”
Ratchet & straps:
Industry plated steel, 2.5 ton
Minimum Breaking Strain,
35mm polyester webbing
Tent weight:
7.95kg / 17.5lbs
Floor:
600D Dacron - 300g/sqm
reinforced with 20+ meters of
seat belt
Maximum capacity:
3 adults
Fire Rating:
Fire resistance meets USA
CPAI-84 and Canadian FR16
DO NOT EXCEED MAXIMUM LOAD 400kg / 880lbs
05 06
Installation and use of the Tentsile Tree Tent may
involve heights, can be dangerous and may lead
to injury and/or death.
The installation must never be executed by
minors, and extreme care and caution must be
taken when executed by adults.
Do not use any other components, parts, tools or
materials other than those included in the Tentsile
Tree Tent package, recommended in this manual
or in other Tentsile literature.
A hanging and/or suspension system is only as
strong as its weakest link and all instructions and
guidelines must be followed.
The Tentsile Tree Tent must only be used in
the manner described in this manual. When
assembled and installed, the Tentsile Tree Tent
places signicant force on the anchor points;
great care must be exercised when using it to
decrease the risk of injury and/or death.
Overloading the Tentsile Tree Tent with more
than 880lbs (400kg) increases the forces and
may cause anchor, Tree Tent and/or any parts
to fail, resulting in injury and/or death.
The manufacturer and resellers of the Tentsile
Tree Tent explicitly disclaim any and all
responsibility and liability for any death,
paralysis, injury, and/or damage to any
person or property that may occur that arises
out of or is in any way related to the use of
this product.
Using any equipment that is suspended above
ground can be a dangerous activity that may
result in serious injury and/or death even
when used properly. Use at your own risk and
always use common sense.

Positioning the Safari TrilliumPositioning the Safari Trillium
Tentsile Tree Tents need 3 secure and strong anchor points to suspend from. The distances areTentsile Tree Tents need 3 secure and strong anchor points to suspend from. The distances are
marked below. Once the location is found, lay out the Trillium on the ground with the corners marked below. Once the location is found, lay out the Trillium on the ground with the corners
facing your selected trees. Protective tree wraps are provided should you wish to use them.facing your selected trees. Protective tree wraps are provided should you wish to use them.
Alignment Sight LinesAlignment Sight Lines
Use line-of-sight to look down the ratchet strap
and up the seam of the underoor straps on the
Safari Trillium. The closer to straight these are, the
better. You have a margin of tolerance of about
7º on either side before performance is impacted.
Minimum setup distances:Minimum setup distances:
5 x 5 x 5m / 16 x 16 x 16ft5 x 5 x 5m / 16 x 16 x 16ft
Maximum setup distances:
14 x 14 x 14m / 45 x 45 x 45ft
Anchor point shouldAnchor point should
be less than 90 degreesbe less than 90 degrees
from each other.from each other.
TreeTree
TreeTree
TreeTree
TreeTree TreeTree
x3 Strapsx3 Straps
x3 Ratchetsx3 Ratchets
TrilliumTrillium
07
TreeTree
08

09 10
1, Wrap the loop end of each
strap around your selected trees.
2, Once around, thread the
strap and pull it all through
towards the Trillium.
3, Ensure the strap is
at against the tree
and not twisted.
Tree Straps
With a location found,
start by wrapping the
tree straps around your
selected trees.

Lay Out The Trillium BaseLay Out The Trillium Base
Take the Trillium base and lay it out on the
ground in between your selected trees.
Ensure it is the correct way up with the
elastic crossed straps facing up.
11 12
Rear/TailRear/Tail
FrontFront
4, Lay the Trillium base on 4, Lay the Trillium base on
the ground inbetweenthe ground inbetween
your selected trees withyour selected trees with
the straps.the straps.

9, Pull tight and dress the
Girth Hitch
8, Pull the ratchet through
the loop.
6, The loop should be passed
through the D-ring in the
corners of the Trillium
5, The ratchet has a loop in
its strap
10, Pushing the strap back
into the knot will loosen it.
7, Pass the ratchet through
the loop.
Attaching The Ratchets
With the tree straps attached and the
Trillium base laid in postion, you can now
attach the 3 ratchet straps to the D-rings at
each corner.
13 14
Rear/TailRear/Tail
Front:Front:
Attach ratchet to each cornerAttach ratchet to each corner

15, Give a strong pull before 15, Give a strong pull before
cranking the ratchet. cranking the ratchet.
14, Lift the Trillium off the ground14, Lift the Trillium off the ground
by pulling through excessby pulling through excess
strap at each point.strap at each point.
12, Feed the tree strap end 12, Feed the tree strap end
through the spindle.through the spindle.
11, Ensuring there’s enough 11, Ensuring there’s enough
length, bring the ratchet length, bring the ratchet
and tree strap together.and tree strap together.
13, Feed it in and pull it 13, Feed it in and pull it
through making sure it through making sure it
does not twist.does not twist.
15 16
Fitting Strap To The Ratchet
With the ratchet strap attached to
the D-rings, it can now be connected
to the tree straps.
Check each corner of the Trillium base is
aligned to each anchor point.

Lift the innerLift the inner
latch handlelatch handle
to disengageto disengage
locking platelocking plate Push down soPush down so
it latches at.it latches at.
20, Once achieved, move the 20, Once achieved, move the
handle to the closedhandle to the closed
position and lock. position and lock.
19, Do this until the handle 19, Do this until the handle
has strong resistance.has strong resistance.
17, This will release the handle 17, This will release the handle
and allow it to be cranked. and allow it to be cranked.
16, Release the ratchet 16, Release the ratchet
lock by pushing the inner lock by pushing the inner
latch upwards.latch upwards.
18, Pull the handle back18, Pull the handle back
and begin cranking and begin cranking
it back and forth. it back and forth.
Tightening The RatchetTightening The Ratchet
Cranking the ratchet will give the tension Cranking the ratchet will give the tension
needed and allows for easy adjustment.needed and allows for easy adjustment.
Ensure the ratchet is correctly in the locked Ensure the ratchet is correctly in the locked
position before continuing.position before continuing.
Attention - Ratchet Locking
Crank the ratchet handle back & forth
7- 9 times to increase tension to straps.
17 18
UNLOCKED LOCKED
LOCKING RATCHET

19 20
Aligning The Trillium BaseAligning The Trillium Base
With the Trillium base now raised, you With the Trillium base now raised, you
must ensure it is correctly aligned with themust ensure it is correctly aligned with the
anchor points.anchor points.
From the centre point of each side ofFrom the centre point of each side of
the Trillium base, the tree straps should linethe Trillium base, the tree straps should line
up straight as shown.up straight as shown.
21, Once the Trillium base is up, 21, Once the Trillium base is up,
ensure it is aligned with theensure it is aligned with the
trees - this means the treetrees - this means the tree
strap must be as straight asstrap must be as straight as
possible to the Trillium base.possible to the Trillium base.
This creates the correct tensionThis creates the correct tension
needed on all corners. If not, needed on all corners. If not,
it will hang incorrectly andit will hang incorrectly and
be unstable.be unstable.

All done!All done!
With it now secured and aligned you canWith it now secured and aligned you can
enjoy your Trillium. Be use not to exceedenjoy your Trillium. Be use not to exceed
our maximum load of 400kg / 880lbs.our maximum load of 400kg / 880lbs.
21 22

Floor Strap Calibration How to use the Ratchet
23 24
UNLOCKED LOCKED
Crank the ratchet handle back & forth 7- 9 times to
increase tension to straps.
Note: All Trilliums come pre-calibrated direct from the factory. You should only need to calibrate the oor again after
many uses. Due to the fact that over time, the fabrics stretch but the seat belt does not, you may need to carry out this
procedure once a year to ensure that the oor is kept in equilibrium and tight on all sides.
If the outside edge of the Trillium is looser than the
underoor straps, you will need to loosen the underoor
straps. Getting the right balance between the outside
edge (periphery strap) and the underoor straps may
take some practice but you will know when you have
got it right! This procedure should be carried out if
ou feel like you are rolling outwards ( towards the edge )
or inwards ( towards the central hatch ) while using
your Trillium.
1, Loosen all oor straps by feeding 3”/10cm backwards
through the adjuster buckles under each corner of
the Trillium.
2, Set up as normal, to the point where you have raised
the Trillium off the ground by pulling excess orange
strap through and have cranked the ratchets to hold
the Trillium off the oor.
3, Trilliums should be raised, and set at half tension ( you
should still be able to ap it up and down quite easily
by about 1”/30cm ).
4, Pull underoor straps through adjuster buckles at
each corner, past the crease left from earlier use by
about ½” / 1cm on each corner.
5, Ratchet to full tension and check all sides are of
equal tension to each other and equal to the under
oor straps.
6, Repeat procedure until you have the right balance
between each edge of the Trillium and the underoor
straps that divide each hammock berth inside.
1) Take tail end of the long strap around your trees
and thread through the loop and away from tree,
towards your Tentsile Tree Tent.
2) Thread loop of the ratchet through the D-Ring at
each corner of your Tentsile Tree Tent and take the
buckle through the loop.
3) Take long strap tail and thread it through the ratchet
buckle spindle, pulling through all excess orange
strap. Crank ratchet until the orange strap has gone
around the spindle at least 1.5 full revolutions to
underlock it. This will prevent any slippage before
moving to the next corner.
4) Repeat step 3 at each corner, trying as much as
possible to keep the corners pointing towards their
respective anchor points.
5) Revisit all corners and adjust as necessary.
Use line of sight down each strap to centralise
your Tentsile Tree Tent between your chosen
anchor points. You have about a 7º degree
margin of tolerance in each direction.
6) Tighten ratchets as much as you can.
ENSURE RATCHETS ARE IN LOCKED POSITION
BEFORE ENTERING THE TENTSILE TREE TENT.
7) Roll and tidy up strap ends to avoid any
possible trip hazzards.

25 26
Policies The small print
Maintenance
Visual and Tactile inspection of all components for structural
damage before every use and dry out Tentsile Tree Tent
thoroughly before packing away. Tentsile Tree Tent should be
stored safely in a dry environment.
Returns
If a customer wishes to return a Tentsile product within 30 days,
they need to pack the unit clean and dry, with all components
included. Retailer can choose to resell this item or send it back to
Tentsile for a credit note.
A restocking fee will be applied (charged to customer) if the tent
is wet, dirty or missing parts. Return shipping will be at customer’s
expense.
Weather
The Tentsile Tree Tent is not intended to be used in severe
weather. If there is weather that creates dangerous conditions,
such as storms, heavy rain, high winds, and/or lightning, do
not use or remain in the Tentsile Tree Tent in or during those
conditions. It is recommended that the Tentsile Tree Tent is taken
down and stored to avoid remaining inside and being subject to
such conditions. Leaving the Tentsile Tree Tent out and installed
in bad weather can lead to potential destruction and/or damage
to it (not covered by warranty). If the Tentsile Tree Tent is subject
to such conditions, it and its anchor/hanging system should be
inspected in detail prior to any future use. Be sure to thoroughly
dry the Tentsile Tree Tent before storing.
Customer Service Charter
Quality rst – We will manufacture, sell and distribute the best
possible quality Tentsuile Tree Tents in the World.
Customer focus – We will provide prompt, courteous and
efcient service, with honesty and integrity and expert, clear, and
timely information to customers and colleagues.
Tentsile Promise - We will strive for a ‘get it right rst time, every
time’ in all our dealings in manufacturing, distribution, sales, and
service.
This policy does not cover damage incurred by environmental
conditions, weather conditions, or apocalyptic events.
Contact us
*use as intended and outlined herein and no more than 3 months
continuous use.
The Tentsile Tree Tent is designed for play, relaxation, and
camping/sleeping. Never jump into, onto or use it as a
trampoline or swing. It is not intended to be used for rock
climbing, cliff faces, overhangs or above or next to large
drops. Do not attach or secure the Tentsile Tree Tent to a
movable platform or anchor; it is not intended to be used
for such recreation or activities. Do not attempt to use this
product for anything other than its intended purpose, and
always observe height and weight limits.
Warranties
Manufacturing Warranty
Tentsile will accept and replace any product with a
manufacturing warranty straight out of the box.
These units should be marked as defective and
[email protected] should be contacted, so that
we can pick up these items and replace them.
Claims of Defects under 1 Year Warranty
Any damage, breakage or defect found after customer use
needs to be assessed on a case-by-case basis. Tentsile will
accept any fault considered
to be manufacturer’s defect if the product is used within Terms
of Use, as set out in Owner’s Manual.
Tentsile will not accept any damage, breakage or defect
caused by customer outside these Terms of Use. This would
include setting up product
outside guided Owner’s Manual instructions, recklessness,
carelessness, misuse product or misunderstanding of product
set up instructions provided.
assessment. Our team will assess if the damage is covered by
warranty, of customer error.
In cases of warranty, Tentsile will ask to be put directly in
touch with customer and we will pick up the unit and replace
it directly with them.
In cases of customer damage, the retailer can pass customer
directly over to talk to our team. Tentsile will then organise for
customers to send their unit in for repair.
Please note:
All Tentsile products are fabric structures which will degrade
over time due to wear and tear. This includes environmental
conditions such as user care, storage conditions, packing
conditions and UV exposure.
Tentsile products comes with care instructions including; not to
be left unattended for more than 1 week. Do not leave set up
for more than 3 months at a time ( product needs to be taken
down and inspected every 3 months for damage and wear
and tear to components), Products have differing levels of UV
protection. Safari Trillium – 3,500 UV hours.
Tentsile will not be held liable for environmental damage
caused by high winds, falling branches, damage made by
animals or any other environmental factors.

All rights reserved Tentsile Ltd
Patent Approved
www.tentsile.com
Table of contents
Other Tentsile Hammock manuals
