Terex Genie Lift Guard S-45 User manual

Maintenance Manual
- Booms
S®Booms
This manual includes detailed
procedures for each
maintenance inspection.
Z®Booms
For Repair procedures, Fault
Codes,
Electrical and Hydraulic
Schematics, refer to the
appropriate Service and Repair
Manual for your machine.
Refer to the inside cover for a list of models
included in this manual.
Original
Instructions
Part No. 1268489GT
Rev J2
June 2022

Maintenance Manual June 2022
Introduction
ii S®Booms • Z®Booms Part No. 1268489GT
Intro ductio n Intro ductio n
Important
Read, understand and obey the safety rules
and operating instructions in the appropriate
Operator's Manual on your machine before
attempting any maintenance procedure.
This manual provides detailed scheduled
maintenance information for the machine
owner and user.
Basic mechanical, hydraulic and electrical
skills are required to perform most procedures.
However, several procedures require
specialized skills, tools, lifting equipment and a
suitable workshop. In these instances, we
strongly recommend that maintenance be
performed at an authorized Genie dealer
service center.
Compliance
Machine Classification
Group B/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection
and scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However,
continuous improvement of our products is a
Genie policy. Therefore, product specifications
are subject to change without notice.
Readers are encouraged to notify Genie of
errors and send in suggestions for
improvement. All communications will be
carefully considered for future printings of this
and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Copyright © 2015 by Terex Corporation
1268489GT Rev J, May 2020
First Edition, Ninth Printing
Genie, "S" and "Z" are registered trademarks of Terex
South Dakota, Inc. in the U.S.A. and many other
countries.
"TraX" and "XC" are trademarks of Terex South Dakota,
Inc.

June 2022 Maintenance Manual
Introduction
Part No. 1268489GT S®Booms • Z®Booms iii
Models included in this
manual
Use the following chart to identify the specific
serial number for models included in this
manual.
Models
Serial number
S
-40, S-45, S
-
40HF, S
-
45HF,
S
-40XC,
S
-45XC
from S4015-20505 to S4016H-23499
from S4515-20505 to S4516H-23499
from S40H-23500 from S45H-23500
from S40XCH-101
from S45XCH-101
S
-60, S-65, S
-
60HF, S
-
65HF, S
-60J,
S
-60X, S-
60XC, S
-
65XC
from S6013-26296 to S6016-31260
from S6016N-31261 to S6016N-35000
from S6016H-35001 to S6016H-36399
from S6014D-101 to S6016D-639
from S6016M-101 to S6016M-399
from S60X13-26296 to S60X16H-36399
from S60XC13-26296 to S60XC16H-
36399
from S60HC13-26296 to S60HC15A-
29544 from S60TX13-26296 to
S60TX16H-36399
from S60TX14D-101 to S60TX16D-639
from S65TX13-26296 to S65TX16H-
36399
from S65TX14D-101 to S65TX16D-639
from S60H/S60X/S60TX/S65TXH-36400
from S60XCH-36400 to S60XCH-45000
from S60XCH/S65XCH-45001
from S60/S60TX/S60XD-640
from S60JH-101
from S60M-400
from S65XCM-101
from S65TXM-101
S
-80, S-85, S
-
80X, S
-
80XC,
S
-85XC, S-
80HF, S
-
85HF, S
-80J
from S80/85/80X15-12264 to16H-13999
from S80/85/80X15D-101 to 16D-339
from S80/85/80XH-14000
from S80/85/80XD-340
from S80/85XCH-101
from S80JH-101
S
-100, S-105 from S10015D-1001 to S10016D-1549
from S10515D-983 to S10516D-1549
from S100D-1550
from S105D-1550
S
-120, S-125 from S12015D-1012 to S12016D-1549
from S12515D-984 to S12516D-1549
from S120D-1550
from S125D-1550
S
-100HD,
S
-120HD
from S100HD14D-200 to S100HD16D-
229
from S120HD14D-201 to S120HD16D-
229
from S100/S120HDD-230
SX
-105 XC from SX105D-101
SX
-125 XC from SX125D-101
SX
-135 XC from SX135H-101
SX
-150 from SX15015-100 to SX15016H-499
from SX150H-500
SX
-180 from SX18014-101 to SX18016H-599
from SX180H-600

Maintenance Manual June 2022
Introduction
iv S®Booms • Z®Booms Part No. 1268489GT
Z
-30/20N, Z-
30/20N RJ
from Z30N14-15222 to Z30N16F-18899
from Z30N16D-104 to Z30N16D-199
from Z30NF-18900
from Z30ND-200
Z
-33/18 from Z331815M-101 to Z331816M-1299
from Z3318M-1300
Z
-34/22 DC from Z3414-9686 to Z3416F-11999
from Z34F-12000
Z
-34/22 N from Z34N14-10984 to Z34N16F-13999
from Z34N15D-102 to Z34N16D-279
from Z34NF-14000
from Z34ND-280
Z
-34/22 IC from Z3406-4800 to Z3413-9460
from Z3413-9461 to Z3415-10688
from Z3416F-10689 to Z3416F-11999
from Z34F-12000
Z
-34/22 BE from Z3414-9686 to Z3416F-11999
from Z34F-12000
Z
-40/23N RJ from Z40N13-1902 to Z40N16N-4499
from Z40NN-4500
Z
-45/25 DC,
Z
-45/25J DC
from Z452513A-48153 to Z452516N-
57199
from Z452513B-3078 to Z452516M-6699
from Z452513D-101 to Z452516D-939
from Z4525D-940
from Z4525M-6700
from Z4525N-57200 to Z4525N-58604
from Z4525F-58605
Z
-45/25 IC, Z-
45/25J IC, Z
-
45HF, Z
-
45XC
from Z452513A-47001 to Z452516N-
57199
from Z452514B-3301 to Z452516M-6699
from Z452513D-101 to Z452516D-939
from Z4525D-940
from Z4525M-6700
from Z4525N-57200 to Z4525N-58604
from Z4525F-58605
from Z4525XCF-101
from Z4525XCM-101
Z
-45/25(J) BE from Z452513A-48153 to Z452516N-
57199
from Z4525N-57200 to Z4525N-58604
from Z4525F-58605
from Z4525M-6700
Z
-45 DC, Z-
45 FE
from Z45EM-101
Z
-51/30J from Z513014B-1201 to Z5130M-2000
from Z5130M-2000
Z
-60/37 DC,
Z
-60/37 FE
from Z6016N-101 to Z6016N-599
from Z60N-600 to Z60N-700
from Z60H-701
Z
-62/40 from Z6215A-101 to Z6216N-2999
from Z6216D-101 to Z6216D-149
from Z6216M-101 to Z6216M-399
from Z62D-150
from Z62H-3000
from Z62M-400
Z
-80/60 from Z8013-4592 to Z8016H-6399
from Z80H-6400
Z
-135/70 from Z13505-101 to Z13513-2000
ZX
-135/70 from ZX13514-2533 to ZX13516H-3199
(includes 2463, 2469, 2531)
from ZX135H-3200

June 2022 Maintenance Manual
Introduction
Part No. 1268489GT S®Booms • Z®Booms v
Identifying the Correct
Procedure for your Model
Unless otherwise noted, each procedure will
apply to all models. Procedures that only apply
to specific models or options will include the
information in the procedure title.
Examples of procedures that apply to specific
models:
•Test the Engine Idle Select - Engine
Models
•Test the Turntable Level Sensor - Z-
80/60
•ALC600 Models, include the following
models: S-40HF, S-45HF, S-40 XC, S-
45 XC, S-60HF, S-65HF, S-60J, S-60
XC from S60XCH-45001, S-65 XC, S-
80HF, S-85HF, S-80J, S-80 XC and S-
85 XC.
•ALC1000 Models, include the following
models: S-100, S-100HD, S-105, S-
120, S-120HD, S-125, SX-105 XC, SX-
125 XC, SX-135 XC, SX-150, SX-180,
Z-80/60, Z-135/70 and ZX-135/70.
Examples of procedures that apply to all
models:
•Test the Drive Speed – Stowed
Position
•Inspect the Tires, Wheels and Lug Nut
Torque
Find additional Manuals for
your Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's
Manuals.

Maintenance Manual June 2022
Introduction
vi S®Booms • Z®Booms Part No. 1268489GT
Revision History
Revision Date Section Procedure / Description
A 9/2015 Initial Release
A1 10/2015 Quarterly Q-27 Test the Primary Angle Sensor
A2 11/2015 Specifications Hydraulic and Drive Hub Capacities
A3 11/2015 Introduction Updated Z-80/60 serial number for models included
A4 12/2015 Quarterly Q-17 Inspect the Calibration Decal
A5 1/2016 Specifications Performance Spec. Z62
B 3/2016 All Sections Add Z-60 DC/FE
Specifications Add Kubota D1105-E4B, GM .998L, GM 3.0L.
Update Deutz D2.9 L4 and Perkins 404F engine rpm's
B1 4/2016 Quarterly Q-7 Check the Generator Belts, Pulleys and voltage - Bi-Energy
Models
Annual
A-3 Inspect for Turntable Bearing Wear
B2 6/2016 Specifications Tires and Wheels, add Z60 DC/FE
B3 9/2016 Introduction Models Included
C 11/2016 All Sections Add SX-135 XC
C1 12/2016 Quarterly Q-26 Test the Secondary Boom Angle Sensor
D 2/2017 Quarterly Q-36 Inspect and Adjust Boom Cables
Annual A-3 Inspect Turntable Bearing Wear
A-11, A-12, A-13 Inspect Boom Cables
Programmed P12-2 Remove and Inspect Boom Cables
E 3/2017 All Sections Add SX-125 XC. Add Z-45 XC CE/AS Models
E1 3/2017 Programmed Remove 10 year cable inspection
F 6/2017 All Sections Add S80/85 XC, SX-105 XC
Specifications Add Deutz D436 L3i CN3 Engine
F1 4/2018 Specifications Deutz TD2011 Engine Specifications
G 10/2018 All Sections Add S60XC, S-65XC, S-80HF, S-85HF Models
Add Perkins 404F-E22T, 404F-E22TA Engine
H 5/2019 All Sections Add S60/S65/Z45XC ANSI/CSA, S60/65HF, S40/S45XC Models
Quarterly Q-17, Q-33
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view the update.
Section – Maintenance, (procedure)

June 2022 Maintenance Manual
Introduction
Part No. 1268489GT S®Booms • Z®Booms vii
Revision History (continued)
Revision Date Section Procedure / Description
J
2/2020
All Sections
Add S40/45HF, S60J, Z45DC/FE, Z45HF models. Add Deutz TD/TCD
2.2 L3 engine
Specifications Hydraulic Specifications
Annual A-11, A-12, A-13
Programmed P0-6, P1-1
J1 3/2022 All Sections Add S80J model
Annual A-8, A-9, A-15, A-16, A-17, A-18
J2 6/2022 Annual Remove A-4, A-8, A-9, A-10, A-15, A-16, A-17, A-18
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view the update.
Section – Maintenance, (procedure)

Maintenance Manual June 2022
Safety Rules
viii S®Booms • Z®Booms Part No. 1268489GT
Sec ti on 1 Safety Rul es
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when
maintenance and repair procedures are
performed.
Do not modify or alter a MEWP without prior
written permission from the manufacturer.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

June 2022 Maintenance Manual
Safety Rules
Part No. 1268489GT S®Booms • Z®Booms ix
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to
identify the following:
Safety alert symbol
—used to
alert personnel to potential
personal injury hazards. Obey all
safety messages that follow this
symbol to avoid possible injury or
death.
Indicates a imminently hazardous
situation which, if not avo
ided,
will result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or
moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved
steel
-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an
approved fire extingu
isher within easy
reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free
of debris that could get into machine
components and cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins an
d self-locking
nuts) are not reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or work
area
is properly ventilated and well lit.

June 2022
Table of Contents
x S®Booms • Z®Booms Part No. 1268489GT
Introduction Introduction...................................................................................................... ii
Important Information ..........................................................................................ii
Models included in this manual...........................................................................iii
Identifying the Correct Procedure for your Model ................................................ v
Find additional Manuals for your Model .............................................................. v
Revision History .................................................................................................vi
Section 1 Safety Rules .................................................................................................. viii
General Safety Rules .......................................................................................viii

June 2022
Table of Contents
Part No. 1268489GT S®Booms • Z®Booms xi
Section 2 Performance Specifications.............................................................................1
Function Speeds - S-100, S-105 and S-100HD...................................................1
Function Speeds - S-120, S-125 and S-120HD...................................................2
Function Speeds - All Other Models....................................................................3
Drive Speeds......................................................................................................9
Torque Specifications ....................................................................................13
Tires and Wheels .............................................................................................13
TraX Torque Specifications...............................................................................15
Engine Specifications ....................................................................................16
Engine Operator and Maintenance Manuals .....................................................16
Deutz Engine Models .......................................................................................17
Perkins Engine Models .....................................................................................18
Ford Engine Models .........................................................................................20
Kubota Engine Models......................................................................................21
GM Engine Models ...........................................................................................22
Continental Engine Models ...............................................................................22
Cummins Engine Models..................................................................................23
Hydraulic Specifications ................................................................................24
Hydraulic Relief Valves.....................................................................................24
Hydraulic and Drive Hub Fluid Capacities .........................................................27
Hydraulic Oil Specifications ..............................................................................29
Hydraulic Hose and Fitting Torque Specifications .............................................32
Torque Procedure ............................................................................................33

June 2022
Table of Contents
xii S®Booms • Z®Booms Part No. 1268489GT
Section 3 Maintenance Procedures............................................................................... 35
Introduction...................................................................................................... 35
Maintenance Schedule..................................................................................... 37
Pre-Delivery Preparation Report....................................................................... 38
Scheduled Maintenance Inspection Report - Quarterly or Frequent .................. 39
Scheduled Maintenance Inspection Report - Annual......................................... 40
Programmed Maintenance Inspection Report - Booms ..................................... 41
Commissioning Procedures .......................................................................... 42
C-1 Perform 50 Hour Service ........................................................................... 42
C-2 Perform Engine Maintenance – 50 Hours................................................... 42
C-3 Perform 150 Hour Service ......................................................................... 43
Quarterly Maintenance Procedures............................................................... 44
Q-1 Check for Open Bulletins and Owner Registration ..................................... 44
Q-2 Battery inspection...................................................................................... 45
Q-3 Inspect the Electrical Wiring ...................................................................... 47
Q-4 Inspect the Electrical Contactors - DC / Bi-Energy Models ......................... 48
Q-5 Check the Exhaust System........................................................................ 49
Q-6 Inspect the Tires, Wheels and Lug Nut Torque .......................................... 50
Q-7 Check the Generator Belts and Pulleys, Bi-Energy Models ........................ 50
Q-8 Check the Oscillate Directional Valve Linkage (if equipped) ....................... 52
Q-9 Visual Inspection of the Hydraulic Oil......................................................... 52
Q-10 Inspect the Hydraulic Filters..................................................................... 53
Q-11 Check and Adjust the Engine RPM.......................................................... 54
Q-12 Test the Ground Control Override............................................................ 60
Q-13 Test the Alarm Package (if equipped) ...................................................... 60
Q-14 Test the Emergency Power System......................................................... 61
Q-15 Test the Engine Idle Select - Engine Models............................................ 62

June 2022
Table of Contents
Part No. 1268489GT S®Booms • Z®Booms xiii
Q-16 Test the Fuel Select Operation - Gasoline/LPG Models ............................63
Q-17 Inspect the Calibration Decal - ALC1000 Models......................................64
Q-18 Test the Recovery Mode System - ALC-1000 Models...............................66
Q-19 Test the Platform Self-leveling .................................................................67
Q-20 Confirm the Proper Brake Configuration...................................................68
Q-21 Test the Drive Brakes ..............................................................................68
Q-22 Test the Drive Speed – Stowed Position ..................................................69
Q-23 Test the Drive Speed - Raised or Extended Position ................................69
Q-24 Test the Drive Speed – Raised and Extended, ALC1000 Models..............70
Q-25 Test the Turntable Level Sensor - Z-80/60, Z-135/70, ZX-135/70,
SX-105XC, SX-125XC, SX-135XC, SX-150 and SX-180 ...........................72
Q-26 Test the Secondary Boom Angle Sensor - Z-135/70 and ZX-135/70.........74
Q-27 Test the Primary Boom Angle Sensor - Z-135/70 and ZX-135/70..............76
Q-28 Test the Primary Boom Angle Sensor -
SX-105XC, SX-125XC, SX-135XC, SX-150 and SX-180 ...........................79
Q-29 Test the Safety Envelope Limit Switches - Z-135/70, ZX-135/70,
SX-105XC, SX-125XC, SX-135XC, SX-150 and SX-180 ...........................84
Q-30 Test the Primary Boom Angle Sensor - Z-80/60 .......................................88
Q-31 Test the Safety Envelope and Circuits - Z-80/60.......................................89
Q-32 Check the Safety Envelope Limit Switches and Angle Sensor -
S-60X, S-80X, and S-60XC to S60XC-45000 ............................................91
Q-33 Test the Safety Envelope and Circuits -
S-100, S-105, S-120 and S-125 ................................................................93
Q-34 Test the Aircraft Protection System (if equipped)......................................99
Q-35 Test the Operator Protection Alarm (if equipped)....................................101
Q-36 Inspect the Boom Extend/Retract Cables - All Models ............................101
Q-37 Test the Recovery Mode System - ALC600 Models................................102
Q-38 Test the Turntable Level Sensor - ALC600 Models.................................103
Q-39 Test the Primary Boom Angle Sensor - ALC600 Models.........................106

June 2022
Table of Contents
xiv S®Booms • Z®Booms Part No. 1268489GT
Annual Maintenance Procedures ................................................................ 108
A-1 Grease the Turntable Rotation Bearing and Rotate Gear ......................... 108
A-2 Check the Turntable Rotation Bearing Bolts............................................. 109
A-3 Inspect for Turntable Bearing Wear.......................................................... 111
A-4 Perform Maintenance - Jib Rotate Bearing............................................... 112
A-5 Test the Bypass/Recovery Key Switch - ALC1000 Models ....................... 114
A-6 Grease the Platform Overload Mechanism (if equipped)........................... 116
A-7 Inspect the Boom Extend/Retract Cables and Sheaves -
S-60/65, S-80/85 and S-80J Models ....................................................... 116
A-8 Inspect the Boom Extend/Retract Cables and Sheaves -
S-100, S-105, S-120, S-125, SX-105XC and SX-125XC ......................... 118
A-9 Inspect the Boom Extend and Retract Cables and Sheaves -
SX-135XC, SX-150 and SX-180 ............................................................. 120
A-10 Check the Drive Hub Oil Level and Fastener Torque.............................. 124
A-11 Perform Engine Maintenance................................................................. 128
A-12 Perform Engine Maintenance................................................................. 129

June 2022
Table of Contents
Part No. 1268489GT S®Booms • Z®Booms xv
Programmed Maintenance Procedures.......................................................130
P0-1 Check the Track Tension and Fastener Torque, TraX Models -
S-60, S-65, S-60 XC, S-65 XC, Z-62 Models ...........................................130
P0-2 Check the Track Tension and Fastener Torque, TraX Models -
S-40, S-45, S-40 XC, S-45 XC Models ....................................................131
P0-3 Grease the Extendable Axles - S-100, S-105, S-120 and S-125 .............133
P0-4 Continental Engine Maintenance – Under 1000 Hours............................134
P0-5 Cummins Engine Maintenance – Under 1000 Hours...............................135
P0-6 Deutz Engine Maintenance – Under 1000 Hours ....................................136
P0-7 Ford Engine Maintenance – Under 1000 Hours ......................................137
P0-8 Kubota Engine Maintenance – Under 1000 Hours ..................................138
P0-9 Perkins Engine Maintenance – Under 1000 Hours..................................140
P0-10 GM .998L Engine Maintenance – Under 1000 Hours ............................141
P0-11 GM 3.0L Engine Maintenance – Under 1000 Hours ..............................142
P1-1 Perform Engine Maintenance – 1000 Hours ...........................................143
P1-2 Replace the Drive Hub Oil......................................................................145
P1-3 Perform Engine Maintenance – 1500 Hours ...........................................148
P2-1 Perform Engine Maintenance – 2000 Hours ...........................................148
P2-2 Test or Replace the Hydraulic Oil ...........................................................150
P2-3 Replace the Hydraulic Filters..................................................................151
P2-4 Check the Free-wheel Configuration.......................................................153
P2-5 Check the Boom Wear Pads ..................................................................155
P2-6 Check the Extendable Axle Wear Pads -
S-100, S-105, S-120, S-125, S-100HD and S-120HD..............................158
P2-7 Check the Turntable Rotation Gear Backlash .........................................158
P2-8 Grease the Steer Axle Wheel Bearings, All 2WD Models,
Except S-60, S-65, Z-60 DC/FE and Z-62 ...............................................159
P2-9 Grease the Steer Axle Wheel Bearings, 2WD Models -
S-60, S-65, Z-60 DC/FE and Z-62 ...........................................................161

June 2022
Table of Contents
xvi S®Booms • Z®Booms Part No. 1268489GT
P3-1 Perform Engine Maintenance – 3000 Hours ........................................... 162
P4-1 Perform Engine Maintenance – 4000 Hours ........................................... 164
P5-1 Perform Engine Maintenance – 5000 Hours ........................................... 164
P6-1 Perform Engine Maintenance – 6000 Hours ........................................... 165
P12-1 Perform Engine Maintenance – 12000 Hours ....................................... 165
P12-2 Remove and Inspect the Boom Extend/Retract Cables ........................ 166
Cable Replacement Criteria ...................................................................... 168

June 2022 Maintenance Manual
Performance Specifications
Part No. 1268489GT S®Booms • Z®Booms 1
Sec ti on 2 Perfor man ce S peci fi catio ns
Function Speeds - S-100, S-
105 and S-100HD Models
Note: Function speeds are maximum from platform
controls with maximum rated load in platform.
Function speeds are shown in seconds.
Primary boom up/down,
(retracted)
80 - 88
Primary boom up/down,
extended to >4 ft / >1.2 m
(time from fully stowed to the
fully raised position)
100 - 100
Primary boom up/down,
extended to >80 ft / >24.4 m
(time from 53° envelope limit to
the fully raised position)
50 - 55
Primary boom extend,
fully raised position
(0 to 100 ft / 0 to 30.5 m)
120 - 140
Primary boom retract,
fully raised position
(100 to 0 ft / 30.5 to 0 m)
120 - 140
Jib boom up/down,
(S-105 models)
28 - 32
Turntable rotate, 360°
boom horizontal and fully
retracted
170 - 190
Turntable rotate,
boom horizontal and extended
>0 ft / >0 m
63 - 70
drive enable to drive enable
Turntable rotate,
boom fully raised and extended
>80 ft / >24.4 m
109 - 120
drive enable to drive enable
Platform rotate 18 - 22
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5
20 - 22

Maintenance Manual June 2022
Performance Specifications
2 S®Booms • Z®Booms Part No. 1268489GT
Function Speeds - S-120, S-
125 and S-120HD Models
Note: Function speeds are maximum from platform
controls with maximum rated load in platform.
Function speeds are shown in seconds.
Primary boom up/down,
(retracted)
80 - 88
Primary boom up/down,
extended to >4 ft / >1.2 m
(time from fully stowed to the
fully raised position)
100 - 100
Primary boom up/down,
extended to >80 ft / >24.4 m
(time from 53° envelope limit to
the fully raised position)
50 - 55
Primary boom up/down,
extended to >100 ft / 30.5 m
(time from 68° envelope limit to
the fully raised position)
24 - 28
Primary boom extend,
fully raised position
(0 to 100 ft / 0 to 30.5 m)
170 - 190
Primary boom retract,
fully raised position
(100 to 0 ft / 30.5 to 0 m)
170 - 190
Jib boom up/down,
(S-125 models)
28 - 32
Turntable rotate, 360°
boom horizontal and fully
retracted
170 - 190
Turntable rotate,
boom horizontal and extended
>0 ft / >0 m
63 - 70
drive enable to drive enable
Turntable rotate,
boom fully raised and extended
>80 ft / >24.4 m
109 - 120
drive enable to drive enable
Platform rotate 18 - 22
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5
20 - 22

June 2022 Maintenance Manual
Performance Specifications
Part No. 1268489GT S®Booms • Z®Booms 3
Function Speeds - All Other Models
Note: Function speeds are maximum from platform controls with maximum rated load in platform. Function
speeds are shown in seconds.
Function S-40, S-45, S-
40HF, S-45HF,
S-40XC, S-
45XC
(all models)
S-60, S-65, S-
60HC, S-60X, S-
60XC to 45000
(all models)
S-60HF, S-65HF,
S-60XC from
S60XCH-45001,
S-65XC
(all models)
S-60J S-80, S-85, S-
80X
(ANSI/CSA
models)
S-80, S-85
(AS/CE
models)
Primary boom up 50 - 60 60 -
70
65 - 75 60 - 66 57 - 65 75 -
83
Primary boom
down
50 - 60 60 -
70
65 - 75 60 - 66 61 - 69 75 - 83
Primary boom
extend
30 - 60 58 - 66 58 - 66 30 - 33 59 - 67 59 - 67
Primary boom
retract
15 - 35
53 - 62 53 - 62 30 - 33 57 - 65 57 - 65
Jib boom up 35 - 45
(S-45)
25 - 35
(S-45XC)
60 - 70
(S-65)
48 - 53
(S-65XC/HF)
25 - 35 25 -
35
(S-85)
25 - 35
(S-85)
Jib boom down 20 - 30
(S-45)
25 - 35
(S-45XC)
40 - 50
(S-65)
28 - 33
(S-65XC/HF)
15 - 25 15 - 25
(S-85)
15 -
25
(S-85)
Turntable rotate
stowed
70 - 100 78 - 86 78 - 86 67 - 84 90 - 103 90 -
103
Turntable rotate
extended
120 - 140 125 - 165 125 - 165 107 - 118 210 - 250 210 - 250
Platform rotate 6 - 10
(S-40/45)
8 - 12
(S-40/45XC)
8 - 12 5 - 15 18 - 22 8 -
12
8 - 12
Platform level
(10° range of
motion)
ANSI/CSA
AS/CE
3 - 5
20 - 22

Maintenance Manual June 2022
Performance Specifications
4 S®Booms • Z®Booms Part No. 1268489GT
Note: Function speeds are maximum from platform controls with maximum rated load in platform. Function
speeds are shown in seconds.
Function S-80J S-80XC, S-
85XC,
S-80HF, S-85HF
Z-30N, Z-30N
RJ
Z-34 BE Z-34N, Z-34
(DC models)
Z-33
Primary boom
up
65 - 70 75 - 83 14 - 22 14 - 22 16 - 22 36 - 40
(retracted)
48 - 52
(extended)
Primary boom
down
65 - 70 110 - 115 12 - 20 12 - 20 13 - 20 46 - 50
(retracted)
55 - 59
(extended)
Primary boom
extend
45 - 50 59 - 67 15 - 19 12 -
18
11 - 15 18 - 20
Primary boom
retract
45 - 50 57 - 65 10 - 14 12 - 18 13 - 17 18 - 20
Secondary
boom up
X X 11 - 18
11 - 18 15 - 22 20 - 24
Secondary
boom down
X X 7 - 15 7 - 15 11 -
18
20 - 24
Jib boom up 30 - 35 25 - 35
(S-85XC/HF)
19 - 23 23 - 29 20 - 24 X
Jib boom
down
30 - 35 15 - 25
(S-85XC/HF)
17 - 21 20 -
26
18 - 22 X
Jib boom
rotate
X X 13 - 17
(Z-30N RJ)
X X X
Turntable
rotate stowed
80 - 90 95 - 103 62 - 72 62 - 72 62 - 72 62 - 65
Turntable
rotate
extended
160 - 1804
Raised or
extended
210 - 250
Raised or
extended
X X X X
Platform rotate 10 - 15 40 - 50 5 - 11 5 - 11 5 - 11 X
Platform level
(10° range of
motion)
ANSI/CSA
AS/CE
3 - 5
20 - 22
10 - 12
