TERK Technologies Trinity Xtend User manual

SETUP GUIDE
Check out setup videos at
www.TERK.com/Setup
AMPLIFIED INDOOR HDTV ANTENNA
WITH WIFI EXTENDER
Instrucciones en español ...............21

2
3
Setup is easy!
Getting up and running with the Trinity Xtend has two parts.
1
2
Download the TERK
XTEND App on your
phone or tablet.
HDTV ANTENNA SETUP
(for free local HDTV)
WIFI EXTENDER SETUP
(for better Wi-Fi coverage around the Xtend)
Find the best place
for the Xtend.
Connect the Xtend to
your TV.
Scan for channels...
and enjoy free HDTV!
HD
HD
HD
NBC
HD
Use the XTEND App to
connect the Xtend to
your WiFi network.
HD
HD
HD
NBC
HD
Switch your streaming
devices to the Xtend’s
network...and enjoy
better Wi-Fi coverage
for your streaming
devices.

2
3
TV antennas perform best when facing the direction of
the broadcaster’s tower.
For help finding your local broadcast towers, go to
www.TERK.com
Antenna Placement Tips
Avoid metal surfaces (like a metal stand).
Move the antenna close to or in a window.
Position the antenna as high as possible.
Place the antenna.
Place the antenna on a flat surface next to your TV, facing the direction where most of
your broadcast towers are located.
Alternate Mounting Option
This antenna can be mounted to a wall as well. To mount this antenna to a wall: Install the included wall-
mount screws (and anchors, if needed) where desired. Align the keyholes on the bottom of the antenna with
wall-mounted screws, then lock the antenna into place.
Setup is easy!
Getting up and running with the Trinity Xtend has two parts.
Find the best location for your antenna.
1
HD ANTENNA SETUP
2
Download the TERK
XTEND App on your
phone or tablet.
WIFI EXTENDER SETUP
(for better Wi-Fi coverage around the Xtend)
Use the XTEND App to
connect the Xtend to
your WiFi network.
Switch your streaming
devices to the Xtend’s
network...and enjoy
better Wi-Fi coverage
for your streaming
devices.

4
5
IMPORTANT: Make sure your TV is turned off.
Raise the five elements to their upright position for
best performance.
For wall-mounting, raise the five antenna elements to their
full 180-degree position.
Raise the antenna’s five elements.
Connect the antenna’s coaxial cable to your TV.
HD ANTENNA SETUP (continued)
Amplifier
TV or
convert
er
box
(back)
ANTENNA
IN
3
Side view
4
5
6

4
5
Plug in the antenna’s power cord to a power outlet.
Raise the five elements to their upright position for
best performance.
Connect the antenna’s coaxial cable to your TV.
Most TVs have a channel scan option in their menu system, many times in a SETUP or
CHANNEL menu under ANTENNA. For detailed instructions on performing a channel
scan, see the owner’s manual that came with your TV.
Scan for channels on your TV.
IMPORTANT: For some channels you might get better performance with the Trinity Xtend antenna in
a different position or facing a different direction. Sometimes just a little bit of adjustment can make a
difference!
HD ANTENNA SETUP (continued)
The Trinity Xtend’s POWER light
illuminates to show that the Xtend is on.
Amplifier
TIP: The AMP / BYPASS switch lets you turn the amplifier for TV signals
on (AMP) or off (BYPASS). Most TV channels will perform better
with this switch left in the AMP position. However, if a channel is not
providing the performance you expect, try watching it with this switch
in the BYPASS position to see if that makes a difference.
5
6

6
7
Download the TERK XTEND App on your phone or tablet.
WIFI EXTENDER SETUP with the APP
1
2
IMPORTANT: The Terk Xtend WiFi Extender can also be set up via
web browser. See the WIFI EXTENDER SETUP with Computer section
on page 14 for more information.
In the Google Play or Apple App Stores, search for “TERK XTEND” and
look for the icon shown here. Then download and install the App.
Note: If you have a QR code reader on your phone or tablet, you can also go directly
to the App using the QR codes on the bottom of the Xtend.
IMPORTANT: Screenshots are for illustration purposes only—
your phone/tablet’s screens might look different.

6
7
ANDROID
Wi-Fi Name (SSID): XTN-000000
Web browser link: http://192.168.168.1/
User Name: admin Password: admin
Wi-Fi Password: 12345678
SN: GMA1B2T31E0001
MAC: 70F8E7200004
iOS
MADE IN CHINA
Download the TERK XTEND App on your phone or tablet.
Connect your phone or tablet to the Terk Xtend.
Go to the WiFi connections menu on
your phone or tablet (in the Settings
menu).
Look at the Wi-Fi Name (SSID) listed
on the bottom of the TERK XTEND.
Find that network listed in the list of
WiFi connection options on your phone
or tablet. Choose that SSID to connect
to it.
Enter the password listed on the
bottom of the Xtend when prompted.
Please note that the password is case-
sensitive.
WIFI EXTENDER SETUP with the APP (continued)
2
Bottom of the
Terk Xtend
In the Google Play or Apple App Stores, search for “TERK XTEND” and
look for the icon shown here. Then download and install the App.
Note: If you have a QR code reader on your phone or tablet, you can also go directly
to the App using the QR codes on the bottom of the Xtend.
iPhone menuAndroid menu
IMPORTANT: Screenshots are for illustration purposes only—
your phone/tablet’s screens might look different.

8
9
WIFI EXTENDER SETUP with the APP (continued)
Connect the Terk Xtend to your network.
In the first screen of the TERK
XTEND App, press the SCAN
button to start scanning for
available networks.
4
Launch the TERK XTEND App on your phone or tablet.
Press on the TERK XTEND App icon to launch the App.
3
iPhone screen Android screen
IMPORTANT: Screenshots are for illustration purposes
only—your phone/tablet’s screens might look different.
IMPORTANT: Screenshots are for illustration purposes
only—your phone/tablet’s screens might look different.

8
9
Connect the Terk Xtend to your network.
In the first screen of the TERK
XTEND App, press the SCAN
button to start scanning for
available networks.
Find your WiFi network in the list and
select it.
WHAT IF I DON’T SEE MY WIFI NETWORK?
• If your network does not broadcast its SSID,
it will show up in the list as [Hidden]. You
can enter the SSID manually by choosing the
[Hidden] option in the list and typing in the
name on the following screen.
• The Terk Xtend supports all password protection
schemes except WEP, which is a older and less
secure. Check how your Wi-Fi network appears
on your computer—if it uses WEP security, it
probably won’t appear in the XTEND App’s list.
Consider changing to a different security option.
• The Terk Xtend supports 2.4GHz 802.11 B/G/N
only. Check your wireless router to see if it is
supported.
Launch the TERK XTEND App on your phone or tablet.
WIFI EXTENDER SETUP with the APP (continued)
iPhone screen Android screen
IMPORTANT: Screenshots are for illustration purposes
only—your phone/tablet’s screens might look different.

10
11
Enter the password for your WiFi
network when prompted. Then press the
Next button.
IMPORTANT: If you chose [Hidden] from the list
of available networks, enter the name of your
WiFi network in the SSID field on this screen
before you enter your password.
iPhone screen Android screen
WIFI EXTENDER SETUP with the APP (continued)
IMPORTANT: Screenshots are for illustration purposes
only—your phone/tablet’s screens might look different.
DOUBLE-CHECK YOUR WIFI
NETWORK’S PASSWORD!!!
The router for your existing WiFi network won’t
tell the Xtend if the password in this step is
incorrect—it will simply not connect after the
Xtend reboots at the end of setup. So, it pays
to be extra careful entering the password in this
step!
IMPORTANT: Screenshots are for illustration purposes
only—your phone/tablet’s screens might look different.

10
11
WIFI EXTENDER SETUP with the APP (continued)
The next screen lets you change the name
and password of the Xtend from what’s
listed on the bottom of the Xtend to a
name and password of your choice (like
“upstairs-xtend,” for example). This step is
optional but recommended.
Just tap on each area, delete the old name
and password, and type new ones. Then
press NEXT to continue.
Note: If you want to customize the Xtend’s name
and password later, simply go through the App
setup again later.
iPhone screen Android screen
Enter the password for your WiFi
network when prompted. Then press the
Next button.
MAKE A NOTE
If you change your Xtend’s name and password,
make sure to make a note of it so that you don’t
forget. You’ll need this name and password to
connect your streaming devices to it!
IMPORTANT: Screenshots are for illustration purposes
only—your phone/tablet’s screens might look different.

12
13
5
iPhone screen Android screen The final screen of the Xtend setup shows
you the name and password of your
existing Wi-Fi network and the name and
password of the Xtend. You might want to
take a screenshot of this screen for your
records.
Press FINISH when you’re ready to
continue.
The final screen confirms that you’ve
finished setup and reboots the Xtend to
apply the network settings.
WIFI EXTENDER SETUP with the APP (continued)
WAIT FOR THE XTEND TO REBOOT!
Allow a minute or so for the Trinity Xtend to restart
before you start connecting devices to it. The LINK
light on the front of the Xtend will turn solid blue
when it’s ready to accept connections from your
devices.

12
13
Connect your devices to the Terk Xtend.
5
Once you’ve finished setup, wait for the Xtend to reboot with its new settings.
When the LINK light on the Xtend’s front panel turns solid blue, go into the WiFi
connection menus of the devices you want to use with the Xtend’s extended WiFi
range and choose the Xtend from the list of available devices to connect to.
IMPORTANT: You must connect to the Xtend in order to use it—otherwise, you
will still be using your existing WiFi router and you won’t get the benefits of the
extended WiFi range.
The final screen of the Xtend setup shows
you the name and password of your
existing Wi-Fi network and the name and
password of the Xtend. You might want to
take a screenshot of this screen for your
records.
Press FINISH when you’re ready to
continue.
The final screen confirms that you’ve
finished setup and reboots the Xtend to
apply the network settings.
WIFI EXTENDER SETUP with the APP (continued)
What to expect...
Once you’ve connected all of the streaming devices near the Xtend to the Xtend’s
network, you’re ready to take advantage of the Xtend’s enhanced WiFi coverage.
You should notice a stronger WiFi signal, which gives your streaming devices a
better chance to perform to their full potential given then speed of the connection
from your provider!
Keep in mind, however, that the connection speed you experience in your home
depends ultimately on the speed of the Internet connection you receive from your
service provider.

14
15
Top
Bottom
TOUR OF THE TRINITY XTEND
Using browser-based setup
The Terk Xtend WiFi Extender can also be set up via web browser on your computer.
1. In your computer’s WiFi connection menu, choose the Wi-Fi Name (SSID) from the bottom
sticker of the Terk Xtend. The password is also on the bottom sticker.
Give your computer a full minute to connect to this new network. You’ll see limited
connectivity.
2. Launch your web browser and enter the following URL:
http://192.168.168.1
If prompted for a user name and password, use admin for the user name and admin for the
password.
3. Follow the directions in the browser-based setup to configure the Xtend with your network.
4. When you’ve finished browser-based setup, wait for the Xtend to restart (about a minute or
so—the LINK light will turn solid blue), then connect the streaming devices you want to use
with the Xtend to the Xtend’s network.
WIFI EXTENDER SETUP with COMPUTER

14
15
POWER indicator illuminates when the Trinity Xtend is
plugged in.
LINK indicator illuminates when the Xtend is linked to
your home network.
ACTIVITY indicator flashes to show that there is WiFi
activity.
RESET button returns the Xtend to its factory default
settings, clearing all of your network information.
Reception elements pick up local television broadcast
and WiFi signals.
Mounting keyholes let you mount the Xtend to a wall
using the supplied mounting hardware.
SSID and password label gives you the information
necessary to set up the Xtend with your WiFi network.
This label also has QR codes for quick access to the
XTEND App for Android or iOS devices.
Top
Bottom
Mounting
keyhole
SSID / password
label
Reception element
TOUR OF THE TRINITY XTEND
Using browser-based setup
The Terk Xtend WiFi Extender can also be set up via web browser on your computer.
1. In your computer’s WiFi connection menu, choose the Wi-Fi Name (SSID) from the bottom
sticker of the Terk Xtend. The password is also on the bottom sticker.
Give your computer a full minute to connect to this new network. You’ll see limited
connectivity.
2. Launch your web browser and enter the following URL:
http://192.168.168.1
If prompted for a user name and password, use admin for the user name and admin for the
password.
3. Follow the directions in the browser-based setup to configure the Xtend with your network.
4. When you’ve finished browser-based setup, wait for the Xtend to restart (about a minute or
so—the LINK light will turn solid blue), then connect the streaming devices you want to use
with the Xtend to the Xtend’s network.
ANDROID
Wi-Fi Name (SSID): XTN-000000
Web browser link: http://192.168.168.1/
User Name: admin Password: admin
Wi-Fi Password: 12345678
SN: GMA1B2T31E0001
MAC: 70F8E7200004
iOS
MADE IN CHINA

16
17
Amplifier
AMP / BYPASS switch lets you turn the amplifier
for TV signals on (AMP) or off (BYPASS). Most
TV channels will perform better with this switch
left in the AMP position. However, if a channel is
not providing the performance you expect, try
watching it with this switch in the BYPASS position
to see if that makes a difference.
TOUR OF THE TRINITY XTEND (continued)
Antenna Reception Problems
I’m having trouble receiving certain channels.
• There are lots of factors that can affect your reception. Tall buildings, mature trees, even hills between
you and the broadcast towers can interfere and change the direction of the signals you receive. You
might still need to make adjustments after you position the antenna to account for these factors. Any
time you change the antenna’s position, make sure you re-scan for channels on your TV or digital TV
converter box. The channels you receive may have changed.
• Is the antenna sitting on a metal surface (like a metal stand)? Move it to a non-metal surface (metal
interferes with reception).
• Try using the antenna without the amplifier. Move the switch on the Xtend’s amplifier to the BYPASS
position.
• Move the antenna close to a window. Some construction materials (such as aluminum siding) make it
more difficult to get good reception. Re-scan for channels when you’re finished.
• Position the antenna as high as possible. Most of the time, this increases your chances of reception. Re-
scan for channels when you’re finished.
• Make sure you uncoil the antenna’s cable completely. Leaving it coiled will reduce reception
performance.
TROUBLESHOOTING

16
17
AMP / BYPASS switch lets you turn the amplifier
for TV signals on (AMP) or off (BYPASS). Most
TV channels will perform better with this switch
left in the AMP position. However, if a channel is
not providing the performance you expect, try
watching it with this switch in the BYPASS position
to see if that makes a difference.
Antenna Reception Problems
I’m having trouble receiving certain channels.
• There are lots of factors that can affect your reception. Tall buildings, mature trees, even hills between
you and the broadcast towers can interfere and change the direction of the signals you receive. You
might still need to make adjustments after you position the antenna to account for these factors. Any
time you change the antenna’s position, make sure you re-scan for channels on your TV or digital TV
converter box. The channels you receive may have changed.
• Is the antenna sitting on a metal surface (like a metal stand)? Move it to a non-metal surface (metal
interferes with reception).
• Try using the antenna without the amplifier. Move the switch on the Xtend’s amplifier to the BYPASS
position.
• Move the antenna close to a window. Some construction materials (such as aluminum siding) make it
more difficult to get good reception. Re-scan for channels when you’re finished.
• Position the antenna as high as possible. Most of the time, this increases your chances of reception. Re-
scan for channels when you’re finished.
• Make sure you uncoil the antenna’s cable completely. Leaving it coiled will reduce reception
performance.
TROUBLESHOOTING

18
19
WiFi Extender Problems
I don’t have an iPhone/iPad or Android phone/tablet. How can I set the Trinity Xtend up?
• The Terk Xtend WiFi Extender can also be set up via web browser. See the Using Browser-Based Setup
section on page 14 for more information.
I can’t connect my phone, tablet, or computer to the Trinity Xtend
• Make sure your phone, tablet, or computer has WiFi turned on.
• The Trinity Xtend will appear by its SSID in the list of available networks. Your Xtend’s SSID is listed on
the label on the bottom of the Xtend.
• You must enter the password listed with the SSID on the bottom of the Xtend in order to connect to
the Xtend.
I can’t connect to my WiFi network from the TRINITY XTEND App.
• Press the Scan button on the screen of the App in order to list the available networks in your area.
• If your network does not broadcast its SSID, it will show up in the list as [Hidden]. You can enter the
SSID manually by choosing the [Hidden] option in the list and typing in the name on the following
screen.
• The Terk Xtend supports all password protection schemes except WEP, which is a older and less
secure. Check how your Wi-Fi network appears on your computer—if it uses WEP security, it probably
won’t appear in the XTEND App’s list. Consider changing to a different security option.
• The Terk Xtend supports 2.4GHz 802.11 B/G/N only. Check your wireless router to see if it is supported.
TROUBLESHOOTING (continued)
My WiFi coverage and/or performance isn’t as good as I expected.
• Make sure you’ve connected each device you want to use to the Trinity Xtend, not directly to your WiFi
router. For example, if you want to use your streaming box, go to the WiFi connection settings on your
streaming box and find your Xtend’s SSID in the list of available connections (if you customized the
Xtend’s name and password, then connect to the customized name with the customized password—
otherwise, look at the label on the bottom of the Xtend for your unit’s default SSID and password).
• Use the TERK XTEND App to check the strength of the WiFi signal the Xtend is receiving from your
WiFi router. If the signal strength is less than two or three bars, you might need to move the Terk Xtend
and WiFi router closer together.
• Once you’ve connected all of your nearby devices to the Xtend, you should notice a stronger WiFi
signal, which gives your streaming devices a better chance to perform to their full potential given then
speed of the connection from your provider! Keep in mind, however, that the connection speed you
experience in your home depends ultimately on the speed of the Internet connection you receive from
your service provider.
I can’t reconnect to the Trinity Xtend.
• Make sure you haven’t automatically reconnected directly to your WiFi router. Go to the WiFi
connection settings for each of your devices and find your Xtend’s name (either the customized one
you created or the default on the bottom of the unit) in the list of available connections.
TROUBLESHOOTING (continued)

18
19
WiFi Extender Problems
I don’t have an iPhone/iPad or Android phone/tablet. How can I set the Trinity Xtend up?
• The Terk Xtend WiFi Extender can also be set up via web browser. See the Using Browser-Based Setup
section on page 14 for more information.
I can’t connect my phone, tablet, or computer to the Trinity Xtend
• Make sure your phone, tablet, or computer has WiFi turned on.
• The Trinity Xtend will appear by its SSID in the list of available networks. Your Xtend’s SSID is listed on
the label on the bottom of the Xtend.
• You must enter the password listed with the SSID on the bottom of the Xtend in order to connect to
the Xtend.
I can’t connect to my WiFi network from the TRINITY XTEND App.
• Press the Scan button on the screen of the App in order to list the available networks in your area.
• If your network does not broadcast its SSID, it will show up in the list as [Hidden]. You can enter the
SSID manually by choosing the [Hidden] option in the list and typing in the name on the following
screen.
• The Terk Xtend supports all password protection schemes except WEP, which is a older and less
secure. Check how your Wi-Fi network appears on your computer—if it uses WEP security, it probably
won’t appear in the XTEND App’s list. Consider changing to a different security option.
• The Terk Xtend supports 2.4GHz 802.11 B/G/N only. Check your wireless router to see if it is supported.
My WiFi coverage and/or performance isn’t as good as I expected.
• Make sure you’ve connected each device you want to use to the Trinity Xtend, not directly to your WiFi
router. For example, if you want to use your streaming box, go to the WiFi connection settings on your
streaming box and find your Xtend’s SSID in the list of available connections (if you customized the
Xtend’s name and password, then connect to the customized name with the customized password—
otherwise, look at the label on the bottom of the Xtend for your unit’s default SSID and password).
• Use the TERK XTEND App to check the strength of the WiFi signal the Xtend is receiving from your
WiFi router. If the signal strength is less than two or three bars, you might need to move the Terk Xtend
and WiFi router closer together.
• Once you’ve connected all of your nearby devices to the Xtend, you should notice a stronger WiFi
signal, which gives your streaming devices a better chance to perform to their full potential given then
speed of the connection from your provider! Keep in mind, however, that the connection speed you
experience in your home depends ultimately on the speed of the Internet connection you receive from
your service provider.
I can’t reconnect to the Trinity Xtend.
• Make sure you haven’t automatically reconnected directly to your WiFi router. Go to the WiFi
connection settings for each of your devices and find your Xtend’s name (either the customized one
you created or the default on the bottom of the unit) in the list of available connections.
TROUBLESHOOTING (continued)

20
QUESTIONS? We’re here to help!
Please call our toll-free help line at 1-800-768-1969 or visit TERK.com
I’m having intermittent connection problems.
• Make sure you’re connected to the Trinity Xtend, not directly to your WiFi router. Go to the WiFi
connection settings for each of your devices and find your Xtend’s name (either the customized one
you created or the default on the bottom of the unit) in the list of available connections.
• Use the TERK XTEND App to check the strength of the WiFi signal the Xtend is receiving from your
WiFi router. If the signal strength is less than two or three bars, you might need to move the Terk Xtend
and WiFi router closer together.
TROUBLESHOOTING (continued)
