TermaTech TT20 Guide

1
User and mounting manual
Please read also:
SUPPLEMENTARY INSTALLATION INSTRUCTIONS FOR THE UK MARKET
(last 6 pages)
Stove models:
TT20 + TT20R + TT20S + TT20RS
CE approved according to: DS/EN13240
DS (Danish Standard), DIN (Deutsche Industrienorm),
SINTEF (Norwegian Standard) and 15A (Austria)
(99-275)
(UK Version 27.05.2011)

2
Congratulations on your new wood-burning stove.
We thank you for choosing a TermaTech wood-burning stove and wish you
many cosy and warm moments in the future.
Before using the stove you should read the user and mounting manual and
also the SUPPLEMENTARY INSTALLATION INSTRUCTIONS FOR THE UK MARKET
(last 6 pages of this manual) so you are familiar with the legal requirements as
well as the instructions regarding maintenance. By this it is ensured that the
product works as it is intended and you get the most out of your investment
for many years to come.
Installation instruction........................................... Page 3
Lighting instruction............................................... Page 6
Maintenance......................................................... Page 8
Hints................................................................... Page 9
Remedy of malfunctions / FAQ................................ Page 10
Technical specifications.......................................... Page 11
Supplementary Inst. Instructions UK....................... Page 12

3
INSTALLATION INSTRUCTION
The stove is intended for ”intermittent combustion”. It is not meant to “heat
over” at night. By following the instruction below in “Lighting instruction” the
best and most environmentally friendly combustion is achieved.
The wood-burning stove is delivered ”ready for mounting” (the exhaust branch
may need to be screwed on) and must be connected to the chimney with a
smoke pipe. The connection between stove and chimney must, as far as
possible, be mounted in one straight piece (with as few bends as possible) and
as minimum horizontally, but preferably rising from the stove to the chimney.
Joints must be tight. Remember that is has to be possible to clean the pipe
(possibly with a cleaning hatch on the pipe).
Any unauthorised changes to the wood-burning stove will be viewed as a
structural change and thereby the warranty will be void and is also a risk to
safety.
In the door on your TT stove there is a spring that makes the door close by
itself when you let go of the handle.
This closing device is not a demand in the UK, Denmark and many other
countries and can therefore be removed. In the bottom hinge the split with
lentil head is removed which removes the tension from the spring. This is most
easily done by using a small screw driver and side-cutting pliers.
National and European norms
The regulations in force at the time in question, including those that refer to
national and European standards, must be respected when installing the wood-
burning stove. Contact your local dealer for further advice and guidance in
connection with mounting. Notify your Hetas installer before you use your
wood-burning stove. It must be ensured that there is sufficient airflow for the
combustion in the stove, so care must be taken concerning closely shut
windows and doors that may hinder the flow of air to the combustion.
Safety references
The surface of the stove as well as knobs, handle, window, smoke pipe, etc.
become very hot when the stove is in use. Touching these parts without
necessary protection (glove or other protective material) can lead to burns.
Remember to make children aware of this danger and make sure to keep them
away from the wood-burning stove when it is in use. For this purpose
TermaTech offers various grates for the protection of children. (Ask your
dealer)
Allowed in the wood-burning stove
Only use dry and clean wood for combustion in the wood-burning stove.
Maximum size of logs used in the stove is up to 30 cm in length and 10 cm in
diameter.

4
Only use dry wood. The burning of waste, synthetic materials and other
treated or impregnated materials is not allowed as it is very hazardous to the
environment. Furthermore the stove and the chimney will be damaged by
these materials. There is a danger of emission of unhealthy substances which
can also lead to complaints from neighbours.
Dry and clean wood has a maximum of 20% water which is achieved with
outdoor storage for between 1 year (soft wood) and 2 years (hard wood). The
wood must be in contact with air during storage so the moisture can get out of
the wood.
Firewood is not meant to ”burn overnight”. Never close off the airflow
completely, instead let the fire die out and light it again when you need it.
We warn against closing off the airflow completely. The wood-burning stove
can only burn sensibly and environmentally friendly if there is sufficient airflow
for the combustion.
Cleaning and checks
The wood-burning stove and the smoke pipe should be checked and cleaned
once a year. The chimney must also be cleaned by the chimney sweep who will
set the necessary intervals for cleaning / sweeping.
The wood-burning stove should be checked by a professional about once a
year.
Combustion air
Combustion air is a precondition for a good and clean combustion.
The air is normally taken from the room where the wood-burning stove is
mounted, however in some circumstances it may be necessary to provide extra
air in the room where the stove is placed. This can e.g. be done by mounting
an air valve in the room’s outer wall. Air valves that supply necessary
combustion air must be kept free from blockage.
An exhaust fan in the same room or close to the wood-burning stove can also
have a negative effect on the combustion (at worst it can lead to exhaust
gases in the room, even with the stove door closed). Therefore, in the above
case, the wood-burning stove and the exhaust fan must never be in use at the
same time.
The TT20 models are available with combustion air branch. Ask your dealer for
further information.
Adjustable feet:
The enclosed adjustable feet are to be used if the floor is uneven or they can
also be used to create the impression that the stove is “flying” / “floating”
Metal plate on the grate:
Delivered with the stove is a metal plate with 4 holes. This plate is to be placed
on the cast iron grate. The plate secures the cleanest combustion.
When you clean out ashes remove the plate from the grate and sweep ashes
down into the ashdrawer.

5
Distance to flammable material:
The stove must be put on a non inflammable foundation. This foundation must
as a minimum cover 150 mm on each side of the stove and 300 mm in front of
the stove.
For inflammable material like inflammable walls made of wood, furniture, etc.
the following minimum distances apply for safety reasons:
150 mm behind the stove to flammable material. (picture 2)
350 mm beside the stove to flammable material. (picture 2)
125 mm behind/beside if mounted 45° in a corner (picture 1)
1000 mm in front of the stove to flammable material.
Picture 1 Picture 2
Distance to non-flammable materials:
It is recommended that there is a minimum of 80-100 mm behind and beside
the stove so the stove can dispose of the heat, this distance makes cleaning of
and around the stove easier. In addition, refer to the relevant Building
Regulations.
Requirements for the chimney:
The chimney must be of sufficient height so the draught conditions are okay
the smoke does not bother anyone. Good draught in the chimney is crucial to
the stove working as intended and burns as environmentally friendly as
possible. The height of the chimney must typically be a minimum of 3.5 m
from the top of the stove to the top of the chimney.
The chimney must have a minimum internal diameter of Ø150mm.
The chimney must be equipped with an easily accessible cleaning hatch. All
joints and connections must be tight and the chimney must be able to provide
a draught of at least 1.2 mm water gauge (12Pa).
It is possible to connect the wood-burning stove to chimneys that are also
used for other purposes. However, the concrete conditions must be assessed
by the fitter and/or chimney sweep.

6
If the stove is to be mounted with back exit the following is done:
The round, welded or screwed cover plate at the back of the stove is removed.
Then the cut-out piece on the base-plate is removed (the thin division plate).
Be careful not to drop the piece between the back plate and the stove! This is
best done with a screwdriver / chisel or pliers.
Finally the screwed smoke cover is removed and then the exhaust branch can
be mounted.
Remember to fix the smoke cover at the top of the stove before use.
Demands for the floor:
The foundation must be able to bear the stove and possibly the chimney’s
weight.
LIGHTING INSTRUCTION
The first time:
The first time the stove is lit is must be done gently as all the materials need
to get use to the heat. The Senotherm varnish that the stove is painted with
will harden the first couple of times the stove is heated, and it may cause
some odour nuisances. So make sure that you have proper ventilation. Do not
touch the painted surface, when the stove is hot. The painting has to harden
up first.
Use of the stove:
Below is the procedure used for testing/approval of the stove. It is this
procedure that will lead to the best combustion for the given chimney.
Firewood amount and damper setting can be adjusted to the individual need
for heating and the draught in the concrete chimney.
On your new TT20 the work with controlling the air input has been simplified
so there is only one knob/damper (below the door).
Between the left position and the middle position you have the normal area
where you control the air input. No air input = left position and maximum
air input = middle position.
As help for lighting the control knob/damper can be pushed down a little and
pushed completely to the right. This start help adds some air from below and
ensures faster lighting. After a few minutes the control knob/damper is
returned to the normal position (between the left and middle position).

7
Lighting and continuous firing at EN-testing
1. The ashpan must always be closed completely, also when you light the fire.
The damper/start-up device can be opened (the knob is pushed down and to
the right) for a few minutes at lighting. Put about 10 kindling sticks (dia. 2-3
cm) in the bottom of the stove, laid in a criss-cross pattern as a log house.
Put 2 firelighters in the middle and light them.
2. Leave the door ajar so there is an opening of about 2-3 cm. Leave the stove
like that for about 8-10 minutes before you close the door completely. Stay
by the stove as long as the door is ajar.
3. When the fire has burned to embers (there are no more flames) open the
door gently so the ash is not whirled out through the door. Gently spread
out the embers with a poker so they are even.
4. Put 2-3 pieces of firewood in the stove, about 1.7 kg total. The pieces are
put in the bottom of the stove and parallel to the front of the stove with
equal distance to the stove’s sides and with mutual distance of about 1 cm.
The front piece is best lit if it has a split side that is turned to the door and
one in the embers. Close the door completely immediately.
5. The knob/damper is opened so it is about 2/3 open (between the left and
middle position) and after about 2 minutes the damper is set to about 1/3
open. How much the damper should be open depends on the individual
chimney’s draught, but the flames should now stabilise to a calm fire.
6. When the wood has burned to embers (after about 1 hour) you start again
from point 3.

8
MAINTENANCE –always use original parts
Maintenance and cleaning of the stove should only be performed when the
stove is cold.
The daily maintenance is limited, but once a year the stove should get
thorough maintenance. The combustion chamber should be cleaned for ashes
and soot and the door hinges and the closing mechanism should be lubricated
with copper grease.
The surface is maintained by brushing it with a soft, long-haired brush or by
using the vacuum cleaner with a brush. The stove can also be dusted with a
duster. Always remember: only when the stove is cold.
Jointings can look okay, but they collapse under the heat and thereby lose
the ability to keep the stove sealed. Jointings should be changed as needed as
it is important to good combustion and a clean window that the stove is sealed.
The insulation plates in the combustion chamber that are broken or worn
can easily be changed as they are loosely fixed. The material used is called
Vermiculite and is a porous, but very suitable insulation material. It has no
effect on the stove’s efficiency that the insulation cracks. However, it should be
changed when the wear surpasses half of the original thickness.
Painting the stove with Senotherm-spray can cover spots or small scratches
from kettles and such. Larger damages needs to be ground with fine steel
wool, vacuumed and then sprayed. The can has to be shaken vigorously and
then sprayed on at a distance of 15-20 cm. It is very important that the stove
is not in use and completely cold before you use the spray due to the fire
hazard. In order to keep the stove’s varnished surfaces looking nice for years
to come you should try to avoid touching the varnished surfaces when the
stove is hot. Make sure to have sufficient ventilation when using spray paint.
Glass normally does not need any maintenance apart from cleaning. This is
most easily done by using TermaTech’s glass cleaner. Remember only to use
glass cleaner when the stove is cold. Glass is made of ceramic glass, be sure of
environmentally disposal.
Original parts which need to be changed due to wear can be found at your
dealer. Because of fit etc. only original parts from TermaTech should be used.
Right to claim compensation for defective product is under current law.
When stating deviations the use of the product must be suspended
immediately and the dealer must be contacted.
Chimney/Flues Must be swept on regular occasions, as per manufacturers
recommendations.

9
HINTS
Lighting after long break
If the stove has not been used for a long time the chimney should be checked
for possible blockage before lighting. Furthermore it is a good idea to remove
any dust from the wood-burning stove as it might smell after a long break.
Chimney fire
In case of chimney fire the doors, drawers and damper of the wood-burning
stove must be closed immediately in order to shut of the supply of oxygen. The
relevant authorities must be notified if necessary. The stove must not be used
until the chimney has been inspected.
Kindling is the designation for finely split wood/sticks that are about 20 cm
long and have a diameter of 2-3 cm.
Wood like birch, beech, oak, ash, elm, pine wood and wood from fruit trees is
all suitable for splitting into firewood.
Waste products like pressure-treated wood, chipboard, coloured brochure or
glossy paper must not be used in a wood-burning stove. They develop
hydrochloric acid or heavy metals which cause a lot of damage to the stove
and the environment.
Firewood should have a diameter of 7-9 cm and be no more than about 30
cm long, otherwise it will get too close to the side of the stove (at the CE-
testing firewood at a length of 28 cm was used). The most important thing for
good combustion is that the wood is dry (15-20% moisture). If the firewood is
too wet it is difficult to get it to burn, the chimney draught is nonexistent,
there is a lot of smoke and the exploitation is lower as the water has to
evaporate first. Furthermore there may be damage to the stove and the
chimney in the shape of shining soot and tarry deposits. At worst it can cause
a chimney fire. If the firewood is too dry it will burn too quickly. Often the
gasses in the wood are released faster than they can burn and some go
unburned through the chimney. This also gives lower exploitation and harms
the environment.
So it is a balance that is quite easy to find with a little practise. See also below
under Storage.
Bio-briquettes can be used, but they develop a lot of ash and dust.
Put in max. 2 kg per hour.
Energy coke must not be used as it contains a lot of sulphur which wears on a
stove, the chimney and the environment. The life of stove and chimney will be
significantly reduced by using this firing type and the right to claim
compensation for the product is void.

10
Storage of the firewood is best under a roof, however with good ventilation,
e.g. in a carport or under a shed roof. Place the wood on a wooden pallet or
the like so it is free from the ground. Fresh wood that has been sawed and
split must be stored for about 1-2 years this way until the moisture in the
wood is down to 15-20%.
The ashes can be put in the rubbish bin for garbage collection. The ashes
should always have cooled for 1-2 days before it is put in the rubbish bin, as
there might still be embers that can light garbage or a garbage bag.
Regulation and smoke damper:
If one is fixed in the chimney it should not close of more than 80% of the
internal diameter of the chimney.
MALFUNCTIONS
If problems should occur with the use of the stove the cause can possibly be
found below. If not, then you are always welcome to contact your dealer.
The stove is difficult to control –it burns too fast
If the stove is new, then check that the directions have been followed.
If the stove is more than 1 year old or if it has been used heavily, then the
jointings may need to be changed. If the jointings sit for too long the heat
makes them lose their ability to keep the stove sealed.
Check that the ashpan is closed completely.
If there is heavy draught in the chimney it may be necessary to fit a damper in
it.
The stove has poor draught after installation
Check that the mounting instructions have been followed. It is especially the
conditions surrounding the chimney that may cause problems. Are diameter
and length okay, is it sealed, are smoke pipe and junctions sealed? Is the
cleaning hatch sealed? You may need to contact a chimney sweep to remedy
the problem as the chimney may be blocked.
Smoke at soot smell
This can be caused by down-draught in the chimney and most often happens
in specific wind directions. The chimney may be too short for the ridge or trees
may have grown and are creating turbulence.
Remember not to open the door while there are flames.
The stove is difficult to light and may die out
There may be a number of causes. The most typical are:
The damper is not sufficiently open.
The firewood is too wet.

11
The draught in the chimney is too small or maybe it is blocked or leaking.
The ember layer was too small/incinerated and did not give enough heat to
light the logs. Possibly give some start-up air to the fire by opening the
damper (pushed down and to the right) to get the stove going again. Then the
damper has to be closed again (back to position between left and the middle).
Depending on the problem it may be necessary to contact the dealer, installer
or a chimney sweep.
The glass soots up
The wood is too moist.
Lack of draught in the chimney.
Check that the damper is not closed.
Door is closed too early at lighting (point 3 section 2).
TECHNICAL SPECIFICATIONS
TT20 TT20R
Nominal heat output 5 kW 5 kW
Height: 1053mm 1053mm
Width: 478mm 531mm
Depth: 419mm 419mm
Weight: ca. 118kg ca. 119kg
TT20S TT20RS
Nominal heat output: 5 kW 5 kW
Height: 1088mm 1088mm
Width: 470mm 531mm
Depth: 419mm 419mm
Weight: ca. 155kg ca. 177kg
Average values for testing of TT20 models:
Exhaust gas temperature 273 °C
Exhaust gas mass flow 4.0 g/s
Efficiency 83,4%
Nominal Heat output 5 kW
Flue draught 12 Pa

12
SUPPLEMENTARY INSTALLATION INSTRUCTIONS FOR THE UK MARKET
TO BE READ IN CONJUNCTION WITH THOSE IN THE INSTRUCTION BOOKLET
R
R
RE
E
EA
A
AD
D
D T
T
TH
H
HE
E
E I
I
IN
N
NS
S
ST
T
TR
R
RU
U
UC
C
CT
T
TI
I
IO
O
ON
N
N B
B
BO
O
OO
O
OK
K
KL
L
LE
E
ET
T
T A
A
AN
N
ND
D
D T
T
TH
H
HE
E
ES
S
SE
E
E S
S
SU
U
UP
P
PP
P
PL
L
LE
E
EM
M
ME
E
EN
N
NT
T
TA
A
AR
R
RY
Y
Y
I
I
IN
N
NS
S
ST
T
TR
R
RU
U
UC
C
CT
T
TI
I
IO
O
ON
N
NS
S
S C
C
CA
A
AR
R
RE
E
EF
F
FU
U
UL
L
LL
L
LY
Y
Y B
B
BE
E
EF
F
FO
O
OR
R
RE
E
E I
I
IN
N
NS
S
ST
T
TA
A
AL
L
LL
L
LA
A
AT
T
TI
I
IO
O
ON
N
N
These instructions together with those in the instruction booklet cover the basic principles
to ensure the satisfactory installation of the stove, although detail may need slight
modification to suit particular local site conditions.
In all cases the installation must comply with current Building Regulations, Local Authority
Byelaws and other specifications or regulations as they affect the installation of the stove.
It should be noted that the Building Regulations requirements may be met by adopting the
relevant recommendations given in British Standards BS 8303, BS EN 15287-1:2007 as an
alternative means to achieve an equivalent level of performance to that obtained following
the guidance given in Approved Document J.
Please note that it is a legal requirement under England and Wales Building Regulations
that the installation of the stove is either carried out under Local Authority Building Control
approval or is installed by a Competent Person registered with a Government approved
Competent Persons Scheme. HETAS Ltd operate such a Scheme and a listing of their
Registered Competent Persons can be found on their website at www.hetas.co.uk.
CO Alarms:-
Building regulations require that when ever a new or replacement fixed solid fuel or
wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be fitted
in the same room as the appliance. Further guidance on the installation of the carbon
monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer’s
instructions. Provision of an alarm must not be considered a substitute for either installing
the appliance correctly or ensuring regular servicing and maintenance of the appliance and
chimney system.
HEALTH AND SAFETY PRECAUTIONS
Special care must be taken when installing the stove such that the requirements of the
Health and Safety at Work Act are met.
Handling
Adequate facilities must be available for loading, unloading and site handling.
Fire Cement
Some types of fire cement are caustic and should not be allowed to come into contact with
the skin. In case of contact wash immediately with plenty of water.

13
Asbestos
This stove contains no asbestos. If there is a possibility of disturbing any asbestos in the
course of installation then please seek specialist guidance and use appropriate protective
equipment.
Metal Parts
When installing or servicing this stove care should be taken to avoid the possibility of
personal injury.
STOVE PERFORMANCE
Please refer to the table in the main instruction manual for details of the stoves’
performances
PREPARATORY WORK AND SAFETY CHECKS
IMPORTANT WARNING
This stove must not be installed into a chimney that serves any other heating appliance.
There must not be an extractor fan fitted in the same room as the stove as this can cause
the stove to emit fumes into the room.
Chimney
In order for the stove to perform satisfactorily the chimney height must be sufficient to
ensure an adequate draught of approximately 15 Pa so as to clear the products of
combustion and prevent smoke problems into the room.
NOTE: A chimney height of not less than 4.5 metres measured vertically from the outlet of
the stove to the top of the chimney should be satisfactory. Alternatively the calculation
procedure given in EN 13384-1 may be used as the basis for deciding whether a particular
chimney design will provide sufficient draught.
The outlet from the chimney should be above the roof of the building in accordance with
the provisions of Building Regulations Approved Document J.
If installation is into an existing chimney then it must be sound and have no cracks or other
faults which might allow fumes into the house. Older properties, especially, may have
chimney faults or the cross section may be too large i.e. more than 230 mm x 230 mm.
Remedial action should be taken, if required, seeking expert advice, if necessary. If it is
found necessary to line the chimney then a flue liner suitable for solid fuel must be used in
accordance with Building Regulations Approved Document J.
Any existing chimney must be clear of obstruction and have been swept clean immediately
before installation of the stove. If the stove is fitted in place of an open fire then the
chimney should be swept one month after installation to clear any soot falls which may
have occurred due to the difference in combustion between the stove and the open fire.
If there is no existing chimney then any new system must be to the designation described
above and in accordance with Building Regulations Approved Document J.

14
A single wall metal fluepipe is suitable for connecting the stove to the chimney but is not
suitable for use as the complete chimney. The chimney and connecting fluepipe must have
a minimum diameter of 150 mm and its dimension should be not less than the size of the
outlet socket of the stove.
Any bend in the chimney or connecting fluepipe should not exceed 45. 90bends should
not be used.
Combustible material should not be located where the heat dissipating through the walls of
fireplaces or flues could ignite it. Therefore when installing the stove in the presence of
combustible materials due account must be taken of the guidance on the separation of
combustible material given in Building Regulations Approved Document J and also in
these stove instructions.
If it is found that there is excessive draught in the chimney then a draught stabiliser should
be fitted. Fitting of a draught stabiliser will affect the requirement for the permanent air
supply into the room in which the stove is fitted in accordance with Approved Document J
(see also combustion air supply).
Adequate provision e.g. easily accessible soot door or doors must be provided for
sweeping the chimney and connecting fluepipe where it is not intended for the chimney to
be swept through the appliance.
Hearth
The hearth should be able to accommodate the weight of the stove and its chimney if the
chimney is not independently supported. The weight of the stove is indicated in the
brochure.
The stove should preferably be installed on a non-combustible hearth of a size and
construction that is in accordance with the provisions of the current Building Regulations
Approved Document J.
The clearance distances to combustible material beneath, surrounding or upon the hearth
and walls adjacent to the hearth should comply with the guidance on the separation of
combustible material given in Building Regulations Approved Document J and also in
these stove instructions.
If the stove is to be installed on a combustible floor surface, it must be covered with a non-
combustible material at least 12mm thick, in accordance with Building Regulations
Approved Document J, to a distance of 30 cm in front of the stove and 15 cm to each side
measuring from the door of the combustion chamber.
Combustion air supply
In order for the stove to perform efficiently and safely there must be an adequate air supply
into the room in which the stove is installed to provide combustion air. The provision of air
supply to the stove must be in accordance with current Building Regulations Approved
Document J. An opening window is not appropriate for this purpose.
Connection to chimney
Stoves may have a choice of either a rear or top flue gas connector that allows connection
to either a masonry chimney or a prefabricated factory made insulated metal chimney in

15
accordance with their instructions. In some cases it may be necessary to fit an adaptor to
increase the diameter of the flue to the minimum required 150 mm section of the chimney
or liner.
Commissioning and handover
Ensure all parts are fitted in accordance with the instructions.
On completion of the installation allow a suitable period of time for any fire cement and
mortar to dry out, before lighting the stove. Once the stove is under fire check all seals for
soundness and check that the flue is functioning correctly and that all products of
combustion are vented safely to atmosphere via the chimney terminal.
On completion of the installation and commissioning ensure that the operating instructions
for the stove are left with the customer. Ensure to advise the customer on the correct use
of the appliance and warn them to use only the recommended fuel for the stove.
Advise the user what to do should smoke or fumes be emitted from the stove. The
customer should be warned to use a fireguard to BS 8423:2002 (Replaces BS 6539) in the
presence of children, aged and/or infirm persons.
READ THE INSTRUCTION BOOK AND THESE INSTRUCTIONS CAREFULLY
BEFORE USING THE STOVE
WARNING NOTE
Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes
from de-ashing and re-fuelling may occur. However, persistent fume emission is potentially dangerous and
must not be tolerated. If fume emission does persist, then the following immediate action should be taken:-
(a) Open doors and windows to ventilate the room and then leave the premises.
(b) Let the fire go out.
(c) Check for flue or chimney blockage and clean if required
(d) Do not attempt to relight the fire until the cause of the fume emission has
been identified and corrected. If necessary seek expert advice.
The most common cause of fume emission is flueway or chimney blockage. For your own
safety these must be kept clean at all times.
IMPORTANT NOTES
General
Before lighting the stove check with the installer that the installation work and
commissioning checks described above have been carried out correctly and that the
chimney has been swept clean, is sound and free from any obstructions. As part of the
stoves’ commissioning and handover the installer should have shown you how to operate
the stove correctly.
CO Alarm

16
Your installer should have fitted a CO alarm in the same room as the appliance. If the
alarm sounds unexpectedly, follow the instructions given under “Warning Note” above.
Use of fireguard
When using the stove in situations where children, aged and/or infirm persons are present
a fireguard must be used to prevent accidental contact with the stove. The fireguard
should be manufactured in accordance with BS 8423:2002 (Replaces BS 6539).
Chimney cleaning
The chimney should be swept at least twice a year. It is important that the flue connection
and chimney are swept prior to lighting up after a prolonged shutdown period.
If the stove is fitted in place of an open fire then the chimney will require sweeping after a
month of continuous operation. This is a precaution to ensure that any “softer” deposits left
from the open fire usage have not been loosened by the higher flue temperatures generated
by the closed stove.
In situations where it is not possible to sweep through the stove the installer will have
provided alternative means, such as a soot door. After sweeping the chimney the stove
flue outlet and the flue pipe connecting the stove to the chimney must be cleaned with a
flue brush.
Periods of Prolonged Non-Use
If the stove is to be left unused for a prolonged period of time then it should be given a
thorough clean to remove ash and unburned fuel residues. To enable a good flow of air
through the appliance to reduce condensation and subsequent damage, leave the air
controls fully open.
Extractor fan
There must not be an extractor fan fitted in the same room as the stove as this can cause
the stove to emit smoke and fumes into the room.
Aerosol sprays
Do not use an aerosol spray on or near the stove when it is alight.
Use of operating tools
Always use the operating tools provided when handling parts likely to be hot when the
stove is in use.
Chimney Fires
If the chimney is thoroughly and regularly swept, chimney fires should not occur.
However, if a chimney fire does occur turn off the stove immediately and isolate the mains
electricity supply (if applicable), and tightly close the doors of the stove. This should cause
the chimney fire to go out. If the chimney fire does not go out when the above action is
taken then the fire brigade should be called immediately. Do not relight the stove until the
chimney and flueways have been cleaned and examined by a professional.
Permanent air vent
The stove requires a permanent and adequate air supply in order for it to operate safely
and efficiently.

17
In accordance with current Building Regulations the installer may have fitted a permanent
air supply vent into the room in which the stove is installed to provide combustion air. This
air vent should not under any circumstances be shut off or sealed.
USER OPERATING INSTRUCTIONS
Please read the important notices given above before referring to the main instruction
book for detailed operating instructions.
Recommended fuels
Stoves may be designed to burn dry seasoned wood logs and/or solid mineral fuel as
indicated in the main stove manuals.
HETAS Ltd Approval
HETAS approval may be limited to specific fuel types as detailed in the main instruction
manuals. Approval does not cover the use of other fuels either alone or mixed with the
recommended fuel, nor does it cover instructions for the use of other fuels.
