SCAN Scan 83-8 User guide

SCAN A/S - DK-5492 VISSENBJERG
Scan 83 Series
ASSEMBLY AND INSTRUCTION MANUAL
Congratulations on your new Scan wood-burning stove
You have purchased a product by one of Europe’s leading manufacturer’s of wood-burning stoves, and we are sure that you will have years of
pleasure with your purchase. To make the best possible use of your stove, it is important that you follow our advice and instructions.
Read through this Assembly and Instruction Manual carefully before you start to assemble your stove.
Product registration number
Please indicate the product registration number at any
enquiry

CONTENTS
Table of contents
Technical data ................................................................................................... 3
Installation
Safety
Certificate of testing
Technical data and dimensions
Dimensional drawings
Type plate
Product registration number
Assembly ........................................................................................................... 10
Additional accessories
Loose parts
Removal of packaging
Disposal of packaging
Height adjustment of stove
Fresh air intake
Closed combustion system
Load-bearing subsurface
Floor plate
Existing chimney and pre-fabricated element chimney
Connection between stove and steel chimney
Requirements for chimney
Connection with 90° elbow pipe
Rotating base and 90° elbow pipe
Erection
Distance to flammable materials
Fitting the flue connection piece in the top outlet
Fitting the flue connection piece in the rear outlet
Adjusting the height of the top module
Fitting the natural stone sides
Fitting the natural stone top
Heat-storage stone Scan 83 Maxi models
Fitting the tile sides
Instructions for use ....................................................................................... 25
CB technology
Primary air
Secondary air
Baffle plates
Ash container
Handle for riddling grate
Instructions for operation .......................................................................... 27
Lighting
Handling fuel
Maintenance ................................................................................................... 29
Troubleshooting ............................................................................................. 33
2

TECHNICAL DATA
Installation
The house owner is responsible for ensuring that installation and
assembly are in accordance with national and local building regu-
lations as well as the information provided in this Assembly and
Instruction Manual.
When you install any kind of fireplace or stove, you must inform the
local building and housing authorities. In addition you are obliged
to have the installation inspected and approved by a local chimney
sweep prior to commissioning.
To ensure best-possible functionality and safety for your installation,
we advise you to call a professional fitter. Your Scan Dealer will be
able to recommend a qualified fitter in your area. For information on
Scan Dealers, please go to http:// scan.dk.
The Scan 83 Series comprises:
Scan 83-1: Stove with handles and trims in black aluminium
Scan 83-2: Stove with handles and trims in brushed aluminium
Scan 83-3: Stove Maxi with handles and trims in black aluminium
Scan 83-4: Stove Maxi with handles and trims in brushed aluminium
Scan 83-5: Stove with natural stones/tiles, handles and trims in black aluminium
Scan 83-6: Stove with natural stones/tiles, handles and trims in brushed aluminium
Scan 83-7: Stove Maxi with natural stones, handles and trims in black aluminium
Scan 83-8: Stove Maxi with natural stones, handles and trims in brushed aluminium
Safety
Any changes made to the product by the dealer, fitter or user could
result in the product and safety functions not functioning as inten-
ded.The same applies to the fitting of accessories or extra equipment
not supplied by Scan A/S. This could also be the case if parts that are
necessary for the operation and safety of the stove are dismantled
or removed.
3
Scan 83-1 / Scan 83-2 Scan 83-3 / Scan 83-4 Scan 83-5 / Scan 83-6 Scan 83-7 / Scan 83-8

TECHNICAL DATA
Scan 83 Series Technical data Unit
CO emissions at 13% O2* 0.07 %
CO emissions at 13% O2 896 mg/Nm3
Dust @ 13% O223 mg/Nm3
Nox@ 13% O2106 mg/Nm3
Efficiency 81 %
Nominal output 5 kW
Chimney temperature EN 13240 227 °C
Temperature in flue connection piece 280 °C
Amount of smoke 5 g/sec
Negative pressure EN 13240 12 Pa
Recommended negative pressure in flue con-
nection piece
16 Pa
Required combustion air supply 14 Nm3/h
Fuel Wood Wood
Fuel consumption 1.6 kg/h
Amount of fuel required to light 1.4 kg
Technical data and dimensions
Materials: ................................... Steel plate, cast iron, galvanised sheet,
vermiculite
Surface treatment: ........................................................................... Senotherm
Max. log length: ........................................................................................... 26 cm
Weight Scan 83-1 / Scan 83-2: .................................................. approx. 117 kg
Weight Scan 83-3 / Scan 83-4: .................................................approx. 125 kg
Weight Scan 83-5/6, natural stone/tile: ..................approx. 186/132 kg
Weight Scan 83-7 / Scan 83-8: ................................................ approx. 212 kg
Fresh air connection piece external diameter: .............................100 mm
Flue connection piece internal diameter: ...................................... 144 mm
Flue connection piece external diameter: ..................................... 148 mm
Approval type: ............................................................ Intermittent operation
Intermittent operation in this context means normal use of a wood-
burning stove. In other words, you should let the fire die down until
only the embers are left before refuelling.
The Scan 83 Series is produced in accordance with type approval for
the product, which also covers the product’s Assembly and Instruction
Manual.
The Declaration of Performance (DoP) is available from http://scan.dk
Tested in accordance with EN 13240
4
* based on 896 mg/Nm3

TECHNICAL DATA
Dimensional drawing for Scan 83-1 and Scan 83-2
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
Målskitse Scan 83-1
Scan 83
VÆGT:
AREAL:
N/A
N/A
1200
460
230
1162 *
1064**
132 ±20 ***
230****
481
* Height to beginning of
flue connection piece at
top outlet
** Centre rear outlet
*** Centre of fresh air intake
rear outlet
**** Centre of fresh air intake
bottom
5

TECHNICAL DATA
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583002.idw
90583002
Målskitse - Scan 83-2
23-01-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
230****
1410
1162*
481
230
460
1064**
132

20
Dimensional drawing for Scan 83-3 and Scan 83-4
* Height to beginning of
flue connection piece at
top outlet
** Centre rear outlet
*** Centre of fresh air intake
rear outlet
**** Centre of fresh air intake
bottom
6

TECHNICAL DATA
Dimensional drawing for Scan 83-5 and Scan 83-6 with natural stones/tiles top module
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
Målskitse Scan 83 med fedtsten
Scan 83
VÆGT:
AREAL:
N/A
N/A
1235
460
230
132 ±20 ***
1064**
1162 *
230****
481
* Height to beginning of
flue connection piece at
top outlet
** Centre rear outlet
*** Centre of fresh air
intake rear outlet
**** Centre of fresh air intake
bottom
7
/1222 (tiles)

TECHNICAL DATA
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
Målskitse Scan 83 Maxi med fedtstenstop
BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
1446
460
481
230
1162*
1064 **
132 ±20 ***
230****
Dimensional drawing for Scan 83-7 and Scan 83-8 with natural stones top module
* Height to beginning of
flue connection piece
at top outlet
** Centre rear outlet
*** Centre of fresh air intake
rear outlet
**** Centre of fresh air intake
bottom
8

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583020.idw
90583020
Ovn med Typeskilt og produktregistreringsnummer
21-02-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
TECHNICAL DATA
Scan 83 - Series
Freestanding room heater fired by solid fuel
Standard:
Fuel type:
Operation type:
The appliance can be operated in a shared flue.
Country
EN 13240 EC no. 90583600
Wood
Intermittent
EUR
Norway
Austria
Classification
Intermittent
Klasse 2
15a B-VG
Certificate/Standard
EN 13240
300-ELAB-1904-NS
FSPS-Wa 2197-EN-A
Approved by
RWE Power AG
Teknologisk Institut
RWE Power AG
Dust at 13% O2: 23 mg/Nm³
Flue gas temperature: 280°C
Nominal heat output: 5 kW
Efficiency: 81%
Angaben für Österreich
Wärmeleistungsbereich: 2,6 - 5,8 kW
Brennstoffwärmeleistung: 7,2 kW
Zulässige Brennstoffe: Scheitholz
Prüfbericht: FSPS-Wa 2197-A
Scan A/S DK 5492 Vissenbjerg
Minimum distance to combustible materials:
Side: 400 mm - Back: 100 mm - Front: 900 mm
CO emission at 13% O2:
Follow assembly- and instructions manual.
Use only recommended fuels.
DIBt Zulassungsnummer:
Montage- und Bedienungsanleitung beachten.
Verwenden Sie nur empfohlene Brennstoffe.
1000 06-2013
0,07% 896 mg/Nm³
Schweiz
Germany
LRV 11
BStV 1
VKF
FSPS-Wa 2197-EN
RWE Power AG
RWE Power AG
Type plate for Scan 83 Series
All Scan wood-burning stoves are fitted with a type plate that speci-
fies the approval standards and the distance to flammable materials.
The type plate is located at the rear of the stove.
Type plate
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583020.idw
90583020
Ovn med Typeskilt og produktregistreringsnummer
21-02-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Product
registration
number
Product registration number
All Scan wood-burning stoves are provided with a product registra-
tion number.
The product registration number is located at the rear of the stove.
Please make a note of this number at the frontpage; you will always
need to quote it when contacting your dealer or Scan A/S.
83XXXXX
9

ASSEMBLY
Additional accessories
• Small shapedfloor plate in glass or steel
• Large shapedfloor plate in glass or steel
• Small corner shapedfloor plate in glass or steel
• Soapstone top module for stove with rear outlet
•Soapstone top module for stove with top outlet
•Heat-storage stone Scan 83 Maxi 4 items approx.
40 kg
•Rotating base
• Tile sides
Loose parts
The flue connection piece and other loose parts are located in the
stove’s combustion chamber.
Scan 83, all types:
• x4 screws for fastening flue connection piece
• Gasket for flue connection piece
• Glove
• Repair lacquer for coloured stoves
Scan 83-5, Scan 83-6, Scan 83-7 and Scan 83-8
• 7/9 m sealing tape
Removal of packaging
Check that the stove is not damaged before starting to install it.
The Scan 83 Series comes attached to a wooden pallet on delivery. To
remove the packaging, see the illustrations below.
Screws to be removed
Disposal of packaging
Your Scan stove may come supplied with the following packaging:
Wood packaging:
The wood packaging can be reused and after final use can be incine-
rated as a CO2 neutral product or sent for recycling.
Flamingotop:
Send for recycling or waste disposal.
Foam:
Send for recycling or waste disposal.
Plastic bags:
Send for recycling or waste disposal.
Stretch film/plastic film:
Send for recycling or waste disposal.
10
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 83\90583033.idw
90583033
Afmontage ovn på palle (skrue i front af ovn)
01-03-2013 BC
Scan 83
VÆGT:
AREAL:
424,19 kg
30212320 mm^2
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 83\90583033.idw
90583033
Afmontage ovn på palle (skrue i front af ovn)
01-03-2013 BC
Scan 83
VÆGT:
AREAL:
424,19 kg
30212320 mm^2
A
A

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583016.idw
90583016
Afmontage dækplade for sokkel
14-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
ASSEMBLY
Remove the screws and fittings for securing the stove to the pallet.
Lift off the front of the base.
Height adjustment of stove
The Scan 83 Series has four adjustment screws under the stove. Use
the adjustment screws to get the stove to stand straight and level.
To adjust the adjustment screws, see the illustrations below.
If you are using a shaped floor plate, you should adjust the stove
upwards to allow the plate to be inserted under the front of the stove.
11
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583032.idw
90583032
Afmontage ovn fra palle
01-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
B
B
C
C
Remove the screws for the cover plate in the base.
Screws to be removed

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Scan A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 83\10583900-Manual.iam
90583049
Lukket forbrændingssystem
23-01-2013 kc
VÆGT:
AREAL:
N/A
N/A
ASSEMBLY
Adjustment screws
Fresh air intake
In a well-insulated house the air used for the combustion process
has to be replaced. This particularly applies to houses with mecha-
nical ventilation. There are different ways of making sure that air is
exchanged.The most important thing is to ensure that there is a sup-
ply of air to the room where the wood stove is located. The external
wall vent must be located as close to the wood stove as possible, and
you must be able to close it when you are not using the stove.
National and local building regulations must be followed with
regard to connection of a fresh air intake.
Closed combustion system
You should use the closed combustion system for the wood-burning
stove if you live in a newly-built, airtight home. External combustion
air is connected through a ventilation pipe via the wall or floor.
It must be possible to shut off the ventilation pipe with a valve, when
the stove is not in use.
• Minimum Ø100 mm ventilation pipe, maximum length: 6 metres
External combu-
stion air via wall
(109 x 152 mm)
External combu-
stion air via floor
(D 185 mm)
If you want external combustion air via a wall, remove the cover plate
at the rear of the stove with a pair of cutting pliers. See the procedure
on page 17.
Connect external combustion air via the connection piece underne-
ath the combustion chamber.
NOTE: if the stove has a fresh air connexion or closed combustion, the
ventilation pipe must be open, when the stove is in use!
12
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583034.idw
90583034
Justering af ovn
01-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583034.idw
90583034
Justering af ovn
01-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
D
D
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583034.idw
90583034
Justering af ovn
01-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A

ASSEMBLY
Load-bearing subsurface
All items in our product range come under the category of light-
weight fireplaces and stoves and do not normally require any rein-
forcement of the beam structure. They can be positioned on ordinary
beams/floor.
You should of course make sure that the subsurface on which the
stove is positioned can indeed support the weight of the stove and,
where applicable, a steel chimney, if you have opted for this solution.
Floor plate
If you are erecting the stove on a flammable floor, you must comply
with the national and local regulations on the size of any non-flam-
mable subsurface required to cover the floor around the stove.
Your local Scan dealer can advise you on regulations concerning pro-
tection of flammable materials in the vicinity of your stove.
The floor plate’s function is to protect the floor and flammable mate-
rial against any sparks that may occur.
A floor plate can be made of steel or glass, but the stove can also be
erected on clinker concrete, natural stone or similar materials.
This Scan wood-burning stove has an integrated floor plate at the
bottom and can thus be erected directly on flammable material wit-
hout the need for further protection underneath the stove.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583021.idw
90583021
Ovn med gulvplade
21-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Small shaped floor plate for the Scan 83 Series
Large shaped floor plate in steel or large subsurface floor plate in
glass for the Scan 83 Series
Existing chimney and pre-fabricated element
chimney
If you intend to connect your stove to an existing chimney, it makes
sense to contact an authorised Scan dealer, or a local chimney sweep,
for advice.These experts will also let you know if your chimney needs
renovating.
When connecting a pre-fabricated element chimney, follow the
manufacturer’s connection instructions for the relevant chimney
type.
Connection between stove and steel chimney
Your Scan dealer, or local chimney sweep, can advise you on choosing
a make and type of steel chimney (we recommend using JØTUL’s
chimney system). This ensures that the chimney will match your
wood-burning stove. As a general rule, the length of the chimney
should not be less than 4 metres, measured from the top of the stove.
Specific weather or installation conditions might require a different
length.
Choosing the wrong length or diameter of steel chimney could
impair functionality.
Always comply exactly with the instructions provided by the steel
chimney supplier.
Requirements for chimney
The chimney must have a minimum internal diameter of 148 mm
and have a T400 designation, with G for the soot fire test.
Connection with 90° elbow pipe
If you opt to connect the Scan 83 with an elbow pipe, you should use
a curved elbow, as this gives a better draught.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583030.idw
90583030
Ovn med buet knærør
28-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Rotating base and 90° elbow pipe
To ensure optimum function of the rotating solution for the stove, it
is important that assembly be performed in a meticulous fashion by
a qualified fitter.
See the separate instructions supplied with the rotating base.
13

ASSEMBLY
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583006.idw
90583006
Opstilling mod brændbart materiale
25-01-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
100
100
467
100
400
Installation along a rear wall. 45° Corner installation
Positioning your wood-burning stove
The stove must be set up so that the stove itself, the flue pipe,and the
chimney can all be cleaned.
Distance to furniture: 900 mm
You should however assess whether furniture or other items might
become excessively dry due to being too close to the stove.
National and local regulations governing safety distances for wood-
burning stoves must be complied with.
If the stove is to be connected to a steel chimney, the chimney require-
ments in terms of safety distances must be met.
Erection:
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583006.idw
90583006
Opstilling mod brændbart materiale
25-01-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
100
100
467
100
400
Distance to flammable materials
These distances apply for an uninsulated flue pipe/insulated flue pipe, all the way down to the stove, having a minimum of 30 mm insulation
14

ASSEMBLY
Installation with rotating base
15
900
900
360°
Flammable materials
900
900
360°

ASSEMBLY
Fitting the flue connection piece in the top outlet
The manufacturer has prepared the stove to take a top outlet.
Flue connec-
tion piece
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583018.idw
90583018
Røgstuds med monteret pakning
21-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Gasket
Lift the top module off the stove.
Place the gasket on the flue connection piece
Tighten the flue connection piece with the screws provided and repo-
sition the top module.
E
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583007.idw
90583007
Afmontage topplade
31-01-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583019.idw
90583019
Montage røgstuds i topafgang
21-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
x4 M5x10 mm screws
16
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583026.idw
90583026
Montage dæksel i topafgang
26-02-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
E

ASSEMBLY
Fitting the flue connection piece in the rear out-
let
The manufacturer has prepared the stove to take a top outlet.
The flue connection piece and screws can be found in the stove’s
combustion chamber.
The gasket for the flue connection piece is in the service box.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583005.idw
90583005
Afmontage dækplade i svøb, topafgang
30-01-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Heat shield
Heat shield
remount
Unscrew the stove’s heat shield and remove it.
Using cutting pliers,cut off the cover plate from the rear plate and the
heat shield (only Scan 83 Maxi) at its securing points.
Lift the top module off the stove.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583007.idw
90583007
Afmontage topplade
31-01-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
17
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583005.idw
90583005
Afmontage dækplade i svøb, topafgang
30-01-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583073.idw
90583073
Scan 83 varmeskjold maxi
24-11-2015 hms
Scan 83
VÆGT:
AREAL:
N/A
N/A
÷
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 68\90068058.idw
90068058
klargøring til vægbeslag
12-05-2015 hms
Scan 68
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 68\90068058.idw
90068058
klargøring til vægbeslag
12-05-2015 hms
Scan 68
VÆGT:
AREAL:
N/A
N/A
Maxi

F
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583041.idw
90583041
Montage røgstuds i bagafgang
06-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
ASSEMBLY
Cover
Remove the cover from the stove’s rear outlet.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583039.idw
90583039
Hul i varmeskjold
05-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583040.idw
90583040
Afmontage dæksel i bagafgang
05-03-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Tighten the flue connection piece with the screws provided.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583019.idw
90583019
Montage røgstuds i topafgang
21-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
x4 M5x10 mm screws
F
Flue connection
piece
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583018.idw
90583018
Røgstuds med monteret pakning
21-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Gasket
Place the gasket on the flue connection piece
18

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583043.idw
90583043
Højdejustering af topplade
08-03-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
ASSEMBLY
Fit the cover in the stove’s top outlet and tighten it.
Reposition the top module.
I
Adjusting the height of the top module
The height of the stove’s top module can be adjusted using the three
socket head cap screws illustrated below.
I
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Scan A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 83\10583900-Manual.iam
10583900-Manual
23-01-2013 kc
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583019.idw
90583019
Montage røgstuds i topafgang
21-02-13 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
x4 M5x10 mm screws
H
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583043.idw
90583043
Højdejustering af topplade
08-03-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
H
19

ASSEMBLY
Fitting the natural stone sides
Scan 83-5 / Scan 83-6 / Scan 83-7 / Scan 83-8 come supplied with loose
natural stones for fitting to the stove. They should be mounted in the
described order.
Important! Start the mounting with stone No. 1.
Natural stones is made from a natural material and may therefore
vary in structure and form.
After mounting, clean the natural stones with water.
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Scan A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 83\90583024.iam
90583024
Fedtsten samlet, Maxi
21-02-2013 kc/SR
Scan 83
VÆGT:
AREAL:
73,86 kg
2135183 mm^2
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583045.idw
90583045
Fedtstensmodel, afmont plade for sokkel og topplade
15-03-2013 BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
Remove the top module and cover plate in the stove’s base
Cover plate in base
20
