Pacific energy ALDERLEA T6 Original operating instructions

Keep these instructions for future reference.
INSTALLATION & OPERATION GUIDE
ALDERLEA T6 CAST IRON WOOD STOVE
MODEL: ALDERLEA T6
SERIES: B
SAFETY NOTICE
If this stove is not properly installed, a house re may result. For your safety,
follow the installation instructions. Contact local building or re officials about
restrictions and installation inspection requirements in your area.
170314-20 AL6B 5055.3272AS
SERIAL #

NOTE:
WE STRONGLY
RECOMMEND THAT
SMOKE DETECTORS BE
INSTALLED.
If smoke detectors have been previ-
ously installed, you may notice that
they are operating more frequently.
This may be due to curing of stove
paint or fumes caused by accidentally
leaving the re door open. Do not
disconnect the detectors. If neces-
sary, relocate them to reduce their
sensitivity.
SAFETY NOTICE:
If this stove is not
properly installed, a
house re may result.
For your safety,
follow the installation
instructions. Contact
local building or
fire officials about
restrictions and
installationinspection
requirements in your
area.
Please read this entire manual before
you install and use your new room
heater. Failure to follow instructions
may result in property damage, bodily
injury, or even death.
Contents ....................................................................................... 2
Safety and Maintenance.............................................................. 3
Maintenance Checks ................................................................... 4
Formation and Need for Removal.......................................................... 5
Chimney Fires........................................................................................ 5
Avoiding a Chimney Fire........................................................................ 5
Creosote ....................................................................................... 5
Appliance Dimensions ................................................................ 6
Outside Air Opening Dimensions .............................................. 6
If You Suspect a Chimney Fire............................................................... 6
In Case of a Chimney Fire ..................................................................... 6
Installation.................................................................................... 7
Clearances ............................................................................................ 8
Minimum Clearances to Combustibles .................................................. 8
Floor Protector............................................................................. 8
Chimney and Connector........................................................................ 9
Installation Procedure ............................................................................ 9
Firebrick Installation Instructions ............................................ 10
Combustion Air...........................................................................11
Operation.................................................................................... 12
Wood Selection.....................................................................................12
How to Test Your Wood .........................................................................13
Lighting for the First Time .....................................................................13
Lighting a Fire.......................................................................................13
Normal Operation .................................................................................13
Restarting After Extended or Overnight Burns......................................14
Proper Draft ..........................................................................................14
Ash Removal ........................................................................................14
Disposal of Ashes .................................................................................15
Baffle Removal ........................................................................... 15
Removal................................................................................................15
Troubleshooting......................................................................... 16
Replacement Parts .................................................................... 17
Compliance Plate....................................................................... 19
2
170314-20 AL6B
Contents

3
170314-20 AL6B
Safety and Maintenance
1. Burn only dry, well seasoned wood. The denser or heavier the wood when dry, the
greater its heat value. This is why hardwoods are generally preferred. Green or wet
wood should not be used, as it will reduce heat output, as well as contributing
signicantly to creosote buildup.
2. Remove ashes frequently and only when the stove is cold. Too much ash could cause
embers to roll out the door when it is opened. This may pose a re hazard. For proper
operation, maintain a 25mm minimum ash base.
3. If glass becomes darkened from slow burning or poor wood, it can readily be cleaned with
replace glass cleaner when stove is cold. Never scrape with an object or use abrasive
cleaners that might scratch the glass. The type and amount of deposit on the glass is
a good indication of the ue pipe and chimney buildup. A light brown dusty deposit that
is easily wiped off usually indicates good combustion and dry, well-seasoned wood,
therefore relatively clean pipes and chimney. On the other hand, a black greasy deposit
that is difficult to remove is a result of wet and green wood and too slow a burning rate.
This will also create heavy deposit buildup in the chimney.
4. DOOR GASKETS - The gasket used by Pacic Energy (8mm medium density berglass
rope) requires only light pressure to seal. This will prolong seal life. It is important that
the door seal be maintained in good condition. Periodically inspect seals and replace
if necessary. Follow instructions included in the door gasket kit obtainable from your
nearest Pacic Energy dealer.
5. DOOR GLASS - Do not slam loading door or otherwise impact glass. When closing
door, make sure that no logs protrude to impact the glass. If the glass gets cracked
or broken, it must be replaced before using the stove. Replacement glass can be
obtained from your dealer. Use ceramic glass only. Do not substitute with any other
type.
GLASS SIZE - 511mm x 302mm x 5mm
To remove broken glass, undo the four retaining screws and remove clamps, noting position
for re-assembly. Remove all particles of glass. Be careful as they are very sharp. Install
new glass complete with gasket. Replace clamps and screws.
6. Do not store wood within heater installation clearances, or within the space required
for fuel loading and ash removal. Keep the area around the heater clean and free of
loose combustibles, furniture, newspapers, etc.
7. If the heater requires cleaning, use mild soap and water only. Use of abrasive cleaners
will void warranty.
8. Establish a routine for fuelling and ring the heater. Check daily for creosote buildup
until experience shows how often you need to clean the chimney to be safe.
9. Be aware that the hotter the re, the less creosote is deposited. Weekly cleaning may
be necessary in mild weather, even though monthly cleaning is usually enough in the
coldest months when burning rates are higher.
10. Instruct all members of your family on the safe operation of the heater. Ensure they
have enough knowledge of the entire system if they are expected to operate it. Study
the section on chimney res and the importance of following the steps outlined "In Case
of Chimney Fire".
WARNING:
Never use chemicals or any other volatile
liquid to start a re. Do not burn garbage,
or ammable uids such as gasoline,
naptha, or engine oil. We strongly
recommend that smoke detectors be
installed.
CAUTION:
• do not overtighten, tighten screws very
carefully
• do not clean glass when hot
• do not use abrasive cleaners on glass
WARNING:
Only use materials and components sup-
plied or specied by manufacturer when
doing maintenence or replacements.

Check the following parts for damage such as cracks, excessive corrosion, burned out sections
and excessive warping: (See website for descriptions and more detail)
Weekly:
- Firebrick - Visual, for cracking.
- Door Gasket - sagging, placement, damage.
Monthly
- Brick rail tabs and brick rails.
- Air riser tube in the back of the rebox.
- Back side of airwash chamber.
- Baffle locking pin.
- Boost tube cover.
When Cleaning the
Chimney System:
- Top baffle board/blanket.
- Baffle.
- Top heat shield and mounting bolt.
- Baffle Gasket.
- Brick Rails.
- Manifold.
**- Some warping of the baffle is normal(up to 1/4” or .65cm).
- Replace if the baffle has permanent warping greater than this or has cracking or breakage.
- Please contact your Dealer if you experience any of the damage listed above. Continuing to
operate your stove with broken parts may accelerate damage to other parts and may void your
warranty
4
170314-20 AL6B
Maintenance Checks

5
170314-20 AL6B
Creosote
Formation and Need for Removal
When wood is burned slowly, it produces tar and other organic vapours, which combine
with expelled moisture to form creosote. The creosote vapours condense in the relatively
cool chimney ue of a slow burning re. As a result, creosote residue accumulates on the
ue lining. When ignited, this creosote makes an extremely hot re.
The chimney connector and chimney should be inspected periodically (at least once every
two months) during the heating season to determine if a creosote buildup has occurred. If
creosote has accumulated (3 mm. or more), it should be removed to reduce the risk of a
chimney re.
1. Highest smoke densities occur when a large amount of wood is added to a bed of hot
coals and the air inlet is closed. The heated wood generates smoke, but without ample
air, the smoke cannot burn. Smoke-free, clean burning requires leaving the air inlet
relatively wide open, especially during the rst 10 to 30 minutes after each loading, when
most of the smoke generating reactions are occurring. After 30 minutes or once the
wood is fully charred, the air inlet can be turned down substantially without excessive
smoke generation. Wood coals create very little creosote-producing smoke.
2. The cooler the surface over which the wood smoke is passing, the more creosote will
be condensed. Wet or green wood contributes signicantly to creosote formation as the
excess moisture that is boiled off cools the re, making it difficult for the tars and gases
to ignite, thus creating dense smoke and poor combustion. This moisture-laden smoke
cools the chimney, compounding the problem by offering the smoke the ideal place to
condense.
In summary, a certain amount of creosote is inevitable and must be lived with. Regular
inspection and cleaning is the solution. The use of dry, seasoned wood and ample
combustion air will help to minimize the buildup.
Chimney Fires
Excessive creosote build-up can cause a chimney re. Creosote comes from tar and organic
vapours released from a slow burning wood re. Flammable creosote will condense and
accumulate in the lining of a relatively cool chimney. When ignited, this creosote can result
in an extremely hot re.
Avoiding a Chimney Fire
There are two ways to avoid chimney res:
1. Keep your chimney clear of creosote build-up by cleaning your chimney before each
burn season, and as necessary (accumulations of 3 mm or more) during the
season.
2. Burn clean, well-seasoned wood only (seasoned at least one year). Avoid wet or
green wood.
3. Do not burn household trash, cardboard, plastics, construction lumber, treated or
beach wood (salt from beach wood will corrode your replace and void your
warranty).
4. Do not leave the air inlet wide-open for extended periods of time.
5. Keep a re extinguisher handy.
6. Prepare a home evacuation plan with a place outside where everyone
is to meet.

Fig #1
Appliance Dimensions
Outside Air Opening Dimensions
743mm 730mm
216mm
757mm
6
170314-20 AL6B
If You Suspect a Chimney Fire
Signs of a chimney re may be one or more of the following:
1. A roaring sound
2. Vibration of the chimney
3. Flames and sparks shooting out of the top of the chimney
In Case of a Chimney Fire
1. Immediately close the air inlets on the stove.
2. Evacuate the home, and call the local re department.
3. After the chimney re has been extinguished, the chimney must be cleaned and
checked for stress and cracking before starting another re. Also check combustibles
around the chimney and roof.
105mm
OUTSIDE AIR INLET
9.5mm
C
L
C
L
* CENTERLINE OF CHIMNEY
OUTLET
*
*
Fig #1a

Do not connect this unit
to a chimney ue serving
another appliance.
7
170314-20 AL6B
Installation
Warning:
Under no circumstances is this heater to be installed in a makeshift or "temporary" manner.
It may be red only after the stove is installed properly.
DO NOT ATTEMPT TO CONNECT THIS HEATER TO ANY AIR DISTRIBUTION DUCT.
Outside combustion air or fresh air into the room may be required in your area, consult local
building codes (see Combustion Air section).
WARNING:THE APPLIANCE AND FLUE-SYSTEM SHALL BE INSTALLED IN ACCORD-
ANCE WITH AS/NZS 2918 ANDTHE APPROPRIATE REQUIRMENTS OF THE RLEVANT
BUILDING CODE OR CODES
WARNING:APPLIANCES INSTALLED INACCORDANCEWITHTHIS STANDARD SHALL
COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE
REGULATORY AUTHORITY, I.E. THE APPLIANCE SHALL BE IDENTIFIABLE BY A
COMPLIANCE PLATE WITH THE MARKING ‘TESTED TO AS/NZS 4013’.
ANY MODIFICATION OFTHEAPPLIANCETHAT HAS NOT BEENAPPROVED INWRITING
BYTHETESTING AUTHORITY IS CONSIDEREDTO BE IN BREACH OFTHE APPROVAL
GRANTED FOR COMPLIANCE WITH AS/NZS 4013.
CAUTION:MIXING OFAPPLIANCE OR LFUE-SYSTEM COMPONENTS FROM DIFFERENT
SOURCES OR MODIFYING THE DIMENSIONAL SPECIFICATION OF COMPONENTS
MAY RESULT IN HAZARDOUS CONDITIONS.WHERE SUCH ACTION IS CONSIDERED,
THE MANUFACTURER SHOULD BE CONSULTED IN THE FIRST INSTANCE.
CAUTION: CRACKED OR BROKEN COMPONENTS, e.g. GLASS PANELS OR CERAMIC
TILES, MAY RENDER THE INSTALLATION UNSAFE.
WARNING:ANY MODIFICATION OFTHEAPPLIANCETHAT HAS NOT BEENAPPROVED
IN WRITING BY THE TESTING AUTHORITY IS CONSUDERED AS BREACHING AS/
NZS 4013.
CAUTION: THIS APPLIANCE SHOULD NOT BE OPERATED WITH A CRACKED GLASS.
CAUTION: THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES
IN ACCORDANCE WITH THESE INSTRUCTIONS.
CAUTION: THE USE OF SOME TYPES OF PRESEVATIVE-TREATED WOOD AS A FUEL
CAN BE HAZARDOUS.

22" 12"
18"
30"
25"
11"
11"
Fig #2
SINGLE WALL
CONNECTOR
Minimum Clearances to Combustibles
175mm
250mm
451mm
730mm
150mm
150mm
514mm
Fig #3
Non-combustible oor
protector
[500mm]
[875mm]
[1124mm]
[200mm] [200mm]
Minimum Width - 875mm
Minimum Overall Depth - 1124mm
Minimum Thickness - 6mm
The stove may be installed on a combustible
oor provided ember protection made from
a 6mm thick non-combustible material with
a thermal resistance value of .8m ˚K/W for
4mm thick cement sheets is used.
This protection must extend as follows:
(500 mm) on the ring side and 200mm
both sides of the door opening. See Figure
#3 below.
Floor Protector
8
170314-20 AL6B
Clearances

Chimney and Connector
WARNING: INSTALL CHIMNEY AND ALL COMPONENTS OF CHIMNEY SYSTEM
ACCORDING TO CHIMNEY MANUFACTURER’S INSTRUCTIONS.
Connect to a listed chimney complying with the requirements of AS/NZS2918/2001 and a
chimney suitable for use with solid fuel that is lined and in good condition and meets local
building codes. The chimney ue size should be the same as the stove outlet for optimal
performance. Reducing or increasing the ue size may adversely affect stove performance.
Chimney ue exit is to be minimum 1000mm above roof and 600mm above highest projec-
tion within 3000mm. The installation must meet all local codes. Do not connect this unit to
a chimney ue serving another appliance. Minimum system height is 4600mm (measured
from base of appliance).
Installation Procedure
1. Install all components to the chimney manufacturer's installation requirements. (Outside
combustion air may be required, consult local building codes. See Combustion Air
section on page 11.)
2. Installed with the crimped or male ends pointing down. This will carry any liquid creosote
or condensation back into the stove.
3. If a roof or ceiling support is used in the installation, you will nd the chimney manufacturer's
complete instructions packed with the roof support.
4. To start installing smoke pipe (chimney connector), slip crimped edge of the pipe inside
the stove collar. Use holes provided in collar to secure pipe with three screws.
5. Install the remaining lengths of pipe, one on top of the other, to the nished height of
the chimney connector and secure to each other.
9
170314-20 AL6B

10
170314-20 AL6B
Firebrick Installation Instructions
This package contains 19 full-size rebricks, as well as 5 various cut bricks.
With the woodstove in the upright position, install rebricks as follows:
1. Place the rebricks on the bottom of the unit rst. Use a total of 6 full-size (D)
and 5 cut bricks (A, B, C & 2E) with ash cleanout system.
2. Next install the side rebricks, 3 full-size and 2 cut rebricks(F) on each side
of the rebox as shown.
3. Finally install 4 full-size bricks against the rear wall as shown.
ITEM SIZE
A 38mm X 114mm X 32mm
B 102mm X 114mm X 32mm
C 184mm X 114mm X 32mm
D 229mm X 114mm X 32mm
E 229mm X 114mm X ANGLED CUT
F 229mm X 89mm X 32mm
B
F
E
C
A
D
F

Intake or combustion air can be supplied to the stove in one of two ways. Consult your local
building code before proceeding.
1. Outside air supply - (Necessary for mobile home installation, optional for residential
installation.) To draw outside air through the oor, cut or drill a 102mm diameter hole
directly below the bottom hole of the ash box enclosure(see page 6 Fig. #1a). Connect
enclosure to the oor with a short 102mm diameter pipe.
This hole must get its air from a ventilated crawl space or be extended with duct to the
outdoors (see Figure #4, Page 11). The use of outside combustion air for residential
installation requires the unit to be secured to the structure to prevent dislodging of the
air duct.
Note: When installed in a mobile home, this unit is not designed to be operated with the
ring door open. In addition to the obvious hazard of sparks landing on combustibles,
an open re door will cause the heater to draw air from the living space and possibly
cause suffocation.
2. Room air supply -There is a 102mm opening in the ash box enclosure. The stove will
draw its air from the room through this opening and into the rebox intake.
Note: The living space around the heater must be well ventilated with good air circulation.
Anything that may cause a negative pressure can cause gases or fumes to be pulled
into the living area. During extremely cold weather, and especially when burning at very
slow rates, the upper parts of the exposed chimney may ice up, partially blocking the
ue gases. If blockage occurs, ue gases may enter living space.
11
170314-20 AL6B
Combustion Air

12
170314-20 AL6B
Operation
CAUTION:
Never use gasoline, gasoline type lantern fuel, kerosene, charcoal lighter uid or similar
liquids to start or "freshen up" a re in this heater. Keep all such liquids well away from the
heater while it is in use.
CAUTION:
Hot while in operation. Keep children, clothing and furniture away. Contact may
cause skin burns.
WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR RE-
KINDLE THE FIRE.
WARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS IN THE VICINITY OF
THIS APPLIANCE WHEN IT IS OPERATING.
WARNING: DO NOT STORE FUEL WITHIN HEATER INSTALLATION CLEARANCES.
WARNING: DO NOT OPERATE THIS APPLIANCE AS AN OPEN FIRE.
WARNING: OPEN AIR CONTROL (AND DAMPER WHEN FITTED) BEFORE OPENING
FIRING DOOR.
Your PACIFIC ENERGY heater is designed for maximum overall efficiency at a moderate ring
rate. Overring is hazardous and a waste of fuel. Too slow a burn contributes to creosote
buildup and lowers combustion efficiency.
NOTE: Left and Right as referred to in this manual are considered your left and
right when facing the front of the woodstove.
Wood Selection
This heater is designed to burn natural wood only. Higher efficiency and lower emissions
generally result when burning air-dried seasoned hardwoods, as compared to softwoods
or too green or freshly cut hardwoods.
Wood should be properly air dried (seasoned) for six months or more. Wet or undried wood
will cause the re to smoulder and produce large amounts of creosote. Wet wood also
produces very little heat and tends to go out often.
DO NOT BURN :
• Salt water wood *
• Treated wood
• Wet or green wood
• Coal/charcoal
• Garbage/Plastic *
• Solvents
* These materials contain chlorides which will rapidly destroy metal surfaces and
void warranty.
Do not burn anything but wood. Other fuels (eg. charcoal) can produce large amounts of
carbon monoxide, a tasteless, odourless gas that can kill. Under no circumstances should
you attempt to barbecue in this heater.

13
170314-20 AL6B
How to Test Your Wood
Add a large piece of wood to the stove when it has a good large bed of coals. It is dry if it
is burning on more than one side within one minute. It is damp if it turns black and lights
within three minutes. If it sizzles, hisses and blackens without igniting in ve minutes it is
soaked and should not be burnt.
Lighting for the First Time
Curing of the Paint Finish
To achieve the best nish, the paint on your stove must be baked on. When burning your
stove for the rst 2-3 times it is very important that the room be well ventilated. Open all
windows and doors. Smoke and fumes caused by the curing process may cause discomfort
to some individuals.
Lighting a Fire
WARNING: Never use chemicals or any other volatile liquid to start a re.
1. Adjust air control to maximum ring position (start position) and open door.
2. Place crumpled newspaper in the centre of the heater and criss-cross with several pieces
of dry kindling. Add a few small pieces of dry wood on top.
3. Ignite the paper and close the door.
4. After the re has established itself, open the door and add a few small logs. Close the
door.
5. Begin normal operation after a good coal base exists and wood has charred.
Normal Operation
1. Set air control to a desired setting. If smoke pours down across the glass (waterfall
effect) this indicates you have shut the control down too soon or you are using too low
a setting. As every home's heating needs vary (based on insulation, windows, climate,
etc.) the proper setting can only be found by trial and error and should be noted for future
burns.
2. To refuel, adjust air control to high, and give the re time to brighten. Open the door
slowly, this will prevent backpuffing.
3. Use wood of different shape, diameter and length (up to 508mm). Load your wood and
try to place the logs so that the air can ow between them. Always use dry wood.
4. Do not load fuel to a height or in such a manner that would be hazardous when opening
the door.
5. For extended or overnight burns, unsplit logs are preferred. Remember to char the wood
completely on maximum setting before adjusting air control for overnight burn.
WARNING:Always keep loading door closed when burning.This heater is not designed
for open door burning.
WARNING: No alteration or modication of the combustion air control assembly is
permitted. Any tampering will void warranty and could be very hazardous.

14
170314-20 AL6B
WARNING: Do not use grates or andirons to elevate the fuel. Burn directly on the re
bricks. Replace broken or missing bricks. Failure to do so may create a hazardous
condition.
Restarting After Extended or Overnight Burns
1. Open door and rake hot embers towards the front of the heater. Add a couple of dry,
split logs on top of embers, close door.
2. Adjust air control to high (left position) and in just a few minutes, logs should begin
burning.
3. After wood has charred, reset air control to desired setting.
4. To achieve maximum ring rate, set control to high (left position). Do not use this setting
other than for starting or preheating fresh fuel loads.
Proper Draft
1. Draft is the force which moves air from the appliance up through the chimney.The amount
of draft in your chimney depends on the length of the chimney, local geography, nearby
obstructions and other factors.
2. Too much draft may cause excessive temperatures in the appliance. An uncontrollable
burn or a glowing red stove part or chimney indicates excessive draft.
3. Inadequate draft may cause backpuffing into the room and plugging of the chimney.
Smoke leaking into the room through appliance and chimney connector joints indicates
inadequate draft.
Ash Removal
Whenever ashes get 76mm to 102mm inches deep in your rebox, and when re has burned
down and cooled, remove excess ashes. Leave an ash bed approximately (25 mm) deep
on the rebox bottom to help maintain a hot charcoal bed.
Ash Chute Operation: Your Alderlea stove is equipped with an ash chute system to ease
removal of ash from the ash lip area. To use this system, rst pull out the ash pan approxi-
mately 51mm, sweep the ash into the chute located to the right side of the ash lip, and
close the ash pan.
Ash Cleanout System: The ash dump handle is located under the ash lip on the left hand
side. To operate ash dump, pull handle out 13mm and turn clockwise. This will unlock the
ash dump and allow it to open. Hold handle open while pulling ashes into the opening.Avoid
large embers as these still contain heat value. Release handle and push in to lock. Ensure
ash dump door is properly engaged. Fill the cavity with the remaining ash level with the
rebox oor. Pull out ashpan and discard ashes into metal container. Replace ashpan and
ensure it is seated properly.
DO NOT OVERFIRE THIS HEATER:
Attempts to achieve heat output rates that
exceed heater design specications can
result in permanent damage to the heater
and chimney.
Do not burn with ash dump door open.
Doing so will create a hazardous
condition. Always leave about 25mm of
ash when cleaning.
CAUTION:
Ashes are to be removed only when the
heater is cold.

15
170314-20 AL6B
Chimney connector pipe should be disconnected from stove to clean and inspect.
Only if this is not possible should you remove baffle assembly.
DO NOT OPERATE WITH BAFFLE ASSEMBLY OR INSULATION REMOVED.
Removal
Remove retaining pin located at the rear top of the rebox, just below the
baffle. Lift baffle up and pull forward to disconnect from the supply tube. Tilt baffle
sideways to drop down and remove from rebox. Inspect gasket between baffle and
supply tube. If necessary, replace with gasket SUMB.BAFGASK(5pcs.) available
from your Pacic Energy dealer. Re-install baffle assembly in reverse order. The
two side pieces of insulation must be tight against the siderails.
Secondary Air Box Removal and Cleaning:
1. The secondary air box is located on the bottom rear of the woodstove and can
be cleaned by removing the two screws securing the cover plate on the rear
face of the secondary air box and using a vacuum to suck out any debris.
2. To remove the secondary air box, use a 10mm wrench and undo the two #10
Keps nuts, one on each side of the secondary air box. Lower the secondary
air box and slide out.
3. Reverse this process to re-install the secondary air box.
* MAKE SURE THE GASKET IS IN GOOD SHAPE AND POSITIONED
CORRECTLY.
Baffle Removal
Disposal of Ashes
Ashes should be placed in a metal container with a tight tting lid. The closed container of
ashes should be placed outside on a non-combustible oor or on the ground, well away
from all combustible materials, pending nal disposal. If the ashes are disposed of by burial
in soil or otherwise locally dispersed, they should be retained in a closed container until all
cinders have thoroughly cooled. Other waste should not be placed in this container.

16
170314-20 AL6B
Problem Cause Cure
Glass is Dirty 1. Wood is wet • Use dry wood
2. Turning down air control • Do not turn down until
or damper too soon a) there is a good bed of coals
b) the wood is charred
3. Draft too low • Improper chimney height and / or
diameter, -consult dealer
• Chimney plugged or restricted,
- inspect and clean
• Provide outside air for combustion
4. Door gasket leakage • Replace gasket
• Check latch for proper operation
Excessive Creosote Buildup See 1,2,3, above. See 1,2,3, above.
Low Heat Output 1. Wood is wet • Use dry wood
2. Fire too small • Build a larger re
3. Draft too low • Chimney plugged or restricted,
- inspect and clean
Won't Burn Overnight 1. Air control is set too high • Set air control lower
2. Not enough wood • Unsplit wood is preferred for
overnight burns
3. Draft too high • Excessive chimney height and/or
diameter
4. Poor quality or wet wood • Use good quality, dry wood
Wood Won't Burn 1. Combustion air supply blocked • Check outside air supply for
obstruction
2. Draft too low • Chimney plugged or restricted,
- inspect and clean
• Chimney oversized or otherwise
unsuitable, -consult Dealer
Troubleshooting
APPENDIX A

Replacement Parts
#1
#2
#3
#4
#5
#6
#7
#8
#6
#9
4b
4a
4c
4d
4f
4e
10
11
12
13
14
15
17
#1 BAFFLE KIT ....................................... SUMB.BAFKIT
#2 BRICK RAILS (2)..............................SUMM.RAILSET
#3 FLAME SHIELD .....................................SUMB.31155
#4 DOOR ASSEMBLY LEFT ................ALT6.4800LMBK
...RIGHT.......................................... ALT6.4800RMBK
CLEARVIEW DOOR ASSY ................................................
...BLACK PAINT ........................ R - ALT6.4811RMBK
...BLACK PAINT ......................... L - ALT6.4811LMBK
#4a DOOR HANDLE................................ ALDR.50380GL
...........................................................ALDR.50380GR
#4d DOOR GASKET KIT........................................... 4880
#4e GLASS C/W GASKET...................................... 2080.9
#4f GLASS CLAMPS............................................ 4720.01
#5 FIREBRICK SET ..................................BRIC.SUMMA
#6 SIDE CASTING MBK (2) ................... ALT6.4805MBK
#7 TOP GRILL ASSEMBLY (3) ........ALT6.TGASSYMBK
#8 ASH DUMP ASSEMBLY..........................WODC.2261
#9 LEG CASTING ASSY(4) ...................ALDR.4807MBK
#10 BOOST MANIFOLD ......................................3105.111
#11 DOOR CATCH ................................................ 4722.01
#12 DOOR CROWN BLACK PAINT ........ ALT6.4802MBK
#13 ASHLIP BLACK PAINT..................... ALT6.4801MBK
#14 LEG ADAPTER .................................... AL6B.LGADA
#15 ASH PAN ASSY. ................................................. 4825
#17 DOOR STOP (LHS) ........................... ALT6.4830MBK
#18 AIR SHUTTER ASSEMBLY ..................... FSND.4631
#19 AIR DEFLECTOR............................................. 4815.5
#20 SECONDARY AIR BOX GASKET ............. 5068.3237
#21 SECONDARY AIR BOX ...........................SUMB.3140
ALL OTHER PARTS NOT INCLUDED IN ABOVE KITS ARE NOT SOLD SEPARATELY
RIGHT AND LEFT ARE DETERMINED WHEN FACING THE FRONT OF THE STOVE
18
19
20
21
17
170314-20 AL6B

18
170314-20 AL6B

19
170314-20 AL6B
Compliance Plate
300114 5050.43AS
Model: ALDERLEA T6, SUMMIT, SUMMIT CLASSIC
Series: C Type: FREESTANDING
MADE IN CANADA
MAXIMUMAVERAGE HEAT OUTPUT BURNING
HARDWOOD - 8.5 kW
OVERALLAVERAGE EFFICIENCY BURNING
HARDWOOD - 64%
WHEN TESTED IN ACCORDANCE WITH
AS/NZS 4012
PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
2975 ALLENBY RD., DUNCAN, BC V9L 6V8
Tested by: HRL TECHNOLOGY PTY LTD
TRAMWAY ROAD, MORWELL, VICTORIA
Test report no: HCMG/13/046 30/SEPT/2013
Tested to: AS/NZS 4013:1999
Distributed by: PIVOT STOVE & HEATING CO
234-238 MOORABOOL STREET, GEELONG VIC 3220
pivotstoves.com.au
COMPLIANCE PLATE
LOCATION
REAR VIEW

PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
Web site: www.pacicenergy.net
2975 Allenby Rd., Duncan, BC V9L 6V8
PRINTED IN CANADA
