Terra Bound Solutions FP-TB6HA-CU-02 User manual

FS-TB6HA-CAP-02
Congratulations ! !
You have just purchased the finest recycled plastic
park bench available. Enjoy ! ! !
ADA Park Bench
6 Foot Traditional
For Fastener Pack
(FP-TB6HA-CU-02)

Before assembly, please make sure all components are included.
B - Bench End B - Bench End
( 3 ) - Three Bench Ends
32 -
#12 x 3" Flat Head Phillips Screw
EM4BA
1
Before assembly, please make sure all fasteners are included.
FP - Fastener Pack
( 1 ) - One Fastener Pack
FS-TB6HA-CAP-02
FP-TB6HA-CU-02
PS-SBBE-H-03
( 1 ) - One Bench Board
BP-TB6HA-A-02
( 2 ) - Two Bench Arms
BSA-HABA-A-00
D - Bench Arm D - Bench Arm
A - 2 x 10 Bench Board
F - 2 x 10 Bench Board
H - 2 x 10 Bench Board w/ Arm Holes
C - 2 x 6 Bench Board w/ Arm Holes
E - 2 x 6 Bench Board
( 3 ) - Three Mounting Plates
BP-TBHA-A-02
G- Mounting Plate
( 1 ) - One Bench Board
BP-TB6BA-A-03
( 1 ) - One Bench Board
BP-TB6B-A-02
( 1 ) - One Bench Board
BP-TB6HA-B-02
( 1 ) - One Bench Board
BP-TB6HA-C-02
B - Bench End
G- Mounting Plate
G- Mounting Plate

Before assembly, please make sure all fasteners are included.
#12 x 3" Flat Head Phillips Screw22 -
FS-TB6HA-CAP-02
Also needed for this assembly will be the following materials:
1 - #3 Phillips Drive Bit
*IMPORTANT NOTICE*:
·DO NOT OVER-TIGHTEN SCREWS.
·USE A DRILL WITH ADJUSTABLE TORQUE FOR
BEST RESULTS.
·OVER-TIGHTENING WILL RESULT IN STRIPPING
OUT THE PILOT HOLE, AND SCREW WILL "SINK"
INTO THE PLASTIC WHICH MAY CAUSE A
STRESS FRACTURE.
#12 x 2" Flat Head Phillips Screw15 -
#12 x 2" Pan Head Phillips Screw24 -

Fig #1:
In order to make the assembly of this
Traditional ADA Bench easier while going
through the assembly process the board
positions are numbered and will be referenced
in later steps.
Step #1:
Stand (1) One bench end (Part B) upright and place (1) One bench board
(Part A) on position 1 being sure to align the pre-drilled holes to the pilot
holes in the bench end. After the holes are properly aligned, fasten with
(1) One #12 x 3" Flat Head Phillips Screw in the top pre-drilled hole.
Note: Do not tighten screw completely. This will be done in a later step.
FS-TB6HA-CAP-02
#12 x 3" Flat Head
Phillips Screw
1
2
345

Step #2:
Stand the other bench end (Part B) upright and place the bench board
(Part A) already attached to the first bench end, on position 1 being sure to
align the pre-drilled holes to the pilot holes in the bench end. After the
holes are properly aligned, fasten with (1) One #12 x 3" Flat Head Phillips
Screw in the top pre-drilled hole.
Note: Do not tighten screws completely. This will be done in a later step.
FS-TB6HA-CAP-02
#12 x 3" Flat Head
Phillips Screw

Step #3:
Align bottom pre-drilled holes to the pilot holes in the bench end (Part B).
After the holes are properly aligned, fasten with (1) One #12 x 3" Flat
Head Phillips Screw per hole.
Note: Be sure to tighten screws completely after this step.
Step #4:
Place a Mounting Plate (Part G) with the countersink's facing up on each
bench end (Part B). Being sure to align the pre-drilled holes to the pilot
holes in the bench end. Use (1) One #12 x 2" Flat Head Phillips Screw
per hole to fasten.
FS-TB6HA-CAP-02
#12 x 3" Flat Head
Phillips Screw
#12 x 2" Flat Head
Phillips Screw

Step #5:
Repeat Steps 1 - 3 to attach bench board (Part C) on position 2 with arm
holes towards bottom of board and bench board (Part E) on position 3.
FS-TB6HA-CAP-02
#12 x 3" Flat Head
Phillips Screw

Step #6:
Lay bench on its back. Attach bench board w/ arm holes (Part H) on
position 4 with arm holes facing front of bench and bench board (Part F)
on position 5. Be sure to align the pre-drilled holes in the mounting
plates to the pilot holes in the bench boards. Use (1) One #12 x 2" Pan
Head Phillips Screw per hole to fasten.
FS-TB6HA-CAP-02
#12 x 2" Pan Head
Phillips Screw

Step #7:
Position the bench arms (Part D) as shown above. Align the pilot holes
to the pre-drilled holes in the bench board w/ arm holes. After the holes
are properly aligned, fasten with (1) One #12 x 3" Flat Head Phillips
Screw per hole.
FS-TB6HA-CAP-02
#12 x 3" Flat Head
Phillips Screw
