Terra Bound Solutions MALIBU BENCH User manual

ASSEMBLY INSTRUCTIONS
MALIBU BENCH
4’ 5’/6’
REF# QTY QTY DESCRIPTION
1 1 1 RIGHT MALIBU BENCH LEG
2 1 1 CENTER MALIBU BENCH LEG
3 1 1 LEFT MALIBU BENCH LEG
4 2 2 BOCA BOARD
5 6 6 2" X 4" PROFILE
HARDWARE
6 40 40
#14X2-1/4" SSPHILLIPS SCREW
STEP 5: PLACE A BOCA BOARD ONTO THE SEAT OF THE LEGS. INSERT SCREWS INTO PREDRILLED HOLES IN THE
BENCH LEGS. REPEAT WITH BOCA BOARD ON THE BACK OF THE BENCH.
HOLD OR CLAMP THE PROFILES SECURELY WHILE TIGHTENING SCREWS. A POWER DRIVER OF SOME TYPE IS
RECOMMENDED – DO NOT OVER TIGHTEN.
Your 100% recycled plastic park bench will give you many years of pleasure and pride,
knowing that you did your part in keeping plastic waste out of landfills and protecting our environment.
STEP 1: PLACE THE BENCH LEGS FACING UPRIGHT ON A
LEVEL SURFACE, MAKING SURE THE MIDDLE LEG IS
CENTERED.
STEP 2: PLACE A 2” X 4” PROFILE TOWARD THE BACK OF
THE SEAT ON THE LEGS, MAKING SURE THE “MOLD” SEAM IS
FACING DOWN. INSERT SCREWS INTO PREDRILLED HOLES
IN THE BENCH LEGS.
STEP 3: PLACE A 2” X 4” PROFILE TOWARD THE BOTTOM
OF THE BACK ON THE LEGS, MAKING SURE THE “MOLD”
SEAM IS FACING THE BACK. INSERT SCREWS INTO
PREDRILLED HOLES IN THE BENCH LEGS.
STEP 4: REPEAT WITH REMAINING 2” X 4” PROFILES.

1234456(screws฀from฀back)6(screws฀from฀bottom)
