TerraTec CINERGY 2400 I DT MCE edition Installation guide

Watch one program while recording another
Two DVB-T tuners on one card means ultimate TV viewing comfort on your PC: finally you can
record one program while watching another on a different channel at the same time.
Use your existing antenna
As it has in the past, the Cinergy 2400i DT MCE receives digital terrestrial television through an
antenna, and because the signal is distributed to the two tuners internally, a single connecting
cable is all you need. The card is inserted into the PCI Express port of your PC, which also
makes it future-proof for your next computer. In conjunction with Windows XP Media Center
Edition, you can enjoy all the benefits of the new TV technology.
Time-shifting TV programs
TerraTec Cinergy 2400i DT MCE version
08.12.2005 – Page 1 – Might change without notice.
All trademarks are registered property of their respective
owners. © TerraTec Electronic GmbH
If you are interrupted for any reason during a program, you can use the time-shifting function to
restart it later exactly where you left off, without missing a single scene. You can also use the
Cinergy 2400i DT MCE as a video recorder for recording digital terrestrial TV programs with
timer and full MPEG-2 support.

TerraTec Cinergy 2400i DT MCE version
08.12.2005 – Page 2 – Might change without notice.
All trademarks are registered property of their respective
owners. © TerraTec Electronic GmbH
Technical Details
Features
• Dual reception of two
independent stations
• Record while Play
• Digital Video Broadcasting
via antenna (DVB-T)
• Lossless TV recording
• TimeShifting
• Electronic Program Guide
Software
• BDA drivers for Windows XP or
Windows XP Media Center Edition
• Cyberlink PowerDVD 6.0
Art.No.: 10239
EAN code: 4017273102399
Warranty: 24 months
System requirements
• 2 GHz Intel Pentium or AMD Athlon CPU
• 1 free PCIe slot (x1, x4 or x16)
• 512 MB RAM
• Sound card with DirectX support
• Graphics card with DirectX and
Video Overlay support
• CD or DVD drive for software installation
• Windows XP MCE 2005
• Digital terrestrial TV reception (DVB-T)
Scope of delivery
• Cinergy 2400i DT PCIe card
• Driver/software CD
• Manual on CD
• Service documents
• Registration documents
