TerraTec HOME ARENA MX 5.1 Installation guide

HomeArena MX 5.1 – 09/2004 – Page 1 / 2
All company names and trademarks are registered trademarks and brand names of their respective owners.
© 1994 - 2004 TerraTec Electronic GmbH
HomeArena MX 5.1: Your entry into the surround sound class
It doesn't matter whether you're into games, DVDs or musical perfection: the HomeArena MX 5.1 speaker
system has everything you need for a successful entry into the surround sound class. Two front and two rear
speakers, one center speaker and a powerful subwoofer in a wooden cabinet deliver crystal-clear audio with a
total power output of 37 watts RMS. The integrated volume and tone controls let you tailor the sound perfectly
to your taste. And if you ever need to keep it down, just use the separate headphone jack.
For traditional audio sources such as your stereo, use the system's virtual surround mode to enjoy your
favorite CDs and movies with an impressive new spatial audio experience.
HomeArena MX 5.1 not only stands out with its audio qualities – with its elegant design, it also has a lot to
offer visually.
A complete set of cables featuring RCA and jack connectors is included, as well as separate wall mounting
brackets and an adapter for X-BoxTM, Playstation® and other game consoles.

HomeArena MX 5.1 – 09/2004 – Page 2 / 2
All company names and trademarks are registered trademarks and brand names of their respective owners.
© 1994 - 2004 TerraTec Electronic GmbH
Technical Details
Total Output Power: 37 Watts RMS
Subwoofer
•1 x 4“ (10,16 cm) Subwoofer
•12 Watts RMS
•MDF cabinet with front bass tube
•Integrated amplifier
•5.1 (6 channel) surround input (3 x 3.5 mm jack plug)
•Stereo line input (3.5 mm jack plug)
•Audio control (woofer and treble)
•Power cable (1.8 m)
Satellites
•5 x 2,5“ (6,35 cm) Satellites
•5 Watts RMS each
•HIPS case
•Center speaker with control unit
•Headphone output (3.5 mm jack plug)
•Volume control/power switch
Dimensions
•Subwoofer (W/H/L): 130 x 267 x 255 mm
•Satellites (W/H/L): 85 x 110 x 105 mm
Power Requirements
•230 V/50 Hz power supply unit
System Requirements/Recommendation
•PC with soundcard or any other audio source (MP3 player, DVD player or video game console) with line
level output
Package Contents
•1 x Subwoofer
•1 x Center Speaker (cable length 3 m)
•2 x Front Satellites (cable length 3 m)
•2 x Rear Satellites (cable length 5 m)
•5 x Wallmounting brackets for satellites
•Quickreference printed (D, NL, F, GB, I, ES)
•4 x cable 3.5 mm jack plug to RCA (1.80 m)
•4 x cable 3.5 mm jack plug to 3.5 mm jack plug (1.80 m)
•1 x adaptor 3.5 mm socket to RCA socket (video game consoles adaptor)
•Customer service form
Art.No.: 10002
EAN-Code: 4017273100029
Warranty: 24 months
