Introduction
Package content
Your TerraTec graphics board package should contain the following documentation, hardware
and software:
· 1 x TerraTec Mystify 440 VGA graphics board
· 1 x Getting Started guide
· 1 x CD ROM with VGA card drivers, manual, Cyberlink Power DVD 4.0 XP and Acrobat
Reader software
· 1 x S-Video cable
· 1 x registration card
· 1 x Service request form
If the package is incomplete or the contents damaged, please contact your retailer as soon as
possible.
What can you expect from your new hardware?
The NVIDIA Geforce4 MX series is the start of a whole new chapter of powerful, flexible graph-
ics performance on your PC. Thanks to the innovative NVIDIA nView display technology, ultra-
fast LAM II memory architecture and the sophisticated Accuview anti-aliasing function, the
GeForce4 MX delivers a wealth of features for maximum performance at an unbeatable
price/performance ratio.
Chipset
· nVIDIA multi-display GeForce4 MX440 series
GPU speed: 270 MHz
Memory speed: 400 MHz
Fill rate: 1,1 billion texels/sec.
Triangles per second: 34 millions
Memory bandwidth: 6,8 GB/sec.
Maximum memory: 64 MB

TerraTec Mystify 440 (English) 5
Interface
· AGP 2.0 compatible
· AGP 4X /2X and AGP texturing supported
Technologies
· nView Display technology
nView hardware and software technology offers maximum flexibility, especially in multi-
display applications. But not only that. It also offers users completely new options to turn
their PC graphics into a truly compelling experience. NView supports connections to a va-
riety of output devices such as flat screens, TVs, or analog CRTs in any combination.
The display properties can be controlled using a simple software application with an intui-
tive user interface.
· Lightspeed Memory Architecture, LMA II Technology
The new LMA II technology increases effective memory bandwidth by up to 300%. Innova-
tive technologies such as Z-occlusion culling, fast Z-clear and auto precharge guarantee
fluid frame rates even with the latest 2D and 3D applications.
· Accuview Antialiasing
The Accuview antialiasing subsystem with multisampling provides a degree of edge
smoothing and natural depiction of complex objects previously unreached on normal PCs.
· MX Memory Crossbar
· Two integrated 350 MHz DACs
· Video Processing Engine (VPE)
· Two 350 MHz DACs
· Integrated two-channel TMDS transmitter
Memory interface
· Supports 64 MB DDR SGRAM
TV Output
· Integrated TV encoder
· Supports one S-Video TV output
· Digital NTSC or PAL output
· Supports external digital TV
Miscellaneous
· Optimized support for Microsoft® Windows® XP
· Unified Driver Architecture (UDA)
· Complete OpenGL® 1.3 and OpenGL support

6 TerraTec Mystify 440 (English)
· Optimized for Microsoft DirectX®
System requirements
Computer system
· Intel® Pentium 4/III/II Celeron, AMD® K7/K6 or compatible with AGP 2X or AGP 2X/4X
slot
· VGA/Super VGA monitor with a resolution of at least 640 x 480
· 32 MB RAM or higher
· CD-ROM drive
Operating system
· Microsoft® Windows 9x/ME/2000/XP must be installed on your computer to take full
advantage of the card's 4 x AGP mode (133 MHz).
Connections
· 15-pin D-SUB female VGA port
· S-Video In/Out cable connection
The Geforce4 Titanium Series can easily be connected to TVs via the S-Video output. Simply
connect an S-Video cable from the appropriate output of the graphics card to the input of your
TV. Please note that some older TVs do not support the S-Video format. (For further informa-
tion, please check the manual of your TV.)
NTSC-PAL switching
If you encounter unexpected problems using your TV as a monitor, this may be due to the
NTSC setting. Please follow the description below to switch to PAL.
1. In the Windows Control Panel, open “Display” and click on “Settings”.

TerraTec Mystify 440 (English) 7
2. Click “Monitor 2”.
3. Click “Extend my Windows desktop onto this monitor”.
4. Click the “Advanced” button.
5. Click “Device Selection”.

8 TerraTec Mystify 440 (English)
6. “Change Format...”, to “PAL” – “OK” – “Apply” - finished!
Pin assignment
Video connection to monitor

TerraTec Mystify 440 (English) 9
Hardware installation
The TerraTec Mystify 440 and its connections at a glance
TV Out
VGA
Please note: This illustration is intended as a typical example. The appearance of your graph-
ics board may vary!
Preparing your computer
Please set your operating system to operate with a standard VGA graphics board. In Windows,
you can find this function in the Control Panel.
Please note: Beware of electrostatic discharge. It can cause severe damage to sensitive com-
puter components. When installing the graphics board, be sure to ground yourself by wear-
ing an antistatic wrist strap or touching metal parts of the PC before touching electronic com-
ponents.

10 TerraTec Mystify 440 (English)
Installing the card
1. Switch the computer off (leave the power cable connected, however, to ensure that the
computer is grounded) and remove the monitor plug.
2. Open the case. Don't forget to ground yourself before touching the old or new graphics
board.
3. Remove the old graphics board if present. First, remove the screw holding the slot plate of
the card to the case. Grasp the card by the edges and carefully pull it out of its slot. Next,
carefully insert your TerraTec Mystify 440 into a free AGP slot and gently press it into the
slot until completely seated.
4. Replace the screw in the case to retain the graphics board and close the case.
5. Reconnect the monitor cable and switch on your PC and monitor.

TerraTec Mystify 440 (English) 11
Installing the TerraTec Mystify graphics board driver software
Introduction
In this chapter we'll briefly explain how to install the drivers for your TerraTec Mystify graphics
board. A setup program can be found on the included driver CD.
Here's how: installing the drivers
The driver software on your CD includes the following components:
· Windows 9x/ME/2000/XP drivers
· Microsoft DirectX 8.1
Driver installation
The setup program
The installation of the drivers in Windows 9x/ME and Windows 2000/XP is child's play thanks
to the user-friendly setup program.
Installing the drivers under Windows 9x/ME/2000/XP
1. Install the TerraTec Mystify graphics board on your mainboard (see previous chapter)
2. Start your computer
3. Boot your Microsoft Windows operating system*
4. Insert the TerraTec CD in your CD-ROM drive. If the CD does not launch automatically,
double-click “autorun.exe” of the CD. This will launch the autostarter of the Mystify
series.
Please note: DirectX 8.1 or higher must be installed before installing the driver software.
To install DirectX 8.1, click on a Mystify 4xxx button on the welcome screen. Next, click the
“DirectX” button, then “DirectX” again. Follow the instructions which will then be dis-
played. Next, install the drivers, as explained below starting with item 5. For more infor-
mation on DirectX, see section Reference, page 15.
If DirectX does not launch automatically, double-click dxsetup.exe on the CD.
5. Please select the correct button for your graphics board.
*When installing the card in Windows for the first time, you will generally be prompted to install the
drivers when Windows boots. We recommend canceling this process (simply click the "Cancel" button).

12 TerraTec Mystify 440 (English)
6. Next, click on the “Driver installation” button.
Windows will now automatically launch and display the setup program. If you have disabled
the autorun function of your CD drive, please launch the nVidia setup file manually.

TerraTec Mystify 440 (English) 13
7. The following window will now appear on your monitor.
8. Click “Next” to start the installation.
9. Follow the instructions which will then be displayed.
10. Click “Finish” to restart your PC. The driver configuration will then be updated automati-
cally.
After restarting your computer, set the screen resolution of your monitor under “Proper-
ties/Display Properties/Settings”.

14 TerraTec Mystify 440 (English)
Advanced users who would like to install the drivers manually should proceed as follows:
Important! In the following, D: stands for a CD-ROM drive. Replace D: with the actual drive
letter of your CD-ROM as required.
Under Windows 9x/ME
In the Control Panel, open “Display” and click SETTINGS/ADVANCED.../ADAPTER/CHANGE.
Here you will find an option for the manual installation of drivers. Specify the file NVAML.INF
for installation. You can find this file in the Drivers folder of the included CD. Replace the drive
letter “D:” with the actual drive letter of your CD-ROM drive. Follow the additional instructions
which will then be displayed.
Under Windows 2000/XP
In the Control Panel, open “Display” and click SETTINGS/ADVANCED.../ADAPTER/CHANGE.
Here you will find an option for the manual installation of drivers. Specify the file
nv4_disp.inf for installation. You can find this file in the Drivers folder of the included CD.
Replace the drive letter “D:” with the actual drive letter of your CD-ROM drive. Follow the addi-
tional instructions which will then be displayed.
Via CD, selection of nVidia setup
On the Mystify CD, open the folder for your operating system and launch the file
Setup.exe. Follow the additional instructions which will then be displayed.

TerraTec Mystify 440 (English) 15
Software
Cyberlink Power DVD XP 4.0
PowerDVD XP 4.0 is a powerful DVD application for maximum audio and video performance
and a range of features that will turn your PC into a versatile entertainment center. The Pow-
erDVD user interface is intuitive and easy to use, letting you concentrate on the essentials: a
first-class visual and audio experience.
Reference
DirectX TM
DirectX is a set of APIs (application programming interfaces) developed by Microsoft. It forms
the foundation for sophisticated audio and graphics on Windows-based systems.
The performance of graphics-intensive software (generally games) is optimized significantly
by the use of DirectX. That also applies to sound effects and even for input devices such as
joysticks and mice. As a constant, shared interface, DirectX offers hardware developers and
software programmers a shared standard for the development of ever more sophisticated and
fascinating technologies. It also simplifies the installation and configuration of software.
DirectX consists of several components: DirectDraw, DirectSound, DirectPlay, Direct3D and
DirectInput.
Direct3D™
Direct3D is the next generation of interactive real-time 3D applications for standard PCs and
the Internet. Direct3D offers software-based rendering with the full range of options (trans-
formation, lighting and rasterization) as well as direct access to hardware rendering. This
permits some or all of the software rendering to be transferred to the hardware, resulting in a
significant acceleration thanks to the reduced CPU load. The TerraTec Mystify 420 supports
and accelerates Direct3D.

16 TerraTec Mystify 440 (English)
Declaration of compliance with FCC standards
This equipment has been tested and found to comply with the limits for a Class B digital de-
vice in accordance with the specifications in Part 15 of FCC rules. These specifications are de-
signed to provide reasonable protection against such interference in a residential installation.
This equipment generates, uses, and can radiate radio-frequency energy. Incorrect use may
lead to radio-frequency interference. However, there is no guarantee that interference will not
occur in a particular installation. You can determine whether this device is causing interfer-
ence by turning it off. If the device does cause interference, try to correct it by using one or
more of the following measures: Turn the television or radio antenna until the interference
stops.
· Move the device farther away from the receiver.
· Plug the device into an outlet that is on a different circuit from the receiver.
· Consult your retailer or an experienced radio/television technician for additional sugges-
tions.
Only devices designated as Class B may be connected and must feature shielded satellite
cables. Changes or modifications to this product not authorized by the group responsible for
the adherence to the regulations could void the FCC certification and negate your authority to
operate the product. This device complies with the specifications in Part 15 of FCC rules. Its
operation is subject to the following rules: 1.) The device must not emit dangerous radiation.
2.) The device must accept interference, including interference that may lead to faulty opera-
tion.

TerraTec Mystify 440 (English) 17
Limited warranty
TerraTec Electronic GmbH (hereinafter: “TerraTec”) guarantees the first buyer (hereinafter:
“buyer”) the product's freedom from defects in materials and workmanship for a period of 24
months if used as intended, installed in the original system under the conditions specified
below. This warranty does not cover problems of compatibility with hardware, software or
alternative configurations used with the device. In the event of damage covered by this war-
ranty, TerraTec shall repair or replace the device free of charge at its own discretion.
TerraTec reserves the right to replace the device with a comparable or superior model. Such
replacement devices may be reconditioned or may contain reconditioned parts. Repaired or
replaced products shall be subject to the same terms of warranty.
This limited warranty does not cover incorrect use, misuse, improper handling, accidents,
improper installation or other reasons not related to defects in materials or workmanship.
TerraTec reserves the right to invoice repairs performed for any of the reasons specified above
as appropriate. This shall also apply to the return of equipment which is in good operating
condition. Memory or other components that were not originally supplied with this product
are not covered by this warranty.
In the event of warranty claims, please contact TerraTec technical support. You must have
spoken to one of our services staff members before returning a device to us. You will be given
an RMA (return material authorization) number and information on how to proceed with the
return of your damaged product. No TerraTec product will be accepted for repairs without an
RMA number and proof of purchase. The sales slip or invoice shall suffice as proof of pur-
chase. The costs for shipping of the product to be repaired by TerraTec shall be borne by the
sender.
No other warranties are made, express or implied, including but not restricted to warranties
with regard to suitability for a specific purpose or commercial viability. TerraTec shall under
no circumstances be held liable for damages arising from the deployment or installation of a
TerraTec product or from the infringement upon an express or implied warranty. TerraTec's
liability toward the buyer shall be limited to the purchase price of the device in the event that
damages arise from the use of the device or negligence by TerraTec. TerraTec reserves the
right to investigate and verify damage to any and all products or components. This warranty
does not apply to software components.
