Teryair ADPB15PPT Instruction Manual

Models Descriptions
ADPB15PPT Polypropylene with PTFE tments
ADPB15PPT
Read this manual carefully before installing, operating or servicing this equipment. It’s the responsi-
bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
is document is issued with Product Serial No
Operation and Maintenance Guide

FF-MM-360-REV - 02
Page 2
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Table of Contents
3 Pump Nomenclature
3 Operating and Safety Instructions
5 Suggested Lubricants
5 Suggested site selection and installation recommendations
7 Troubleshooting
8 Maintenance
8 Bill of Materials for ADPB15PPT Pumps
9 Exploded View for ADPB15PPT Pump
10 Dimensional Data
10 Repair Kits for ADPB15PPT Pumps
10 Repair and Replacement Kits
11 Eu Declaration Of Conformity
12 Warranty Certicate

FF-MM-360-REV - 02
Page 3
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Pump Nomenclature
XX XX XX X X X
Air Valve Type Pump Size Material of Construction Material of
Diaphragm
Bolted or
Clamped
Threading on Inlet
and Outlet
DP - Classic
ADP - Advanced
SDP - MaxFlo
06 - 1/4”
AL - Aluminium
SS - Stainless Steel 316L
PP - Polypropylene
CI - Ductile Iron
B - Nitrile
N - Neoprene
S - Santoprene
T - PTFE
V - Viton
H - Hytrel
B - Bolted
C - Clamped
R- NPT
G - BSPT
P - BSPP
F - Flanged
12 - 1/2”
15 - 1/2”
25 - 1”
40 - 1 - 1/2”
50 - 2 “
75- 3”
100 - 4”
Operating and Safety
Instructions
Warning: Static Electricity
Static sparks can cause explosion resulting in
severe injury or death.
Ground the pump and the pump connections
like hoses and containers into which or from
the uid is being transferred. Connect the
grounding wire to any bolt on the pump.
Check continuity of electrical path to ground
at regular intervals.
Consult local building and electrical codes for
grounding requirements where needed.
Use hoses containing a grounding wire.
Warning: Pump Exhaust
In case of a diaphragm failure, u-
id being pumped may spray out from the
exhaust of the pump. is may cause severe
injury depending on the uid being pumped.
If the uid is hazardous, pipe away the
exhaust to a safe remote location using a
generous diameter pipe preferably with a
grounding arrangement, and ret the muer
at the end of this arrangement.
Always wear safety glasses while in the
vicinity of an operating pump.
Warning: Over pressure / Hazardous Pressure
Do not exceed the max supply air pressure of
100 PSI.
Make sure all connected hoses and pipelines
are rated to operate safely with the pressures
generated by pump of 100 PSI.
Do not open or handle pump or hoses while
pressurized.
Disconnect air supply line and relieve
pressure from the system by carefully opening
discharge and supply lines.
Warning: Hazardous Materials
Do not move a pump that contains
hazardous uids trapped inside it. Please
observe prescribed handling and safety codes.
Drain the pump safely, by turning it upside
down and collecting the uid safely, before
moving the pump.
Warning :Explosion
Please check compatibility of uids
intended to be handled with the materials of
construction of the pump. Severe reactions
and explosions may occur if materials are
incompatible. Caution: Chemical
compatibility

FF-MM-360-REV - 02
Page 4
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Please check that the uid being pumped is
compatible with the wetted parts of the pump.
Refer Cole Parmer compatibility (http://www.
coleparmer.in/Chemical-Resistance) guide
for details. Note that chemical compatibility
may change with temperature; take this into
account while selecting pump material.
Caution: Structural support
Please refer gure 1 and ensure that the
piping system is independently supported
and does not load the pump. e pumps are
not designed to take the continuous and oen
pulsating load of a piping system. Important
to use a exible connection between rigid
piping and pump casings.
Caution: Running dry, disconnection of hoses when
not in use
Although these pumps can be run dry for
long periods, it is advisable to avoid this as it
causes unnecessary wear of wearing parts.
Caution: Operator
understanding
Please ensure that all operators have read this
manual and have the required understanding
of safe working practices and are equipped
with safety equipment when working on/
around the pump.
Caution: Using genuine

Use genuine teryair parts to ensure correct
pump operation and maximize life.
 
e Teryair diaphragm pump generates a alternate stroking of the diaphragms against the
uid in the liquid chambers of the Pump. is reciprocatory action is responsible for the uid
being pumped.
It is possible to control the output of the pump by controlling the supply air pressure.
It is also possible to control the output of the pump by throttling action on the uid owing
in the outlet piping by means of a valve. if such a valve is shut completely the pressure in the
discharge piping increases to a point when the pressure at pump discharge equals it and the
pump comes to a stop. is causes no damage to the pump and the pump consumes no more
energy.
Upon opening of the valve, the pump starts reciprocating once again and resumes uid deliv-
ery.
Operating Instructions

FF-MM-360-REV - 02
Page 5
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Caution: Temperature limitations and diaphragm options
PTFE
Excellent choice when pumping highly aggressive
uids such as aromac or chlorinated hydrocarbons,
acids, causcs, ketones and acetates.
Temperature range +4°C to +104°C (+40°F to +220°F)
Suggested Lubricants
Brand Above 27 Deg C ( From 5 Deg C to 27 Deg C Below 5 Deg C
Shell Toona R 72 Toona R 41 Toona R 27
Mobil Almo 529 Almo 527 Almo 525
Esso -- -- -- Arox EP 65 Arox EP 45
Caltex Rando Oil 150 Rando Oil 100 Rando Oil 46
Texaco Regal Oil F Regal Oil PE Regal Oil B
Daltron Silkolene 881 Silkolene 548 Silkolene 773
Burmah Castrol RD Oil 3 RD Oil Light Megna SPX
BP RD 220 HP60C RD150 HP20C RD80 HP10C
Duckham Garnet 7 Garnet 6 Zero Flo 5
Sternol Merlin 87 Merlin 71 Merlin 54
Petrona Purifoc 53 Purifoc 46 Purifoc 32
Chevron Vistac Oil 18X Vistac Oil 19X Vistac Oil 9X
Suggested site selection and installation recommendations
Figure 1

FF-MM-360-REV - 02
Page 6
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Location selection
Pump location must be easily accessible with reasonable
space around for maintenance operations.
Pump dimensional data for each variant is available in
section showing exploded views
Air supply
Compressed air at 90 PSI ( Stroke pumps can take a max
of 100PSI), free from moisture and having an oil mist is
essential. Use of a lter (50 microns), a lubricator and a
regulator is highly recommended and should be installed
as close as possible to the pump inlet.
Ensure correct grade of oil is used in thelubricator bowl.
Too thick oil may slow down the valve shiing mecha-
nism and aect pump performance. See suggested lubri-
cants on page no 5.
Piping
A minimum number of bends and ttings to be used.
A exible connection between suction, delivery and air
supply piping is highly recommended such that piping
stresses and loads do not transfer to pump housing.
Select piping materials such that chemical compatibility is
maintained with the uid being pumped.
Suction
Ensure that the suction head aer installation is well
within the pumps suction capabilities

Use of supplied muer is recommended to bring pump
operation sounds down to comfortable levels, in case of
hazardous uids handling, please read section of safety
regarding piping away of exhaust see
Warning: Pump Exhaust) earlier in this manual.

FF-MM-360-REV - 02
Page 7
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Troubleshooting
Serial No Description Causes Remedial Action
1 Pump stops and
will not start
Insucient Air Pressure Check air pressure is as recommended
at the pump air inlet
Air Filter Blocked Check if debris has clogged the inlet l-
ter on the FRL unit/pump inlet air valve
( some models have air lter on the air
inlet valve ) and ensure clear passage of
air
Internal damage or excessive wear
on components
roceed to dismantle the pump, examine
component for wear, replace any worn
components, re assemble carefully as
instructed in this manual and re start
the pump.
2 Pumps runs slowly,
poor delivery
Cavitation Check if cavitation is occurring in the
suction side, if so reduce suction vacu-
um by slowing down the pump.
Worn Balls and Seats Check proper sealing action of balls
against seals, these components need to
be replaced as a set if they are worn.
Insucient or wrong lubricant in
the air supply.
Ensure that the lubricant is as per the
recommended chart, a thicker lubricant
oen makes the air valve work sluggish-
ly
Internal damage or excessive wear
on components
Proceed to dismantle the pump, exam-
ine component for wear, replace any
worn components, re assemble carefully
as instructed in this manual and re start
the pump.
3 Pump air valve
frerzes
Excessive moisture in supply air
line.
Ensure that the dew point of the
supplied air is low enough. Install a
air dryer or moisture separator on the
supply line
4 Air bubbles in
pump discharge or
product sprays out
of exhaust vent
Broken Diaphragm
Proceed to dismantle the pump,
examine component for wear, replace
any worn components, re assembly care-
fully as instructed in this manual and re
start the pump
mproper seal between inner
pistons, outer pistons and sha.
Air leakage into product from
balls / seats area
Air sucked into suction pipeline
due to insuciently tight joints on
suction pipeline.

FF-MM-360-REV - 02
Page 8
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY Repair kit-
1769701
A.V replacement kit-
1769702
1 176 08 01 Sha Housing With Bush 1
2 178 08 02 Outer chamber 2
3 176 08 03 Inlet 1
4 176 08 04 Outlet 1
5 176 08 05 Air valve Body 1 1 1
6 176 36 02 PTFE Diaphragm 2 2
7 176 08 06 Spool 1 1 1
8 176 08 07 End cap for Air valve 1 1 1
9 176 08 08 Sleeve for secondary sha 5
10 176 08 09 Cover for sha 2
11 176 08 10 Outer Flange 2
12 176 36 01 Ball 4 4
13 176 08 11 Ball seat 4 4
14 176 08 12 Ball cage 4 4
15 176 21 01 Primary Sha 1
16 176 21 02 Secondary Sha 1
17 176 40 01 Gasket for Blocking Pad 1 1 1
18 176 40 02 Back up Diaphragm 2 2
19 176 40 03 Seal for secondary sha 6 6
20 176 40 04 Seal for primary sha 2 2
21 176 40 05 O ring for Spool (Big) 1 1 1
22 176 40 06 O Ring for End cap 1 1 1
23 176 40 08 O ring 4 4
24 176 09 01 Ceramic Pad 1 1
25 176 09 02 Shiing pad 1 1
26 176 82 01 Inner Flange 2
27 176 90 01 Dome Bolt 4
28 176 40 07 O ring for Spool (Small) 1 1 1
29 176 90 02 Dome Bolt 4
30 176 90 03 Allen bolt 16
31 176 90 04 Plain Washer 16
32 176 90 05 Collar Nut 24
33 176 40 09 O ring 4
34 176 90 07 Self tapping screw 4
35 176 90 08 Allen Bolt 4
36 176 27 02 Pin for End cap 1 1
37 176 25 01 Silencer 1
38 176 50 02 PU Tube St, Fitting 3/8" - 8mm 1 1
39 176 90 09 Plain Washer 4
Bill of Materials for ADPB15PPT Pumps

FF-MM-360-REV - 02
Page 9
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Exploded View for ADPB15PPT Pump
1
27
29
32
33
13
14
23
12
4
3
30
31
6
9
10
11
15
16
18
19
20
26
34
32
1
35
37
38
17
39
5
7
8
22
24
25
36
28
21

FF-MM-360-REV - 02
Page 10
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Dimensional Data
ADPB15PPT

FF-MM-360-REV - 02
Page 11
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
EU DECLARATION OF CONFORMITY
We hereby certify that the Listed Product stipulated below comply with all relevant provisions of the machinery direc-
tive (2006/42/EC) and the national laws and regulations adopting this directive.
Description : AIR OPERATED DOUBLE DIAPHRAGM PUMP
Model Number : ADPB 15 PPT
Date :
Serial No :
Is in conformity with the provisions of the following European Directives: (2006/42/EC) Machinery Safety and Har-
monized standards
ISO 12100-1: 2010: Safety of Machinery –general Principles for Design –Risk Assessment and Risk Reduction.
Registered Oce : 416 Gundecha Industrial Complex, Akuril Road,
Kandivali East, Mumbai – 400101, Maharashtra, India.
Web site : www.teryair.com
Works : A-1, Tirupati Udyog Nagar, Sativali Road, Vasai East,
Palghar – 401208, Maharashtra, India.
CE certication registration no – C E 16831
Issued by – BMQR Certications Pvt Ltd.
www.cemarking-india.com
Valid Till – 03/11/2025
Signed for and on behalf of
TERYAIR EQUIPMENT PVT. LTD. Place of Issue : Vasai
Date :

FF-MM-360-REV - 02
Page 12
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
Warranty Certicate
Every product manufactured by Teryair
is built to meet the highest standards of quality.
Teryair warrants that the Products, accessories and parts manufactured or supplied by the company be
free from defects in material and workmanship for a period of six months from date of Teryair authorized
dealer invoice to customer, or one year from date of Teryair invoice to dealer, whichever is earlier. Failure
due to normal wear, misapplication, or abuse is, of course, excluded from this warranty.
Since the use of Teryair products and parts is beyond our control, Teryair cannot guarantee the suitability
of any product or part for a particular application and Teryair shall not be liable for any consequential dam-
age or expense arising from the use or misuse of its products on any application. Teryair does not war-
ranty bought out products or components such as electric motors and hardware but will assist in directing
warranty queries to the dealer/manufacturer responsible. Teryair responsibility is limited solely to replace-
ment or repair of defective Teryair products or components.
Dealer/End User shall have no right or remedy and Teryair shall have no liability or obligation under the warranty, if: (i) a Product is altered,
changed, modied or tampered with in any way, (ii) a Product is damaged after deposit with the transporter for shipment; (iii) a Product is not
properly preserved, packaged, stored, processed or handled after receipt; (iv) a Product is not used and maintained in accordance with Teryair’s
recommended operating and maintenance manuals, instructions and procedures, if any; (v) a Product is not properly incorporated or installed in,
or not properly combined with, an Other Product; (vi) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results
from or arises out of, a failure, substandard performance or other issue with another product, material, component or part not supplied by Teryair;
(vii) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results from or arises out of, compliance with any de-
sign, specication or other specic requirement of Dealer/End User; (viii) a Product is used in a manner, with a substance or for a purpose other
than the normal manner, substance and purpose for which it is intended or is otherwise subjected to abnormal use or service; (ix) a Product is
subjected to a power surge, brown out or other similar occurrence; (x) the issue with a Product is directly or indirectly attributable to, or directly or
indirectly results from or arises out of, normal wear and tear of such Product (including, without limitation, things such as worn seals, diaphragms,
balls, O rings, gaskets, chisels, cutters, hoses and other such wearing components; (xi) the issue with a Product is directly or indirectly.
Model Number : ADPB 15 PPT
Serial Numbar :
Dated : Ajay Bhagat, Q.A. Manager
(Company Seal)

FF-MM-360-REV - 02
Page 13
Operation and Maintenance Guide ADPB 15 Plastic Pump Series
is page is intentionally
Le blank.
