Teufel iTeufel Magnum Manual
Technical description and operating instructions
Table radio with iPod dock and Bluetooth interface
iTeufel® Magnum
2 • iTeufel® Magnum
Contents
General notes and information . . . . . . . . . . . . . . . . . . 3
Safety notes................................4
Caution icons.......................... 4
Safety notes........................... 4
Overview..................................5
Control elements and connections . . . . . . . . . . . . . . . . 6
Setup and connection . . . . . . . . . . . . . . . . . . . . . . . . . 8
Location tips........................... 8
Audio input ........................... 8
Video output jacks . . . . . . . . . . . . . . . . . . . . . . 8
Antenna.............................. 8
Connecting to a power supply . . . . . . . . . . . . . . 8
Remote control..............................9
Changing the batteries . . . . . . . . . . . . . . . . . . . 9
Functionality........................... 9
Basic functions ..............................10
Activating and deactivating . . . . . . . . . . . . . . . . 10
Selecting a source....................... 10
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . 10
Adjusting the subwoofer . . . . . . . . . . . . . . . . . . 10
Mute................................ 10
Clock and alarm.............................11
Setting the time......................... 11
Setting the alarm ....................... 11
Activating and deactivating the alarm . . . . . . . . . 11
Reading the time........................ 11
Sleep function ......................... 11
Radio playback .............................12
Setting the radio stations . . . . . . . . . . . . . . . . . . 12
Mono/Stereo . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Station memory ........................ 12
Saving stations......................... 12
Selecting stations from the memory . . . . . . . . . . . 12
iPod mode .................................13
Inserting an iPod........................ 13
iPod playback ......................... 13
Removing an iPod....................... 13
Bluetooth operation . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Pairing a Bluetooth device . . . . . . . . . . . . . . . . . 14
Playback ............................. 14
Care and cleaning ...........................15
Troubleshooting .............................15
Reset................................ 15
Protecting the environment . . . . . . . . . . . . . . . . . . . . . 16
Batteries and rechargeable batteries. . . . . . . . . . 16
Disposing of the unit . . . . . . . . . . . . . . . . . . . . . 16
Technical data ..............................16
• iTeufel® Magnum 3
Notice
The information in this document may be changed with-
out
prior notice and in no way constitutes any liability on
the part of Lautsprecher Teufel GmbH.
No part of these instructions may be reproduced in any
form or be broadcasted in any way electronically, me-
chanically, by photocopy or recording without the written
permission of Lautsprecher Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 1.1
Dezember 2011
Original packaging
If you wish to exercise your eight-week right of return, we
ask that you be absolutely sure to hold onto the packag-
ing. We can only accept the return of the device IN
THE ORIGINAL PACKAGING.
Empty boxes are not available!
Complaints
In case of complaint we will need the following informa-
tion to process your enquiry:
1. Invoice number
Can be found on the sales slip (enclosed with the
product) or on the order confirmation received as a PDF
document, e.g. 4322543
2. Serial number and batch number respectively
Located on the back side of the device,
e.g. MO 04007480121A
Many thanks for your support!
Contact
For questions, suggestions or any other issues please
contact our customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen
Buelowstrasse 66
10783 Berlin (Germany)
Phone: 00800 - 200 300 400 (free of charge)
Fax: +49 (0)30 - 300 930 930
E-Mail: service@teufelaudio.com
www.teufelaudio.com
Proper use
Only use the unit as specified in these instructions. Any
other use will be deemed as not in accordance with the
instructions and may lead to damage to property or even
injury to persons.
The manufacturer accepts no liability for damage of the
device caused by use not in accordance with the instruc-
tions.
The unit is intended for private use.
Before operating the unit please
read the safety notes and operating instructions
carefully. This is the only way to use all functions
safely and reliably.
Keep the operating instructions safe and pass them on to
anyone who may own the unit after you.
General notes and information
4 • iTeufel® Magnum
Safety notes
Caution icons
You will find the following caution icons in these instruc-
tions:
Danger High risk!
Failure to observe the warning may result in
severe personal injury or death.
Attention Moderate risk!
Failure to observe the warning may result in
property damage.
Minor risk!
Points which should be observed when han-
dling the unit.
Safety notes
Danger Risk of electric shock!
Faulty installation of electrical equipment or
mains voltage which is too high can cause
electric shocks
.
• The device is only suitable for use with a power supply
voltage of 220–240 V~/50 Hz.
• If the unit’s case or mains cable is defective or shows
other signs of visible damage, disconnect the mains
adapter immediately from the socket and do not oper-
ate the device.
• If the unit emits smoke or smells of burning or other
unusual odours, disconnect it immediately from the
power supply and do not operate it.
• The standby button does not disconnect the unit from
the mains supply. For this reason, connect it to an eas-
ily accessible socket so that you are able to quickly dis-
connect it from the mains supply in the event of faults.
• Never open the unit case.
Repairs may only be carried out by an authorised
specialist workshop. Only use parts which conform
to the original unit specifications. There are electrical
and mechanical parts in this unit which are essential in
order to avoid exposure to sources of danger.
• Do not insert any object through the vent slots in the
case.
• Only use the unit in indoor areas.
• Do not operate the unit in moist areas and protect it
from drops of water or splash water.
Also take care not to place vases or other containers of
liquid on or near the unit in order to avoid liquid get-
ting
into the case. If water or other foreign
objects should
enter the case, immediately disconnect the mains plug
and remove any batteries. Send the unit to
our service address.
• Never touch the mains adapter with wet hands.
• Check the unit regularly for damage.
Danger Danger to children!
Children can become trapped in the packing
film when playing and suffocate.
• Do not allow children to play with the unit or the pack-
ing film. Danger of suffocation.
• Ensure that children do not remove small parts from
the unit or take them off of the unit (e.g. the remote
control batteries, control buttons or plug adapters).They
could swallow the parts and choke.
If, however, a battery is ingested, seek immediate
medical attention with the child.
• Never allow children to operate electrical devices
unsupervised.
Danger Danger to hearing!
Loud noise may lead to hearing loss.
There is a potential risk of sudden very high
noise pressure especially when activating the device
which is set to full volume. Besides physical injury this
may also have psychological consequences. Children
and pets are particularly at risk.
• Set your signal source unit volume control to a low
setting.
• When the volume is set high, always keep a certain
distance from the unit and never place your ear directly
on the speaker.
• To avoid damage to health, avoid extended listening at
high volume.
Danger Danger of chemical burns!
Leaking battery acid may lead to chemical
burns.
• Do not allow battery acid to come into contact with
skin, eyes or mucus membranes. In case of contact
with acid rinse the affected location immediately with
plenty of plain water and if necessary see a doctor.
Danger Danger of explosion!
Lithium batteries can explode if handled im-
properly.
• Never attempt to recharge lithium batteries.
• Only use batteries of the same or equivalent type.
• Do not heat or short circuit batteries or rechargeable
batteries and do not dispose them in fire.
Do not expose the batteries and rechargeable batteries
to direct sunlight.
• iTeufel® Magnum 5
Danger Danger of injury/damage!
Incorrect location may result in damage.
• Never use the unit unmounted in vehicles, in unstable
locations, on wobbly tripods or furniture, on under-
dimensioned brackets etc. The device could tip or fall
down and cause injury to persons or be damaged
itself.
• Arrange the device so that it cannot be knocked over
accidentally and make sure that the cables do not pose
a trip hazard.
• Handle the speaker (subwoofer) on the bottom of the
device with care – do not place the device on objects
that could damage the speaker.
• Do not place the unit near sources of heat (e.g. heaters,
ovens, other heat generating equipment such as ampli-
fiers etc.)
Attention Fire hazard!
Improper use may lead to damage or fire.
• Do not place open flames such as burning candles or
similar on or near the unit.
• Ensure sufficient ventilation.
• Do not place the unit in direct sunlight.
• Do not cover the ventilation slots with curtains, blankets,
newspapers or similar. Heat build-up inside the unit can
shorten the lifetime of the unit.
Attention Risk of damage!
Power overload due to lightning strike may
damage or destroy the unit.
• If the unit is to be left unsupervised for a long period
(e.g. during a holiday), or if a thunderstorm is forecast,
disconnect it from the mains power supply.
• Leaked batteries may damage the remote control.
• In case of prolonged absence, remove the batteries
from the remote control.
Product contents
a 1 x table radio
b 1 x remote control
c 1 x power cord
d 1 x FM throw-out aerial
e 4 x Dock adapter
Overview
a
Check to be sure
• Check that all items have been delivered and that noth-
ing is damaged.
• If the delivery is incomplete or you find damage sus-
tained in transit, do not operate the unit but contact our
service department (see page 3).
b
c
d
e
6 • iTeufel® Magnum
Control elements and connections
Front and top side
Back side
Pos Name Description
1 – Display panel
2 – iPod Dock
3 Mode Switch audio source
4 Time Set the time/alarm
5 + Increase the volume
6 – Reduce the volume
Pos Name Description
7Turn the unit on or to standby
8Next track or fast forward
9Restart track/previous track and
fast rewind respectively
10 Mem Save radio stations
11 Preset Access saved stations
Pos Name Description
12 Line In Input jack for connecting an
audio source
13 Video Audio output jack for connecting
to a television set (FBAS)
14 – Connector jack for power cord
Pos Name Description
15 S-Video Output jack for connecting to a
television set (S-Video)
16 FM Ant. Antenna connection
12 13 14
16
15
1
2
4
57 6
3
89
10
11
• iTeufel® Magnum 7
Pos Name Description
17 Line In Audio source: External
18 + Vol Increase the volume
19 + Sub Increase the subwoofer volume
20 – Vol Reduce the volume
21 – Sub Decrease the subwoofer volume
22 Audio source: Bluetooth
23 BT pairing Register Bluetooth device
24 Next track and fast forward
respectively
25 Sleep Sleep function
26 Alarm Turn alarm on/off
27 Set Set time and alarm time
28 Enter Confirm entry
29 Restart track/previous track and
fast rewind respectively
30 Playback/pause
31 Navigation buttons
32 Memo Save radio stations
33 Mute
34 Radio stereo/mono playback
35 iPod Audio source: iPod dock
36 Tuner Audio source: Radio
37 Switch device on or to standby
Remote control
30
29
28
27 26
25
24
23
22
21
20
19
18
17
31
33
34
35
36
37
32
8 • iTeufel® Magnum
Setup and connection
Location tips
• Select a stable, level base.
• Make sure that the environment is clean and free from
dust.
• Avoid placing the unit close to sources of heat or in
direct sunlight.
• Arrange the connector cables so that they do not pose
a trip hazard.
• Do not place any heavy objects on top of the cables or
the unit.
Audio input
You can also connect almost any audio source to the mini
jack plug socket 12 “Line In” on the back of the device
such as computers, MP3 players, video game systems,
televisions etc. The source device only needs an output
with line level. These outputs are configured as stereo
RCA jacks or as 3.5 mm jack plugs. With a correspond-
ing connector cable, you can connect these devices to
the jack 12 “Line In”. You can purchase these cables in
our webshop (www.teufelaudio.com) in the “Accessories”
area.
Video output jacks
Some iPod models (e.g. iPod Touch) are also capable of
video playback and send the signal via the dock connec-
tor jack.
With the iTeufel® Magnum, this signal is still available
as always from the connector jacks 13 “Video” and 15
“S-Video”. You can connect a television via an RCA or
s-video cable in order to view images and movies from
the iPod on a large screen. Audio playback is emitted
from the iTeufel® Magnum.
Antenna
Danger Risk associated with lightning strike!
If you are using outdoor or roof antennas, be
absolutely sure that the antenna has lightning
protection.
Connect the antenna for receiving FM/USW stations
to the jack 16 “FM Ant.” in order to receive FM/USW
stations. This can be a roof/outdoor antenna or a cable
television connection. You will need a coaxial cable for
this.
If an antenna connection is not available at your setup
location, you can use the enclosed throw-out aerial d.
Unwind the throw-out aerial, insert the plug into the jack
16 “FM Ant.” jack and adjust the position of the throw-out
aerial until you have the best possible reception. Then fix
the antenna in place with tape.
Connecting to a power supply
Connect the jack 14 on the back of the device with a
power supply socket via the power cord c.
The Teufel logo on the front of the unit will illuminate in
red.
12 13 14
16
15
• iTeufel® Magnum 9
A 3-volt button cell, type CR2025 is used to power the
remote control.
At delivery, this battery is already in the remote control
and is secured by a plastic strip. The strip is visible on the
back of the remote control. Just pull it out carefully. The
remote control is now ready for use.
Changing the batteries
• Hold the remote control with the bottom facing up.
• Push the bar of the battery compartment towards the
middle (A) and pull out the compartment (B).
• Take out the empty batteries (please observe the notes
on page 16).
• Insert the new battery in the bracket. In the process,
the “+” symbol must be visible on the battery and
bracket.
• Put the bracket back into the unit and push the com-
partment until it locks into place.
Functionality
The remote control transmits infrared control signals.
For this, it is necessary that you point the remote control
towards the iTeufel® Magnum. Ensure that no objects are
in the way of the infrared signal.
Fluorescent lamps and energy-saving lights installed in
the direct vicinity may affect the functions of the remote
control or may even fully impair them.
Remote control
A
B
10 • iTeufel® Magnum
Basic functions
Activating and deactivating
• Push the button 7 or 37 “ ” to switch your iTeufel®
Magnum to operation and standby respectively. In
standby, the “Teufel” logo on the front side of the unit
illuminates in red and in blue in operation mode.
Selecting a source
After activation, the last audio source selected is acti-
vated.
Push the button 3 “Mode” to switch the source or select a
source directly with the buttons
• 36 “Tuner” (radio)
• 35 “iPod” (iPod dock)
• 17 “Line In” (external audio source)
• 22 “ ” (Bluetooth device)
The selected source is shown in the display panel 1.
Adjusting the volume
• To increase the volume:
Push the button 5 “+” or 18 “+ Vol”.
• To decrease the volume:
Push the button 6 “–” or 20 “– Vol”.
The selected volume is shown in the display field 1 in the
range 0 (low) to 40 (high).
Adjusting the subwoofer
The subwoofer is located on the bottom side of the unit
and produces powerful bass tones. You can set the vol-
ume of the subwoofer from –10 to +10 in relation to the
stereo speakers:
• To increase the subwoofer volume:
Push the button 19 “+ Sub”.
• To decrease the subwoofer volume:
Push the button 21 “– Sub”.
Mute
• Turn off the sound with the button 33 “ ”.
The notice “Mute” will appear on the display panel 1
instead of the volume.
• To turn the sound back on: Push the button 33 “ ”
again or change the volume.
7
37
3
36
35
1
17
22
5
18
19
21
6
20
33
• iTeufel® Magnum 11
The integrated clock displays the current time on the
display panel 1. An alarm function and a sleep function
(up to 120 minutes) are available.
Setting the time
• Briefly push the button 27 “Set” once. The notice
“TIME” and the time will appear on the display
panel 1. The hour value will blink.
• Select the hours, minutes and seconds with the naviga-
tion buttons 31 right “ ” and left “ ”.
• Set the numbers with the navigation buttons 31 up “ ”
and down “ ”.
• Push the button 28 “Enter” to confirm the setting.
You have now set the time.
Setting the alarm
You can also set your iTeufel® Magnum to wake you up to
music. To set the alarm time:
• Briefly push the button 27 “Set” twice. The notice
“ALARM” and the alarm time will appear on the dis-
play panel 1. The hour value will blink.
• Select the hours, minutes and seconds with the naviga-
tion buttons 31 right “ ” and left “ ”.
• Set the numbers with the navigation buttons 31 up “ ”
and down “ ”.
• Push the button 28 “Enter” to confirm the setting.
You have now set the alarm time.
Activating and deactivating the alarm
With the button 26 “Alarm”, you can turn the alarm on
and off. When you turn the alarm on, “ALARM ON” will
briefly appear on the display panel; when you turn it off,
“ALARM OFF” will be displayed.
Important!
• Do not use the sources Bluetooth or Line In for the
alarm as these devices may enter into standby, which
the iTeufel® Magnum is not able to control!
• If you select tuner or iPod as an alarm source, the re-
spective device must also be configured for playback,
meaning the station must be set and the iPod must be
inserted. Otherwise, no sound will be played when the
alarm goes off and you will oversleep!
If the alarm has been activated and the device is in
standby, a clock symbol appears on the display panel
between the notice “Time” and the time of day.
Reading the time
To read the time, push any button except for the On/Off
buttons 7 and 37 “ ” respectively. The display panel will
then illuminate for 20 seconds.
Clock and alarm
Sleep function
This function turns off the iTeufel® Magnum after a set
amount of time.
• Start the selected playback.
• Push the button 25 “Sleep”. The notice “SLEEP OFF”
will appear on the display panel 1.
• Pushing the button 25 “Sleep” again sets the time be-
fore turning off in 30 minute increments. The maximum
time is 120 minutes. The setting “SLEEP OFF” deacti-
vates the sleep function.
Important!
If you set the music volume to low when falling
asleep and also have selected music for your
alarm, the volume may be too low!
31
28
26
25
27
12 • iTeufel® Magnum
Radio playback
Select “Radio” as the source (see page 10). The iTeufel®
Magnum is capable of receiving mono and stereo sta-
tions in the range from 87.5 to 108 MHz.
The name of the station is shown on the display panel for
stations with a RDS signal and you can view the radio
text by pushing the button 30 “ ” (not all radio stations
offer this service).
Setting the radio stations
With the buttons 8 “ ” and 9 “ ” and the navigation
buttons 31 up “ ” and down “ ” respectively you can
set the tuning frequency:
• The frequency is increased and reduced respectively
by one increment (0.05 MHz) each time the button is
depressed.
• Holding down the button initiates station scanning until
a station with an adequate signal is located.
Mono/Stereo
Stations with a weak signal may result in poor reception
in stereo mode. With the button 34 “ ”, you can then
switch to mono mode.
Station memory
Your radio can save 20 stations. You can easily select the
stations in the memory later by pushing a button.
Saving stations
• Set the desired station as previously described, then...
On the device:
1. Push the button 10 “Mem”. The memory slot number
will blink on the display panel.
2. With the buttons 8 “ ” and 9 “ ”, select the desired
memory slot number.
3. Push the button 10 “Mem” again. The station has now
been stored.
On the remote control:
1. Push the button 32 “Memo”. The memory slot number
will blink on the display panel.
2. With the navigation buttons 31 right “ ” and left “ ”,
select the desired memory slot number.
3. Push the button 28 “Enter”. The station has now been
stored.
Selecting stations from the memory
• Push the button 11 “Preset” to select the memory slots
“00” to “19” one after another.
• With the navigation buttons 31 right “ ” and left “ ”
you can increase and decrease the memory slot
number.
34
89
10
11
32
28
31
30
• iTeufel® Magnum 13
You can use all current iPod with a dock connector jack
on the iTeufel® Magnum. It is possible that not all func-
tions are available with older devices.
Inserting an iPod
Important!
With the iPod Touch or iPhone,
you will have to launch the appli-
cation “iPod”. It is normally located in the
dock area of the home screen.
• Put a matching iPod adapter e into the dock 2 at the
top of the iTeufel® Magnum. Press the adapter firmly
until it clicks into place.
• Carefully set the iPod on the dock plug 2.
The iTeufel® Magnum will automatically switch to the
source “iPod” and the notice “iPod register” will ap-
pear on the display panel for a moment. Playback is
then initiated and the name of the iPod appears on the
display panel.
The iPod is now ready for use and its rechargeable bat-
tery is being charged by the iTeufel® Magnum.
iPod playback
• Select “IPOD” as the source with the button 3 “Mode”
and 35 “iPod” respectively.
You can now control the iPod directly with the remote
control of the iTeufel® Magnum:
Remote control button Corresponds to the iPod
button
31 MENU
11 Preset, 28 Enter Select
9 , 29
8 , 24
30
31 ▲/▼ Scroll wheel/navigation
• Start and stop playback:
Push the button 30 “ ”.
• Play the next track:
Tip the button 8 “ ” and 24 “ ” respectively.
• Play the previous track:
Tip the button 9 “ ” and 29 “ ” respectively.
• Fast track playback: Hold down the button 8 “ ” and
24 “ ” respectively
or button 9 “ ” and 29 “ ” respectively. Release the
button to continue normal playback.
Removing an iPod
• Stop playback by pushing the button 30 “ ”.
• Carefully take the iPod out of the dock.
iPod mode
31
35
3
11
28
9
29
8
24
30
2
e
14 • iTeufel® Magnum
Bluetooth operation
The Bluetooth transmission technology replaces connector
cables between two devices over short distances (ap-
proximately 10 m) and is most often attributed to head-
sets and hands-free cell phone car kits. With the “A2DP”
specification, it is possible to transfer stereo audio signals
in good quality. Your iTeufel® Magnum can operate as
a receiver for such signals and also control the source in
accordance with the AVRCP specification.
Almost all current cell phones are suitable as a source as
well as other devices (e.g. computer), which function in
accordance with the above specifications (see operating
instructions).
Pairing a Bluetooth device
Before you can establish a connection, both devices must
synchronise with one another – this process is referred
to as pairing. The iTeufel® Magnum can save up to eight
devices, pairing of additional devices will delete the first
ones.
1. Prepare the source device for a Bluetooth connection
(see operating instructions).
2. Push the button 22 “ ” on the iTeufel® Magnum to
select Bluetooth as the source.
3. Push the button 23 “BT pairing”. The notice “PAIRING”
will appear on the display panel and a countdown
from 90 seconds begins – this is the remaining time for
the pairing process.
4. A device called “iTeufel® Magnum” should now ap-
pear on your source device. Select it.
5. You will now be asked for a password – enter “0000”.
The process is now complete and the name of your
source device will appear on the display panel of the
iTeufel®.
6. If necessary, select the iTeufel® as the audio output de-
vice on the source device (see operating instructions).
Playback
• Push the button 22 “ ” on the iTeufel® Magnum to
select Bluetooth as the source.
• Depending on the source device, the following buttons
on the iTeufel® Magnum can control the device:
Button Function
30 Playback, pause
8 , 24 Next track
9 , 29 Restart the current track,
back to the previous
track
Note: The Bluetooth device can not control the volume of
the iTeufel® Magnum.
BLUETOOTH®
9
29
30
8
24
22
23
• iTeufel® Magnum 15
Troubleshooting
The following advice should help you to solve problems. If this doesn’t work, the extensive FAQs on our website will sure-
ly provide you with support. Otherwise, please contact our hotline (see page 3). Take note of the warranty instructions.
Problem Possible cause Solution
The device doesn’t work,
the display is dark.
No power supply. Make sure that the power cord is properly
seated.
Check that the socket is functioning properly
by connecting another device to it.
The speakers produce no
sound.
Wrong source selected. Select the correct audio source.
Volume is set to “0”. Increase the volume.
Poor radio reception. Try to improve the reception by adjusting the direction of the antenna.
Adjust the station for an optimal signal.
iPod does not play. iPod was not inserted properly. Check whether the iPod has been properly
inserted.
iPod malfunction. Take the iPod out of the dock and check
whether the iPod works with headphones.
Consult the iPod instructions on how to reset
the iPod or visit the website www.apple.com.
Remote control doesn’t
work.
No line of sight between the remote con-
trol and the device.
Remove any obstacles.
Remote control not pointed properly. Point the remote control towards the device.
Batteries inserted in the remote control with
incorrect polarity.
Insert the batteries the right way around (see
diagram in the battery compartment).
Batteries in the remote control are empty. Insert new batteries.
Reset
Bluetooth radio interference or an improperly connected
iPod may prevent your iTeufel® Magnum from operating
normally. If your receiver is acting “unusually”, you can
restart the device:
1. If necessary, remove the iPod.
2. Press and hold the button 4 “Time” on the device for
approx. two seconds.
The notice “RESET” will appear on the display panel.
Now numerous parameters are reset to the default set-
tings and your iTeufel® Magnum will function properly
again.
Care and cleaning
Regularly clean your iTeufel® Magnum with a soft, damp
microfiber cloth. In the process, be absolutely sure to
observe the following notes:
Danger Risk of electric shock!
In contact with live parts, water can lead to
electric shock or short circuit.
• Ensure that no liquid penetrates the unit.
• Before cleaning, disconnect the mains adapter.
Attention Risk of damage!
Using the wrong cleaning materials may dam-
age the delicate surface of the case.
• If possible use only plain water without any cleaning
products. In case of stubborn marks, a mild soap solu-
tion may be used.
• In no circumstances should caustic cleaning products,
white spirit, thinners, petrol or similar be used for clean-
ing.
Technical data
Operating voltage: 220–240 V~, 50/60 Hz
Radio reception range: USW (87.5 MHz – 108.0 MHz)
Dimensions (W x H x D): 370 x 190 x 210 mm
Net weight: 5,1 kg
This product conforms to Council of the
European Union guidelines 2004/108/EC
and 2006/95/EC
Technical changes reserved!
Protecting the environment
Batteries and rechargeable batteries
Batteries and rechargeable batteries must
not be disposed of with household waste!
Every consumer is required by law to bring all
batteries and rechargeable batteries, whether
they contain harmful substances*) or not, to a collection
point run by the communal authority or borough or run
commercially, so that they can be disposed of in an envi-
ronmentally friendly manner.
Please only hand in fully discharged batteries!
*) labelled: Cd = cadmium, Hg = mercury, Pb = lead
Disposing of the unit
Used units must not be disposed of with house-
hold waste
If the unit is no longer operational, every
consumer is required by law to dispose of
used devices separate from household waste,
e. g. at a collection point run by the communal author-
ity borough. In this way, used devices can be recycled
and waste materials disposed of in an environmentally
friendly manner.
For this reason, electrical equipment is labelled with the
displayed symbol
Instruction No. 91318_GB / HC-20111205
For questions, suggestions or other issues please contact our customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen - Aufgang D1
10783 Berlin (Germany), Buelowstr. 66
Tel.:
00800 200 300 400 (toll-free)
Fax: +49 (0)30 - 300 930 930
www.teufelaudio.com
No liability is accepted for the
accuracy of this information. Tech-
nical changes, typographical errors
and other errors reserved.
Table of contents
Other Teufel Radio manuals
