Setup Guide
Raumfeld Speaker S
For a detailed online manual, visit
http://manual.raumfeld.com

2

3
Contents
General Notes and Information............ 4
Overview............................................ 5
System Requirements........................... 6
Connections & Operational Controls..... 7
Operation Modes ................................ 8
Installation .......................................... 9
Setup ................................................ 10
Integrating Your Music Collection ....... 13
Frequently Asked Questions............... 14
Advice on Safe Use & Maintenance.... 18
Cleaning & Maintenance.................... 20
Environmental Protection ................... 21
CE Conformity ................................... 22
Contact our customer service for help!
Phone 00800 - 200 300 40 (free of charge)
E-Mail [e-mail]
Please have the following information ready:
• Customer number
• Brand, model, and manual of your router
• LED status of your Raumfeld products
Do you have any questions or problems in
setting up your Raumfeld system?
?

4
Notice
The information in this document may be
changed without prior notice and in no
way constitutes any liability on the part of
Lautsprecher Teufel GmbH.
No part of these instructions may be
reproduced in any form or be broadca-
sted in any way electronically, mechani-
cally, by photocopy or recording without
the written permission of Lautsprecher
Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 2.0
September 2012
Original packaging
If you wish to exercise your eight-week
right of return, we ask that you be absolu-
tely sure to hold onto the packaging. We
can only accept the return of the device
WITH THE ORIGINAL PACKAGING.
Empty boxes are not available!
Complaints
In case of complaint we will need the
following information to process your
enquiry:
1. Invoice Number
Can be found on the sales slip (enclosed
with the product) or on the order confir-
mation received as a PDF document, e.g.
4322543.
2. Serial number or batch number
Visible on the back side of the device, e.g.
serial #: IL30009440122A-123
Many thanks for your support!
Contact
For questions, suggestions or any other
issues please contact our customer service
department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen
Buelowstraße 66
10783 Berlin (Germany)
Tel.: [phone] (free of charge)
Fax: [phone]
www.teufelaudio.com
Proper use
Only use the unit as described in these
instructions and in the online manual. Any
other use will be deemed as not in accor-
dance with the instructions and may lead to
damage to property or even persons. The
manufacturer accepts no liability for damage
caused by use not in accordance with the
instructions. The unit is intended for private
use.
Before operating the unit for
the first time please read the
safety notes and the setup guide
carefully. This is the only way to use all
functions safely and reliably. Keep the
setup guide safe and pass them on to
anyone who may own the unit after you.
General Notes and Information

5
Package Contents
a1 x Active speaker
b1 x Passive speaker
1 x Speaker cable (5m)
1 x Power cable
8 x Speaker feet
• Please check if your shipment is
complete and not damaged.
• Should your shipment be incomplete or
damaged, please contact our service
department before use (see page 4).
Overview
a



b

6
System Requirements
System requirements
• For initial setup and music playback
control: The Raumfeld Controller OR
the Raumfeld Controller App for your
Smartphone or tablet
• For integration into your home network:
Network router with DHCP
• For wireless music playback:
A Raumfeld Base OR Wi-Fi router
(IEEE 802.11g)
• For internet radio or online music
services: Broadband internet connec-
tion
Raumfeld App for your
smart phone
If you would like to set up your system
with your smart phone or tablet, please
first install the Raumfeld Controller App.
You can download a free version for
iPhone, iPod touch, and iPad from the
App Store.
A version for Android™ smart phones
and tablets is also available to you for
free download in the Google Play Store.
Note: In case you have a Wi-Fi router, you do not
need an additional network router. Please make
sure, though, that your Wi-Fi router has DHCP
enabled.
ROUTER
DHCP
RAUMFELD BASE Wi-Fi-ROUTER
RAUMFELD CONTROLLER SMARTPHONE / TABLET
OR
OR
RAUMFELD CONTROLLER APP
IN THE APPLE APP STORE
RAUMFELD CONTROLLER APP
IN THE GOOGLE PLAY STORE

7
Connections and Operational Controls
1 2 3 4
5
6
7
8
9
10
11
12
1
Active Speaker
1 Volume control
2 Power LED
3 System LED
4 On/Off button
5 Reset button
6 Setup button
7 USB port (master, type A)
8 Power cable socket
9 Audio input analogue (RCA)
10 Network connector
11 Clamps for speaker cables
12 Main power switch
Passive Speaker
1 Clamps for speaker cables

8
Operation Modes
Overview
System mode Setting the mode Mode characteristics
On
Briefly press On/Off
button with the main
power switch turned on
Powersave
System reverts automa-
tically to powersave when
inactive
Amplifier off,
CPU throttled
Sleep Mode Briefly press
On/Off button
Amplifier, CPU
and WLAN off
Off Turn main power
switch off All modules off
Status Display
Betriebszustand Power-LED System-LED
Starting Off On
On /
Powersave On On
No Connection to the
Raumfeld System On Flashing
Off /
Sleep Mode Off Off
Setup Flashing Flashing

9
Installation
1. Position the two speakers in your
room and connect them to each other
using the speaker cable provided.
≥ You can choose which of the two
speakers you want to control with the
left stereo signal, and which with the
right, at a later stage.
≥ Please make sure that the colour
coding of the cables match the
connectors on each speaker, as the
wrong polarity will have an adverse
effect on the sound.
≥ Please make sure that there is
room for a sufficient supply of air at
the back of each speaker.
2. Attach the active speaker to the
power supply and turn on the main
power switch on the back of the
active speaker.
3. Briefly press the On/Off button on
the front of the active speaker to start
the device. Continue when the System
LED (right) starts blinking.
Connecting the Raumfeld
Speaker S

10
1. Installing the Raumfeld App
Installation can be carried out using the
Raumfeld Controller and, optionally, a
smart phone or a tablet.
If you would like to set up the Raumfeld
Speaker with your smart phone or tablet,
please first install the Raumfeld Controller
App on your device.
You can download a free version for
iPhone, iPod touch, and iPad from the App
Store.
A version for Android™ smart phones and
tablets is also available for free download
in the Google Play Store.
If you prefer to carry out the setup using
the Raumfeld Controller, this step will not
be necessary.
2. Running the setup wizard
Activate the Raumfeld Controller, OR start
the Raumfeld Controller App on your
smart phone or tablet.
After a few seconds the setup wizard will
start, and will then guide you through the
installation process.
Setup: New Raumfeld System
PRESS BRIEFLY
RAUMFELD CONTROLLER APP
IN THE APPLE APP STORE
RAUMFELD CONTROLLER APP
IN THE GOOGLE PLAY STORE
RAUMFELD CONTROLLER SMARTPHONE / TABLET
OR

11
SMARTPHONE / TABLET
Setup: New Raumfeld System
3. Following the setup wizard
Please follow the wizard steps in order to
set up your Raumfeld Speakers.
In the beginning of the setup wizard you are asked if you own a Raumfeld Base.
Please check carefully if your order contains a „Raumfeld Base“. The Base is an
optional Raumfeld component which is recommended to be used as Wi-Fi access
point in a multiroom setup. You can easily recognize the Base by its two antennas
and three LEDs.
In a system with Raumfeld Base your other Raumfeld devices will be connected to the
Wi-Fi network provided by the Raumfeld Base.
In a system without a Raumfeld Base your Raumfeld devices will be connected to your
own Wi-Fi network.
Do you own a Raumfeld Base?

12
Setup: Extending Your System
Adding to an existing system
Should you wish to add the Raumfeld
Speakers to a system that has already
been set up, follow these instructions:
1. Take the Raumfeld Controller and
switch it on, OR start the Raumfeld
Controller App on your smart phone
or tablet.
2. Go to “Settings > Room
configuration”. Then select “Add
room > Raumfeld Speakers“.
3. Follow the instructions on the display
to connect the speakers to your
Raumfeld system, and to assign a
room name to them.

13
Integrating Your Music Collection
There are several possibilities for you to
integrate your music collection into the
Raumfeld system.
Copying music onto the
Raumfeld Base
If you have a Raumfeld Base, you can
save your music collection on the internal
hard drive of the Base.
When connected with your local network,
the Base appears as a shared folder in
your file management programme:
• In your Windows® Explorer, you
can find the Raumfeld Base under
“Network”,
• and in the Mac OS Finder in the
sidebar under “Shared”.
Simply use your file management
programme to copy music onto the Base.
After your music collection has been
copied onto the Raumfeld Base, it automa-
tically appears under “My music”, without
any further configuration.
Copying music onto a USB
memory
Copy your music collection onto a USB
key or a USB drive, and connect it to the
host of your Raumfeld system. To find out
which device is the host of your Raumfeld
system, go to “Settings > Network > Host
configuration”.
Your music collection appears without
further configuration shortly after you
have plugged the USB memory into the
host of your Raumfeld system.
Sharing music on your
network
Music that has been shared on the
network can easily be integrated into the
Raumfeld system. There are various ways
of sharing music on your network:
• You can share music files that are
saved on a PC via media sharing in
the Windows Media Player. Alter-
natively, you can use another media
server software for your PC.
• If you prefer not to use any media
server software, or have a Mac, you
can share the music file through file
sharing.
• A network storage device allows you
to share music on your network even
while the computer is switched off
(for example NAS or network router
with integrated hard drive / connec-
tion facility for USB memories).
In all cases it is necessary to add the
shared file under “Settings > Music
resources” as a music resource.
For more detailed assistance on sharing
music on your network, please visit
http://manual.raumfeld.com.

14
Frequently Asked Questions
You can find a full list of frequently asked
questions as well as a detailed online
manual online at:
http://manual.raumfeld.com.
General questions
Question 1: Where can I find internet
radio?
≥ TuneIn offers you free access to a wide
range of internet radio stations from all
over the world.
For radio stations which are tailored
specifically to your own taste of music, try
the music service Last.fm (registration is
required but allows you a non-binding test
period and 30 free music titles).
Question 2: Can I try out the music
services Napster and simfy?
≥ The music services Napster and simfy
each offer a 30-day test period of their
premium service, during which you can
listen to all titles available from that
provider in full and for free. The test
period is absolutely non-binding, you do
not enter into any obligation. For simfy,
you need to register to make use of the
test period, while Napster offers an
anonymous test period.
Question 3: What is an active and a
passive speaker?
≥ The active speaker is the one which
contains the amplifiers for both spea-
kers (Master-Box). It also includes the
power connection and Wi-Fi antenna. The
passive speaker (Slave-Box) is connected
to the active speaker via a speaker wire.
Question 4: My Raumfeld Speaker does
not appear under “Line In”. What could
be the reason for this?
≥ Raumfeld playback devices are only
displayed on the Controller or in the
Raumfeld App under the application
“Line In” if they are ready to transmit an
analogue audio signal to other rooms. The
following requirements must be fulfilled:
• The device needs to be set up and
connected to the Raumfeld system
(both LEDs light up).
• The device is being run in “strea-
ming” mode. You can find related
instructions in the online manual.
System requirements
Question 1: What system requirements
need to be in place?
• Your Wi-Fi router must have DHCP
enabled.
• IP-addresses should be distributed to
new devices automatically.
If this is not the case, look into the
administration software of your router
and make sure all Raumfeld devices
are assigned a fixed IP address.
• If you are setting up a system without
the Raumfeld Base (see page 11),
your Raumfeld devices are connected
with your own Wi-Fi network. In
this case, your Wi-Fi router needs to
transmit in the frequency band 2.4
GHz (802.11g) and has to be WPA/
WPA2-encrypted or unencrypted.
• If you are setting up a system with the
Raumfeld Base, make sure that your
router is connected to the network

15
Frequently Asked Questions
socket of the Base on the right, the
one which is labelled “ROUTER”.
Installation using the
Raumfeld App
Question 1: The App does not connect to
the Raumfeld system during setup. What
can I do?
1. First check if all system requirements
are in place.
2. Make sure that the smart phone
or tablet with the App installed is
connected to your Wi-Fi router.
3. After that, remove all Raumfeld
devices from power supply. Delete
the App and reinstall it. Restart your
Wi-Fi router as well by temporarily
disconnecting it from power supply.
4. Then start the setup from the begin-
ning. When being prompted „Do you
own a Raumfeld Base?“, carefully
check if your order contains a Raum-
feld Base (also see page 11) and
choose the appropriate path in the
setup wizard.
5. If the App still fails to connect with
the Raumfeld system, it could be
because of compatibility problems
with your router. You can avoid this
problem if, during installation, you
interpose a standard network switch
(about EUR 10, available at electronic
shops) between your router and the
Raumfeld device you would like to
install first. In this case, please also
inform our customer service.
Question 2: When can I remove the
network cable after setting up the speaker
with the Raumfeld App?
You can remove the network cable as
soon as the setup wizard of the App
has finished, and the home screen is
displayed.
Question 3: The App does not react any
longer. What can I do?
• Devices with Android OS: Go to the
device settings and select the Raum-
feld App under „Apps“. Choose
„Clear data“ and restart the Raum-
feld app subsequently from the
device‘s app menu.
• Devices with iOS: Close the Raum-
feld App. Then, double-push the
Home button of the iOS device. A
bar containing four app symbols
will appear on the bottom of the
screen. Press and hold the Raumfeld
symbol on this bar until a minus sign
appears. Briefly tap the symbol to
clear it from the bar, then restart the
app from the device‘s main menu.
Installation with the
Raumfeld Controller
Question 1: The Controller does not
connect to the Raumfeld system during
setup. What can I do?
1. First check if all system requirements
are in place.
2. Then remove all Raumfeld devices
from power supply. Switch off the
Controller by holding the on/off key
pressed down (at least 10 seconds).
Restart your Wi-Fi router by tempora-
rily disconnecting it from power
supply.

16
Frequently Asked Questions
3. Then start the setup from the begin-
ning. When being prompted „Do you
own a Raumfeld Base?“, carefully
check if your order contains a Raum-
feld Base (also see page 11) and
choose the appropriate path in the
setup wizard.
Question 2: The Controller does not react
any longer. How can I restart it?
≥ When the Controller no longer reacts
to finger touch or turning the volume
control:
1. First switch off the device by pushing
and holding the On/Off button for at
least 10 seconds.
2. Now, briefly press the On/Off
button. After approximately two
seconds the Raumfeld Logo is
displayed and the Controller is
started.
Should the Controller still not react, the
battery may need to be recharged
Resetting
Question 1: Can I reset the system and
start installation from the beginning?
≥ If the Controller or the App are
connected to your Raumfeld system, you
can restart the setup wizard by reset-
ting the „Controller configuration“ under
„Settings > System maintenance > Reset“.
If the Controller or the App are not
connected to the system, a help option
will appear after a short time, offering a
possibility to reset.
Setting up music resources
Question 1: The Raumfeld Base does not
appear under “Network” in the Windows
Explorer. What can I do?
≥ Enter \\Raumfeld Base into the
address line of your Windows Explorer
(not Internet Explorer!).
Should that not work enter the IP address
of the Raumfeld Base into the address bar,
e.g. \\192.168.0.15.
Question 2: The Raumfeld Base does not
appear under “File sharing” in the Mac
OS Finder. What can I do?
≥ Open the menu item “Go > Connect to
server...” in the Finder. Then enter
smb://base.local into the field “Server
address” and confirm the dialog box that
appears afterwards.
Question 3: My USB memory device is
not recognised as a music resource. What
could be the reason for this?
≥ USB memory devices are only included
as a music resource if they are connected
to the host of the Raumfeld system. In
a system with a Raumfeld Base (see
page 11), this is the Base. In a system
without Raumfeld Base, you can specify
the device you would like to act as host
under “Settings > Network > Host confi-
guration”. Please also note that USB hard
drives which are connected to a Raumfeld
playback device need to have their own
power supply. This restriction does not
apply to the Raumfeld Base.
Question 4: Music from my media server
is displayed unreliably and playback

17
Frequently Asked Questions
keeps being interrupted. What can I do?
≥ With certain music servers, compatibi-
lity problems can arise. In order to avoid
such problems quickly, we recommend
you include the content of the media
server via file sharing (see also page
13). In this case, please also inform our
customer service team.
Music playback interruption
Question 1: The music playback keeps
being interrupted. What could be the
reason for this?
≥ If music playback is frequently inter-
rupted, it is mostly due to Wi-Fi connec-
tion problems between your wirelessly
connected playback devices and the
Raumfeld Base, or your Wi-Fi router,
respectively.
You can find instructions on how to
improve the signal strength in the Raum-
feld online manual in chapter “Network
an al ysis”.

18
Advice on Safe Use and Maintenance
Warning icons
The following symbols can be found in this
guide:
Danger High Risk!
Disregard for this warning can
cause life threatening damage.
AttentionMiddle Risk!
Disregard for this warning can
cause damage to the product.
Low Risk!
Procedures that should be
observed while handling the
product.
Advice on Safe Use
Danger Electrical Shock Hazard!
Faulty installation or high voltage
may lead to electrical shock.
• When connecting, ensure that the
voltage is correct. Further information
can be found at the power cable socket
of the active speaker.
• In order to completely remove power
from the device, unplug the power cord.
• In order to be easily able to remove
power from the device, the plug should
be easily accessible.
• Should the device begin to smoke, emit
burning smells, or produce unfamiliar
sounds immediately remove the power
cord and do not turn it back on.
• Do not open the case of the device.
The device may only be serviced by an
authorized party. Unauthorized access
of the device will void the guarantee.
Instructions on how to proceed in case
of repair will be provided by our service
department. Please make sure to use
only replacement components that
comply with the technical specifications
of the original part. This device contains
electrical and mechanical parts that are
essential for the protection of the unit.
• Only use device accessories specified
by the manufacturer.
• Do not insert any objects into the case’s
air vents.
• Only use the product indoors.
• Do not expose the equipment to rain
or humidity of any kind. Do not place
objects filled with liquid, such as vases
or bottles, anywhere near the equip-
ment. Should water or any other foreign
body make its way into the case, imme-
diately remove the power cord. For
further support please contact our
service department.
• Constantly check the device for physical
defects.
Danger Danger of Explosion!
Poor placement of the device can
lead to an explosion.
• Do not use the equipment in extreme
temperatures, or where there is a fire or
explosion hazard.

19
Danger Child Safety!
Children can get caught in the
packaging materials and suffo-
cate.
• Never let your children play with the
device or its packaging material. There
is a risk of suffocation.
• Make sure that your children do not
remove or pull small pieces from the
device (such as cables or buttons), as
they may swallow the piece and choke.
Should your child have swallowed a
small piece of the device, immediately
contact your local hospital.
•Never leave children unattended while
using electronic devices.
AttentionRisk of Damage!
Poor placement can cause
damage to the device.
• Position the device so that it cannot be
accidentally kicked and so that cables
are not trip hazards.
• Avoid using magnetic or paramagnetic
objects nearby the speakers.
• Keep this device away from sources of
heat such as radiators and stoves and
keep it out of the immediate vicinity of
other devices to prevent excessive heat
from developing.
AttentionFire Danger!
Improper use of the device may
cause damage or fire.
• Do not place open flames such as
candles or other similar items on top of
the device.
• Make sure vent holes are not blocked
when positioning the equipment.
• Provide adequate ventilation.
• Do not expose the device to direct
sunlight.
• Do not cover the ventilation openings
with curtains, blankets, magazines or
other similar items. Built up heat within
the device can shorten its lifespan.
AttentionRisk of Damage!
Electrical surges caused by light-
ning can damage or destroy the
device.
• As a precaution, disconnect the equip-
ment from the power supply in the
event of impending thunderstorms.
• Disconnect the equipment from the
power supply if not in use for a
prolonged period of time.
AttentionRisk of Damage!
Improper use of the device can
cause damage.
• Only use a dry, soft cloth when clea-
ning the equipment. Detergents may
affect the surface of the equipment.
Advice on Safe Use and Maintenance

20
Cleaning and Maintenance
• Use as clear of a water as possible
without any cleaning product. By stub-
born spots use a mild combination of
water and soap.
Clean the device regularly with a soft, lightly damp micro fiber cloth.
Pay close attention to the following details:
• Under no circumstances should
harsh cleansers, alcohol, paint
thinner, gasoline, or similar
substances be used for cleaning.
