Teufel BAMSTER PRO Manual

Technical Description and
Operating Instructions
2.0 Bluetooth speaker
BAMSTERPRO

2• BAMSTER PRO
General Notes and Information
Notice
The information in this document may change
without prior notice and in no way constitutes
any liability on the part of Lautsprecher Teufel
GmbH.
No part of these instructions may be repro-
duced in any form or be broadcasted in any
way electronically, mechanically, by photocopy
or recording without the written permission of
Lautsprecher Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 2.1
September 2020
Trademarks
® All trademarks are the property of their
respective owners.
Bluetooth®and the Bluetooth
symbol are trademarks of Blue-
tooth SIG, Inc.
Contents
General Notes and Information. . . . . . . . . . 2
For Your Safety . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Contents. . . . . . . . . . . . . . . . . . . . . . 9
Control Elements and Connections . . . . . 10
Charging the Rechargeable Battery. . . . . 12
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning & Maintenance . . . . . . . . . . . . . . 17
Protecting the Environment . . . . . . . . . . . . 18
Technical Data . . . . . . . . . . . . . . . . . . . . . . . 19
Declaration of Conformity . . . . . . . . . . . . . 20

3• BAMSTER PRO
aptX®and the aptX symbol are
trademarks of CSR plc or affiliated
companies and may be registered
in several countries.
Original packaging
If you wish to exercise your eight-week right of
return, we ask that you be absolutely sure to
hold onto the packaging. We can only accept
the return of the speakers WITH THE ORIGINAL
PACKAGING.
Empty boxes are not available!
Complaints
In case of complaint we will need the following
information to process your enquiry:
1. Invoice number
Can be found on the sales slip (enclosed with
the product) or on the order confirmation re-
ceived as a PDF document, e.g. 4322543
2. Serial number or batch number
Located on the back of the device,
e.g. serial no.: KB20240129A-123.
Thank-you for your support!
Contact
Please contact our customer service with any
questions, suggestions or criticism:
Lautsprecher Teufel GmbH
BIKINI Berlin
Budapester Str. 44
10787 Berlin (Germany)
Phone 00800 - 200 300 40 (toll-free)
Fax: +49 (0)30 / 300 930 930
Service: www.teufelaudio.com/service
Contact: www.teufelaudio.com/contact

4• BAMSTER PRO
For Your Safety
Proper use
The BAMSTER PRO is designed for the play-
back of music and speech from an external
player. The devices can be connected via
Bluetooth or AUX cable
The BAMSTER PRO is protected against
splash water and dust and may be used
outdoors. However, you must protect your
BAMSTER PRO against strong and persistent
rain.
Only use the BAMSTER PRO as described
in this user manual. Any other use will be
deemed as not in accordance with the instruc-
tions and may lead to physical damage or
even injury of persons.
The manufacturer accepts no liability for dam-
age
caused by improper use .
The BAMSTER PRO is only intended for private
use.
Before operating the BAMSTER PRO,
please first read the safety notes and
user manual carefully. Only in this way,
can you ensure that all functions are used in a
safe and reliable manner. Store the user man-
ual in a safe place and also be sure to pass it
on to any subsequent owner.
Definition of terms
You can find the following signal terms in
these instructions:
WARNING
This signal term indicates a moder-
ate risk, which, if not avoided, may
result in death or severe injury.

5• BAMSTER PRO
CAUTION
This signal term indicates a low risk,
which, if not avoided, may result in
minor or moderate injury.
NOTICE
This signal term warns you of poten-
tial damage.
Safety Notes
Read these instructions.
Follow all instructions.
WARNING
Risk of electric shock:
Improper electrical installation or
excessive mains voltage may result
in an electrical shock.
–Only use attachments/accessories
specified by the manufacturer.
–Use only the supplied mains adapt-
er. Make sure that the mains voltage
is correct. More detailed information
is available directly on the mains
adapter.
–Check the mains adapter regularly
for damage. Never use the mains
adapter, if its casing is defective or
exhibits other visible damage.
–Only use the BAMSTER PRO and the
mains adapter in indoor areas, do
not use it in moist areas and pro-
tect it from drops of water or splash
water.

6• BAMSTER PRO
–Never open the unit’s hous-
ing of the mains adapter or the
BAMSTER PRO.
–Unplug this mains adapter during
lightning storms or when unused for
long periods of time.
Risk of explosion:
Batteries (particularly lithium batter-
ies) can explode if used improperly.
–Do not install the BAMSTER PRO
near any heat sources such as
radiators, heat registers, stoves, or
other apparatus (including amplifi-
ers) that produce heat.
Do not expose the BAMSTER PRO to
direct sunlight and do not dispose of
it in a fire.
–Only use the accessories/tools of
outfit (e.g. battery pack) indicated
offering from producer.
–Battery pack shall not be exposed
to excessive heat such as sunshine,
fire or the like.
–No naked flame sources, such as
lighted candles, should be placed on
the apparatus.
–Do not use this BAMSTER PRO near
water.
–If the housing is defective, stop us-
ing the device and store it in an area
that is not accessible for children.
–Refer all servicing to qualified ser-
vice personnel. Servicing is required
when the BAMSTER PRO has been
damaged in any way, such as pow-

7• BAMSTER PRO
er-supply cord or plug is damaged,
liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain,
does not operate normally, or has
been dropped.
–Only use the BAMSTER PRO under
the following conditions:
• Ambient temperature: max. 40 °C
• Maximum height above sea level:
2000 m
Risk of injury:
The BAMSTER PRO permanently
generates magnetic fields that may
interfere with pacemakers and im-
planted defibrillators.
–Make sure that the BAMSTER PRO
and pacemaker/defibrillator are
always at a minimum distance of
10cm apart.
–Please contact your physician if you
have any questions on whether this
might affect the operation of your
implantable medical device.
CAUTION
An unsuitable location could lead to
damage.
–Do not use the BAMSTER PRO in en-
vironments with a risk of explosion.
–Only use Bluetooth in locations
where wireless transmission is per-
mitted.

8• BAMSTER PRO
Extended listening at high vol-
umes may lead to hearing loss.
–To avoid damage to health, avoid
extended listening at high volumes.
–When the volume is set high, always
keep a certain distance from the
device and never place your ear
directly on the speaker.
–If the signal source device is set to
full volume, it may produce very high
sound pressure. This may have psy-
chological consequences and also
cause physical injury. Children and
pets are particularly at risk. Set your
signal source device volume control
to a low setting before turning on the
power.
Explanation of symbols
Safety class II
Dual insulation
May only be used indoors.

9• BAMSTER PRO
Product Contents
1 × BAMSTER PRO
1 × Docking pad with mains adapter
DC 12 V/2 A
• Check that all items have been delivered
and that nothing is damaged. Should the
delivery be incomplete or damaged in any
way, please contact our customer service
department (see “Contact”).
• Do not operate a damaged device.

10 • BAMSTER PRO
Control Elements and
Connections
Control panel:
⑦⑧⑥⑤⑨
②①③④
①Show battery status (see ⑨).
②Activate Bluetooth pairing or disconnect
the Bluetooth connection (press and
hold for 3 s).
③Widening sound on/off.
④In Bluetooth-mode only: Pause ( ) and
play (►).
Answer / end a call.
⑤Volume up (+) / volume down (–).
⑥In Bluetooth-mode only:
Press: next track.
Press and hold: fast forward.
⑦Switch device on/off.
⑧In Bluetooth-mode only:
Press: previous track.
Press and hold: rewind.
⑨LED ring display for volume and charging
(see ①).

11• BAMSTER PRO
Rear side:
⑩⑪
⑩AUX input jack (3.5 mm) for connecting
an external player via an audio cable
with a 3.5 mm jack plug.
⑪USB type B micro jack to charge the
rechargeable battery.

12 • BAMSTER PRO
Charging the Rechargeable
Battery
The rechargeable battery in your
BAMSTER PRO is charged via the docking pad.
Charge it for approx. 4 h before first use.
⑦
1. Plug the power adapter into a power outlet
(100-240 V~, 50/60 Hz).
2. Place the BAMSTER PRO on the docking pad
so that the contact surfaces on the bottom
of the BAMSTER PRO rest on the charging
contacts of the docking pad (see arrows).
During charging, the LEDs in the button
⑦
will pulse in red.
When charging is complete, the LED will go
out when switched off or stay permanently lit
when switched on.
• You can also use the Micro-USB-B socket
⑪
to charge the BAMSTER PRO by connecting it
via a suitable cable to a PC or USB charger.
However, the charging time can be extended.

13• BAMSTER PRO
Operation
Activating/deactivating
• Press the - button ⑦to switch the device
on/off.
• If the BAMSTER PRO has been switched on,
the red LED of the
- button ⑦ will illumi-
nate.
It will turn off when unit shuts down.
Tip: You should always turn off your
BAMSTER PRO when it is not in use to save
battery power.
Automatic deactivation
When the BAMSTER PRO is not in opera-
tion and you do not push any button, the
BAMSTER PRO will switch off after approx.
40minutes.
Volume
By turning the volume control ring ⑤you can
increase or decrease the volume in 24 steps.
The current setting is shown by the LED ring
display ⑨. After 5 seconds, the LED ring dis-
play is turned off.
The volume level of the source device
will also affect the volume of the
BAMSTER PRO.
Widening sound
With the -button ③you can switch widening
sound (Dynamore®) on und off. When on, the
red LED in the button lights up.
Call up the battery charge status
While the BAMSTER PRO is turned on, press
the button ①. The LED ring display ⑨will
light up and display the battery charge status.
To go back to “normal” volume display, press
the button ①again, or wait 5 seconds.

14 • BAMSTER PRO
Bluetooth®pairing
You can connect compatible devices, such as
most smartphones, with your BAMSTER PRO
via Bluetooth®(pairing). The audio output of
your smartphone is then played back by the
BAMSTER PRO.
1. Activate the Bluetooth function of your ex-
ternal player (e.g. smartphone).
2. Push and hold the button ②for approx. 3
seconds.
The red LED of the button ②will now
blink until pairing is complete (no more than
60 seconds).
3. Let your smartphone search for Bluetooth
devices (you can find more information in
the instruction manual of your smartphone).
“Teufel BAMSTER PRO” should also appear
in the list of detected devices following the
scan.
4. Select “Teufel BAMSTER PRO” from the list
of detected devices.
If your external player requires the entry of a
PIN code, enter the PIN code “0000” set by
factory default.
Pairing is now complete and your
BAMSTER PRO is linked to the external
player. The red LED of the button ②is
now continuously illuminated and your
BAMSTER PRO will play back all sounds that
would otherwise be played by your external
player/telephone.
To terminate the Bluetooth connection, hold
the button ②down for approx. 3 seconds.
Restoring the connection with a paired
external player
If your BAMSTER PRO was previously connect-
ed to the external player, it is no longer nec-
essary to switch it to pairing mode to connect
again. Simply selecting it from the list of paired
devices is enough.

15• BAMSTER PRO
NFC
With NFC, you can quickly and comforta-
bly establish a Bluetooth connection be-
tween a compatible external player and the
BAMSTER PRO.
1. Make sure that the NFC function on your
external player has been switched on.
2. Hold your external player close to the
button ④ of the BAMSTER PRO.
A Bluetooth connection will be established
between the two devices after a short time.
Notice: You may be asked to allow the
NFC connection. In this case, confirm the
request on your external player.
Interruption of connection
The Bluetooth connection will be cut if you are
outside of the range of your external player
with your BAMSTER PRO. The connection will
be re-established automatically when you are
back within range.
Receiving a call
If your BAMSTER PRO is connected to your
smartphone via Bluetooth®, you can use the
BAMSTER PRO as a speaker phone.
• With an incoming call, your smartphone as
well as the BAMSTER PRO will ring. Any cur-
rent media playback will be interrupted.
• Press the button ④, in order to answer
the call.
• A built-in microphone above the button④
will allow the conversation to take place
through the BAMSTER PRO.
• Press the button ④again in order to end
the phone call.
Media playback will then be resumed.

16 • BAMSTER PRO
Playback control during Bluetooth
connection.
• Interrupt playback: press the button ④.
• Continue playback: press the button ④
again.
• Play next track: press the button ⑥.
• Play track from the beginning: press the
button ⑧.
• Play previous track: press the button ⑧
quickly two times.
• Track fast forward: press and hold the
button ⑥.
• Track fast reverse: press and hold the
button ⑧.
Connection via AUX
As an alternative to Bluetooth®, you can also
connect your BAMSTER PRO to the headphone
jack of the external player via an AUX cable
with 3.5 mm jack plugs, for example.
Select the cable connection if you do not
wish or are not allowed to use the Bluetooth
function.
Please note:
• With some smartphones, Bluetooth®must
be switched off for transmission via AUX.
• A connection via AUX takes precedence over
Bluetooth®.
• The control buttons “ ”, “ ”, “ ” do not
work with this connection.
• Due to differing output levels from source
devices, the volume may be lower when
using AUX as opposed to Bluetooth®.
• To avoid any possible interference while
using the Line-in / AUX from the comptuer,
use the supplied docking pad or a USB
power supply (not included) to power the
BAMSTER PRO.

17• BAMSTER PRO
Cleaning & Maintenance
NOTICE
Risk of damage: Liquid can de-
stroy the electronics inside your
BAMSTER PRO! Using unsuitable
cleaning agents may damage the
housing.
–Make sure that no liquids penetrate
the device.
–Do not in any case use solvents or
abrasive cleaners.
To clean your BAMSTER PRO
• Turn the BAMSTER PRO off and remove all
cable connections before you start cleaning.
• Ideally, you can remove any dust or light dirt
with a dry microfibre cloth.
• You can wipe off more stubborn dirt with
a cloth which has been slightly dampened
with water. Make sure that no water can
penetrate into the housing case.
• Then immediately wipe the damp surfaces
off with a soft cloth without applying pres-
sure.

18 • BAMSTER PRO
Protecting the Environment
Old devices must not be dis-
posed of with household waste!
If the device is no longer operational,
every consumer is required by law to
dispose of old devices separately from house-
hold waste, e.g. at a collection point run by the
communal authority/borough. This ensures
that old devices are recycled in a professional
manner and also rules out negative conse-
quences for the environment.
For this reason, electrical equipment is
marked with the following symbol.
Batteries and rechargeable
batteries do not belong in the
household waste!
Every consumer is required by law to bring all
batteries and rechargeable batteries, regard-
less whether they contain harmful substanc-
es*) or not, to a collection point run by the
communal authority or borough or to a retailer,
so that they can be disposed of in an environ-
mentally friendly manner.
Please only turn in batteries and rechargeable
batteries which are empty!
*) labelled with: Cd = cadmium, Hg = mercury,
Pb = lead

19• BAMSTER PRO
Technical Data
Bamster Pro
Power supply: DC 12 V / 2 A
Micro USB: DC 5 V / 500 mA
Dimensions (L×W×H): 82 × 204 × 78 mm
Mains adapter
Manufacturer’s
name:
Lautsprecher Teufel
GmbH
Manufacturer’s
address: Budapester Straße 44
D-10787 Berlin
Commercial regis-
tration number: HRB198813B
Model identifier: Golden Profit Electronics
Ltd. GPE024L-120200-2
Input: 100-240 V~, 50/60 Hz
Output: 12.0 V DC / 2.0 A / 24.0W
Average efficiency: 88.0 %
Efficiency at low
load (10 %): 84.0 %
No load power
consumption: 0.04 W
Battery
Li-Ion 7.4 V/2200 mAh
The following radio frequency bands and radio
transmitters are used in this product:
Radio
network
Frequency
bands
in Mhz
Transmitter
power
in mW/dBm
Bluetooth 2400–2483,5 2.5/4
NFC 13.56 –
You can find further technical data on our web-
site . Technical changes reserved!Declaration
of Conformity

Please contact our customer service with any
questions, suggestions or criticism:
Lautsprecher Teufel GmbH
BIKINI Berlin
Budapester Str. 44
10787 Berlin (Germany)
Phone 00800 - 200 300 40 (toll-free)
Fax: +49 (0)30 / 300 930 930
Service: www.teufelaudio.com/service
Contact: www.teufelaudio.com/contact
No responsibility is assumed for the correct-
ness of this information.
Technical changes, typographical errors and
other errors reserved.
Manual No. 93751_GB_20200915
Declaration of Conformity
Lautsprecher Teufel GmbH hereby
declares that this product is in
accordance with the requirements
of directives 2014/30/EU, 2014/35/EU
and 2014/53/EU as long as it is installed
and used according to the manufacturer‘s
instructions. The full text of the EU Declara-
tion of Conformity is available at the following
Internet address:
www.teufelaudio.com/declaration-of-con-
formity.html
