MOTIV® GO VOICE
Technical Description and
User Manual

2• MOTIV® GO VOICE
General Information.............. 3
Contact.............................4
For Your Safety ...................... 5
Proper use ........................ 5
Safety Information............ 6
Package Contents ................ 11
Operational Controls And
Connections.........................12
The Rechargeable Battery....14
Charging the
Rechargeable Battery ......14
Charge Level of Battery ...15
Setup ....................................16
Set-up with the Google Home
App.......................................17
Operation.............................18
Power on and off .............19
Volume ...........................20
Dynamore®.....................20
Playback...........................21
Google Assistant ................. 22
Switching Off the
Microphones .................. 23
Bluetooth®........................... 24
Bluetooth® Settings........ 24
Pairing............................. 24
Terminating the
Bluetooth® Connection.. 25
AUX playback ...................... 26
Connection..................... 26
Playback.......................... 26
Care and Cleaning ............... 27
Troubleshooting.................. 28
Reset to factory
settings........................... 29
Technical Data .....................30
Contents

3• MOTIV® GO VOICE
General Information
Notice
The information in this
document may change without
prior notice and in no way
constitutes any liability on the
part of Lautsprecher Teufel
GmbH.
No part of this user manual
may be reproduced in any form
or be broadcasted in any way
electronically, mechanically,
by photocopy or recording
without the written permission
of Lautsprecher Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 1.2
September 2022
Trademarks
© All trademarks are the
property of their respective
owners.
The Bluetooth®
word mark and Bluetooth®
symbol are registered
trademarks of Bluetooth
SIG, Inc. and any use by
Lautsprecher Teufel GmbH is
licensed.
Google, Google Play, Google
Assistant, Chromecast and
their respective logos are
trademarks of Google LLC.
Data Protection Statement
and Information about
Advertising
Lautsprecher Teufel GmbH
is not affiliated in any way to
the services provided by the
Google Assistant system. We
do not store any personal data
and do not participate in any
advertising mail.

4• MOTIV® GO VOICE
Original Packaging
If you wish to exercise your
right of return, we ask that
you be absolutely sure to hold
onto the packaging. We can
only accept the return of the
speaker WITH THE ORIGINAL
PACKAGING.
Empty boxes are not available!
Complaints
In case of a complaint we will
need the following information
to process your enquiry:
1. Invoice number
The invoice number can
be found on the sales slip
(enclosed with the device)
or on the order confirmation
received as a PDF document.
2. Serial number
The serial number is located on
the bottom of the device.
Contact
Please contact our customer
service department with any
questions, suggestions, or
complaints:
Lautsprecher Teufel GmbH
BIKINI Berlin
Budapester Straße 44
10787 Berlin (Germany)
Telephone (Freephone):
[phone]
Online support:
www.teufelaudio.com/service
Contact form:
www.teufelaudio.com/contact

5• MOTIV® GO VOICE
Proper use
The speaker is designed for
the playback of audio over
the Internet as well as from an
external Bluetooth® or cable
connection player.
Only use the speaker as
described in this user manual.
Any other use will be deemed
as not in accordance with the
instructions and may lead to
damage of property or even
persons.
The manufacturer accepts no
liability for damage caused by
improper use.
The speaker is intended for
private use.
Before operating the
speaker, please read
the safety information
and user manual carefully. Only
in this way, can you ensure that
all functions are used in a safe
and reliable manner. Store the
user manual in a safe place and
also be sure to pass it on to any
subsequent owner.
For Your Safety

6• MOTIV® GO VOICE
Signal terms
You can find the following
signal terms in this user
manual:
WARNING
This signal term indicates a
moderate risk, which, if not
avoided, may result in death or
severe injury.
CAUTION
This signal term indicates a low
risk, which, if not avoided, may
result in minor or moderate
injury.
NOTICE
This signal term warns you of
potential damage.
Safety Information
This chapter contains general
safety information which
you should always observe
to protect yourself and third
parties. Also observe the
warning notes in each chapter
of this user manual.
WARNING
Touching live parts can result
in severe injury or death.
–Make sure that the
correct voltage is present
when you connect the
charger. You can find more
information about this on
the rating plate.
–Never touch the charger
with wet hands.
–Check the device regularly
for damage.
Do not use the device if
its housing is defective
or exhibits other visible
damage.

7• MOTIV® GO VOICE
–This device can only be
completely disconnected
from the mains by pulling
the charger out of the
socket. Please therefore
ensure that the charger is
always easily accessible.
–If the device emits smoke
or smells of burning or
emits unusual sounds,
disconnect it immediately
from the mains and do not
operate it anymore.
–Never open the device
housing.
Repairs may only be carried
out by an authorised
specialist workshop.
Only parts that match the
original specifications may
be used.
–Only use the accessory
products specified by the
manufacturer.
–Never modify the
device. Unauthorised
modifications may
affect the safety and
functionality.
WARNING
An unsuitable setup location
may result in injury and
damage.
–If the speaker is not
securely mounted, do
not use it in vehicles,
in unstable locations,
on wobbly tripods
or furniture, on
underdimensioned
brackets etc. The speaker
may tip or fall over and
cause injury to persons or
be damaged itself.
–Position the speaker
in such a way that it
cannot be knocked over
inadvertently and make
sure that the cables do not
pose a tripping hazard.
–Do not use the device in
environments where there
is a risk of explosion.

8• MOTIV® GO VOICE
–Do not place the device
and charger near heat
sources (e.g. heaters,
ovens, other heat-
generating equipment such
as amplifiers).
–Only use the device
indoors. Do not operate
the device in wet rooms
and protect it from
dripping and splashing
water.
–Only use the Bluetooth®
function in locations where
wireless radio transmission
is allowed.
WARNING
Children can become trapped
in the plastic wrapping when
playing and suffocate.
–Do not allow children to
play with the device or the
plastic wrapping. There is a
danger of suffocation.
–Never allow children
to operate electrical
equipment unsupervised.
WARNING
Lithium rechargeable
batteries can explode if
handled improperly.
–You must not heat or
short circuit rechargeable
batteries or dispose of
them in fire.
–Do not expose the
rechargeable batteries to
direct sunlight.

9• MOTIV® GO VOICE
CAUTION
Extended listening at
high volumes may lead
to hearing loss.
–Avoid extended listening at
high volumes.
–When the volume is set
high, always keep a certain
distance from the device
and never place your ears
directly on the speaker.
–If a speaker is set to
full volume, this may
produce very high
sound pressure. This
may have psychological
consequences and also
cause physical injury.
Children and pets are
particularly at risk. Set
your signal source device
volume control to a low
setting before turning on
the power.
CAUTION
This product contains
magnetic material.
–If necessary, consult
your physician and ask
about effects on implants
such as pacemakers or
defibrillators.
NOTICE
Gross misuse and incorrect
care are the main reasons for
damage to high-performance
rechargeable batteries.
–Avoid deep discharge of
under 10 % for optimal
rechargeable battery
power.
–Store your rechargeable
battery in a cool but frost-
free area, ideally at 15 °C.
Higher temperatures result
in a higher rate of self-
discharge and shorten the
intervals between charges.

10 • MOTIV® GO VOICE
–Do not expose the
rechargeable battery to
direct sunlight or other
sources of heat. This
applies in particular when
charging the rechargeable
battery.
–A deep discharge damages
the rechargeable battery
cells. The most frequent
cause of deep discharge
is prolonged storage or
failure to use a partially
discharged rechargeable
battery. Only store the
rechargeable battery once
it is fully charged.
Old devices must not
be disposed of with
household waste!
If the MOTIV® GO VOICE is
no longer operational, every
consumer is required by law
to dispose of used devices
separately from household
waste, for example, at a
collection point run by the
communal authority. This
ensures that old devices are
recycled in a professional
manner and also rules out
negative consequences for the
environment.
For this reason, electrical
equipment is marked with the
adjacent symbol.

11• MOTIV® GO VOICE
Package Contents
(1) MOTIV® GO VOICE
(2) Charger
• Check that all items have
been delivered and that
nothing is damaged. Do
not use the device if it is
damaged; instead contact
our Customer Service
department (see ‘Contact’
on page 4).
• Please keep the original
packaging for the duration
of the warranty period.
(2)
(1)

12 • MOTIV® GO VOICE
Operational Controls And Connections
(3) (4) (12)(8) (11) (13)
(9) (10)
(6)
(5) (5)(7)
(14)
(15)
(16)
(17)
(18)

13• MOTIV® GO VOICE
(3) Press and hold for
2 seconds in order to
switch the device on or
off;
tap during operation:
display charge level with
LEDs (4)
(4) LED indicator for battery
charging, charge level
(white) and Wi-Fi signal
strength (orange)
(5) Microphones
(6) Tap : Select the
Bluetooth® source;
Push and hold
for 2 seconds: start
Bluetooth® pairing;
press and hold for
10 seconds: Delete
Bluetooth® device list
(7) Bluetooth® LED
(8) Switch Dynamore®
stereo-expanding
technology on/off
(9) Dynamore® indicator
(10) Google button
(11) Reduce the volume
(12) Play/pause
(13) Increase the volume
(14) Reset button
(15) Switch microphones (5)
on/off
(16) Stereo input with a
3.5 mm jack plug socket
(17) Connector for charger
(18) Activity lights:
red = microphones off,
white running light =
processing voice
command,
white = volume indicator

14 • MOTIV® GO VOICE
The Rechargeable Battery
WARNING
Batteries (particularly lithium
batteries) can explode if used
improperly.
–You must not heat or
short circuit rechargeable
batteries or dispose of
them in fire.
–Do not expose the
rechargeable batteries to
direct sunlight.
• Before first use, charge the
rechargeable battery for
approx. 3 to 4 hours.
• Use the enclosed charger (2)
for this.
• The fully charged battery
provides an operating time
of up to 8 hours at medium
volume.
Charging the
Rechargeable Battery
The built-in lithium-ion
rechargeable battery
charges as soon as the
MOTIV® GO VOICE is
connected to the charger (2)
through the connector (17) and
is then supplied with power.
(2)
(3) (4)
(17)

15• MOTIV® GO VOICE
The LED indicator (4) is
illuminated white to show
charging: The upper LEDs
show the current level of
the rechargeable battery by
lighting up in sequence. The
LEDs will be permanently
lit when the battery is fully
charged.
Room temperature is ideal
for charging the battery. In
an excessively cold or hot
environment, the battery
doesn’t reach its full capacity
during charging.
Charge Level of
Battery
You can display the charge level
of the battery by tapping the
button (3) while the device is
in operation:
76–100 % all 4 LEDs are
illuminated
51–75 % 3 LEDs are
illuminated
26–50 % 2 LEDs are
illuminated
11–25 % Bottom LED is
illuminated
<11 % Bottom LED
pulses
To protect the battery,
the MOTIV® GO VOICE
has deep discharge protection,
which switches the device
off once the threshold is
reached. In this case, the
MOTIV® GO VOICE can not be
switched on again.

16 • MOTIV® GO VOICE
Setup
NOTICE
In case of very high volumes
and bass-accented music, the
device may move.
–Make sure that the device
is securely and firmly
positioned. There is no
warranty for damages
caused by falling or
dropping.
Location Tips
• Select a stable level of base.
• Select a location away from
heat sources and direct
sunlight.
• If applicable, lay the
connector cords so that
they do not pose a tripping
hazard.
• Do not place any objects on
the MOTIV® GO VOICE.

17• MOTIV® GO VOICE
Set-up with the Google Home App
To make setting up the
MOTIV® GO VOICE easy, please
download the ‘Google Home
App’ for iOS and Android from
the relevant store onto your
smartphone or tablet.
1. Switch on the Motiv® Go
Voice.
2. Start the Google Home App.
3. Follow the app’s easy
instructions to set up a new
device.
NOTICE
Bluetooth® operation is only
possible after set-up has been
completed.
During setup, you can give the
MOTIV® GO VOICE your own
name. This name is then also
displayed when connecting via
Bluetooth® and in the Spotify
app and the Google Home
app.
Google Home App

18 • MOTIV® GO VOICE
Operation
CAUTION
Extended listening at
high volumes may lead
to hearing loss.
–To avoid damage to health,
avoid extended listening at
high volumes.
–When the volume is set
high, always keep a certain
distance from the device
and never place your ears
directly on the speaker.
–If a speaker is set to full
volume, this may produce
very high sound pressure.
Set your signal source
device volume control to a
low setting before turning
on the power.
NOTICE
If the device is subjected
to warm temperatures
after being cold (e.g. after
transport), condensation may
occur inside of it.
–In this case, wait at least
2 hours before you connect
and activate it.

19• MOTIV® GO VOICE
Power on and off
• To switch the device on, push
and hold the button (3)
for approx. 2 seconds. The
MOTIV® GO VOICE switches
on and searches for Wi-Fi.
The LED indicator (4) shows
an orange running light
during this process. As
soon as a Wi-Fi connection
is established or no known
Wi-Fi network is found, a
signal tone sounds and the
LED indicator (4) briefly
shows the charge level of the
rechargeable battery in white
(see page 15). The LEDs
then show the Wi-Fi signal’s
strength in orange.
(3)
(4)
(11) (13)
After switching on the
MOTIV® GO VOICE selects
the last used source.
• To switch the device
off, push and hold the
button (3) for approx.
2 seconds.
The MOTIV® GO VOICE
switches off and the LED
indicator (4) briefly shows
the charge level of the
rechargeable battery (see
page 15).
Auto standby
When the device is set to
battery mode, it automatically
switches to energy-saving
mode after 5 minutes if there
is no input signal. The energy-
saving mode will end with any
new input signal.

20 • MOTIV® GO VOICE
Volume
The volume setting
of the external player
affects the volume of the
MOTIV® GO VOICE.
• With the buttons (11) and
(13), you can decrease or
increase the volume.
You can gradually adjust the
volume by tapping. Pushing
and holding will change the
volume continuously.
While setting the volume,
the activity lights (18) show
the current volume in
purple.
(8)
(9)
(11) (13)
Dynamore®
Dynamore® technology is
developed by Teufel and
virtually expands the sound
panorama in order to create
impressive, wide-ranging
sound.
Use the button (8) to switch
Dynamore® on or off.
The red LED for the Dynamore®
indicator (9) is illuminated
when Dynamore® is switched
on.
(18)
