Tevion 42623 User manual

4GB MINI MP3 PLAYER
Users Guide
UK/N.IRELAND HELPLINE NO 0844 635 0008
REP. IRELAND HELPLINE NO 1800 995 036
WEB SUPPORT WWW.QUESH.CO.UK
MODEL NUMBER: 42623
AFTER SALES SUPPORT
Now you have purchased a Tevion® product you can rest assured in the
knowledge that as well as your 3 year parts and labour warranty you
have the added peace of mind of dedicated helplines and web support

Contents
02. Welcome Section
03. General Information and Safety Instructions
04. Battery Safety
05. Accessories
06. Features & Functions
07. Getting Started
08. Frequently Asked Questions
09. Warranty Card
10. Fault Report Card
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 1
1

Welcome Section
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623
Congratulations on choosing to buy a Tevion® product. By doing so
you now have the assurance and peace of mind that comes with
purchasing a product made by one of Europe’s leading
manufacturers.
All products brought to you by Tevion® are manufactured to the
highest standards of performance and safety, and, as part of our
philosophy of customer service and satisfaction, are backed by our
comprehensive 3 year warranty.
We hope you enjoy using your purchase for many years to come.
2
2

General Information and Safety Instructions
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623
Please read this User Manual carefully before use.
3
3
1. Never attempt to repair the player yourself. Opening the unit
will invalidate the warranty.
2. To avoid risk of explosion, do not throw the product into fire.
3. Do not immerse into water or allow to become wet.
4. Avoid exposure for prolonged periods to direct sunlight.
5. Charge the battery for 4 hours before first use and ensure the
power switch is set to OFF.
6. The player will start charging immediately it is connected to a
PC.
7. Recharge the battery if the player suddenly ‘powers off’ or the
buttons do not respond.
8. Always switch OFF the player when not in use to preserve the
battery.
9. Discharge completely from time to time to prolong battery life.
10. Do not unplug the USB cable during file download. This may
cause malfunction to your player or PC.
11. Do not attempt to connect earphones or audio cable during file
download.

Battery Safety 4
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 4
Never throw batteries into fire or expose to excessive heat sources. The
rechargeable battery inside this unit cannot be replaced.
Disposal of Your Old Product
Electric and electronic equipment (EEE) contains materials, parts and
substances which can be dangerous to the environment and harmful to
human health. Once this appliance has reached the end of its life span,
the unit in its entirety should be taken to a recycling centre. Please
contact your local authority for details of recycling schemes in your area.
Do not dispose of this product in your household
waste. Please contact your local authority for details
of recycling schemes in your area.

Accessories 5
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623
In ear earphones Around neck earphones
USB cable
5

Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623
Features & Functions 6
6
•4GB Intel® flash memory
•Music playback formats MP3 / WMA
•High speed USB 2.0
•Data storage device
•Built in rechargeable lithium battery
•Up to 8 hours music playback
•3.5mm earphone Jack
•Mini USB Input socket
•Supports Win98 (driver download required), 2K, XP, VISTA, Windows®7
•Handy ‘clip-on’ design
•Dimensions 44 x 12 x 29 (W x D x H)

Features & Functions
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 7
Power ON/OFF Switch
2345
67
9
1. LED charge display
2. ON/OFF switch
3. Previous song
4. Play/pause button
5. Mini USB port
6. Volume +
7. Volume –
8. LED playback display
9. Next song
1
8

Features & Functions
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 8
Button Operation
PLAY:
NEXT SONG:
PREV SONG:
VOLUME +
VOLUME -
Long press powers ON/OFF. Short press while playing
will pause the music.
Long press fast forward. Short press next song and
play
Long press fast reverse. Short press previous song
and play
Long press continuous volume up. Short press
stepped volume up.
Long press continuous volume down. Short press
stepped volume down.
Please note, in order to switch on your MP3 player, slide the power
switch to ON then press and hold the play button for approx 5 seconds
Power ON/OFF
LED Indicators
There are two LED indicators on the player. The top one next to the
ON/OFF switch is the battery indicator, and the green one at the bottom
flickers during music playback and remains lit when music is paused.

Getting Started 7
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 9
Connecting to a PC
1. The power switch can be set to ON or OFF but will only charge
the battery in the OFF position.
2. Connect your MP3 player to your PC using the USB cable
supplied and charge for 4 hours before first use.
3. When you connect the MP3 player to your PC, you will notice a
small icon with a green arrow appear on the bottom right-
hand side of your desktop toolbar. This denotes connection of a
USB device.
4. Double click ‘My Computer’ icon and you will see a ‘Removable
Disk’ in the list of drives on the left-hand side. That is your MP3
player.
5. To ensure safe removal of your MP3 player from your PC. Click
the small icon with the green arrow and single left click the
drive you wish to remove. A dialogue box will appear
confirming it is safe to remove the device.

Getting Started
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623
Adding Music (MP3/WMA) Files to Your Player
The easiest way to put music files onto your player is by ‘Drag and Drop’.
Connect your MP3 player to your PC, then using ‘windows explorer’ or
‘My Computer’ select the music file or folder you which to copy to your
MP3 player by right clicking and holding the mouse button down whilst
dragging the selected file over the ‘Removable Disk’. Release the mouse
button and a small dialogue box will appear, click copy with the left
mouse button, and the file will be copied to your MP3 player.
10
Syncing with Windows Media Player
The most recent edition of Windows Media Player is version 11. To
check what version you are running, open Windows Media Player and
click the ‘Help’ tab and ‘About Windows Media Player’, or ‘Check for
Updates’. After opening Windows Media Player, connect your MP3
player to your PC. You will see a dialogue box asking you to rename
your device. This can be any name of your choice. Follow the ‘on screen’
instructions. Use the Sync tab to select which music files you want to
put on the MP3 player, then click the ‘Start Sync’ button. Once
synchronisation is complete, you will see a note on the right-hand side
of Media Player saying ‘You can now disconnect your player’.

Getting Started
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 11
Once you have set up a device for the first time, you can then configure
Windows Media Player to sync your MP3 player automatically each time
it is connected to your PC. To do this, click the small arrow underneath
the ‘Sync’ tab and select your device. From the sub menu, select ‘Set up
Sync’. Click the box ‘Sync this device automatically. This also gives you
the option to add or remove tracks manually. For further assistance
using Windows Media Player, please refer to the ‘Help’ menu.
Music Playback
1. Short press PLAY to play music and press PLAY again to pause.
Note: The player will auto power off if left on pause for more
than one minute. This is to preserve the battery.
2. Press NEXT or PREVIOUS to play next or previous song.
3. Press VOL+ or VOL- to increase / decrease the volume.
USB Connection
Use the USB cable supplied to connect your MP3 player to your PC. The
power switch should be set to OFF to charge the player. The unit will
start charging automatically.

Frequently Asked Questions 8
Helpline No. UK/N.Ireland: 0844 635 0008 Rep. Ireland: 1800 995 036
Web Support www.quesh.co.uk
Model Number: 42623 12
Why won’t my music play on my MP3 player?
Check that your songs are in the correct format. The player can only
support MP3 and WMA.
My MP3 player keeps automatically switching off?
Ensure the battery has been fully charged. The player will also auto
power off if left on ‘pause’ over one minute.
My PC won’t display the ‘Removable Disk’ drive in My Computer?
Try using other USB ports on your computer, or try using another USB
cable if available. If using windows 98 or ME, you must download the
driver from the website at the bottom of this page.
My player is saying ‘Disk Full’ despite only having a few songs?
You may need to re-format your player. Right click ‘Removable Disk’
(MP3 player), then left click format. Ensure your music files are backed
up before proceeding as this procedure with erase all of the music and
data on your player.
Should you experience any other difficulties, please always
call our customer support team in the first instance as most
issues can be resolved quickly on the telephone.

4GB MINI MP3 PLAYER
W A R R A N T Y C A R D
Congratulations! You have made an excellent choice with the purchase of this quality product. Our
commitment to quality also includes our service. Should you, contrary to expectations, experience
defeats due to manufacturing faults during private use within 36 months of the date of purchase we
shall be liable for warranty in accordance with statutory warranty regulations provided that: -
-the device was not put to any use other than the intended
-was not overloaded
-was not used with the wrong accessories
-repairs were not carried out by any other than the authorised workshop
The warranty certificate is only valid in connection with the receipt. Please keep both in a safe place.
This does not affect your statutory rights.
The purchase is guaranteed for a period of three years beginning on the day of purchase. Keep your
purchase receipt safe as proof of date of purchase. The guarantee can only be extended for the
duration of any repair required.
Should your item become defective during the warranty period, in the first instance, please call our
customer service centre, they will then inform you of what to do next. We will at our discretion, either
repair or exchange the device in accordance with warranty legislation.
Please enclose the following when sending your product in for repair: -
1.Receipt (proof of purchase)
2.This warranty certificate and fault report card complete with your contact details and fault
description.
If the original receipt is not enclosed the repair will be charged in all cases. After the warranty has
expired you can still send defective devices for repairs to the address stated below. Quotes as well as
repairs after the warranty period are to be paid in all cases.
Ensure that the product is well packed as no responsibility can be
accepted for items lost or damaged in transit. This warranty does not
affect your statutory rights.
3
YEAR
WARRANTY

4GB MINI MP3 PLAYER
F A U L T R E P O R T C A R D
Name_____________________________________________
Address___________________________________________
__________________________________________________
Email_____________________________________________
Contact Tel No_____________________________________
Model Number 42623
Fault Description___________________________________
__________________________________________________
SERVICE HELPLINE
UK/N.Ireland 0844 635 0008 – Rep.Ireland 1800 995 036
www.quesh.co.uk
Quesh Ltd, 1 Solway Court, CW1 6LD
