Tevion DIGITAL MINI SATELLITE SYSTEM User manual

After Sales Support
DIGITAL MINI SATELLITE SYSTEM
User’s Guide
AFTER SALES SUPPORT
UK / N.IRELAND HELPLINE NO 01422 263270
REP. IRELAND HELPLINE NO 1890 812 049
Now you have purchased a Tevion® product you can rest assured
in the knowledge that as well as your 3 year parts and labour
warranty you have the added peace of mind of dedicated
helplines.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
2
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Overview of equipment
Front side of the receiver
Rear side of the receiver
Remote control

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 3
Overview of equipment
Front of the receiver
1- Infrared sensor for the signals of the
remote control
2LED PWR ON LED is illuminated if the receiver is
switched on or in standby mode
3LED STBY
ON
LED is only illuminated if the receiver is in
standby mode
4CH+ key Switches to the next higher channel
location
Cursor moves up
5CH- key Switches to the next lower channel
location
Cursor moves down
6Standby Switches on and switches to the standby
mode
Rear of the receiver
1LNB IN LNB connection for the antenna cable
2IF OUT LNB connection for a second satellite
receiver
3VCR (output) SCART connection for the video set
4TV (output) SCART connection for the TV set
5RS 232 Serial port
6DC IN 11-14V Connection 12V/power pack
7COAXIAL Digital coaxial audio output
8AUDIO L Stereo audio connection L(eft)
9AUDIO R Stereo audio connection R(ight)

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
4
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Remote control
1Standby Switches on and to the standby mode
2ZOOM Enlarges TV image
3LIST Invokes TV channel list
4TIMER Invokes timer
5TEXT Invokes Teletext
6MUTE Turns off sound
7M/P Multi-picture function, invokes thumbnail view
8V+ Increases volume/cursor moves to the right
9OK In normal mode: invokes current channel list In a
menu: confirms menu item
10 CH źSwitches to the next lower channel location/cursor
moves down
11 FAV Invokes own favorite list
12 RECALL Switches to previously selected channel
13 PAUSE Stills the frame
14 INFO Displays reception data of the current channel
(satellite-finder function)
15 0–9 Selects channel directly, numerical input
16 P– In normal mode: changes channel group
In TV channel list: Ten-key block commutation
17 P+ In normal mode: changes channel group
In TV channel list: Ten-key block commutation
18 V– Decreases volume/cursor moves to the left
19 CH ŸSwitches to the next higher channel location/cursor
moves up
20 MENU Invokes main menu
21 EXIT Exits menu or menu item
22 AUDIO Changes audio mode
23 EPG Invokes Electronic Programme Guide (if offered by
the broadcasting station)
24 TV/SAT Switches between terrestrial and satellite antenna
25 TV/RADIO Switches between TV and radio mode

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 5
5
Preface
This operating manual will help you in the
xappropriate
xsafe
usage of the digital mini satellite system, hereafter called the
“satellite system” in short.
The satellite system is packed in a soft carry bag and consists of:
xa digital satellite receiver (receiver unit), hereafter called the
receiver in short and
x the antenna unit with installation material.
We assume that users of the satellite system have overall knowledge
regarding handling audio and video equipment.
Every person who
xinstalls,
xconnects,
xoperates,
xcleans
xdisposes of
this satellite system must be familiar with the entire contents of this
operating manual. Always keep this operating manual in the
proximity of the satellite system.
Style features
Specific style features have been given in different sections of the
operating manual. Thus, you can easily differentiate whether it
concerns
normal text,
xenumerations or
Öactions.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
6
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
6
Contents
Overview of equipment ....................................................................2
Remote control .................................................................................4
Preface...............................................................................................5
Style features ....................................................................................5
Contents ............................................................................................6
Safety instructions ........................................................................... 8
Basic safety instructions......................................................... 8
Appropriate use ..............................................................................11
Contents ..........................................................................................13
Description ......................................................................................14
Quick guide .....................................................................................17
Antenna installation .......................................................................18
Installation of the antenna .............................................................18
Installation options.........................................................................21
Receiver connection.......................................................................30
LNB cable installation ....................................................................31
Connection with the Scart cable ...................................................33
Connection with the Cinch cable ..................................................35
Connection of an audio-digital receiver .......................................35
Direction of the antenna.................................................................37
Correct location ..............................................................................37
Rough direction of the antenna ....................................................39
Getting started ................................................................................42
Remote control ...............................................................................42
Receiver...........................................................................................43
Fine tuning of the antenna.............................................................44
Operation.........................................................................................47

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 7
7
Screen-inlays while switching channels......................................47
User interface on the TV screen....................................................49
Menu structure................................................................................49
Menu structure................................................................................50
Menu navigation .............................................................................51
Channel (symbol: TV).....................................................................52
Installation (symbol: Satellite antenna)........................................ 57
System Setup (symbol: gearwheel)..............................................61
Tools (symbol: tools) .....................................................................65
Software update via satellite .........................................................66
Keys with special functions ..........................................................67
Switch between TV and SAT .........................................................67
Switch between TV and radio........................................................67
ZOOM ...............................................................................................67
LIST ..................................................................................................67
AUDIO ..............................................................................................68
EPG ..................................................................................................68
TEXT.................................................................................................68
M/P....................................................................................................69
MUTE................................................................................................69
FAV...................................................................................................69
RECALL ...........................................................................................70
INFO - acoustic signal for directing the satellite antenna..........70
0 – Sleep timer ................................................................................70
PAUSE .............................................................................................70
Dismantling the satellite system...................................................71
Cleaning...........................................................................................72
Maintenance ....................................................................................72
Tips and tricks/Trouble shooting..................................................73
Disposal...........................................................................................76
Specifications .................................................................................77
Declaration of conformity ..............................................................79
Glossary ..........................................................................................80

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
8
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
9
Safety instructions
Please read the safety instructions carefully before operating the
satellite system .
Please follow all warnings and instructions on the equipment and in
the operating manual.
Basic safety instructions
Electrical connection
xDo not expose the receiver to rain or any kind of humidity to avoid
risk of fire and electric shock.
xNever open the casing. Otherwise, there is a risk of electric
shock.
xConnect the receiver only to the power source installed by an
expert. It is either:
-for an external power pack:
a 100–240 V, 50-60 Hz mains socket as per specifications or
- for a 12 V cable:
a 11 V – max. 14 V DC supply as per specifications.
xEnsure that the total power consumption by the antenna
connection of the receiver does not exceed “LNB IN” 300 mA.
xDisconnect the external power pack from the mains socket if you
will not be using the device for a long period of time. Only
disconnect at the external power pack or at the head piece of the
12 V cable, do not pull the cable itself.
xIn case of a storm, disconnect the external power pack (from the
mains socket) or the 12 V cable of the receiver.
x In case of a storm, unscrew the LNB-cable out of the receiver.
xIf foreign bodies or fluids enter the receiver, immediately pull out
the external power pack or the 12V cable out of the socket. Ask a
qualified person to check the equipment before operating it once
again. Otherwise, there is a risk of electric shock.
xDo not bend or crimp any cable.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 9
10
xIf a cable used for the mains supply is damaged, the receiver
must be repaired by an expert before reusing it. Otherwise, there
is a risk of electric shock.
xNever allow children to operate the receiver or to play with the
antenna unit unless supervised.
xAlways ask qualified personnel to carry out repair work.
Otherwise, you are putting yourself and others at risk.
xDisconnect the receiver from the power source in case of
operational disruptions.
xEnsure that the power source is easily accessible.
xModifications to the device will invalidate the waranty
xRemove protective film.
Correct position
xPlace the receiver on a stable and even base.
xUse the receiver only in adequate climatic conditions.
xAvoid proximity to:
-heat sources, like e. g. heaters,
-naked flames, like e. g. candles,
-devices with strong magnetic fields, e.g. loudspeakers.
-Never place receptacles filled with liquid (such as vases) on
the receiver.
xAvoid direct sunlight and places with an extremely high amount of
dust.
xNever cover ventilation slits. Provide for sufficient ventilation by
maintaining a safety distance of 5 cm to other objects.
xDo not place any heavy objects on the receiver.
xHumidity may settle in the receiver if it is brought into hot
surroundings from a cold one. In this case, wait for about an hour
before operating the equipment.
xArrange all cables in such a manner that no-one steps or trips
over them.
xThe antenna unit is not suitable for operating in high wind
pressures. Do not expose it to strong wind.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
10
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
11
Correct battery handling
xBatteries may contain toxic agents. Ensure that batteries are not
within the reach of children. Children may eat and swallow
batteries.
xBatteries that are discharged may damage the remote control. If
the receiver is not in use for a long period of time, remove the
batteries from the remote control.
xBatteries may contain toxic agents. Therefore, dispose of the
batteries immediately in an ecologically acceptable manner
according to the prevailing statutory regulations. Never throw the
batteries into normal household waste.
xNever expose the batteries to open fire or strong heat, as
otherwise there is a danger of explosion.
xReplace the batteries always by batteries of the same type.
Explanation of the safety instructions
The following categories of safety instructions are included in the
operating manual:
Danger!
Instructions with the word DANGER give a warning against
possible personal injuries.
Caution!
Instructions with the word CAUTION give a warning against
possible material or environmental damages.
LThese instructions contain special information for the
commercial use of the satellite system.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 11
12
Appropriate use
The satellite system receives digital satellite channels for private use.
It is exclusively meant for this purpose and must only be used for the
same. This also includes paying attention to all information contained
in these operating instructions, especially the safety instructions.
Due to its user-friendly installation and disassembly, the satellite
system is ideal for mobile use (camping or caravans). As there are
diverse installation options, the system can be used in many places:
xon/at tables
xat masts
xat walls
xon lawns
xon crates
xetc.
LPlease observe all prohibitions or information of the local
administration (if any).
Please observe the following safety instructions for each kind of
installation:
Danger!
Do not expose the satelite system to high loads due to wind
pressures, e.g.
- installation at great heights (balcony railings)
- storm (wind speed > 75 km/h)
In case of non-observance, there is a risk of damage to property
and personal injury.
Wind speed
(km/h) 40 50 60 70 80 90 100 110
Load of the
antenna due to
wind pressure (N)
11.27 17.64 25.48 34.59 45.28 57.23 70.66 85.55

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
12
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
13
Caution!
The maximum bending moment of the satellite system is 15.30 Nm.
Please make sure during installation that the fixation is able to
withstand this pressure.
Do not install the satellite system In places with difficult access.
Mount the satellite system only in places where it will be easily
accessible to you without any danger. Make sure that in case of
need you will always be able to remove the system.
Any other use is considered to be improper and may lead to material
damages and even personal injuries.
Amongst others, information on wind speed is available on the
Internet.
Do not leave the satellite system unattended.
The manufacturer does not bear any liability for damages caused
due to improper use.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 13
14
Contents
ÖCheck the product contents after your purchase.
ÖThe receiver, the remote control, the 2 batteries, the external
power pack and the 12V cable for the cigarette lighter are
included in a box. We recommend packing these pieces again in
the box when dismounting the system.
No. Pieces Description
without
figure
1 Operating manual
11 Transport bag
21 Antenna with base
31 Digital satellite receiver
41 External power pack
52 Battery for the remote control
62 Wing nut for U bracket
72 Plain washer for U bracket
81 Sat beeper
92 Lateral rods
10 1 Single universal LNB
11 1 LNB-bracket
12 1 12V cable for cigarette lighter
13 1 Scart cable
14 2 F connector
15 1 10m coaxial cable (not pre-converted)
16 1 Remote control
17 1 U bracket

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
14
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
15
Description
You can receive uncoded (free-to-air) digital satellite channels with
the satellite system without depending on a fixed mounted satellite
antenna. The mobile antenna allows you to receive signals at
different places, e.g. on a camping site. With the mounting parts, the
antenna can be installed e.g. on a balustrade, a mast or a wall.
Naturally, you can also connect the receiver to a fixed installed
satellite antenna.
It is not necessary to set the receiver yet. The most important
broadcasting stations and satellites have already been preset.
The following satellites have been preset by the factory:
xAstra 19.2E
xHotbird 13.0E
xTürksat 42.0E
xSirius2 5.0E
xAmos/Atlantic4-5W
xAstra 28.2E
xHispaSat 30W
xEutel W3A 7E
xEutel W2 16E
xHellasat 39E
The antenna has to be directed towards the desired satellite.
LPlease note that the reception of the preset satellites
depends on the location. The satellite system has been
designed for mobile use. Therefore not all preset satellites
can be received at all locations due to the size of the
antenna. Please compare the elevation table in the section
"Rough direction of the antenna"on page 39.
The receiver will scan for further new broadcasting stations as soon
as you initiate the automatic scan of broadcasting stations for this
satellite. Satellites not preset may be added.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 15
16
All receiver settings can be easily undertaken using the user
interface (menu) on the TV screen.
The multilingual user interface supports following languages:
xGerman
xItalian
xSpanish
xGreek
xEnglish
xPolish
xCzech
xSlovak
xHungarian
xDanish
xFrench
xSwedish
xCroatian
Further features:
xSoftware update via satellite ASTRA 19° East or via the RS232
connection on the rear side of the device.
xShort switching time, fast boot process when switching on the
receiver
xSaves the channel last watched (Last Station Memory)
xLNB control logic (sound 0/22 kHz), max. current delivery for LNB
300 mA
xSymbol rate 1-35 MS/s and 950-2150 MHz input frequency
xManual PID entry possible
x3 keys on the front panel
x4-digit LED display
xPlug & play
x External power pack 100–240 V, 50/60 Hz, output 12V; 1.0A

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
16
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
17
x4,500 channel-storage locations
xParental lock (preset password: 0000)
x1 favourite list and 8 channel groups
xAutomatic scan of broadcasting stations
xList editor for broadcasting stations
xAnalogue sound output through Cinch connector (stereo), volume
adjustment possible via remote control
xCoaxial digital output (digital audio)
x2 Euro-SCART connections for TV and video set
xVideo output signal CVBS
xLoop-through-function in standby mode for the connection of an
analogue receiver
xSuper fast videotext with a memory of 800 pages
xDigital radio reception, background image for radio (background
display)
xAdditional channel information is displayed when the channel is
changed.
xDiSEqC 1.0, 1.2, Go-to X is supported if an appropriate antenna
unit is connected
xSWAP function (via Recall key)
xScreen aspect ratios can be set to 4:3, 16:9, and automatically
(letterbox)
xMulti-functional timer, 8x and linked with EPG, sleep timer
xElectronic Programme Guide EPG (up to 14 days in advance,
channel-dependent)
xSCPC/MCPC reception standard C/Ku-band satellites
xAutomatic selection of the TV standard with video converter
xZoom function
xMulti-picture function
xDigital satellite finder for optical and acoustic adjustment of the
antenna

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 17
19
Quick guide
You must install, connect and adjust your satellite system in the
following sequence to be able to use it.
ÖInstall the antenna.
ÖConnect the receiver to the equipment.
ÖInstall the LNB cable.
ÖConnect the LNB cable to the antenna.
ÖDirect the antenna roughly.
ÖInsert the batteries in the remote control.
ÖConnect the receiver and the equipment to the power source and
switch them on.
ÖSet the channels using the remote control.
ÖDirect the antenna accurately if the reception quality is not
satisfactory.
ÖIf you would like to make individual settings for the receiver,
invoke the user interface on the TV screen.
ÖMake the desired settings in the menus.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
18
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
20
Antenna installation
The antenna consists of a few individual components and is simple
to install.
ÖTake out the system components from the transport bag.
ÖRemove the packing material.
Installation of the antenna
ÖStep 1: Place the antenna with its base on a suitable surface
and open it in the direction of the arrow until it is in a
vertical position.
ÖStep 2: Now, the antenna is open. For fixing the angle of
inclination of the antenna please tighten both wing nuts
(arrow 1). The adjustment of the angle of inclination is
described in section "Direction of the antenna" on page
37. The horizontal direction (azimuth) by rotating the
antenna will be fixed with the wing nut at arrow 2.
antenna
Base of antenna
1
2

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049 19
21
ÖStep 3: Now take the LNB arm down in direction of the arrow
until it is locked in place.
ÖStep 4a: For installing of the LNB in the LNB bracket untighten
the 2 screws of the LNB bracket and remove the top
half of the LNB bracket. Then insert the LNB as shown
in the picture and fix the top cover again with the screws
and nuts. Tighten the screws uniformly.
L

Picture of the LNB can be similar.
L

For step 4a you will need a crosstip screwdriver (not included
in the contents). Tighten the screws of the LNB bracket only in
such a way that the LNB is fixed. If you tighten them too much,
the LNB bracket could break. Additionally, the LNB could be
deformed or damaged.

Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
20
Helpline No. UK/Northern Ireland 01422 263270 Rep. Ireland 1890 812049
22
ÖStep 4b: Insert the LNB bracket in direction of the arrow as far as
it will go into the LNB arm until the LNB bracket is
locked. While you are doing this, press the clip with the
button for installation slightly down.
ÖStep 5: Now, the antenna is completely installed. Fix the
antenna cable at the LNB. The installation of the
antenna cable is described in the section "LNB cable
installation"on page 31.
LFor dismantling the antenna carry out step 1 - 5 in reverse
order.
Press button
to remove.
