NAVIGATOR NANO TECHNICAL MANUAL
Introduction
Dear Customer,
We would like to thank you for choosing a TEXA product for your
workshop.
We are certain that you will get the greatest satisfaction from it
and receive a great deal of help in your work.
Please read through the instructions in this manual carefully and
keep it for future reference.
Reading and understanding the following manual will help you to
avoid damage or personal injury caused by improper use of the
product to which it refers.
TEXA S.p.A reserves the right to make any changes deemed
necessary to improve the manual for any technical or marketing
requirement; the company may do so at any time without prior
notice.
This product is intended for use by technicians specialized in the
automotivefieldonly.Readingandunderstandingtheinformation
inthismanualcannotreplaceadequatespecializedtraininginthis
field.
The sole purpose of the manual is to illustrate the operation of the
product sold. It is not intended to offer technical training of any
kind and technicians will therefore carry out any interventions
under their own responsibility and will be accountable for any
damage or personal injury caused by negligence, carelessness,
orinexperience,regardlessofthe fact thataTEXAS.p.A.toolhas
been used based on the information within this manual.
Any additions to this manual, useful in describing the new
versions of the program and new functions associated to it, may
be sent to you through our TEXA technical bulletin service.
7
en

This manual should be considered an integral part of the
product to which it refers. In the case it is resold the original
buyer is therefore required to forward the manual to the new
owner.
Reproduction, whole or in part, of this manual in any form
whatsoever without written authorization from the producer is
strictly forbidden.
© copyright and database rights 2011. The material
contained in this document is protected by copyright and
database rights. All rights reserved according to law and
international agreements.
8

ABOUT THE MANUAL
In this document the terms "tool" and "device" refer to the
purchased product, subject of this manual.
Any other specific term is explained in the text.
This manual is divided into the following chapters:
1. Legend of the Symbols: provides the description of the symbols
used in the manual.
2. Glossary: provides the meaning of the technical terms used in the
manual.
3. General Safety Rules: provides important information concerning
the safety of the operator and its workplace.
4. Specific Safety Rules: providesimportant information concerning
the safety of the operator in relation to the use of the product.
5. Environmental information: provides indications related to the
disposal of the purchased tool/device.
6. OperationoftheRadioDevices:providesinformationconcerning
the wireless connectivity of the tool/device.
7. Normative information: reports the declaration of conformity of
the tool/device
8. Description: describes the tool/device, the technical features, the
equipment.
9. Operation: explains all the functions and operation modes of the
tool/device.
10.Maintenance: provides indications on the maintenance of the tool/
device.
11.Solutions to problems: suggests "what to do when... " and gives
information on our client help service.
12.Legal Notes: provides indications related to the guarantee of the
purchased tool/device.
9
en

1 LEGEND OF THE SYMBOLS USED
Thesymbolsusedinthemanualaredescribedinthischapter.
Asphyxiation Risk
Explosion Risk
High Voltage Hazard
Fire / Burn risk
Poisoning Hazard
Corrosive Substances Risk
Noise Hazard
Moving Parts Risk
Crushing Risk
General Risk
Important information
10

2 GLOSSARY
This chapter provides the meaning of the technical terms
used in the manual:
•Diagnosis/diagnostic socket: female connector mounted on the
vehicle that allows the connection with the control unit of the
vehicle.
•OBD socket: diagnosis socket specific for the OBD protocol.
•Diagnosis/diagnostic connector: male connector mounted on
the diagnosis tool or as end part of a cable to be connected to the
diagnosis tool.
•OBD connector: diagnosis connector specific for the OBD
protocol.
•Diagnosis/diagnostic cable: cable that allows connecting the
diagnosis cable to the diagnosis socket.
•OBD cable: diagnosis cable specific for the OBD protocol.
•Display unit: device equipped with a screen (PC, mobile device,
etc.) on which the special software is mounted that allows
communicating with the tool, configuring it, processing and
displaying the data collected by it.
•Device connector: USB connector used to connect to the device.
•Host connector: USB connector used to connect to the display
unit.
11
en

3 GENERAL SAFETY REGULATIONS
3.1 Glossary
•Operator: qualified individual, in charge of using the device/tool.
•Machine/device/tool: the product purchased.
•Workplace: the place where the operator must carry out her/his
work.
3.2 Operator Safety Regulations
3.2.1 General Safety Regulations
•The operator must be completely clear-headed and sober when
using the device; taking drugs or alcohol before or when operating
the device is strictly forbidden.
•The operator must not smoke during device operation.
•The operator must carefully read all the information and
instructions in the technical documents provided with the device.
•The operator must follow all the instructions provided in the
technical documents.
•Theoperatormustalways watch over the device duringthe various
operating phases.
•The operator must make sure she/he is working in environment
which is suitable for the operations that must be carried out.
•The operator must report any faults or potentially hazardous
situation in connection with the workplace or the device.
•The operator must carefully follow the safety regulations required
for the workplace in which she/he is working and required by the
operations she/he has been asked to carry out.
12

3.2.2 Risk of Asphyxiation
Exhaust gas from internal combustion engines,
whethertheymaybepetrolordiesel,arehazardous
to your health and can cause serious harm to your
body.
Safety Precautions:
•The workplace must be equipped with an adeguate ventilation and
air extraction system and must be in compliance with standards
according to current national laws.
•Always activate the air extraction system when working in closed
environments.
3.2.3 Risk of Impact and Crushing
The vehicles which are undergoing A/C system
recharging operations and the devices, must be
properly blocked using the specific mechanical
brakes/blocks, while being service.
Safety Precautions:
•Always make sure that the vehicle is in neutral gear (or that it is set
in parking position in case of a vehicle equipped with automatic
transmission).
•Always activate the hand brake or parking brake on the vehicle.
•Always block the wheels on the vehicle with the specific
mechanical blocks.
•Make sure the device is stable, on a flat surface and the wheels
are locked with the specific brakes.
13
en

3.2.4 Hazards Caused by Moving Parts
Vehicle engines include parts that move, both while
running and not running (eg: the cooling fan is
controlledbyathermalswitchinconnectionwiththe
coolant temperature and become activated even
when the vehicle is off), that can injure the operator.
Safety Precautions:
•Keep hands away from moving parts.
•Disconnect the engine cooling fan each time the engine you are
working on is still hot. This will avoid the fan from becoming
activated unexpectedly even when the engine is off.
•Do not wear ties, loose clothes, wrist jewellery or watches when
working on a vehicle.
•Keepconnection cables, probesand similardevices awayfrom the
moving parts of the engine.
3.2.5 Risk of Burning or Scalding
The parts that are exposed to high temperatures in
engines that are moving or have just stopped could
burn the operator.
Remember that catalytic mufflers reach very high
temperatures, able to cause serious burns or even
start fires.
Acid in the vehicle batteries is another potential
hazard.
Safety Precautions:
•Protect your face, hands, and feet by using suitable protection.
•Avoid contact with hot surfaces, such as spark plugs, exhaust
pipes, radiators and connections within the cooling system.
•Make sure there are no oil stains, rags, paper or other inflammable
material near the muffler.
•Avoid splashing electrolyte on skin, eyes and clothes, as it is a
corrosive and highly toxic compound.
14

3.2.6 Fire and Explosion Hazard
The following are potential fires and/or explosion
hazards:
•The types of fuel used by the vehicle and the vapours
released by these fuels.
•The refrigerants used by the A/C system.
•The acid in the vehicle batteries.
Safety Precautions:
•Let the engine cool.
•Do NOT smoke near the vehicle.
•Do NOT expose the vehicle to open flames.
•Make sure that the electrical connections are all well insulated.
•Collect any fuel that might have spilled.
•Collect any refrigerant that might have spilled.
•Make sure you are always working in an environment equipped with a
good ventilation and air extraction system.
•Always activate the air extraction system when working in closed
environments.
•Cover the openings of the batteries with a wet cloth in order to stifle the
explosive gases before proceeding in testing or recharging.
•Avoid causing sparks when connecting cables to the battery.
15
en

3.2.7 Noise Hazard
Loud noises that may occur within the workplace,
especially during service operations may damage the
operator's hearing.
Safety Precautions:
•Protect your ears with suitable protective ear wear.
3.2.8 High Voltage Hazard
The voltage supply from the mains that powers the
devices in the workplace and the voltage within the
vehicle starter system is a potential shock hazard to the
operator.
Safety Precautions:
•Make sure the electrical system in the workplace is compliant to current
national standards.
•Make sure the device being used is connected to ground.
•Cut off the power supply voltage before connecting or disconnecting
cables.
•Do NOT touch the high voltage cables when the engine is on.
•Operate in conditions of insulation from ground.
•Work with dry hands only.
•Keep conductive liquids away from the engine while working.
•Never leave tools on the battery in order to avoid accidental contacts.
16

3.2.9 Poisoning Hazard
The hoses used to extract the refrigerants can release
toxic gases, dangerous to the operator if exposed to
temperatures higher than 250 °C or in case of a fire.
Safety Precautions:
•Contact a doctor immediately should you inhale these gases.
•Use neoprene or PVC gloves when eliminating combustion deposits.
17
en

3.3 General User and Maintenance Warnings
When using the device or carrying out scheduled maintenance
(eg. fuse replacement) on the device, carefully follow the
information provided below.
•Do not remove or damage the labels/tags and the warnings on the
device; do NOT in any case make them illegible.
•Donotremove,orblock,anysafetydevices thedeviceisequippedwith.
•Only use original spare parts or spare parts approved by the
manufacturer.
•Contact your retailer for any non-scheduled maintenance.
•Periodically check the electrical connections of the device, making sure
they are in good condition and replacing any damaged cables.
•Check parts that are subject to wear periodically and replace if
necessary.
•Do not open or disassemble the device.
18

4 NAVIGATOR NANO USER SAFETY
The technology used for the design and inspection of the
manufacture of the NAVIGATOR NANO diagnostic tools, make
them reliable, simple and safe to use.
Personnel in charge of using the diagnostic tools is required to
follow the general safety regulations and use the NAVIGATOR
NANO devices for their intended use only. Furthermore, they are
requiredtocarryoutthemaintenanceasdescribedinthismanual.
4.1 Glossary
Operator: qualified person responsible for using the diagnosis
tool.
Tool/device: any NAVIGATOR NANO device.
4.2 General Rules
•Theoperatormusthavebasicknowledgeinmechanics,automotive,car
repairs and potential dangers that can occur during the auto-diagnosis
operations.
•The operator must carefully read all the information and instructions in
the technical documents provided with the tool.
19
en

4.3 Operator Safety
Airbags inflate with great force; a tool placed in their
expansion area may be projected towards the
occupants of the vehicle causing serious harm.
Safety Measures:
•DO NOT position the tool in the airbag expansion area.
Some auto-diagnosis operations allow enabling/
disabling certain actuators and safety systems in the
vehicle.
Safety Measures:
•Do not allow unqualified personnel using the tool, in order to avoid
accidents to people or damages to the tool or to electronic systems of
the vehicle to which it is connected.
•Follow the instructions provided by the software closely and carefully.
20
