Texas Instruments bq20z60EVM-001 User manual

User's GuideSLUU354 – June 2009
bq20z60EVM-001 SBS 1.1 Impedance Track™ TechnologyEnabled Battery Management Solution Evaluation Module
This evaluation module (EVM) is a complete evaluation system for the bq20z60/bq29330/bq29412 batterymanagement system. The EVM includes one bq20z60/bq29330/bq29412 circuit module, a current senseresistor, two thermistors, and Windows™-based PC software. The circuit module includes one bq20z60integrated circuit (IC), one bq29330 IC, one bq29412 IC, and all other onboard components necessary tomonitor and predict capacity, perform cell balancing, monitor critical parameters, protect the cells fromovercharge, over discharge, short circuit, and overcurrent in 2-, 3- or 4-series cell Li-ion or Li-polymerbattery packs. The circuit module connects directly across the cells in a battery. With the EV2300 interfaceboard and software, the user can read the bq20z60 data registers, program the chipset for different packconfigurations, log cycling data for further evaluation, and evaluate the overall functionality of thebq20z60/bq29330/bq29412 solution under different charge and discharge conditions.
Contents1 Features ....................................................................................................................... 22 bq20z60/bq29330-Based Circuit Module ................................................................................. 23 bq20z60/bq29330 Circuit Module Schematic ............................................................................ 34 Circuit Module Physical Layouts and Bill of Materials .................................................................. 35 EVM Hardware and Software Setup ...................................................................................... 96 Troubleshooting Unexpected Dialog Boxes .............................................................................. 97 Hardware Connection ....................................................................................................... 98 Operation .................................................................................................................... 119 Calibration Screen.......................................................................................................... 1410 Pro (Advanced) Screen .................................................................................................... 1511 Related Documentation From Texas Instruments ..................................................................... 16
List of Figures
1 Layout (Silk Screen) ......................................................................................................... 42 Top Assembly ................................................................................................................ 43 Top Layer ..................................................................................................................... 44 Bottom Layer ................................................................................................................. 55 Bottom Assembly ............................................................................................................ 56 Schematic ..................................................................................................................... 87 bq20z60bq29330 Circuit Module Connection to Cells and System Load/Charger ................................ 108 SBS Data Screen........................................................................................................... 129 Data Flash Screen, 1st Level Safety Class ............................................................................. 1310 Calibration Screen.......................................................................................................... 1511 Pro (Advanced) Screen .................................................................................................... 16
List of Tables
1 Components and Flash-Memory Settings for Different Precharge Modes ........................................... 32 Bill of Materials ............................................................................................................... 63 Performance Specification Summary ..................................................................................... 94 Circuit Module to EV2300 Connections ................................................................................. 10
Impedance Track is a trademark of Texas Instruments.Windows is a trademark of Microsoft Corporation.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 1Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

1 Features
1.1 Kit Contents
1.2 Ordering Information
2 bq20z60/bq29330-Based Circuit Module
2.1 Circuit Module Connections
2.2 Pin Descriptions
Features www.ti.com
•Complete evaluation system for the bq20z60 SBS 1.1-compliant advanced gas gauge with ImpedanceTrack™ Technology, bq29330 analog front end (AFE) and protection IC, and bq29412 independentovervoltage protection IC•Populated circuit module for quick setup•Software that allows data logging for system analysis
•bq20z60/bq29330/bq29412 circuit module•Set of support documentation
EVM PART NUMBER CHEMISTRY CONFIGURATION CAPACITY
bq20z60EVM-001 Li-ion 2, 3, or 4 cell Any
The bq20z60/bq29330/bq29412-based circuit module is a complete and compact example solution of abq20z60 and bq29330 circuit for battery management and protection of Li-ion or Li-polymer packs. Thecircuit module incorporates a bq20z60 battery monitor IC, bq29330 AFE and protection IC, bq29412independent overvoltage protection IC, and all other components necessary to accurately predict thecapacity of 2-, 3-, or 4-series cells.
Contacts on the circuit module provide the following connections:•Direct connection to the cells: 1N (BAT–), 1P, 2P, 3P, 4P (BAT+)•To the serial communications port (SMBC, SMBD, VSS)•The system load and charger connect across PACK+ and PACK–•To the system-present pin (SYS PRES)
PIN NAME DESCRIPTION1N –ve connection of first (bottom) cell1P +ve connection of first (bottom) cell2P +ve connection of second cell3P +ve connection of third cell4P +ve connection of fourth (top) cellSMBC Serial communication port clockSMBD Serial communication data portSYS PRES System present pin (if low, system is present)PACK– Pack negative terminalVSS Pack negative terminalPACK+ Pack positive terminal
2bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

3 bq20z60/bq29330 Circuit Module Schematic
3.1 Schematic
3.2 Modifications for Choosing Particular Precharge Mode
3.3 Testing Fuse-Blowing Circuit
4 Circuit Module Physical Layouts and Bill of Materials
www.ti.com bq20z60/bq29330 Circuit Module Schematic
This section contains information on the schematic for the bq20z60/bq29330/bq29412 implementation.
The schematic follows the bill of materials in this user's guide.
In order to charge, the charge FET (CHG-FET) must be turned on to create a current path. When theV
(BAT)
is 0 V and CHG-FET = ON, the V
(PACK)
is as low as the battery voltage. In this case, the supplyvoltage for the device is too low to operate. This function has three possible configurations, and thebq29330 can be easily configured according to the application needs. The three modes are 0-V ChargeFET mode, Common FET mode, and Precharge FET mode.1. 0-V Charge FET mode - Dedicates a precharge current path using an additional FET (ZVCHG-FET) tosustain the PACK+ voltage level.2. Common FET mode - Does not use a dedicated precharge FET. The charge FET (CHG-FET) is set toON state as default.3. Precharge FET mode - Dedicates a precharge current path using an additional open-drain (OD) pindrive FET (PCHG-FET) to sustain the PACK+ voltage level.
To use a particular mode of charging with the EVM, add or remove some elements shown in Table 1 , anduse the given settings of DF.Configuration, ZVCHG1, 0.
Table 1. Components and Flash-Memory Settings for Different PrechargeModes
MODE RESISTORS PRECHG FET ZVCHG1 ZVCHG0
1 0-V Chg R18, R23 Q3 0 0(default)
2 Common FET R20 Q2 0 13 Precharge R19, R23 Q3 1 0
For more details about precharge operation and mode choices, see the bq29330 data sheet at(SLUS673 ).
To prevent the loss of board functionality during the fuse-blowing test, the actual chemical fuse is notprovided in the circuit. FET Q1 drives TP3 low if a fuse-blow condition occurs; so, monitoring TP3 can beused to test this condition. Fuse placement on the application board is shown in the bq20z60 data sheetreference-board schematic.
This section contains the board layout, bill of materials, and assembly drawings for the bq20z60/ bq29330/bq29412 circuit module.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 3Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

4.1 Board Layout
Circuit Module Physical Layouts and Bill of Materials www.ti.com
This section shows the dimensions, PCB layers (Figure 1 through Figure 5 ), and assembly drawing for thebq20z60/bq29330 module.
Figure 1. Layout (Silk Screen)
Figure 2. Top Assembly
Figure 3. Top Layer
4bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

www.ti.com Circuit Module Physical Layouts and Bill of Materials
Figure 4. Bottom Layer
Figure 5. Bottom Assembly
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 5Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

4.2 Bill of Materials and Schematic
Circuit Module Physical Layouts and Bill of Materials www.ti.com
Table 2. Bill of MaterialsCount RefDes Value Description Size Part Number MFR
21 C1–C12, C15, 0.1 µF Capacitor, Ceramic, 50V, X7R, 20% 0603 STD AnyC18–C22, C25,C26
1 C13 0.22 µF Capacitor, Ceramic, 50 V, X7R, 20% 0603 STD Any
3 C14, C16, C28 1.0 µF Capacitor, Ceramic, 25 V, X7R, 20% 0805 STD Any
1 C17 47 nF Capacitor, Ceramic, 50 V, X7R, 20% 0603 STD Any
2 C23, C27 0.47 µF Capacitor, Ceramic, 16 V, X7R, 20% 0603 STD Any
1 C24 4.7 µF Capacitor, Ceramic, 10 V, X5R, 10% 0603 STD Any
4 D1–D3, D11 BAS16 Diode, Switching, 150mA, 75V, 350mW SOT23 BAS16 Vishay-Liteon
2 D4, D10 Diode, Dual, Zener, 5.6V, 300mW SOT23 AZ23C5V6 Vishay-Telefunken
5 D5– D9 LN1361C Diode, LED, Green, Gullwing, GW Type, 0.120 ×0.087 inch LN1361C Panasonic20mA, 7.5 mcd typ.
1 J1 22-05-3041 Header, Friction Lock Assy, 4-pin right 0.400 ×0.500 inch 22-05-3041 Molexangle
1 Q1 NDS331N MOSFET, N-Ch, 20V, 1.3A, 210 m ΩSOT23 NDS331N Fairchild
2 Q2, Q4 FDS8817NZ MOSFET, N-Ch 30V, 15A , 7 m ΩSO8 FDS8817NZ Fairchild
1 Q3 FDS4435BZ MOSFET, P-Ch, -30V, -8.8A, 20 m ΩSO8 FDS4435BZ Fairchild
1 Q5 BSS138 MOSFET, N-Ch, 50V, 0.22A, 3.5 ΩSOT23 BSS138 Fairchild
12 R1–R5, R25, R26, 100 Resistor, Chip, 1/16W, 5% 0603 STD AnyR28, R32, R33,R37, R38
2 R13, R24 3.01M Resistor, Chip, 1/16W, 5% 0603 STD Any
1 R14 300 Resistor, Chip, 1W, 5% 2512 STD Any
3 R15, R18, R22 5.1K Resistor, Chip, 1/16W, 5% 0603 STD Any
4 R17, R35, R36, 1M Resistor, Chip, 1/16W, 5% 0603 STD AnyR41
0 R19 5.1K Resistor, Chip, 1/16W, 5% 0603 STD Any
0 R20 100K Resistor, Chip, 1/16W, 5% 0603 STD Any
1 R23 100K Resistor, Chip, 1/16W, 5% 0603 STD Any
1 R21 0.010 75 ppm Resistor, Chip, 1W, 1% 2512 WSL-2512-010 Vishay1% R86
2 R30, R40 8.45K Resistor, Chip, 1/16W, 1% 0603 STD Any
2 R31, R39 61.9K Resistor, Chip, 1/16W, 1% 0603 STD Any
4 R6, R11, R12, 220K Resistor, Chip, 1/16W, 5% 0603 STD AnyR34
7 R7– R10, R16, 1K Resistor, Chip, 1/16W, 5% 0603 STD AnyR27, R29
2 RT1**, RT2** 10K Thermistor, NTC, 3-A 0.095 ×0.150 inch 103AT-2 Semitec
1 SW1 Switch, Push button, Momentary, N.O. Low 5mm ×5mm EVQ-PLHA15 PanasonicProfile
2 TB1, TB4 ED555/3DS Terminal Block, 3-pin, 6-A, 3,5mm 0.41 ×0.25 inch ED555/3DS OST
2 TB2, TB3 ED555/2DS Terminal Block, 2-pin, 6-A, 3,5mm 0.27 ×0.25 inch ED555/2DS OST
1 TP1 GND Test Point, Black, Thru Hole Color Keyed 0.100 ×0.100 inch 5001 Keystone
1 TP2 2.5V Vcc Test Point, Red, Thru Hole Color Keyed 0.100 ×0.100 inch 5000 Keystone
1 TP3 Fuse Test Point, White, Thru Hole Color Keyed 0.100 ×0.100 inch 5002 Keystone
1 U1 bq29412DCT IC, Voltage Protection for 2, 3, 4 SSOP-08 BQ29412DCT TICell Lion , 2nd Protection, 4.45 v OVP
1 U2 bq29330DBT IC, 2-3 or 4 Cell Series Protection TSSOP30 bq29330DBT TIControl AFE
1 U3 bq20z60DBT IC, SBS 1.1-Compliant Gas Gauge TSSOP30 bq20z60DBT TIEnabled With Impedance Track
1 — PCB HPA435 Any
6bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

www.ti.com Circuit Module Physical Layouts and Bill of Materials
Table 2. Bill of Materials (continued)Count RefDes Value Description Size Part Number MFR
Connector
2 J1 mate Connector, Female, 0.100 Centers Molex 22-01-3047
8 N/A Terminals, Crimp, Tin Molex 08-50-0114
N/A Wire, Insulated 24 AWG, Red, 18 Inches ( ±3 Alpha 1854-3inches)(USB_5V)
N/A Wire, Insulated 24 AWG, White, 18 Inches (+/- 3 Alpha 1854-1inches)(SCL)
N/A Wire, Insulated 24 AWG, Black, 18 Inches ( ±3 inches)(GND) Alpha 1854-2
N/A Wire, Insulated 24 AWG, Brown, 18 Inches (+/- 3 inches) Alpha 1854-7(SDA)
1 N/A Heatshrink 1 inch Any Any
Notes: 1. These assemblies are ESD sensitive, ESD precautions shall be observed.
2. These assemblies must be clean and free from flux and all contaminants. Use of no clean flux is not acceptable.
3. These assemblies must comply with workmanship standards IPC-A-610 Class 2.
4. Ref designators marked with an asterisk ('**') cannot be substituted.All other components can be substituted with equivalent MFG's components.
5. Make one SMBus connector wire assembly for each assembly produced, from J1 mate, 4–24 AWG wires and Crimp terminals. Wire colors for Pinnumbers are listed below. The wire assembly shall have a J1 mate on each end.Red – Pin # 4 (Signal USB_5V)Brown – Pin # 3 (Signal SDA)White - Pin # 2 (Signal SCL)Black – Pin # 1 (GND)
6. RT1 and RT2 should be assembled horizontally laying flat against the board Edge.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 7Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

Circuit Module Physical Layouts and Bill of Materials www.ti.com
Figure 6. Schematic
8bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

4.3 bq20z60/bq29330/bq29412 Circuit Module Performance Specification Summary
5 EVM Hardware and Software Setup
5.1 System Requirements
5.2 Software Installation
6 Troubleshooting Unexpected Dialog Boxes
7 Hardware Connection
www.ti.com EVM Hardware and Software Setup
This section summarizes the performance specifications of the bq20z60/ bq29330/bq29412 circuit module.
Table 3. Performance Specification Summary
Specification Min Typ Max Units
Input voltage Pack+ to Pack– 6 15 25 VCharge and discharge current 0 2 7 A
This section describes how to install the bq20z60EVM-001 PC software, and how to connect the differentcomponents of the EVM.
The bq20z60EVSW software requires Windows 2000 or Windows XP.
Find the latest software version in the bq20z60 tool folder on power.ti.com . Use the following steps toinstall the bq20z60EVSW software:1. Copy the files from the web into a temporary directory you select, double-click onbqEV-EASYSetup00.09.xx.exe, where xx indicates the version, and follow the installer instructions tocomplete the bq20z60 EVSW installation.2. If the EV2300 was not previously installed, after bq20z60 EVSW installation, a TI USB DRIVERINSTALLER pops up. Click "Yes" for the agreement message and follow its instructions. Two driversare associated with the EV2300. Follow the instructions to install both. Do no reboot the computereven if asked to do so.3. Plug the EV2300 into a USB port. The Windows system may show a prompt that new hardware hasbeen found. When asked "Can Windows connect to Windows Update to search for software?", select"No, not this time" and click on "NEXT". In the next dialog window, it indicates "This wizard helps youinstall software for: TI USB Firmware Updater", select "Install the software automatically(Recommended)" and click "NEXT". It is common for the next screen to be the Confirm File Replacescreen. Click "No" to continue. If this screen does not appear, then go to the next step. After Windowsindicates that the installation was finished, a similar dialog window pops up to install the second driver;proceed with the same installation preference as the first one. The second driver is "TI USB bq80xxDriver".
Ensure that the files were extracted from the zip file using the Preserve Folder names option.
Ensure that all the files were extracted from the zip file.
The user that is downloading the files must be logged in as the administrator.
The driver is not signed, so the administrator must allow installation of unsigned drivers in the operatingsystem policy.
The bq20z60EVM-001 comprises two hardware components: the bq20z60/bq29330/bq29412 circuitmodule and the EV2300 PC interface board.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 9Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

7.1 Connecting the bq20z60/bq29330/bq29412 Circuit Module to a Battery Pack
7.2 PC Interface Connection
Hardware Connection www.ti.com
Figure 7 shows how to connect the bq20z60/bq29330/bq29412 circuit module to the cells and systemload/charger.
The cells must be connected in the following order:1. 4-Cell Pack: 1N (BAT-), 1P, 2P, 3P, and 4P (see Section 2.1 for definitions).2. 3-Cell Pack: 1N (BAT-), 1P, 2P, and then connect 4P and 3P together.3. 2-Cell Pack: 1N (BAT-), 1P, and then connect 4P, 3P, and 2P together
To start charge or discharge test, connect SYS PRES pin to PACK- pin to set SYS PRES state. To testsleep mode, disconnect the SYS PRES pin.
Figure 7. bq20z60bq29330 Circuit Module Connection to Cells and System Load/Charger
The following steps configure the hardware for interface to the PC:1. Connect the bq20z60/bq29330-based smart battery to the EV2300 using wire leads as shown inTable 4 .
Table 4. Circuit Module to EV2300 Connections
bq20z60/bq29330-Based Battery EV2300
SMBD SMBDSMBC SMBCVSS GND
2. Connect the PC USB cable to the EV2300 and the PC USB port.
The bq20z60EVM-001 is now set up for operation.
10 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

8 Operation
8.1 Starting the Program
www.ti.com Operation
This section details the operation of the bq20z60 EVSW software.
Run bq20z60 EVSW from the Start | Programs | Texas Instruments | bq20z60 EVSW | menu sequence.The SBS Data screen (Figure 8 ) appears. Data begins to appear once the < Refresh> (single time scan)button is clicked, or when the < Keep Scanning> check box is checked. To disable the scan feature,deselect < Keep Scanning>.
The continuous scanning period can be set via the | Options | and | Set Scan Interval | menu selections.The range for this interval is 0 ms to 65,535 ms. Only items that are selected for scanning are scannedwithin this period.
The bq20z60 EVSW provides a logging function which logs the values that were last scanned by EVSW.To enable this function, select the Start Logging button; this causes the Keep Scanning button to beselected. When logging is Stopped, the keep scanning button is still selected and has to be manuallyunchecked.
The logging intervals are specified under the | Options | menu with the maximum value of 65,535 ms. TheLog interval cannot be smaller than scan interval because this results in the same value being logged atleast twice.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 11Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

8.2 Setting Programmable bq20z60 and bq29330 Options
Operation www.ti.com
Figure 8. SBS Data Screen
This screen (Figure 8 ) shows the SBS data set along with additional ManufacturersAccess() commandinformation such as individual cell measurements. Additional Flag and Static data can be viewed byselecting the appropriate tab at the bottom of the SBS screen.
Data such as SBS.ManufacturerName() is static and does not change. This data is viewed separatelyusing the Static Data tab available at the bottom of the screen.
Dragging the splitter bar (line that separates the Flags/Static data from SBS values) changes the height ofthe Flags/Static Data display. Selecting | View |, then | Auto Arrange | returns the splitter bar to its originallocation.
The bq20z60 data flash comes configured per the default settings detailed in the bq20z60 data sheet.Ensure that the settings are correctly changed to match the pack and application for the bq20z60/bq29330solution being evaluated.
IMPORTANT: The correct setting of these options is essential to get the best performance.
The settings can be configured using the Data Flash screen (Figure 9 ).
12 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

www.ti.com Operation
Figure 9. Data Flash Screen, 1st Level Safety Class
To read all the data from the bq20z60 data flash, click on menu option | Data Flash | Read All |.
To write to a data flash location, click on the desired location, enter the data and press < Enter>, whichwrites the entire tab of flash data, or select menu option | Data Flash | Write All |. The data flash must beread before any writes are performed to avoid any incorrect data being written to the device.
The | File | Special Export | menu options allows the data flash to be exported, but it configures theexported data flash to a learned state ready for mass production use.
The data flash configuration can be saved to a file by selecting | File | Export | and entering a file name. Adata flash file can also be retrieved in this way, imported, and written to the bq20z60 using the | Write All |button.
The configuration information of the bq29330 and module calibration data is also held in the bq20z60 dataflash.
The bq20z60 allows for an automatic data flash export function, similar to the SBS Data logging function.This feature, when selected via | Options | Auto Export |, exports Data Flash to a sequential series of filesnamed as FilenameNNNNN.gg where N = a decimal number from 0 to 9.
The AutoExport interval is set under the | Options menu | with a minimum value of 15 s. The AutoExportfilename is also set under the | Options menu |.
When a check is next to | AutoExport |, the AutoExport is in progress. The same menu selection is used toturn on/off AutoExport.
If the data flash screen is blank, then the bq20z60 that is being used may not be supported by thebqEVSW version that is being used. An upgrade may be required.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 13Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

9 Calibration Screen
9.1 How to Calibrate
9.2 To Calibrate the bq20z60
9.3 Board Offset Calibration
9.4 Pack Voltage Calibration
Calibration Screen www.ti.com
The bq20z60 should be calibrated using power supplies or a power supply and cell simulation resistors(200 to 1000 ohm each) before cells are attached. Before the bq20z60 is calibrated::•Connect and measure a 2-A current source from 1N (-) and Pack- (+) to calibrate without using theFETs (calibration using the FETs is not recommended).•Measure the pack voltage from Batt+ to Batt- (Total of Cell voltages).•Measure the temperature of the pack.•These steps may or may not be required, depending on the type of calibration being performed.
Select the types of calibration to be performed (see Figure 10 ).
Enter the measured values for the types selected (except for CC Offset Calibration).
If Voltage Calibration is selected, then enter the number of cells on the pack.
If Temperature Calibration is selected, then select the sensor that is to be calibrated.
If the current source is connected between 1N and Pack-, then select the Off (bypassed) check box in theFET Control section.
Press the Calibrate Part button.
This performs the offset calibration for the current offset of the board.
Remove load/external voltage and short Pack- to Batt-.
Press the CC Board Offset Calibration button.
This calibrates the voltage at the AFE Pack pin.
Ensure that Voltage Calibration has been performed for the pack. Make sure to have a stable chargervoltage higher than 8-V present at Pack+.
Press the Pack Voltage button to calibrate.
14 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

10 Pro (Advanced) Screen
10.1 SMB Communication
10.2 Hexadecimal/Decimal Converter
www.ti.com Pro (Advanced) Screen
Figure 10. Calibration Screen
The set of read/write operations over SMBus are not specific to any gas gauge. These are provided asgeneral-purpose communication tools (Figure 11 ).
These two boxes convert between hexadecimal and decimal as soon as values are typed into the boxes.Invalid values may cause erroneous results.
When scaling converted hexadecimal values to a higher number of bytes, follow these rules:•When unsigned is selected, the left pad contains zeroes.•When signed is selected, the left pad contains zeroes for a positive number, or the left pad contains Ffor negative numbers.
SLUU354 – June 2009 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology 15Enabled Battery Management Solution Evaluation ModuleSubmit Documentation Feedback

10.3 Programming
11 Related Documentation From Texas Instruments
Related Documentation From Texas Instruments www.ti.com
This Pro Screen allows for reprogramming device firmware.
Figure 11. Pro (Advanced) Screen
1. bq20z60, SBS 1.1-Compliant Gas Gauge Enabled With Impedance Track™ Technology for Use Withbq29330 data sheet (SLUS877 )UNPUBLISHED2. bq29330, 2-, 3-, AND 4-Cell Lithium-Ion or Lithium-Polymer Battery Protection AFE data sheet(SLUS673 )
16 bq20z60EVM-001 SBS 1.1 Impedance Track™ Technology SLUU354 – June 2009Enabled Battery Management Solution Evaluation Module
Submit Documentation Feedback

FCC Warning
This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSESONLY and is not considered by TI to be a finished end-product fit for general customer use. It generates, uses, and can radiate radiofrequency energy and has not been tested for compliance with the limits of computing devices pursuant to part 15 of FCC rules, which aredesigned to provide reasonable protection against radio frequency interference. Operation of this equipment in other environments maycause interference with radio communications, in which case the user at his own expense will be required to take whatever measures maybe required to correct this interference.
EVM TERMS AND CONDITIONS
Texas Instruments (TI) provides the enclosed Evaluation Module and related material (EVM) to you, the user, (you or user) SUBJECT TOthe terms and conditions set forth below. By accepting and using the EVM, you are indicating that you have read, understand and agree tobe bound by these terms and conditions. IF YOU DO NOT AGREE TO BE BOUND BY THESE TERMS AND CONDITIONS, YOU MUSTRETURN THE EVM AND NOT USE IT.This EVM is provided to you by TI and is intended for your INTERNAL ENGINEERING DEVELOPMENT OR EVALUATION PURPOSESONLY. It is provided “AS IS” and “WITH ALL FAULTS.” It is not considered by TI to be fit for commercial use. As such, the EVM may beincomplete in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including product safetymeasures typically found in the end product. As a prototype, the EVM does not fall within the scope of the European Union directive onelectromagnetic compatibility and therefore may not meet the technical requirements of the directive.Should this EVM not meet the specifications indicated in the EVM User’s Guide, it may be returned within 30 days from the date of deliveryfor a full refund of any amount paid by user for the EVM, which user agrees shall be user’s sole and exclusive remedy. THE FOREGOINGWARRANTY IS THE EXCLUSIVE WARRANTY MADE BY TI TO USER, AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE ORNON-INFRINGEMENT.
TI shall have no obligation to defend any claim arising from the EVM, including but not limited to claims that the EVM infringes third partyintellectual property. Further, TI shall have no liability to user for any costs, losses or damages resulting from any such claims. User shallindemnify and hold TI harmless against any damages, liabilities or costs resulting from any claim, suit or proceeding arising from user’shandling or use of the EVM, including but not limited to, (I) claims that the EVM infringes a third party’s intellectual property, and (ii) claimsarising from the user’s use or handling of the EVM. TI shall have no responsibility to defend any such claim, suit or proceeding.User assumes all responsibility and liability for proper and safe handling and use of the EVM and the evaluation of the EVM. TI shall haveno liability for any costs, losses or damages resulting from the use or handling of the EVM. User acknowledges that the EVM may not beregulatory compliant or agency certified (FCC, UL, CE, etc.). Due to the open construction of the EVM it is the user’s responsibility to takeany and all appropriate precautions with regard to electrostatic discharge.EXCEPT TO THE EXTENT OF THE USER’S INDEMNITY OBLIGATIONS SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE TOTHE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES WHETHER TI IS NOTIFIED OF THEPOSSIBILITY OR NOT.TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not exclusive.TI assumes no liability for applications assistance, customer product design, software performance, or infringement of patents orservices described herein.
User agrees to read the EVM User’s Guide and, specifically, the EVM warnings and Restrictions notice in the EVM User’s Guide prior tohandling the EVM and the product. This notice contains important safety information about temperatures and voltages.It is user’s responsibility to ensure that persons handling the EVM and the product have electronics training and observe good laboratorypractice standards.
By providing user with this EVM, product and services, TI is NOT granting user any license in any patent or other intellectual property right.
EVM WARNINGS AND RESTRICTIONS
It is important to operate this EVM within the input voltage range of 6 V to 25 V and the output voltage range of 0 V to 16.4 V.Exceeding the specified input range may cause unexpected operation and/or irreversible damage to the EVM. If there are questionsconcerning the input range, please contact a TI field representative prior to connecting the input power.Applying loads outside of the specified output range may result in unintended operation and/or possible permanent damage to the EVM.Please consult the EVM User's Guide prior to connecting any load to the EVM output. If there is uncertainty as to the load specification,please contact a TI field representative.During normal operation, some circuit components may have case temperatures greater than 60 °C. The EVM is designed to operateproperly with certain components above 60 °C as long as the input and output ranges are maintained. These components include but arenot limited to linear regulators, switching transistors, pass transistors, and current sense resistors. These types of devices can be identifiedusing the EVM schematic located in the EVM User's Guide. When placing measurement probes near these devices during operation,please be aware that these devices may be very warm to the touch.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265Copyright © 2009, Texas Instruments Incorporated

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,and other changes to its products and services at any time and to discontinue any product or service without notice. Customers shouldobtain the latest relevant information before placing orders and should verify that such information is current and complete. All products aresold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standardwarranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except wheremandated by government requirements, testing of all parameters of each product is not necessarily performed.TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products andapplications using TI components. To minimize the risks associated with customer products and applications, customers should provideadequate design and operating safeguards.TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Informationpublished by TI regarding third-party products or services does not constitute a license from TI to use such products or services or awarranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectualproperty of the third party, or a license from TI under the patents or other intellectual property of TI.Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompaniedby all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptivebusiness practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additionalrestrictions.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids allexpress and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is notresponsible or liable for any such statements.TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonablybe expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governingsuch use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, andacknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their productsand any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may beprovided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products insuch safety-critical applications.TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products arespecifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet militaryspecifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely atthe Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products aredesignated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designatedproducts in automotive applications, TI will not be responsible for any failure to meet such requirements.Following are URLs where you can obtain information on other Texas Instruments products and application solutions:Products ApplicationsAmplifiers amplifier.ti.com Audio www.ti.com/audioData Converters dataconverter.ti.com Automotive www.ti.com/automotiveDLP® Products www.dlp.com Broadband www.ti.com/broadbandDSP dsp.ti.com Digital Control www.ti.com/digitalcontrolClocks and Timers www.ti.com/clocks Medical www.ti.com/medicalInterface interface.ti.com Military www.ti.com/militaryLogic logic.ti.com Optical Networking www.ti.com/opticalnetworkPower Mgmt power.ti.com Security www.ti.com/securityMicrocontrollers microcontroller.ti.com Telephony www.ti.com/telephonyRFID www.ti-rfid.com Video & Imaging www.ti.com/videoRF/IF and ZigBee® Solutions www.ti.com/lprf Wireless www.ti.com/wireless
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265Copyright © 2009, Texas Instruments Incorporated

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Texas Instruments:
BQ20Z60EVM
