48-V to 3.3-V Forward Converter withActive Clamp Reset Using theUCC2891 Active Clamp Current ModePWM Controller
User's Guide
December 2006 Power Supply MAN
SLUU178A

48-V to 3.3-V Forward Converter with ActiveClamp Reset Using the UCC2891 ActiveClamp Current Mode PWM Controller
User's Guide
Literature Number: SLUU178ANovember 2003 – Revised December 2006

1 Introduction
2 Description
User's GuideSLUU178A – November 2003 – Revised December 2006
Using the UCC2891 Active Clamp Current Mode PWMController
The UCC2891EVM evaluation module (EVM) is a forward converter providing a 3.3-V regulated output at30 A of load current, operating from a 48-V input. The EVM operates over the full 36 V to 72 V telecominput range, and is able to fully regulate down to zero load current. The module uses the UCC2891 currentmode active clamp PWM controller for effectively demonstrating the active clamp transformer resettechnique.
Benefits of the active clamp include a control driven transformer reset scheme allowing zero voltageswitching (ZVS) to increase overall efficiency, lower drain-to-source voltage stress, extended duty cyclebeyond 50% and reduced electromagnetic radiated emissions. Combined with synchronous rectification,this EVM is configured to operate at 300 kHz and exhibits a peak efficiency of just over 92%, with a fullload efficiency of 89%. The EVM displays many features that might be typical of a more complex design,yet its compact board layout and low component count make it elegantly simple.
The UCC2891 controller family provides advanced active clamp control features such as programmablemaximum duty cycle clamp, programmable dead time between the two primary switches and the ability todrive either a P-channel, or N-channel MOSFET in either a high-side or low-side active clampconfiguration. The UCC2891 also allows the ability to start-up directly from the 48-V telecom bus voltage,eliminating the need for external start-up circuitry. It includes programmable soft start, internal slopecompensation for peak current mode control, internal low-line voltage sensing, internal syncronizable clockinput, cycle-by-cycle current limiting, and a robust 2-A sink/source TrueDrive™ internal gate drive circuit.The result is a highly efficient design loaded with features, requiring very few external components.
The TrueDrive™ hybrid output architecture used in the UCC2891 uses TI's unique TrueDrive™Bipolar/CMOS output. To the user, this simply means ultra-fast rise and fall times by providing the highestpossible drive current where it is needed most, at the MOSFET Miller plateau region.
The UCC2891/2/3/4 is available in either a 16-pin SOIC or 16-pin TSSOP package for applications whereabsolute minimal board space is required.
The UCC2891EVM highlights the many benefits of using the UCC2891 active clamp current mode PWMcontroller. This user's guide provides the schematic, component list, assembly drawing, artwork and testset up necessary to evaluate the UCC2891 in a typical telecom application. More detailed designinformation can be found listed in the References section.
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 3Submit Documentation Feedback

www.ti.com
2.1 Applications
2.2 Features
Description
The UCC2891 is suited for use in isolated telecom 48-V input systems requiring high-efficiency andhigh-power density for very low-output voltage, high-current converter applications, including:•Server Systems•Datacom
•Telecom
•DSP's, ASIC's, FPGA's
The UCC2891EVM features include:•ZVS transformer reset using active clamp technique in forward converter•All surface mount components, double sided half brick (2.2 ×2.28 ×0.5) inches•Complementary auxilliary drive for active clamp with programmable dead time for ZVS•Current mode control with synchronization function•Internal PWM slope compensation•Start-up directly from telecom input voltage•Synchronous rectifier output stage allows high-efficiency operation•Programmable soft-start•Up to 30-A dc output current•Regulation to zero load current•Non-latching, output overcurrent and short circuit protection•Non-latching, Input undervoltage protection•1500-V isolation primary to secondary
Using the UCC2891 Active Clamp Current Mode PWM Controller4 SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
3 UCC2891EVM Electrical Performance Specifications
4 Schematic
UCC2891EVM Electrical Performance Specifications
The UCC2891EVM electrical performance specifications are listed in Table 1 .
Table 1. UCC2891EVM Performance Summary
PARAMETER TEST CONDITIONS MIN TYP MAX UNITS
Input Characteristics
Input voltage range 36 48 72 VNo load intput current V
IN
= 36 V, I
OUT
= 0 A 75 100 mAMaximum input current V
IN
= 36 V, I
OUT
= 30 A 3.00 3.25 AInput voltage ripple V
IN
= 72 V, I
OUT
= 30 A 1.50 1.75 V
P-P
Input voltage ripple
Output voltage 36 V ≤V
IN
≤72 V, 0 A ≤I
OUT
≤30 A 3.25 3.30 3.35 VOutput voltage regulation Line regulation (36 V ≤V
IN
≤72 V, I
OUT
= 0 A) 0.003%Load regulation (0 A ≤I
OUT
≤30 A, V
IN
= 48 V) 0.060%Output voltage ripple V
IN
= 48 V, I
OUT
= 30 A 30 35 mV
P-P
Output load current V
IN
= 48 V, I
OUT
= 30 A 0 30
AOutput current limit 36 V ≤V
IN
≤72 V 32
Output current limit
Switching frequency 275 325
kHzControl loop bandwidth 36 V ≤V
IN
≤72 V, I
OUT
= 10 A 5 8Control loop bandwidth 36 V ≤V
IN
≤72 V, 2 A ≤I
OUT
≤30 A 30 50 °CPeak efficiency 92%Full load efficiency V
IN
= 48 V, I
OUT
= 30 A 89%
A schematic of the UCC2891EVM is shown in Figure 1 . Terminal block J1 is the 48-V input voltage sourceconnector and J8 is the output and return for the 3.3-V output voltage.
On the primary side, U1 is the UCC2891 shown with the necessary discrete circuitry for configuring thecontroller to operate at 300 kHz with the maximum duty clamp set for 0.65. The EVM is programmed tostart at VIN=36 V, as determined by R11 and R12. To minimize power dissipation in the current sense, acurrent sense transformer, T1 is used, as opposed to simply using a sense resistor between the source ofQ2 and power ground. Q2 is the primary switching MOSFET and is selected based upon VDS and lowRDS(on). Q1 is the AUX (active reset) MOSFET and is selected based upon preferred package only, withonly minor consideration given for R
DS(on)
and Qg. Since the active clamp used in this design is low-sidereferenced, Q1 must be a P-channel type MOSFET. The reason for this is further explained in applicationnote SLUA299[2]. C9 is the clamp capacitor used to maintain a constant dc voltage. The input voltage issubtracted from the clamp voltage to allow transformer reset during the active clamp period.
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 5Submit Documentation Feedback

www.ti.com
+
+
+
+
Schematic
Figure 1. UCC2891EVM Schematic
6Using the UCC2891 Active Clamp Current Mode PWM Controller SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
5 EVM Test Setup
V2
-
+
J1
+Vout -Vout
J9 J10
Loop+
Loop-
J6
J7
Texas Instruments
HPA034
UCC2891 Active Clamp Converter
J3
V-Clamp
J2
Q2 Gate
J4
SR-QF Gate
J5
SR-QR Gate
LOAD1
3.3V/30A
-
+
A1
VIN
-
+
V1
FAN
+
+
--
-+
+VIN
-VIN
DANGER HIGH VOLTAGE
+VOUT
-VOUT
J8
EVM Test Setup
High efficiency is achieved using self-driven synchronous rectification on the secondary side. Q3 and Q4are placed in parallel and make up the forward synchronous rectifier (SR), while the reverse SR is madeup of the parallel combination of Q5, Q7 and Q8. If the duty cycle were limited to 50% then the reverse SRcould be reduced to only two parallel MOSFETs, but since these devices are operating near 60% dutycycle during the freewheel mode, they carry a higher average current than seen by Q3 and Q4. Theoutput inductor L1 has a coupled secondary, referenced to the primary side, used to provide bootstrappingvoltage to U1. A stable bias for the optocoupler, U2 is provided by the series pass regulator made up ofD6, Q6 and some associated filtering.
Scope jacks J2 and J3 allow the user to measure the gate-to-source and drain-to-source signals for Q2,the primary MOSFET. J4 and J5 allow convenient access to the gate drive signals of each SR on thesecondary side. J6 and J7 are available allowing the option of using a network analyzer to non-invasivelymeasure the control to output loop gain and phase.
Figure 2 shows the basic test set up recommended to evaluate the UCC2891EVM.
Figure 2. Recommended EVM Test Configuration
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 7Submit Documentation Feedback

www.ti.com
5.1 Output Load (LOAD1)
5.2 DC Input Source (VIN)
5.3 Network Analyzer
5.4 Recommended Wire Guage
5.5 Fan
EVM Test Setup
For the output load to VOUT, a programmable electronic load set to constant current mode and capable ofsinking between 0A
DC
and 30A
DC
, is used. Using a dc voltmeter, V2, it is also advised to make all outputvoltage measurements directly at J9 and J10 pins. Unless the load has remote sense capability,measuring VOUT at LOAD1 results in some voltage measurement error, especially at higher load current,due to finite voltage drops across the wires between J8 and the electronic load.
The input voltage is a variable DC source capable of supplying between 0 V
DC
and 72 V
DC
at no less than3.5 A
DC
, and connected to J1 and A1 as shown in Figure 2 . For fault protection to the EVM, good commonpractice is to limit the source current to no more than 4 A
DC
for a 36 V input. A dc ammeter, A1 shouldalso be inserted between VIN and J1 as shown in Figure 2 .
A network analyzer can be connected directly to J6 and J7. The UCC2891EVM provides a 51.1- Ωresistor(R25) between the output and the voltage feedback to allow easy non-invasive measurement of thecontrol to output loop response.
The connection between the source voltage, VIN and J1 of the EVM can carry as much as 3.25A
DC
. Theminimum recommended wire size is AWG #20 with the total length of wire less than 8 feet (4 feet input, 4feet return). The connection between J8 of the EVM and LOAD1 can carry as much as 30A
DC
. Theminimum recommended wire size is AWG #16, with the total length of wire less than 8 feet (4 feet output,4 feet return).
Most power converters include components that can be hot to the touch when approaching temperaturesof 605C. Because this EVM is not enclosed to allow probing of circuit nodes, a small fan capable of200-400 LFM is recommended to reduce component temperatures when operating at or above 50%maximum rated load current.
Using the UCC2891 Active Clamp Current Mode PWM Controller8 SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
6 Power Up/Down Test Procedures
Power Up/Down Test Procedures
The following test procedure is recommended primarily for power up and shutting down the EVM.Whenever the EVM is running above an output load of 15 A
DC
, the fan should be turned on. Also, neverwalk away from a powered EVM for extended periods of time.1. Working at an ESD workstation, make sure that any wrist straps, bootstraps or mats are connectedreferencing the user to earth ground before power is applied to the EVM. Electrostatic smock andsafety glasses should also be worn.2. Prior to connecting the DC input source, VIN, it is advisable to limit the source current from VIN to3.5-A maximum. Make sure VIN is initially set to 0 V and connected to J1 as shown in Figure 2 .3. Connect the ammeter A1 (0A to10A range) between VIN and J1 as shown in Figure 2 .4. Connect voltmeter (can optionally use voltmeter from VIN source if available), V1 across VIN as shownin Figure 2 .5. Connect LOAD1 to J8 as shown in Figure 2 . Set LOAD1 to constant current mode to sink 0 A
DC
beforeVIN is applied.6. Connect voltmeter, V2 across J9 and J10 as shown in Figure 2 .7. Increase VIN from 0 V to 36 V
DC
.8. Observe that VOUT is regulating when VIN is at 36 V.9. Increase VIN to 48 V.10. Increase LOAD1 from 0 A to 15 A
DC
.11. Turn on fan making sure to blow air directly on the EVM.12. Increase LOAD1 from 15 A
DC
to 30 A
DC
.13. Decrease LOAD1 to 0 A.14. Decrease VIN from 48 V
DC
to 0 V.15. Shut down VIN.
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 9Submit Documentation Feedback

www.ti.com
7 Power Up/Down Test Procedures
81
79
87
83
91
89
93
85
2 6 18 262210 14
IOUT - Output Current - A
VIN = 36 V
VIN = 72 V
VIN = 48 V
Percent Efficiency - %
VOUT = 3.3 V
fS= 300 kHz
OVERALL EFFICIENCY
vs
OUTPUT CURRENT
10
-40
-60
100 1 k 10 k 100 k
0
-20
40
20
60
-120
-180
0
-60
120
60
180
VIN = 36 V
IOUT = 10 A
gM= -8 dB
FM= 50°
Gain
Phase
f - Frequency - Hz
Gain - dB
Phase - °
GAIN AND PHASE
vs
FREQUENCY
4
2
10
6
12
8
6 18 26 302210 14
2
IOUT - Output Current - A
VIN = 36 V
VIN = 72 V
VIN = 48 V
PLOSS - Power Loss - W
VOUT = 3.3 V
fS= 300 kHz
POWER LOSS
vs
OUTPUT CURRENT
Power Up/Down Test Procedures
Figure 3.
Figure 5.
Figure 4.
Using the UCC2891 Active Clamp Current Mode PWM Controller10 SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
t − Time − 2.5 µs/div
VIN = 36 V
IOUT = 30 A
500 mV/div
1 V peak-to-peak
Input Ripple Voltage
10
-40
-60
100 1 k 10 k 100 k
0
-20
40
20
60
-120
-180
0
-60
120
60
180
VIN = 48 V
IOUT = 10 A
gM= -10 dB
FM= 50°
Gain
Phase
f - Frequency - Hz
Gain - dB
Phase - °
GAIN AND PHASE
vs
FREQUENCY
t − Time − 2.5 µs/div
VIN = 72 V
IOUT = 30 A
50 mV/div
36 mV peak-to-peak
Output Ripple Voltage
10
-40
-60
100 1 k 10 k 100 k
0
-20
40
20
60
-120
-180
0
-60
120
60
180
VIN = 72 V
IOUT = 10 A
gM= -9 dB
FM= 50°
Gain
Phase
f - Frequency - Hz
Gain - dB
Phase - °
GAIN AND PHASE
vs
FREQUENCY
Power Up/Down Test Procedures
Figure 8.Figure 6.
Figure 9.
Figure 7.
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 11Submit Documentation Feedback

www.ti.com
t − Time − 1 µs/div
VIN = 36 V
6.3 V, QF Gate (J5)
(5 V/div)
8.4 V, QR Gate (J6)
(5 V/div)
SR Gate Drive
t − Time − 2.5 µs/div
VIN = 36 V
IOUT = 30 A
50 mV/div
23 mV peak-to-peak
Output Ripple Voltage
t − Time − 1 µs/div
VIN = 72 V
12.3 V, QF Gate (J5)
(5 V/div)
5.4 V, QR Gate (J6)
(5 V/div)
SR Gate Drive
t − Time − 2.5 µs/div
VIN = 48 V
IOUT = 10 A
VPRI
(40 V/div)
IPRI
(0.5 A/div)
Transformer Primary
Power Up/Down Test Procedures
Figure 12.Figure 10.
Figure 13.Figure 11.
12 Using the UCC2891 Active Clamp Current Mode PWM Controller SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
8 EVM Assembly Drawing and Layout
EVM Assembly Drawing and Layout
Figure 14 through Figure 20 show the top-side and bottom-side component placement for the EVM, aswell as device pin numbers where necessary. A four layer PCB was designed using the top and bottomlayers for signal traces and component placement along with an internal ground plane. The PCBdimensions are 3.6" x 2.7" with a design goal of fitting all components within the industry standardhalf-brick format, as outlined by the box dimensions 2.28" x 2.20" shown in Figure 15 . All components arestandard OTS surface mount components placed on the both sides of the PCB. The copper-etch for eachlayer is also shown.
Figure 14. Top Side Component Assembly
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 13Submit Documentation Feedback

www.ti.com
EVM Assembly Drawing and Layout
Figure 15. Top Side Silk Screen
Figure 16. Top Signal Trace Layer
14 Using the UCC2891 Active Clamp Current Mode PWM Controller SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
EVM Assembly Drawing and Layout
Figure 17. Internal Split Ground Plane
Figure 18. Internal Signal Trace Layer
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 15Submit Documentation Feedback

www.ti.com
EVM Assembly Drawing and Layout
Figure 19. Bottom Signal Trace Layer
Figure 20. Bottom Side Component Assembly
Using the UCC2891 Active Clamp Current Mode PWM Controller16 SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

www.ti.com
9 List of Materials
List of Materials
The following table lists the UCC2891EVM components corresponding to the schematic shown inFigure 1 .
Table 2. List of Materials
QTREF DESCRIPTION MFR PART NUMBERY
C1, C2, C4 3 Capacitor, ceramic, 2.2 µF, 100 V, X7R, 20%, 1812 TDK C4532X7R2A225MC3, C14, C17 3 Capacitor, ceramic, 0.1 µF, 50 V, X7R, 20%, 805 Vishay VJ0805Y104MXAAC5 1 Capacitor, ceramic, 100 pF, 50 V, NPO, 10%, 805 Vishay VJ0805A101KXAAC6, C7 2 Capacitor, ceramic, 0.22 µF, 50 V, X7R, 20%, 805 TDK C2012X7R1H224MC8 1 Capacitor, ceramic, 10 nF, 50 V, X7R, 20%, 805 Vishay VJ0805Y103MXAAC9 1 Capacitor, ceramic, 33 nF, 250 V, X7R, 10%, 1206 MuRata GRM31CR72E333KW03LC10, C11 2 Capacitor, tantalum chip, 47 µF, 16 V, C Vishay 595D476X9016C2TC12, C18 2 Capacitor, ceramic, 10 µF, 16 V, X5R, 20%, 1206 TDK C3216X5R1C106MC13 1 Capacitor, ceramic, 1.5 µF, 10 V, X5R, 20%, 805 TDK C2012X5R1A155MC15 1 Capacitor, ceramic, 82 nF, 50 V, X7R, 10%, 805 Vishay VJ0805Y823KXAAC16 1 Capacitor, ceramic, 220 pF, 50 V, NPO, 10%, 805 Vishay VJ0805A221KXAAC19, C20 2 Capacitor, POSCAP, 330 µF, 6.3 V, 20%, 7343 (D) Sanyo 6TPD330MD1, D2, D3, D4, D5 5 Diode, schottky, 200 mA, 30 V, SOT23 Vishay BAT54D8 1 Diode, switching, 200 mA, 200 V, SOT23 Philips/NXP BAS21D6 1 Diode, zener, 5.1 V, 350 mW, SOT23 Vishay BZX84C5V1D7 1 Adjustable precision shunt regulator, 0.5%, SOT23 TI TLV431BCDBZJ1 1 Terminal block, 2 pin, 15 A, 5.1 mm, 0.40 ×0.35 OST ED500/2DSJ2, J3, J4, J5 4 Adaptor, 3.5 mm probe clip (or 131-5031-00), 3.5 mm Tektronix 131 4244 00J6, J7, J9, J10 4 Printed circuit pin, 0.043 hole, 0.3 length, 0.043 Mill Max 3103-1-00-15-00-00-0X-0J8 1 Terminal block, 4 pin, 15 A, 5.1mm, 0.80 ×0.35 OST ED500/4DSL1 1 Inductor, 2 µH, 1 pri, 1 sec, 0.920 ×0.780 Pulse PA0373Q1 1 MOSFET, P-channel, 150 V, 2.2 A, 240 m Ω, SO-8 IR IRF6216MOSFET, N-channel, 150 V, 6.7 A, 50 m Ω,Q2 1 Vishay Si7846DPPowerPak SO-8Q3, Q4, Q5, Q7, Q8 5 MOSFET, N-channel, 30 V, 55 A, 2.5 m Ω, LFPAK Renesas HAT2165HQ6 1 Bipolar, NPN, 40 V, 600 mA, 225 mW, SOT23 Vishay MMBT2222A
SLUU178A – November 2003 – Revised December 2006 Using the UCC2891 Active Clamp Current Mode PWM Controller 17Submit Documentation Feedback

www.ti.com
10 References
References
Table 2. List of Materials (continued)
QTREF DESCRIPTION MFR PART NUMBERY
R1 1 Resistor, chip, 8.45 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-8451-FR2 1 Resistor, chip, 57.6 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-5762-FR3 1 Resistor, chip, 76.8 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-7682-FR4, R10, R15, R16,
7 Resistor, chip, 2.21 Ω, 1/10 W, 1%, 805 Vishay CRCW0805-2R21-FR20, R23, R24R5 1 Resistor, chip, 158 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-1583-FR6 1 Resistor, chip, 1.82 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-1821-FR7, R8, R12 3 Resistor, chip, 1 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-1001-FR9 1 Resistor, chip, 11.8 Ω, 1/10 W, 1%, 805 Vishay CRCW0805-11R8-FR11 1 Resistor, chip, 26.7 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-2672-FR13 1 Resistor, chip, 2 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-2001-FR14 1 Resistor, chip, 10 Ω, 1/10 W, 1%, 805 Vishay CRCW0805-10R0-FR17, R18 2 Resistor, chip, 499 Ω, 1/10 W, 1%, 805 Vishay CRCW0805-4990-FR19 1 Resistor, chip, 665 Ω, 1/10 W, 1%, 805 Vishay CRCW0805-6650-FR21, R22 2 Resistor, chip, 10 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-1002-FR25 1 Resistor, chip, 51.1 Ω, 1/10 W, 1%, 805 Vishay CRCW0805-51R1-FR26 1 Resistor, chip, 28.7 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-2872-FR27 1 Resistor, chip, 12.1 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-1212-FR28 1 Resistor, chip, 4.99 k Ω, 1/10 W, 1%, 805 Vishay CRCW0805-4991-FT1 1 Transformer, current sense, 10-A, 1:100, SMD Pulse P8208T2 1 Transformer, high-frequency planar, planar Pulse PA0810IC, current mode active clamp PWM controller,U1 1 TI UCC2891DSO-16U2 1 IC, phototransistor, CTR 100%-300%, SOP-4 Vishay SFH690BT
1. UCC2891 Current Mode Active Clamp PWM Controller, Datasheet, (SLUS542)2. Designing for High Efficiency with the UCC2891 Active Clamp PWM Controller, by Steve Mappus,Application Note (SLUA299)
18 Using the UCC2891 Active Clamp Current Mode PWM Controller SLUU178A – November 2003 – Revised December 2006Submit Documentation Feedback

EVM IMPORTANT NOTICE
Texas Instruments (TI) provides the enclosed product(s) under the following conditions:
This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR
EVALUATION PURPOSES ONLY and is not considered by TI to be fit for commercialuse. As such,
the goods being provided may not be complete in terms of required design-, marketing-, and/or
manufacturing-related protective considerations, including product safety measures typically
found in the end product incorporating the goods. As a prototype, this product does not fall within
the scope of the European Union directive on electromagnetic compatibility and therefore may not
meet the technical requirements of the directive.
Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide,the kitmay
be returned within 30 days from the date of delivery for a full refund. THE FOREGOING
WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further,
the user indemnifies TI from all claims arising from the handling or use of the goods. Please be
aware that the products received may not be regulatory compliant or agency certified (FCC, UL,
CE, etc.). Due to the open construction of the product, it is the user’s responsibility to take any and
all appropriate precautions with regard to electrostatic discharge.
EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL
BE LIABLE TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES.
TI currently deals with a variety of customers for products, and therefore our arrangement with the
user is not exclusive.
TI assumes no liability for applications assistance, customer product design, software
performance, or infringement of patents or services described herein.
Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice
in the EVM User’s Guide prior to handling the product. This notice contains important safety
information about temperatures and voltages. For further safety concerns, please contact the TI
application engineer.
Persons handling the product must have electronics training and observe good laboratory practice
standards.
No license is granted under any patent right or other intellectual property right of TI covering or
relating to any machine, process, or combination in which such TI products or services might be
or are used.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright ©2003--2006, Texas Instruments Incorporated

DYNAMIC WARNINGS AND RESTRICTIONS
It is important to operate this EVM within the input voltage range of 0 Vdc to 72 Vdc.
Exceeding the specified input range may cause unexpected operation and/or irreversible damage
to the EVM. If there are questions concerning the input range, please contact a TI field
representative prior to connecting the input power.
Applying loads outside of the specified output range may result in unintended operation and/or
possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to connecting
any load to the EVM output. If there is uncertainty as to the load specification, please contact a TI
field representative.
During normal operation, some circuit components may have case temperatures greater than
50°C. The EVM is designed to operate properly with certain components above 50°C as long as
the input and output ranges are maintained. These components include but are not limited to linear
regulators, switching transistors, pass transistors, and current sense resistors. These types of
devices can be identified using the EVM schematic located in the EVM User’s Guide. When placing
measurement probes near these devices during operation, please be aware that these devices
may be very warm to the touch.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright ©2003--2006, Texas Instruments Incorporated
