Introduction

This chapter gives a brief overview of the SN65LVDS122EVM and highlights
the high-speed performance and functionality of the SN65LVDS122, 2x2
cross-point switch.
Topic Page
1.1 Overview 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Signal Paths 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Overview
1-2
1.1 Overview
The SN65LVDS122 is a 1.5-Gbps 2x2 cross-point switch. The four different
functions that the SN65LVDS122 provides are shown in Figure 1–1. The
function of the SN65LVDS122 is selected via pins S0 and S1. Control pins 1DE
and 2DE enable or disable the outputs. The output levels of this device are
LVDS, while the receiver has a wide input common-mode voltage range with
an ability to accept LVPECL and CML signaling levels in addition to LVDS.
Figure 1–1.Functional Configurations of the SN65LVDS122
1A
1B
2A
2B
1Y
1Z
2Y
2Z
1A
1B
2A
2B
1Y
1Z
2Y
2Z
A
B
1Y
1Z
2Y
2Z
1A
1B
2A
2B
Y
Z
MUX
2×2 Crosspoint Dual Repeater
1:2 Splitter 2:1 MUX
(1 or 2)
(1 or 2)
Figure 1–2 is a picture of the SN65LVDS122PW and EVM. The EVM
part number is SN65LVDS122EVM. The EVM comes with the
SN65LVDS122PW (TSSOP) installed. A copy of the data sheet is
shipped with the EVM. The lastest version of the data sheet is available
from www.ti.com.
Figure 1–2.SN65LVDS122 EVM

Signal Paths
1-3
Introduction
1.2 Signal Paths
The signal paths on this EVM include eight edge-launch SMA connectors
(J1–J8) for high-speed data transmission, two jumpers (W1, W2) for active
switch logic control, two jumpers (W3, W4) for static switch logic control, one
jumper (J9) for enabling and disabling the outputs, and three banana jacks
(J10, J11, J12) for power and ground connections.

1-4

2-1
Setup and Equipment Required
   
This chapter describes the equipment, setup, and operation of the
SN65LVDS122EVM.
Topic Page
2.1 Overview 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Applying an Input 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Observing an Output 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Typical Test Results 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2

Overview
2-2
2.1 Overview
TIA/EIA–644 specifies the LVDS driver output characteristics such that it
maintains at least 247 mV across a 100-Ωdifferential load. This requirement
includes the effects of up to 32 standard receivers with their ground reference
up to1Vdifferent from that of the driver. This common-mode loading limitation
of LVDS drivers affects how they are observed and much of the test set up that
follows. By using three power jacks (J10, J11, and J12), different methods of
termination or probing the output characteristics can be observed without
exceeding the common-mode drive capability. Figure 2–1 shows the typical
setup for the SN65LVDS122EVM.
Figure 2–1.EVM Power Connections for SN65LVDS122 Evaluation
J1
J2
J5
J6
SN65LVDS122 EVM
Power Supply #1 +
3.3 V
–
Power Supply #2 +
1.2 V
–
CH1
CH2
CH3
CH4
Oscilloscope
OUTPUT1
OUTPUT2
/OUTPUT2
/OUTPUT1
Pattern Generator J10
J11
J12
J3
J4
J7
J8
50 Ω
50 Ω
50 Ω
50 Ω
R8
100 Ω
R10
100 Ω
GND
(EVM GND)
VEE
(DUT GND) VCC

Applying an Input
2-3
Setup and Equipment Required
2.2 Applying an Input
When using a general-purpose signal generator with 50-Ωoutput impedance,
make sure that the signal levels are between 0 V and 4 V with respect to J12,
device under test ground (DUT GND), designated as VEE.
Inputs should be applied to the SMA connectors J1, J2, J5, and J6. Matched
cable lengths must be used when connecting the signal generator to the EVM
to avoid inducing skew between the noninverting and inverting inputs. The
EVM comes with 100-Ωresistors installed across the differential inputs for
LVDS termination. The simple 100-Ωterminations do not provide the
necessary termination for LVPECL or CML[1] output structures. In order to
interface the SN65LVDS122 EVM with CML or LVPECL drivers, external
terminations are required. Figure 2–2 shows an example termination for
LVPECL and CML output structures. Remove resistors R8 and R10 when
using the external terminations.
Figure 2–2.External Termination for Interfaceing CML or LVPECL Drivers
LVPECL or CML
Driver
EVM (INPUT 1 or 2)
AA
B
50 Ω
50 Ω
VT for LVPECL
VCC for CML
VT for LVPECL
VCC for CML
The use of external resistors creates a significant stub between the
termination and the actual device receivers. The user needs to verify that the
transition time of the input signal, coupled with the stub length, does not lead
to reflection problems. In normal applications, the termination would be placed
as close as possible to the device inputs to minimize reflections.
The control lines S0 and S1 can be stimulated by an external 50-Ωsource, via
jumpers W1 and W2. These control signals are LVTTL compatible inputs and
therefore the external source should provide LVTTL inputs relative to J12. If
S0 and S1 are controlled by an external source, then remove the jumpers from
W3 and W4 and install 50-Ωresistors R2 and R3.
[1
]CML is not a standardized physical layer and therefore the output structures and required termination differ from vendor to
vendor.

Observing an Output
2-4
2.3 Observing an Output
When the SN65LVDS122 EVM is connected directly to an oscilloscope with
50–Ω internal terminations to ground; resistors R4, R5, R6, and R7 are not
needed (the EVM is shipped without R4–R7 installed). All external cabling
needs to be matched in length to prevent skew between inverting and
noninverting signals and between channels.
The three power jacks (J10, J11, and J12) are used to provide power and a
ground reference for the EVM. The power connections to the EVM determine
the common-mode load the device outputs must drive. LVDS devices have
limited common-mode driver capability and when using 50-Ωtermination on
each line of the signal pair, they should be connected to a 1.2-V termination
voltage with respect to the driver ground. When connecting the EVM outputs
directly to oscilloscope inputs, the oscilloscope ground becomes termination
voltage and the objective of the three power jacks (split power plane) is to
offset the SN65LVDS122, so that the termination appears as 50 Ωto 1.2 V.
Returning to Figure 2–1, power supply #1 provides 3.3 V to the EVM and
power supply #2 provides the offset voltage. This offset is used to set the DUT
ground potential with respect to EVM GND. The ground returns in the SMA
connectors connects EVM GND to the oscilloscope ground. Optimum device
setup can be confirmed by adjusting the voltage on the offset power supply
until its current is minimized. It is important to note that use of the dual supplies
and offsetting the EVM relative to the DUT ground are steps needed for the
test and evaluation of devices. Actual designs would include high-impedance
receivers, which would not require offsetting the load.
If the EVM outputs are to be evaluated with a high-impedance probe, direct
probing on the EVM is supported via installation of a 100-Ωresistor across the
solder pads for R4 and R5 (see Figure 2–3) and another 100-Ωresistor across
the solder pads for R6 and R7. The advantage of using a high-impedance
probe is that the power supply #2 of Figure 2–1 can be omitted with J12 and
J11 connected together. In order to successfully offset the EVM, power supply
#2 must be able to sink current. The disadvantage is the possible bandwidth
limitations of the probe and measurement quality.
Figure 2–3.100- Parallel Termination Using Solder Pads From R4 and R5
To J3
To J4
100 Ω
Resistor
R4
R5
From U1

Typical Test Results
2-5
Setup and Equipment Required
2.4 Typical Test Results
Figure 2–4 is a typical result obtained with the EVM setup shown in
Figure 2–1. The upper waveform is the difference voltage between channels
1 and 2 of the oscilloscope and the lower trace is the difference voltage
between channels 3 and 4. The DUT was configured to send the 1B/1A inputs
to the outputs 2Z/2Y and inputs 2A/2B to outputs 1Y/1Z by setting 1DE and
2DE to a high level and by setting W3 and W4 to VCC. The stimuli were a 223–1
PRBS to J1 and J2 at 1.5 Gbps, and a 750 MHz clock to J5 and J6. The input
levels for both clock and data were a differential voltage of 400 mV with a
common-mode voltage of 0 V (referenced to the ground of the pattern
generator).
Figure 2–4.Typical Test Results With the SN65LVDS122EVM

2-6

3-1
EVM Construction
 
This chapter provides the SN65LVDS122EVM schematic, board layers, and
bill of materials.
Topic Page
3.1 Schematic 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Board Layout Patterns 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Bill of Materials 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3

Schematic
3-2
3.1 Schematic
Figure 3–1.SN65LVDS122EVM Schematic
SN65LVDS122
J3
S0
S1
S1
2DE
VEE
1DE
1DE
2DE
R8
R2*
R3*
R10
VCC
VEE
C9 R4*
R5*
R6*
R7*
1B
1A
2A
2B
2Z
2Y
1Y
1Z
C1 C3 C5 C7 C11
VCC J10
J11
C2 C4 C6 C8 C12 J12
VEE
J3
J4
J7
J8
J1
J2
J5
J6
S0
VCC
VCC
VEE
VCC
VEE
VEE
VEE
VEE
VCC VCC
1DE 2DE
S1
S0
VCC
J9
W1
W2
W4 W3
U1
Cross–Point
R2, R3, R4, R5, R6,
and R7 are uninstalled

Board Layout Patterns
3-3
EVM Construction
3.2 Board Layout Patterns
Figure 3–2.SN65LVDS122EVM Silk Screen
Figure 3–3.Signal Layer and GND Fill Figure 3–4.Layer 2 GND Plane

Board Layout Patterns
3-4
Figure 3–5.Layer 3 Split VCC amd VEE Figure 3–6.Layer 4 GND Plane
Figure 3–7.PCB Fabrication Notes and Stackup
Single: Layer 1
GND: Layer 2
Split Power: Layer 3
GND: Layer 4
Stackup
0.006”
0.042”
0.006”
Notes: 1) PWB to be fabricated to meet or exceed IPC-6012, Class 3 standards and workmanship conform to IPC-A-600,
Class 3 current revisions
2) Board material and construction to be UL approved and marked on the finished board.
3) Laminate materal: Copper-clad NELCO N4000-13 (DO NOT USE—13SI)
4) Copper weight: 1 oz finished
5) Finished thickness: 0.62”±0.10”
6) Minimum plating thickness in through holes: 0.001”
7) SMOBC/HASL
8) LPI soldermask both sides using appropriate layer
artwork: color = green
9) LPI silkscreen as required: color = white
10)LPI soldermask both sides using appropriate layer
artwork: color = green
11)Minimum copper conductor width is: 0.010”
Minimum conductor spacing is: 0.009”
12)Number of finished layers: 4
13)Top layer 10 mil traces to be 50-Ωimpedance
14)Spacing between layers 3 and 4 should be 0.006”
